Page 2 of 123
5FAMILIARISATION-
INSTRUMENTS AND CONTROLS
12. Windscreen demisting vents.
13. Speaker (tweeter).
14. Door window demisting vents.
15. Side adjustable heating/
ventilation vents.
16.
Passenger air bag disarming control.
17. Upper glove box or passenger air bag.
18. Lower glove box.
19. RD3 audio equipment.
20. Heating/air conditioning controls.
21. Storage compartment.
22. Movable ashtray.
23. Gear lever.
24. Lighter.
25. Handbrake.
26. Heated seats control.
27. Steering lock and ignition.
28. Steering wheel adjustment
control.
29. Bonnet release.
30. Fuse box.
31. Headlamp height adjustment.
32. Passenger's electric mirror
control.
1. Speed limiter/cruise control
switch.
2. Lights and direction indicators
controls.
3. Driver's air bag.
Horn.
4. Instrument panel.
5. Audio equipment steering wheel
control.
6. Wipers/wash-wipe controls.
7. Central adjustable heating/
ventilation vents.
8. Hazard warning lights switch.
9. Multifunction display or clock.
10. Central locking button.
11. Controls:
- Electric windows.
- Rear door windows or tailgate demisting.
- Air conditioning.
Page 8 of 123
11FAMILIARISATION-
SPEED LIMITER * CRUISE CONTROL *
75
73 I f t h e v e h i c l e i s fi t t e d w i t h
a speed limiter and cruise
control, these functions can-
not be activated at the same
time.
This limiter indicates the status of
selection of the function on the in-
strument panel and displays the
programmed speed. The minimum
speed which can be programmed is
at least 18 mph (30 km/h).
It prevents exceeding of the speed
programmed by the driver, this func-
tion remains active regardless of any
action on the brake or clutch pedals.
On the other hand, pressing the ac-
celerator pedal to the point of resist-
ance does not have any effect.
It is possible to exceed the programmed
speed temporarily by pressing the acce-
l e r a t o r fi r m l y b e y o n d t h i s p o i n t o f r e s i s t -
ance.
The operating actions must be carried
out with the engine running. The cruise control has a display on
the instrument panel to indicate the
programmed reference speed.
It enables the vehicle to maintain the
reference speed programmed by the
driver.
In order for it to be programmed or
activated, the vehicle speed must be
greater than 25 mph (40 km/h) with
at least fourth gear engaged.
* According to version.
Page 14 of 123
MONITORING and DISPLAY SCREENS18 -
1. Seat belt not fastened warning
light
2. Front and side air bags warning
light
3. Passenger air bag disarmed
warning light
4. Front fog lamps indicator light
5. Anti-lock braking system (ABS)
warning light
6. Rear fog lamp indicator light
7. Diesel pre-heat warning light
8. Left hand direction indicator
9. Total distance recorder, service
indicator and engine oil level
indicator
10. Right hand direction indicator
11. Emission control system warning
light
12.
Main beam headlamps indicator light
13. H a n d b r a k e , l o w b r a k e fl u i d
level and electronic brake force
d i s t r i b u t i o n w a r n i n g l i g h t
14. Dipped beam headlamps
indicator light
15. Battery charge warning light
16. E n g i n e o i l p r e s s u r e a n d
t e m p e r a t u r e w a r n i n g l i g h t
17. W a t e r i n d i e s e l fi l t e r w a r n i n g l i g h t
18. Low coolant level warning light
19. C o o l a n t t e m p e r a t u r e i n d i c a t o r
20. T o t a l d i s t a n c e r e c o r d e r b u t t o n
21. Central (STOP) warning light
22. Speedometer
23. R e v c o u n t e r
24. L i g h t i n g r h e o s t a t b u t t o n
25. F u e l l e v e l i n d i c a t o r
26. L o w f u e l l e v e l w a r n i n g l i g h t
27. S p e e d l i m i t e r / c r u i s e c o n t r o l
display
INSTRUMENT PANEL: PETROL - DIESEL
Page 15 of 123
19MONITORING and DISPLAY SCREENS-
INSTRUMENTS AND CONTROLS
A permanently lit warning light or
o n e fl a s h i n g , w i t h t h e e n g i n e r u n -
n i n g , i n d i c a t e s a n o p e r a t i n g f a u l t
o f t h e u n i t c o n c e r n e d . T h e i l l u m i -
n a t i o n o f c e r t a i n w a r n i n g l i g h t s
m a y b e a c c o m p a n i e d b y a n a u d i -
b l e s i g n a l a n d a m e s s a g e o n t h e
d i s p l a y . D o n o t i g n o r e t h i s w a r n -
i n g : c o n s u l t a CITROËN d e a l e r a s
s o o n a s p o s s i b l e .
I f t h e c e n t r a l S T O P w a r n i n g l i g h t
c o m e s o n w h e n y o u a r e d r i v i n g ,
s t o p y o u r v e h i c l e i m m e d i a t e l y ,
w h e r e i t i s s a f e t o d o s o .
Central (STOP)
warning light
Linked to the warning
lights:
- ' ' e n g i n e o i l p r e s s u r e a n d t e m p e - r a t u r e ' ' ,
- ''low coolant level'',
- 'handbrake'',
- ' ' l o w b r a k e fl u i d l e v e l ' ' ,
- ' ' e l e c t r o n i c b r a k e f o r c e d i s t r i b u t i o n s y s t e m f a u l t ' ' .
L i n k e d w i t h t h e " c o o l a n t t e m p e r a t u r e "
i n d i c a t o r .
Y o u m u s t s t o p i f t h e l i g h t fl a s h e s
w i t h t h e e n g i n e r u n n i n g .
C o n s u l t a C I T R O Ë N d e a l e r . E n g i n e o i l p r e s s u r e
a n d t e m p e r a t u r e
warning light
Linked to the central (STOP) warning
l i g h t .
Y o u m u s t s t o p .
This warning light indicates one of
the following:
- i n s u f fi c i e n t o i l p r e s s u r e i n d i c a t e d by the message " O i l p r e s s u r e
i n s u f fi c i e n t " o n t h e d i s p l a y .
- a l a c k o f o i l i n t h e l u b r i c a t i o n c i r c u i t . T o p u p t h e l e v e l .
- a n o i l t e m p e r a t u r e w h i c h i s t o o h i g h . T o l o w e r t h e o i l t e m p e r a t u r e ,
r e d u c e y o u r s p e e d .
Lighting of the warning light is ac-
c o m p a n i e d b y a n a u d i b l e s i g n a l .
C o n s u l t a C I T R O Ë N d e a l e r .
L o w e n g i n e c o o l a n t
l e v e l w a r n i n g l i g h t
Linked to the central (STOP)
w a r n i n g l i g h t .
This comes on for a few seconds
w h e n t h e i g n i t i o n i s s w i t c h e d o n .
Lighting of this warning light is ac-
c o m p a n i e d b y a n a u d i b l e s i g n a l a n d
the message " T o p u p e n g i n e fl u i d
l e v e l " o n t h e d i s p l a y .
Y o u m u s t s t o p .
Wait for the engine to cool before
t o p p i n g u p t h e l e v e l .
T h e c o o l i n g c i r c u i t i s p r e s s u r i s e d . H a n d b r a k e , l o w
b r a k e f l u i d l e v e l a n d
E l e c t r o n i c B r a k e F o r c e
D i s t r i b u t i o n s y s t e m
f a u l t w a r n i n g l i g h t
Linked to the central (STOP) warning
l i g h t .
This comes on each time the ignition
i s s w i t c h e d o n .
Lighting of this warning light is ac-
c o m p a n i e d b y a n a u d i b l e s i g n a l a n d
a message on the display indicating
t h e c a u s e o f t h e w a r n i n g :
- " H a n d b r a k e o n " , if the handbrake
i s a p p l i e d o r n o t f u l l y r e l e a s e d .
- " B r a k e fl u i d l e v e l l o w " if there is
a n e x c e s s i v e d r o p i n b r a k e fl u i d
level (if the warning light remains
on even when the handbrake is
r e l e a s e d ) .
- " B r a k i n g f a u l t " is displayed to-
gether with the ABS warning
l i g h t , i n d i c a t i n g a m a l f u n c t i o n o f
the Electronic Brake Force Distri-
b u t i o n s y s t e m . Y o u m u s t s t o p .
C o n s u l t a C I T R O Ë N d e a l e r .
In the event of breakdown and to
p r e v e n t a n y r i s k o f b u r n s , u n -
s c r e w t h e c a p b y t w o t u r n s t o a l l o w
t h e p r e s s u r e t o d r o p .
W h e n t h e p r e s s u r e h a s d r o p p e d , r e -
m o v e t h e c a p a n d t o p u p t h e l e v e l .
C o n s u l t a C I T R O Ë N d e a l e r .
Page 16 of 123
MONITORING and DISPLAY SCREENS20 - B a t t e r y c h a r g e w a r n i n g
light
This comes on for a few se-
conds when the ignition is
s w i t c h e d o n . L i g h t i n g o f t h i s w a r n i n g
l i g h t , w h e n t h e e n g i n e i s r u n n i n g , a c -
c o m p a n i e d b y a n a u d i b l e s i g n a l a n d
the message " B a t t e r y c h a r g e f a u l t "
on the display, indicates one of the
following:
- f a u l t y o p e r a t i o n o f t h e c h a r g i n g c i r c u i t ,
- slack battery or starter terminals,
- a c u t o r s l a c k a l t e r n a t o r b e l t ,
- a n a l t e r n a t o r f a i l u r e .
C o n s u l t a C I T R O Ë N d e a l e r . E m i s s i o n c o n t r o l
s y s t e m w a r n i n g l i g h t
This comes on for a few
seconds each time the igni-
t i o n i s s w i t c h e d o n .
I f i t c o m e s o n w i t h t h e e n g i n e r u n n i n g ,
a c c o m p a n i e d b y a n a u d i b l e s i g n a l
and the message on the display:
- " A n t i p o l l u t i o n f a u l t " , this indi-
c a t e s a f a i l u r e o f t h e e m i s s i o n
c o n t r o l s y s t e m .
- " C a t a l y t i c c o n v e r t e r f a u l t " , this
i n d i c a t e s a m a l f u n c t i o n o f t h e i n -
j e c t i o n o r i g n i t i o n s y s t e m . T h e r e
is a risk of damage to the catalytic
c o n v e r t e r ( p e t r o l e n g i n e o n l y ) .
C o n s u l t a C I T R O Ë N d e a l e r .
D i e s e l e n g i n e
pre-heat warning
light
W a i t u n t i l t h e w a r n i n g l i g h t g o e s o u t
b e f o r e s t a r t i n g t h e e n g i n e .
I f t h e t e m p e r a t u r e i s h i g h e n o u g h ,
the warning light comes on for less
t h a n o n e s e c o n d . Y o u c a n s t a r t t h e
e n g i n e w i t h o u t w a i t i n g . L o w f u e l l e v e l
warning light
This comes on for a few
seconds when the igni-
t i o n i s s w i t c h e d o n .
When the ignition is on, it is accom-
p a n i e d b y a n a u d i b l e s i g n a l a n d t h e
message " F u e l l e v e l l o w " on the
d i s p l a y .
I f i t fl a s h e s w i t h t h e f u e l g a u g e n e e d l e
in the lowest position, when the igni-
t i o n i s o n , t h i s i n d i c a t e s a m a l f u n c t i o n
o f t h e f u e l g a u g e .
W h e n t h i s w a r n i n g l i g h t fi r s t c o m e s
o n , y o u h a v e e n o u g h f u e l l e f t t o d r i v e
a p p r o x i m a t e l y 3 0 m i l e s ( 5 0 k m ) .
Capacity of the tank:
- approximately 55 litres for petrol engines,
- approximately 60 litres for Diesel e n g i n e s .
W a t e r i n d i e s e l f i l t e r
i n d i c a t o r *
There is a risk of damage to the
i n j e c t i o n s y s t e m .
C o n s u l t a C I T R O Ë N d e a l e r a s s o o n
a s p o s s i b l e .
A n t i - l o c k b r a k i n g
s y s t e m ( A B S ) w a r n i n g
light
This comes on for a few seconds each
t i m e t h e i g n i t i o n i s s w i t c h e d o n .
If the warning light remains on or
comes on above 8 mph (12 km/h),
t h i s i n d i c a t e s a n A B S m a l f u n c t i o n .
However, the vehicle retains conven-
t i o n a l s e r v o - a s s i s t e d b r a k i n g .
Lighting of this warning light, accom-
p a n i e d b y a n a u d i b l e s i g n a l a n d t h e
message " A B S f a u l t " on the display,
i n d i c a t e s a n A B S f a u l t .
C o n s u l t a C I T R O Ë N d e a l e r .
* A c c o r d i n g t o c o u n t r y .
Page 17 of 123
21MONITORING and DISPLAY SCREENS-
S e a t b e l t n o t f a s t e n e d
w a r n i n g l i g h t *
When the ignition is switched
on, this indicator light comes
on if the driver has not fastened his
s e a t b e l t .
Above 12 mph (20 km/h), the warn-
i n g l i g h t fl a s h e s f o r t w o m i n u t e s .
O n c e t h e t w o m i n u t e s h a v e e l a p s e d ,
t h e w a r n i n g l i g h t r e m a i n s o n u n t i l t h e
d r i v e r f a s t e n s h i s s e a t b e l t . C o o l a n t t e m p e r a t u r e i n d i c a t o r
- needle in zone (A) , the tempera-
t u r e i s c o r r e c t ,
- needle in zone ( B ) , the tempera-
t u r e i s t o o h i g h . T h e c e n t r a l STOP
w a r n i n g l i g h t fl a s h e s , a c c o m p a -
n i e d b y a n a u d i b l e s i g n a l a n d t h e
message " E n g i n e c o o l a n t t e m p .
too high" o n t h e d i s p l a y .
Y o u m u s t s t o p .
C o n s u l t a C I T R O Ë N d e a l e r .
* A c c o r d i n g t o c o u n t r y . P a s s e n g e r a i r b a g
d i s a r m e d w a r n i n g
l i g h t *
Lighting of this warning light is accom-
panied by the message " P a s s e n g e r
a i r b a g d e a c t i v a t e d " o n t h e d i s p l a y .
If the passenger air bag is disarmed,
the warning light comes on when
the ignition is switched on and it re-
m a i n s o n .
A l w a y s c o n s u l t a C I T R O Ë N d e a l e r i f
t h e w a r n i n g l i g h t fl a s h e s . F r o n t a n d s i d e a i r b a g s
warning light
This comes on for a few
seconds when the ignition is
s w i t c h e d o n .
W i t h t h e e n g i n e r u n n i n g , i l l u m i n a t i o n
of this warning light accompanied by
a n a u d i b l e s i g n a l a n d t h e m e s s a g e
" A i r b a g f a u l t " o n t h e m u l t i f u n c t i o n
d i s p l a y , i n d i c a t e s a f a u l t i n t h e a i r
b a g s .
C o n s u l t a C I T R O Ë N d e a l e r .
Page 18 of 123
21MONITORING and DISPLAY SCREENS-
S e a t b e l t n o t f a s t e n e d
w a r n i n g l i g h t *
When the ignition is switched
on, this indicator light comes
on if the driver has not fastened his
s e a t b e l t .
Above 12 mph (20 km/h), the warn-
i n g l i g h t fl a s h e s f o r t w o m i n u t e s .
O n c e t h e t w o m i n u t e s h a v e e l a p s e d ,
t h e w a r n i n g l i g h t r e m a i n s o n u n t i l t h e
d r i v e r f a s t e n s h i s s e a t b e l t . C o o l a n t t e m p e r a t u r e i n d i c a t o r
- needle in zone (A) , the tempera-
t u r e i s c o r r e c t ,
- needle in zone ( B ) , the tempera-
t u r e i s t o o h i g h . T h e c e n t r a l STOP
w a r n i n g l i g h t fl a s h e s , a c c o m p a -
n i e d b y a n a u d i b l e s i g n a l a n d t h e
message " E n g i n e c o o l a n t t e m p .
too high" o n t h e d i s p l a y .
Y o u m u s t s t o p .
C o n s u l t a C I T R O Ë N d e a l e r .
* A c c o r d i n g t o c o u n t r y . P a s s e n g e r a i r b a g
d i s a r m e d w a r n i n g
l i g h t *
Lighting of this warning light is accom-
panied by the message " P a s s e n g e r
a i r b a g d e a c t i v a t e d " o n t h e d i s p l a y .
If the passenger air bag is disarmed,
the warning light comes on when
the ignition is switched on and it re-
m a i n s o n .
A l w a y s c o n s u l t a C I T R O Ë N d e a l e r i f
t h e w a r n i n g l i g h t fl a s h e s . F r o n t a n d s i d e a i r b a g s
warning light
This comes on for a few
seconds when the ignition is
s w i t c h e d o n .
W i t h t h e e n g i n e r u n n i n g , i l l u m i n a t i o n
of this warning light accompanied by
a n a u d i b l e s i g n a l a n d t h e m e s s a g e
" A i r b a g f a u l t " o n t h e m u l t i f u n c t i o n
d i s p l a y , i n d i c a t e s a f a u l t i n t h e a i r
b a g s .
C o n s u l t a C I T R O Ë N d e a l e r .
Page 19 of 123
MONITORING and DISPLAY SCREENS22 - S e r v i c e i n d i c a t o r
T h i s i s a v i s u a l r e m i n d e r o f w h e n t h e
n e x t s e r v i c e i s d u e . T h i s s e r v i c e i s t o
b e c a r r i e d o u t a c c o r d i n g t o t h e m a n u -
f a c t u r e r ' s s e r v i c i n g s c h e d u l e . 5 seconds after the ignition is switched
o n , t h e t o t a l d i s t a n c e r e c o r d e r r e s u m e s
normal operation and the display shows
t h e t o t a l o r t r i p d i s t a n c e s .
T h e d i s t a n c e r e m a i n i n g b e f o r e t h e n e x t
s e r v i c e i s l e s s t h a n 5 0 0 m i l e s ( 1 , 0 0 0 k m ) .
Example: 400 miles (900 km) remain
b e f o r e t h e n e x t s e r v i c e i s d u e .
When switching on the ignition and
for 5 seconds, the display shows:
5 seconds after the ignition is
switched on, the total distance re-
c o r d e r r e s u m e s n o r m a l o p e r a t i o n
a n d t h e s y m b o l r e m a i n s l i t .
T h i s i n d i c a t e s t h a t a s e r v i c e s h o u l d
b e c a r r i e d o u t s h o r t l y . T h e d i s p l a y
s h o w s t h e t o t a l o r t r i p d i s t a n c e s . T h e s e r v i c e i s o v e r d u e .
Each time the ignition is switched on
and for 5 seconds, the symbol and
t h e e x c e s s d i s t a n c e fl a s h .
Example: t h e s e r v i c e i s o v e r d u e b y
3 0 0 m i l e s / k m . T h e s e r v i c e s h o u l d b e
c a r r i e d o u t v e r y s h o r t l y .
When the ignition is switched on and
for 5 seconds, the display shows:
5 seconds after the ignition is
switched on, the total distance re-
c o r d e r r e s u m e s n o r m a l o p e r a t i o n a n d
t h e s y m b o l r e m a i n s l i t . T h e d i s p l a y
s h o w s t h e t o t a l o r t r i p d i s t a n c e s .
Note: the spanner lights if the two-year
i n t e r v a l h a s b e e n e x c e e d e d .
INSTRUMENT PANEL DISPLAY
After switching on the ignition, three
f u n c t i o n s a r e s h o w n i n s u c c e s s i o n :
- service indicator,
- engine oil level indicator,
- total distance recorder/total and t r i p d i s t a n c e s .
Note
: the total and trip distances are
displayed for 30 seconds when the
ignition is switched off, on opening
the driver's door, as well as on lock-
i n g a n d u n l o c k i n g t h e v e h i c l e .
Example: 4,800 miles/km remain be-
f o r e t h e n e x t s e r v i c e i s d u e . W h e n t h e
ignition comes on and for 5 seconds
the display shows:
Operation
As soon as the ignition is switched
on and for 5 seconds, the spanner
s y m b o l i s i n g ' ' s e r v i c e o p e r a t i o n ' ' i s l i t .
The trip recorder display shows the
d i s t a n c e r e m a i n i n g ( i n r o u n d fi g u r e s )
b e f o r e t h e n e x t s e r v i c e .
Page 20 of 123
23MONITORING and DISPLAY SCREENS-
E n g i n e o i l l e v e l i n d i c a t o r
When the ignition is switched on,
the engine oil level is indicated for
approximately 10 seconds, after the
s e r v i c e i n f o r m a t i o n .
F l a s h i n g o f t h e s i x s q u a r e s a n d d i s -
p l a y i n g o f " m a x " i n d i c a t e a s u r p l u s o f
o i l w h i c h c o u l d d a m a g e t h e e n g i n e .
I f t h e s u r p l u s o f o i l i s c o n fi r m e d b y
a c h e c k u s i n g t h e d i p s t i c k , c o n t a c t a
C I T R O Ë N d e a l e r w i t h o u t d e l a y .
Y o u r C I T R O Ë N d e a l e r c a r r i e s o u t
t h i s o p e r a t i o n a f t e r e a c h s e r v i c e .
T h e r e s e t p r o c e d u r e i s a s f o l l o w s :
- S w i t c h o f f t h e i g n i t i o n .
- P r e s s a n d h o l d b u t t o n
1 .
- S w i t c h o n t h e i g n i t i o n .
T h e d i s p l a y b e g i n s a 1 0 s e c o n d c o u n t -
d o w n .
-
K e e p b u t t o n 1 p r e s s e d f o r 1 0 s e c o n d s .
The display shows [=0] and the spanner
d i s a p p e a r s .
Flashing of the six segments and dis-
playing of "min" indicate a lack of oil
w h i c h c o u l d d a m a g e t h e e n g i n e .
I f t h e l a c k o f o i l i s c o n fi r m e d b y a
c h e c k u s i n g t h e d i p s t i c k , i t i s e s s e n t i a l
t h a t t h e l e v e l i s t o p p e d u p . Flashing of the six segments indi-
c a t e s a m a l f u n c t i o n o f t h e o i l l e v e l
i n d i c a t o r .
There is a risk of damage to the
e n g i n e .
C o n s u l t a C I T R O Ë N d e a l e r .
T h e l e v e l r e a d o n t h e d i p s t i c k o r o n
t h e i n d i c a t o r w i l l o n l y b e c o r r e c t i f
t h e v e h i c l e i s o n l e v e l g r o u n d a n d
t h e e n g i n e h a s b e e n o f f f o r m o r e
t h a n 1 5 m i n u t e s .
R e s e t t i n g t h e s e r v i c e i n d i c a t o r
S u r p l u s o f o i l
L a c k o f o i l O i l l e v e l i n d i c a t o r f a u l t
Page 21 of 123
MONITORING and DISPLAY SCREENS24 - B r i e fl y p r e s s i n g b u t t o n 1 alternates
between the total and trip distance
d i s p l a y s .
To reset the trip recorder to zero,
w h e n i t i s d i s p l a y e d p r e s s b u t t o n 1
u n t i l z e r o s a p p e a r .
T o t a l d i s t a n c e r e c o r d e r
W i t h t h e l i g h t s o n , p r e s s t h e b u t t o n
to vary the intensity of the lighting of
t h e i n s t r u m e n t s a n d c o n t r o l s . W h e n
t h e l i g h t i n g r e a c h e s t h e m i n i m u m ( o r
m a x i m u m ) s e t t i n g , r e l e a s e t h e b u t t o n
then press it again to increase (or re-
d u c e ) t h e b r i g h t n e s s .
As soon as the lighting is of the re-
q u i r e d b r i g h t n e s s , r e l e a s e t h e b u t t o n .
LIGHTING RHEOSTAT CLOCK
B u t t o n 1 : h o u r a d j u s t m e n t
B u t t o n 2 : m i n u t e a d j u s t m e n t
P r e s s a n d h o l d t h e b u t t o n f o r r a p i d
a d v a n c e .
