Page 2 of 115
5FAMILIARISATION-
INSTRUMENTS AND CONTROLS
12. Windscreen wash-wipe stalk.
13. Audio equipment steering
wheel control.
14. Steering lock and ignition.
15. Fuse box.
16. Passenger air bag disarming
control.
17. Alarm.
18. Steering wheel adjustment
control.
19. Passenger's electric mirror
control.
20. Headlamp height adjustment.
21. Heated seats control.
22. Handbrake.
23. Lighter.
24. Removable ashtray.
25. Gear lever.
26. Storage.
27. Heating/air conditioning controls.
28. Audio RD3.
29. Lower glove box.
30. Upper glove box or passenger
air bag.
31. Bonnet release.
32. Side adjustable heating/
ventilation vents.
33. Side window de-icing/
demisting vents.
1. Speaker (tweeter).
2. Windscreen demisting vents.
3. Controls:
- Electric windows.
- Demisting of rear door windows.
- Air conditioning.
4. Central locking button.
5. Multifunction display or clock.
6. Hazard lights button.
7. Central adjustable heating/
ventilation vents.
8. Lights and direction indicators
stalk.
9. Speed limiter/cruise control.
10. Instrument panel.
11. Driver's air bag
Horn.
Page 94 of 115
91PRACTICAL INFORMATION-
R e m o v i n g a n d fi t t i n g a f u s e
B e f o r e c h a n g i n g a f u s e , t h e c a u s e
o f t h e f a u l t m u s t b e f o u n d a n d r e m e -
d i e d . T h e f u s e n u m b e r s a r e i n d i c a t e d
o n t h e f u s e b o x .
Use the pliers B .
CHANGING A FUSE
T h e f u s e b o x e s a r e l o c a t e d u n d e r
the fascia and in the engine compart-
ment.
Fascia fuse box
Unclip the cover to gain access to the
f u s e s .
T h e s p a r e f u s e s a n d t h e p l i e r s B are
s e c u r e d o n t h e i n s i d e o f t h e c o v e r A .
Correct
Incorrect
Pliers B
Always replace a faulty fuse with a fuse
o f t h e s a m e r a t i n g ( t w o f u s e t y p e s a c -
c o r d i n g t o m a n u f a c t u r e r - s e e i m a g e s ) .
Page 95 of 115
91PRACTICAL INFORMATION-
R e m o v i n g a n d fi t t i n g a f u s e
B e f o r e c h a n g i n g a f u s e , t h e c a u s e
o f t h e f a u l t m u s t b e f o u n d a n d r e m e -
d i e d . T h e f u s e n u m b e r s a r e i n d i c a t e d
o n t h e f u s e b o x .
Use the pliers B .
CHANGING A FUSE
T h e f u s e b o x e s a r e l o c a t e d u n d e r
the fascia and in the engine compart-
ment.
Fascia fuse box
Unclip the cover to gain access to the
f u s e s .
T h e s p a r e f u s e s a n d t h e p l i e r s B are
s e c u r e d o n t h e i n s i d e o f t h e c o v e r A .
Correct
Incorrect
Pliers B
Always replace a faulty fuse with a fuse
o f t h e s a m e r a t i n g ( t w o f u s e t y p e s a c -
c o r d i n g t o m a n u f a c t u r e r - s e e i m a g e s ) .
Page 98 of 115
PRACTICAL INFORMATION94 -
Fuse N° Rating Functions
1 1 0 A P r e - h e a t u n i t ( d i e s e l ) - B r a k e a n d c l u t c h s w i t c h e s -
Reversing lights.
2 15 A F u e l p u m p .
3 1 0 A A B S c o n t r o l u n i t .
4 1 0 A E n g i n e c o n t r o l u n i t .
5 - N o t u s e d .
6 15 A Front fog lamps.
7 2 0 A H e a d l a m p w a s h p u m p .
8 2 0 A F a n a s s e m b l y r e l a y - E n g i n e c o n t r o l u n i t .
9 15 A Left-hand dipped beam.
1 0 15 A Right-hand dipped beam.
11 1 0 A Left-hand main beam.
12 1 0 A Right-hand main beam.
13 15 A Horn.
14 1 0 A F r o n t a n d r e a r w i n d s c r e e n w a s h p u m p s .
15 3 0 A O x y g e n s e n s o r - A i r fl o w s e n s o r .
16 3 0 A A i r p u m p r e l a y .
17 3 0 A Front windscreen wiper.
18 4 0 A Air conditioning fan.
E n g i n e c o m p a r t m e n t f u s e b o x
To gain access to the box in the engine
c o m p a r t m e n t ( n e x t t o t h e b a t t e r y ) , u n -
clip the cover.
A f t e r c a r r y i n g o u t w o r k , c l o s e t h e
c o v e r v e r y c a r e f u l l y .
