Citroen BERLINGO MULTISPACE RHD 2013.5 2.G Owner's Manual

9.81
09 SCREEN MENU MAP
MONOCHROME C AUDIO FUNCTIONS
alternative frequencies (RDS)
activate / deactivate
FM BAND PREFERENCES
regional mode (REG)
activate / deactivate
radio-text information (RDTXT)
activate / deactivate
1
2
3
4
3
4
3
4
PLAY MODES
album repeat (RPT)
activate / deactivate
track random play (RDM)
activate / deactivate
2
3
4
3
4
TRIP COMPUTER
Distance: x miles
ENTER DISTANCE TO DESTINATION
Diagnostic s
ALERT LOG
Functions activated or deactivated
STATUS OF THE FUNCTIONS *
1
2
3
3
2
3
2
Pressing the MENU button displays:
* The parameters vary according to vehicle.

9.82
09 SCREEN MENU MAP
BLUETOOTH TELEPHONE
Connect/Disconnect a device
Consult the paired device
BLUETOOTH CONFIGURATION
Telephone function
Audio Streaming function
Delete a paired device
Perform a Bluetooth search
Calls list
CALL
Directory
Terminate the current call
MANAGE THE TELEPHONE CALL
Activate private mode
1
2
3
3
3
4
4
4
2
3
4
2
3
3
video brightness adjustment
DISPLAY CONFIGURATION
DEFINE THE VEHICLE PARAMETERS *
PERSONALISATION-CONFIGURATION
normal video
inverse video
brightness (- +) adjustment
date and time adjustment
day/month/year adjustment
hour/minute adjustment
choice of 12 h / 24 h mode
choice of units
l/100 km - mpg - km/l
°Celsius / °Fahrenheit
CHOICE OF LANGUAGE
1
2
4
3
2
4
4
3
4
4
2
3
4
4
4
* The parameters vary according to vehicle.

9.83
FREQUENTLY ASKED QUESTIONS
QUESTIONANSWERSOLUTION
There is a difference in sound quality between the different audio sources (radio, CD...).
For optimum sound quality, the audio settings (Volume, Bass, Treble, Ambience, Loudness) can be adapted to the different sound sources, which may result in audible differences when changing source (radio, CD...).
Check that the audio settings (Volume, Bass, Treble, Ambience, Loudness) are adapted to the sources listened to. It is advisable to set the AUDIO functions (Bass, Treble, Front-Rear Balance, Left-Right Balance) to the middle position, select the musical ambience "None" and set the loudness correction to the "Active" position in CD mode or to the "Inactive" position in radio mode.
The CD is ejected automatically or is not played by the player.
The CD is inserted upside down, is unplayable, does not contain any audio data or contains an audio format which the player cannot play.
The CD is protected by an anti-pirating protection system which is not recognised by the audio equipment.
- Check that the CD is inserted in the player the right way up.
- Check the condition of the CD: the CD cannot be played if it is too damaged.
- Check the content in the case of a recorded CD: consult the advice in the "Audio" section.
- The audio equipment's CD player does not play DVDs.
- Due to their quality level, certain writeable CDs will not be played by the audio system.
The message "USB peripheral error" is displayed on the screen.
The Bluetooth connection is cut.
The battery of the peripheral may not be suffi ciently charged. Recharge the battery of the peripheral device.
The USB memory stick is not recognised.
The memory stick may be corrupt.
Reformat the memory stick.
The CD player sound is poor. The CD used is scratched or of poor quality. Insert good quality CDs and store them in suitable conditions.
The audio equipment settings (bass, treble, ambiences) are unsuitable. Set the treble or bass level to 0, without selecting an ambience.

9.84
QUESTIONANSWERSOLUTION
The stored stations do not function (no sound, 87.5 Mhz is displayed...).
An incorrect waveband is selected. Press the BAND AST button to return to the waveband (AM, FM1, FM2, FMAST) on which the stations are stored.
The traffi c announcement (TA) is displayed. I do not receive any traffi c information.
The radio station is not part of the regional traffi c information network. Tune to a radio station which broadcasts traffi c information.
The quality of reception of the radio station listened to gradually deteriorates or the stored stations do not function (no sound, 87.5 Mhz is displayed...).
The vehicle is too far from the transmitter used by the station listened\
to or there is no transmitter in the geographical area through which the\
vehicle is travelling.
Activate the RDS function to enable the system to check whether there is a more powerful transmitter in the geographical area.
The environment (hills, buildings, tunnels, basement car parks...) blo\
ck reception, including in RDS mode. This phenomenon is normal and does not indicate a failure of the audio equipment.
The aerial is absent or has been damaged (for example when going through a car wash or into an underground car park). Have the aerial checked by a CITROËN dealer.
Sound cut-outs of 1 to 2 seconds in radio mode. During this brief sound cut-out, the RDS searches for any frequency permitting better reception of the station. Deactivate the RDS function if the phenomenon is too frequent and always on the same route.
With the engine off, the audio equipment switches off after a few minutes of use.
When the engine is switched off, the audio equipment operating time depends on the battery charge.
The switch-off is normal: the audio equipment switches to economy mode and switches off to prevent discharging of the vehicle's battery.
Start the vehicle's engine to increase the battery charge.
The message "the audio system is overheated" appears on the display.
In order to protect the installation if the surrounding temperature is t\
oo high, the audio equipment switches to an automatic thermal protection mode leading to a reduction of the volume or stopping of the playing of \
the CD.
Switch the audio system off for a few minutes to allow the system to cool.

169
Exterior
VISUAL SEARCH
10
EXTERIOR
Remote control 17-18
Changing the battery,
reinitialisation 18 Key 17
Starting 47
Hill start assist 48
Central locking / unlocking 17, 26
Filler cap, fuel tank 140-141
Fuel cut-off, Diesel priming 141
Wiper blades
160
Door mirrors 100
Side repeaters 153
Front lamps, foglamps, direction indicators 49-51, 152-153
Headlamp beam height adjustment 51
Changing front bulbs 151-153
Headlamp wash 53, 137
Snow cover 149
Front doors 20
Sliding side doors 21-22
Key 17
Opening the bonnet 133
Child lock 126
Towing, lifting 128-129, 161
Towbar 128-129
Parking sesnsors 104-105 Rear roof fl ap 25
Emergency control 22
Spare wheel, jack, changing a wheel,
tools 145-149
Temporary puncture repair kit 144
Infl ation, pressures 167
Modutop roof
87-88
Roof bars 91, 92
Rear lamps, direction indicators 49-50, 154-155
3rd brake lamp 155
Changing rear bulbs 151, 154-155
Doors, tailgate 22-24
Accessories
130-131
Number plate lamps 155 Dimensions
162-165
Brakes, pads 103, 138
Emergency braking 106
ABS, EBFD 106
ASR, DSC 107
"Grip control" 108-109
Tyres, pressures 167
Snow chains 150
Tyre under-infl ation detection 36-37

170
Instruments and controls
ESC 107
Parking sensors 104-105
Electric mirrors 100

Headlamp beam height adjustment 51
Stop & Start 44-46
Cruise control
54-56
Speed limiter 57-59
Lighting controls
49-51
Automatic illumination of headlamps 50-51
Foglamps 50
LED daytime running lamps 50
INSTRUMENTS AND CONTROLS
Dashboard, passenger compartment fuses 156-158
Opening the bonnet 133
Parking brake 103 Instrument panels, screens,
dials 27-28
Warning lamps, indicator lamps 29-34
Indicators, fuel gauge 35, 38-39
Setting the time in the instrument panel 28
Lighting dimmer 39
Gear shift indicator 40-41
Gearbox 40
Ignition switch
47
Wiper controls
52-53
Automatic rain sensitive wipers 52
Screenwash / headlamp wash 53, 137
Trip computer Section 9
Audio equipment steering mounted controls Section 9
Steering wheel adjustment 43
Horn 103

171
Instruments and controls
VISUAL SEARCH
10
Cruise control 54-56
Speed limiter 57-59
Lighting control stalk 49-51
Automatic illumination of
headlamps 50-51
Front foglamps 50
LED daytime running lamps 50
INSTRUMENTS AND CONTROLS
Parking brake 103 Instrument panels,
displays, screens, dials 27-28
Warning and indicator lamps 29-34
Indicators, gauge 35, 38-39
Setting the time at the instrument panel 28
Lighting dimmer 39
Gear shift indicator 40-41
Gearbox 40
Steering wheel adjustment 43
Horn 103 Starter motor, ignition switch 47 Wiper control stalk 52-53
Automatic wipers
52
Sreenwash / headlamp wash 53, 137
Trip computer Section 9
Steering mounted radio controls Section 9
Passenger's airbag
deactivation 116
ESC 107
Parking sensors 104-105
Electric door mirrors 100
Headlamp beam adjustment 51
Stop & Start 44-46

172
Instruments and controls
Rear view mirror 101
Toll cards, car park tickets 101
Child surveillance mirror 101
In-car technology Section 9
- eMyWay
- Audio system
Controls - central locking 26
- electric child lock 126
- electric windows 102
- hazard warning lamps 103
Emergency or roadside
assistance call Section 9
Electronic gearbox 41-43 Heating, ventilation
- heating 60-61
- air conditioning A/C 60-61
Digital air conditioning 62-63
Demisting/defrosting 64-65 Deactivating the passenger's airbag 116
Courtesy lamps 93, 153
Front fi ttings 83-85
- glove box,
- overhead storage,
- console,
- sun visor,
- bottle holder,
- bag holder,
- storage drawers,
- storage compartment.
Screens, display 27, Section 9
Setting the time
in the screen Section 9
"Grip control" 108-109

173
Instruments and controls
VISUAL SEARCH
10
Fuses, dashboard, cabin 156-158
Bonnet release lever 133
Rear view mirror
101
Toll payment, parking 101
Child surveillance mirror 101
Emergency or assistance call Section 9
Front fi titngs 83-85
- glove box,
- roof storage,
- console,
- sun visor,
- bottle holder,
- bag holder,
- storage drawers,
- storage compartment.
"Grip control"
108-109 Technology on-board Section 9
- eMyWay
- Audio system
Controls - central locking 26
- electric child lock 126
- electric windows 102
- hazard warning lamps 103
Electronic gearbox 41-43
Heating, ventilation - heating 60-61
- air conditioning A/C 60-61
Digital air conditioning 62-63
Demisting-defrosting 64-65
Courtesy lamps 93, 153
Screens, display 27, Section 9
Setting the time
in the screen Section 9

174
Interior
Rear view mirror 101
Toll cards, car park tickets 101
Front courtesy lamp 93
Changing courtesy lamp bulbs 153
Front, lateral ,
curtain airbags 113-116
Passenger's airbag
deactivation 116 Battery, charging, starting 142
Opening the bonnet 133
Rear windows 101
Front seats, adjustments,
head restraint 66-67
Seat belts 97, 110-112
Accessories 130-131
INTERIOR
Rear bench seat 68-70
Rear seats (5-seat version) 71-73, 81
Seat confi guration, benches 81-82
Rear courtesy lamp 93
Changing courtesy lamp bulbs 153
Rear fi ttings 86
- fl oor boxes,
- side blinds,
- aircraft style table,
Modutop roof 87-88
Scented air freshener 89-90
Load space cover (5-seat version) 94
Load space cover (7-seat version) 98-99 Child seats 117-122, 126
ISOFIX mountings 123-125
Parking brake, handbrake 103
Rear seats (7-seat version) 74-80, 82
Fittings (7-seat version) 96-97 - stowing rings,
- cup holder,
- 12 V socket,
- storage fl ap.
Towing, llifting 128-129, 161
Towable loads 166
Spare wheel, jack,
changing a wheel,
tools 145-149
