Practical information
89
Do not charge the battery without first disconecting the terminals and removing it from the vehicle.Do not disconnect the terminals whenthe "Ready" lamp is on, nor when thevehicle is being charged.
Before disconnecting
You must wait 2 minutes after switchingoff the ignition before disconnecting the battery.


Batteries contain harmful substancessuch as sulphuric acid and lead. Theymust be disposed of in line with legal requirements and never put out withhousehold waste. Ta k e used batteries to an authorisedcollection point.
)Disconnect the negative (-) terminal.)Lift the protective cover on the (+)terminal 2.)Slacken nut 3.)Disconnect the positive (+) terminal. )Remove the battery.)Charge the battery following the
instructions given by the manufacturer of
the battery charger. )Reconnect the battery starting with
the (+) cable.
After reconnecting
After reconnecting the battery, switchon the ignition and wait 1 minute
before star ting, to allow initialisation of the electronic systems. However, if minor problems persist after doingthis, contact a CITROËN dealer or a qualified workshop.Remember to enter the radio code yourself, referring to the relevant section.

Ensure that the battery posts and cable terminals are clean. If they are coveredwith sulphates (whitish or greenish deposit), disconnect and clean them.

Practical information
90
This kit is installed in the storage box, under
the rear seat, right hand side.
You must therefore remove the rear seat cushion for access to the kit.
Complete system consisting of a compressor and a sealant car tridge which permits
the temporary repairof a tyre so that you canrdrive to the nearest garage.
It is designed to repair most punctures which could affect the tyre, located on the tyre tread or shoulder.



















Temporary puncture repair kit
Access to the kit

Removing the rear seat cushion
)
Pull the controls Aforwards to releasethe rear seat cushion.
)
Lift the front of the cushion and tip itupwards to remove it.

Removing the metal cover
)Remove the four "butterfly" screws. )Remove the metal cover.
You now have access to the repair kit.

8
i
!
Practical information
91
1.12 V compressor with integral pressure gauge, to measure and adjust the tyre
pressure.
Composition of the kit
2.Sealant car tridge for the temporary repair
of a tyre.3.Injection pipe. 4.Suction pipe, to remove the sealant product
if necessary.
5.Sachet containing a replacement valve core, a tool for removing/refitting the valve core and a speed restriction sticker.

The speed restriction sticker must beaffixed to the vehicle's steering wheel toremind you that a wheel is in temporary use.

Do not exceed a speed of 50 mph(80 km/h) when driving with a tyre repaired using this type of kit.


Refi tting the rear seat cushion
)Put the metal cover back into place. )Refit the four "butterfly" screws.)Insert the metal hooks into the seat backrest. )Fold the seat cushion down until it locks
in place.

When refitting the cushion, take care not to trap the seat belt buckles.

!
i
Practical information
92
Repair procedure
1. Sealing
)Switch off the ignition.)Indicate on the speed restriction sticker provided, the wheel to be repaired, then fix it to the steering wheel as a reminder that a
wheel is in temporary use. )Shake the sealant car tridge, remove the cap and screw on the injection pipe.
) Remove the valve cap for the tyre to be
repaired.) Remove the valve core using the tool
provided, and store in in a clean place.
) Connect the injection pipe to the valve of
the tyre to be repaired.
)Tap the sealant car tridge (top down)several times with your hand, so as to injectall of the product into the tyre. )Remove the injection pipe.)Refit the valve core and tighten it using the
tool provided.

Take care, this product is harmful (e.g. ethylene-glycol, colophony...) if swallowed andcauses irritation to the eyes.Keep it out of reach of children. The use-by date of the sealant is marked on the car tridge.
After use, do not discard the empty cartridge but take it to a CITROËN dealer (France) or
an authorised waste disposal site. Don't forget to obtain a replacement cartridge; they are available from a CITROËN dealer or a qualified workshop.

Avoid removing any foreign bodieswhich have penetrated into the tyre.

8
!
i
Practical information
93

2. Infl ation
)Check that the compressor switch A
is in
the "OFF" position. )Uncoil the compressor pipe B.
)
Connect this pipe to the valve of the
repaired wheel. )
Connect the compressor's electric plug to
the vehicle's 12 V socket (ignition switch in
position "ON" or "ACC"). ) Star t the compressor by turning the
switch A
to the "ON" position. )
Using the compressor, adjust the pressure in accordance with the vehicle's tyre
pressure label (located in the driver's door
aperture).
A loss of pressure indicates that the
puncture has not been fully plugged;contact a CITROËN dealer or a qualified
workshop for assistance.
) Remove the compressor and stow the kit. )
Drive off straight away at reduced speed (50 mph [80 km/h] max) limiting thedistance travelled to approximately
120 miles (200 km).


As soon as possible, go to a CITROËN dealer or a qualified workshop. Tell the technician that you have used the kit. After checking, the technicianwill advise you whether the tyre can berepaired or must be replaced.


If after around 5 to 7 minutes the pressure is not attained, this indicates that the tyre is not repairable; contacta CITROËN dealer or a qualifiedworkshop for assistance.

i
Practical information
94








Changing a wheel



- A jack: for lifting the vehicle.

- A wheelbrace: for removin
g and refitting
the wheel bolts.

- A handle: for operating the jack.
These tools are not supplied with your vehicle.
Parking the vehicle

Immobilise the vehicle where it does notblock traffic: the ground must be level,stable and not slippery. Apply the parking brake, switch off the ignition and put the drive selector in
position Pto lock the wheels.
If necessary, place a chock under thewheel diagonally opposite the wheel to be changed.
You must ensure that the occupants get out of the vehicle and wait where they are safe. Never go underneath a vehicle raised using a jack; use an axle stand.

8
Practical information
95
)Slacken the bolts using the wheelbrace.)Place the jack in contact with one of the
two front A or rear B
locations provided
on the underbody, whichever is closest to
the wheel to be changed.
Removing the wheel
) Using the handle, extend the jack until its base plate is in contact with the ground.
Ensure that the centreline of the jack base
plate is directly below the location A or Bused.)
Raise the vehicle until there is sufficientspace between the wheel and the ground.
)
Remove the bolts and store them in a clean place. )
Remove the wheel.

i
Practical information
96
Fitting the wheel
)Put the wheel in place on the hub. )Screw in the bolts by hand.)Pre-tighten the bolts using the wheelbrace.
) Lower the vehicle fully. )
Fold the jack and detach it.)Tighten the bolts using the wheelbrace.



After changing a wheel

Have the tightening of the bolts andthe pressure of the new wheel checked by a CITROËN dealer or a qualifiedworkshop without delay.

8
!
Practical information
97








Changing a bulb
1.Direction indicators(W21W - 21 W).2.Sidelamps (W5W - 5 W).3.Main beam headlamps (HB3 - 60 W).4.Dipped beam headlamps (H11 - 55 W).

The headlamps are fitted with polycarbonate glass with a protectivecoating:)do not clean them using a dry or abrasive cloth, nor with a detergent or solvent product,)
use a sponge and soapy water, )
when using a high pressure washer on persistent marks, do not directat the lamps or their outlines for too long, so as not to damage their protective coating and seals.
)
Do not touch the bulb directly with your fingers, use lint-free cloths.
Changing a bulb should only be done after the headlamp has been switched
off for a few minutes (risk of serious burns). It is imperative to use only anti-ultraviolet (UV) type bulbs in order notto damage the headlamp. Always replace a failed bulb witha new bulb with the same type andspecification.
Front lamps
5. Front foglamps(H8 - 35 W).6.Daytime running lamps (P13W - 13 W).

Practical information
98
) Lift the cover B
, using a screwdriver
protected by a cloth.) Slacken fixing screw C
until the head of the screw touches the trim.
)Remove the bumper retaining clips, usinga screwdriver. )Carefully lift the bumper. To replace a failed bulb,
you must first remove
the lamp. To remove the lamp:)Open the bonnet. )Press tab A to release the connector.
Access to bulbs
