bulb Citroen C ZERO RHD 2012 1.G Owner's Manual

.
.
Contents
2
ISOFIX child seats 67
Child lock 70
Child safety
Direction indicators 71
Hazard warning lamps 71
Horn 71
Emergency or assistance call 72
Braking assistance systems 72
Tr ajectory control systems 74
Fr
ont seat belts 75
Airbags 78
Safety
Charging the main battery 82
Ancillaries battery 88
Te m p o r a ry puncture repair kit 92
Changing a wheel 96
Changing a bulb 99
Changing a fuse 107
Changing a wiper blade 112
To w i ng the vehicle 112
Precautions for washing 113
Accessories 113
Practical information
Bonnet 116
Front compartment 117
Rear compartment 118
Checking levels 119
Checks 121
Checks
Motor and main battery 122
Weights 123
Dimensions 124
Identifi cation markings 125
Technical data
Emergency or assistance 127
Audio system 129
Audio and telematics
Visual search
Alphabetical index

5
Visibility
59
Daytime running lamps
Special daytime lighting so that the vehicle can
be seen more easily.
The daytime running lamps come on
automatically when starting the motor, if no
other lighting is on.
They cannot be deactivated.
With the main lighting control ring in the AUTOposition, the sidelamps and dipped beam headlamps come on automatically, without any action by the
driver, when a low level of ambient light is detected.
When the light returns to a sufficient level or the wipers are switched off, the lighting is switched off automatically.
The sensor is located at the base of the windscreen.
Automatic illumination of headlamps
Automatic lighting off
When the lighting stalk is in the "AUTO"position, if the ignition switch is in the "LOCK"
or "ACC" position or if the key has beenremoved, the lighting switches off automaticallywhen the driver's door is opened.
The initial setting is position "0".









Headlamp
adjustment

To avoid causing a nuisance to other road
users, the height of the halogen headlamps should be adjusted according to the load in the
vehicle.
0. Driver only or driver + 1 front passenger.
1 or 2. 4 people (including the driver). 3.4 people (including the driver) + maximumauthorised load.4.Driver + maximum authorised load.

Although these lamps are located in the same unit as the front foglamp, theyoperate with a specific bulb.
Their use is covered by road vehiclelighting regulations.

In foggy weather or in snow, thesunshine sensor may detect sufficient light. The lighting will not come onautomatically. Do not cover the sunshine sensor, theassociated functions will no longer becontrolled.

8
Practical information
99








Changing a bulb
1.Direction indicators(W21W - 21 W).2.Sidelamps (W5W - 5 W).3.Main beam headlamps (HB3 - 60 W).4.Dipped beam headlamps (H11 - 55 W).

The headlamps are fitted with polycarbonate glass with a protectivecoating:)do not clean them using a dry or abrasive cloth, nor with a detergent or solvent product,)
use a sponge and soapy water, )
when using a high pressure washer on persistent marks, do not keep the lance directed towards thelamps or their edges for too long, so as not to damage their protectivecoating and seals,)
do not touch the bulb directly withyour fingers, use lint-free cloths.

Changing a bulb should only be done after the headlamp has been switchedoff for a few minutes (risk of serious burns).
It is imperative to use only anti-ultraviolet (UV) type bulbs in order notto damage the headlamp. Always replace a failed bulb with anew bulb with the same type andspecification.
Front lamps
5. Front foglamps
(H8 - 35 W).6.Daytime running lamps (P13W - 13 W).

Practical information
100
) Lift the cover B
, using a screwdriver
protected by a cloth.) Slacken fixing screw C
until the head of the screw touches the trim.
)Remove the bumper retaining clips, using ascrewdriver. )Carefully lift the bumper. To replace a failed bulb,
you must first remove
the lamp. To remove the lamp:)Open the bonnet. )Press tab A to release the connector.
Access to bulbs

Practical information
102
Changing sidelamp bulbs
) Turn the bulb holder to the left and pull it out.)
Pull the bulb out and and change it.
To reassemble, carry out these operations in reverse order.
Changing main beam headlampbulbs
)Turn the bulb holder to the left and pull it out.)Remove the bulb by pressing on the tongue. )Change the bulb.
For reassembly, carry out these operations in
r
everse order.

Changing direction indicator
bulbs
)Turn the bulb holder to the left and pull it out. )Pull the bulb out and change it.
To r e f i t , c a r ry out these operations in reverse order.
Amber coloured bulbs must be replaced with bulbs of identical specifications and colour.

8
Practical information
103
Changing dipped beam headlamp bulbs
)Turn the bulb holder to the left and pull it out. )Remove the bulb by pressing on the tongue. )Change the bulb.
To r efit, carry out these operations in reverse order.
Changing front foglamp bulbs / daytime running lamp bulbs
) Put the front wheels onto full lock,
to facilitate access.) Remove the clips securing the protective covers on the bulb holders.)
Move the cover aside.
)
Turn the bulb holder ( Afor the front fog
lamp, B for the daytime running lamp) to
the left and pull it out.
) Pull the bulb out and change it.
To reassemble, carry out these operations in
reverse order.

Practical information
104
1.Brake lamps / Sidelamps (21 W / 15 W or LEDs).2.Direction indicators (W Y21W - 21 W).3.Reversing lamps (W21W - 21 W).
Rear lamps
Amber coloured bulbs, such as the direction indicators, must be replaced with bulbs of identical specification and colour.
In some weather conditions (e.g. lowtemperature or humidity), the presenceof misting on the internal sur face of the glass of the headlamps and rear lamps is normal; it disappears after the lampshave been on for a few minutes.
Changing integrated directionindicator side repeater bulbs (WY5W - 5 W)
)Push the repeater towards the rear anddisengage it.)Turn the bulb holder to the left and pull itout.)Pull the bulb out and change it.
To reassemble, carry out these operations inreverse order.

Access to bulbs
)Remove the two screws.)Disengage the lamp unit by pulling it towards you.

8
Practical information
105
Changing a direction indicator bulb
) Turn the bulb holder to the left and pull it out. )
Pull the bulb out and replace it.
To r efit, carry out these operations in reverse order.
Changing brake lamp / sidelamp bulbs (21 W / 15 W)
Changing brake lamp / sidelamp LEDs
All work on the LED lamps must be carried out
by a CITROËN dealer or qualified workshop.
Changing a reversing lamp bulb
) Turn the bulb holder to the left and pull it out.)
Pull the bulb out and replace it.
To r efit, carry out these operations in reverseorder.

)Turn the bulb holder to the left and pull it out.)Pull out the bulb and change it.
To r efit, carry out these operations in reverseorder.

Practical information
106
Changing a foglamp bulb (W21W - 21W)
)Remove the cover.)Turn the bulb holder to the left and pull itout.)Pull the bulb out and change it.
To r e f i t , c a r r
y out these operations in reverse order.
Third brake lamp (W5W - 5W)
) Remove the two screws. )
Pull out the bulb-holder. )
Pull out the bulb and change it.
To r efit, carry out these operations in reverseorder.

Changing number plate lamp
bulbs (W5W - 5W)
)Push the cover inwards.)Turn the bulb holder and pull it out.)Remove the bulb and change it.
To r efit, carry out these operations in reverse order.

Practical information
114
"Protection":
mats, boot carpet, vehicle cover, translucent bumper protectors, side rubbing strips...
"Multimedia":
audio systems, driving aids, universal solar charger, semi-integral navigation system (with
locations of charging stations), Wi-Fi hub,
iPhone ®compatible phone charger, hands-free®
kit, DVD players...
The fitting of electrical equipment or accessories which are not recommended by CITROËN may result
in a failure of your vehicle's electronicsystem and excessive electricalconsumption. Please note this precaution. You are advised to contact a CITROËNrepresentative to be shown the range of recommended equipment and accessories.
Installation of radiocommunicationtransmitters
Before installing any after-market radio communication transmitter, you cancontact a CITROËN dealer for thespecification of transmitters which canbe fitted (frequency, maximum power,aerial position, specific installation requirements), in line with the VehicleElectromagnetic Compatibility Directive(2004/104/EC).



Depending on the legislation in forcein the country, it may be compulsory to have a high visibility safety vest, warning triangle and spare bulbs andfuses available in the vehicle.
