Citroen C ZERO RHD 2017 1.G Owner's Manual

159
QUESTIONANSWER SOLUTION
The quality of reception of
the radio station listened
to gradually deteriorates
or the stored stations do
not function (no sound,
87.5

MHz is displayed...). The vehicle is too far from the transmitter used by the station
listened to or there is no transmitter in the geographical area
through which the vehicle is travelling.
Activate the RDS function to enable the system
to check whether there is a more power ful
transmitter in the geographical area.
The environment (hills, buildings, tunnels, basement car parks...)
block reception, including in RDS mode. This phenomenon is normal and does not indicate
a failure of the audio equipment.
The aerial is absent or has been damaged (for example when going
through a car wash or into an underground car park). Have the aerial checked by a CITROËN dealer.
Sound cut-outs of 1 to
2

seconds in radio mode. During this brief sound cut-out, the RDS searches for any frequency
permitting better reception of the station. Deactivate the RDS function if the phenomenon is
too frequent and always on the same route.
Traffic announcement TA is
displayed. I do not receive
any traffic information. The radio station does not broadcast traffic information.
Tune to a radio station which broadcasts traffic
information.
The stored stations are not
found (no sound, 87.5 MHz
is displayed...). An incorrect waveband is selected.
Press the SRC/ TEL button to return to the
waveband (FM1 or FM2) on which the stations are
stored.
.
Audio and Telematics

160
QUESTIONANSWER SOLUTION
The CD is ejected
automatically or is not
played by the player. The CD is inserted upside down, is unplayable, does not contain any
audio data or contains an audio format which the player cannot play.
The CD is protected by an anti-pirating protection system which is
not recognised by the audio equipment. -

C
heck that the CD is inserted in the player the
right way up.
-

C
heck the condition of the CD: the CD cannot
be played if it is too damaged.
-

C
heck the content in the case of a recorded
CD: consult the advice in the "Audio" section.
-

T
he audio equipment's CD player does not
play DVDs.
-

D
ue to their quality level, certain writeable
CDs will not be played by the audio system.
The CD player sound is
p o o r. The CD used is scratched or of poor quality.
Insert good quality CDs and store them in suitable
conditions.
The audio settings (bass, treble, ambience) are unsuitable. Set the treble or bass level to 0, without selecting
an ambience.
The Bluetooth connection
is cut. The battery of the peripheral may not be sufficiently charged. Recharge the battery of the peripheral device.
The message "USB device
error" is displayed on the
screen. The USB memory stick is not recognised.
Use only USB memory sticks formatted to FAT32
(28 -bit file allocation table).
A telephone connects
automatically, disconnecting
another telephone. Automatic connection overrides manual connection.
Modify the telephone settings to remove
automatic connection.
Audio and Telematics

161
QUESTIONANSWER SOLUTION
An iPod is not recognised
when connecting to the
USB port. The iPod is of a generation that is not compatible with the USB
connection.
The hard disk or device
is not recognised when
connecting to the USB
port. Some hard disks and devices need a power supply greater than is
provided by the audio system.
Connect the device to the 230 V socket, the 12 V
socket or an external power supply.
Caution
: ensure that the device does not transmit
a voltage greater than 5 V (risk of destruction of
the system).
When streaming, the sound
cuts momentarily. Some telephones prioritise connection of the "hands-free" profile. Delete the "hands-free" connection profile to
improve streaming.
In "Random all" play, not all
of the tracks are played. In "Random all" play, the system can only take into account up to
999 tracks.
With the engine off, the
audio system switches off
after a few minutes of use. When the engine is switched off, the audio system operating time
depends on the battery charge.
The switch-off is normal: the audio system switches to economy
mode and switches off to prevent discharging the vehicle's battery. Start the vehicle's engine to increase the battery
charge.
The message "the audio
system is overheated"
appears on the display. In order to protect the installation if the surrounding temperature
is too high, the audio system switches to an automatic thermal
protection mode leading to a reduction of the volume or stopping of
the playing of the CD. Switch the audio system off for a few minutes to
allow the system to cool.
.
Audio and Telematics

1
2
1
2
163
KENWOOD - KDC-X7000DAB
For more information, consult the KENWOOD
user guide provided with the system.
For obvious safety reasons, the vehicle
must be stationary when the driver
carries out operations which require
sustained attention.
Short press: on.
Long press: off.
Rotation: adjust the volume, navigate
in a list.
Press: confirm.
Change audio source.
Short press: search for a service.
Long press: updating of the list of
stations available.Abandon the current operation.
Go up one level.
Reject or end a call.
Select an analogue waveband FM1 /
FM2 / FM3 / MW / LW.
Select a digital waveband DB1
/
DB2 / DB3.
Change of search method (automatic
or manual). Navigate in a list.
Short press: search for a radio
station, a frequency or a service,
search for a previous/next track or
file, navigate in a list.
Long press: Rewind / fast for ward.
Short press: select a stored radio
station.
Long press: store a radio station.
Short press: accept an incoming
call, switch between two calls, enter
Bluetooth mode.
Long press: smartphone voice
commands via the system.
Fitting the control
panel.
Removing the control
panel.
.
Audio and Telematics

164
Accessories ..................................................58
Access to bulbs ................................... 1 27, 131
Adjusting headlamps
.................................... 56
A

djusting head restraints
..............................32
A

djusting seat
.........................................3
2, 34
Advice on driving

..............................
............ 87
Airbags
...............

..................................... 70, 77
Airbags, curtain
....................................... 7

2, 73
Airbags, front........................................... 70, 73
Airbags, lateral
........................................ 7

2, 73
Air conditioning
...............................

..42, 44, 45
Air vents

..............................
..........................41
Anti-lock braking system (ABS)

....................63
A

nti-slip regulation (ASR)
............................65
A

ssistance call
...............................
...............61
Audio streaming (Bluetooth)
..............................

..................151
Battery, 12 V

...............................
......... 109, 113
Battery, main

......................................... 9
7, 140
Bluetooth (hands-free)

................................15

2
Bonnet
...............

.......................................... 10 6
Bonnet stay
................................................. 10

6
Brake discs

.................................................. 111
B

rake lamps
...............................
........... 59, 132
Brake lamps, automatic operation

................59
B

rakes
......................................................... 111
B

raking assistance system
...........................63
B

ulbs (changing)
...............................
.. 126, 131Daytime running lamps

......................... 5
5, 130
Deactivating the passenger airbag
......... 7

0, 77
Deactivating the passenger and
rear window control switches

.....................3

0Filter, passenger compartment
...................
111
F

itting a wheel
...............................
..............121
Fittings, interior
............................................. 38
D

efrosting / demisting, front .........................46
D
imensions .............................. ...................142
Direction indicators
....................... 5

5, 129, 132
Display screen
..............................

.......... 21, 22
Door pockets

.................................................38
D

oors
.............................................................28
D

rive selector
...............................
.................90
Electric motor

..............................................14

0
Electronic brake force distribution (EBFD)
...............................

.........................63
Electronic stability programme (ESP)

..........65
E

mergency braking assistance
(EBA)
..............................

......................63, 64
Emergency call
............................................. 61
E

mergency warning lamps
...........................59
E

ngine brake
.................................................66
E

ngine brake reduction indicator lamp
... 1
0, 66
Environment
...............................

..................... 9
A
B
C
DF
CD, MP3 .............................................. 149, 150
Changing a bulb .................................. 1 26, 131
Changing a fuse
.......................................... 13

4
Changing a wheel

...............................
........121
Changing a wiper blade

..............................11

2
Charging, fast
.............................................. 10

4
Charging, normal
..............................

............97
Charging time
...............................

...............140
Checking components
......................... 1

0 7, 111
Checking the levels

.............................10

9, 110
Checking tyre pressures (using the kit)

......11

7
Child lock

...............................
..................85, 86
Children
...............................

.............. 81, 83, 85
Child seats

............................6
9, 74-76, 80, 81
Child seats, conventional

..............................80
C

hild seats, ISOFIX
................................ 83

-85
CITROËN Connect Box

...............................61
C

ITROËN Localised Emergency Call........... 61
Closing the boot

...............................
.............29
Compartment, front

..................................... 10

7
Compartment, rear
..................................... 10

8
Control, heated seats

.................................... 34
C

ontrol stalk, lighting
.................................... 53
C

ontrol stalk, wipers
..................................... 56
C

ontrol unit
.................................................... 99
C

ourtesy lamp
...............................
................57
Cup holder

...............................
......................38
E
Alphabetical index

165
Fitting the mat ...............................................39
F laps, charging ............................................. 31
F
lashing indicators
................ 5
5, 129, 131, 132
Foglamp, rear
...............................

......... 54, 133
Foglamps, front
...............................

......54, 130
Folding the rear seat backrest

......................34
F

olding / unfolding the door mirrors
.............36
Fu

ses
................
........................................... 13 4
Hazard warning lamps
.................................. 59
H

eadlamp adjustment
................................... 56
H

eadlamps, automatic illumination
..............55
H

eadlamps, dipped beam
...........................13

0
Headlamps, main beam

..............................12

9
Head restraints........................................ 32-34
Heating
................

.......................................... 44
Horn ............................................................... 59
Immobiliser, electronic
............................ 2

6, 27
Indicator, energy consumption / generation
...............................

....................20
Indicator lamps, operation

............................11
I

ndicators, direction
...................................... 55
I

nflating tyres
..............................
.........117, 144Instrument panel
............................... ............10
Isofix mountings ...............................
.......83-85
Jack
........

.....................................................121Lighting, automatic off
..................................55
L
ighting dimmer .............................. ........ 21, 22
Localised Assistance Call

.............................61
L

ocking from the inside
.................................28
K

ey with remote control
.......................... 2
5, 27
Kit, hands-free
............................................ 15

2
Kit, temporary puncture repair

....................11

7
Labels, identification
................................... 14

3
Lamps, front

................................................12

6
Lamps, rear
...............................

..................131
Level, brake fluid

.........................................10

9
Level, engine coolant

..................................10

9
Level, heating system fluid

.........................10

9
Levels and checks

.......................1
07, 109, 110
Level, screenwash fluid

..............................10

9Markings, identification
...............................
14

3
Mat
.......

.........................................................39
Mirror, rear view

............................................37
M

irrors, door..................................................36
Mountings, Isofix
...............................

......83-85
MP3, CD

.............................................. 1
49, 150
Number plate lamps

....................................13

3
Opening the boot

..............................
............29
Opening the front compartment

.................10

6
H
I
K
L
JM
N
O
.
Alphabetical index

166
Safety, children ......................74-76, 81, 83, 84
Screen menu map ....................................... 15
7
Screenwash
..............................

....................56
Seat belts
.......................................... 6

7- 69, 80
Seats, front
...............................

.....................32
Seats, heated
...............................

.................34
Seats, rear
..................................................... 34
Sel

ector, drive
............................................... 90
S

erial number, vehicle
................................14

3
Service indicator
........................................... 2

2
Sidelamps
........................................... 1

29, 132
Side repeater
..............................

................131
Snow chains
................................................ 12

5
Socket, 12 V accessory

..........................3
8, 39
Speedometer
..............................

..................10
Stability control (ESP)

...................................65
S

tarting the vehicle
.................................8
8, 90
Stopping the vehicle

...............................8
8, 90
Storage
................

.......................................... 38
Sun visor
....................................................... 39
T

echnical data
..................................... 14

0, 141
Third brake lamp

......................................... 13

3
Total distance recorder

.................................21
T

owing another vehicle
...............................13

9
Traction control (ASR)

..................................65
T

raffic information (TA)
...............................14

8
Ty r e s
......................................................9

2, 144
Tyre under-inflation detection

........... 1
7, 24, 92
T
Under-inflation detection, tyre .......... 17, 24, 92
Unlocking from the inside .............................28
U
SB player
..............................................3
8, 40
U
Ventilation ......................................... 41, 42, 44
Warning and indicator lamps
............ 1
1, 14, 15
Warning lamp, seat belts

..............................67
We

ights
...............
........................................ 141
Wheel, spare
............................................... 14

4
Window controls

........................................... 3

0
Wiper blades (changing)
............................. 11

2
Wiper, rear ..................................................... 57
Wipers
........................................................... 56
V
W
Pads, brake .................................................111
P arking brake ........................................ 8
9 , 111
Pedestrian horn

..............................
..............60
Player, MP3 CD

...............................
.... 149, 150
Port, USB

.............................................. 4
0, 150
Pressures, tyre
..............................9

2, 143, 144
Pre-tensioning seat belts

..............................69
P

rotecting children
................. 7
4-76, 81, 83 - 86
Puncture
................

...................................... 117
PS
Radio ........................................................... 147
Range ................ ...................................... 21, 24
Rear screen, demisting
................................. 46
R

echarging the main battery
........................97
R

ecirculation / exterior air intake
..................44
R

eminder, lighting on
.................................... 54
R

emote control
........................................ 2
7, 47
Removing a wheel

..............................
........121
Removing the mat

...............................
..........39
Replacing bulbs
..............................

.... 126, 131
Replacing fuses
..............................

............13 4
Replacing the passenger compartment
filter
........

................................................... 111
Reservoir, screenwash
............................... 10

9
Reversing lamps
......................................... 13

2
R
Alphabetical index
