Citroen C3 2013 2.G Owner's Manual

7
Child safety
99
Weight of the child and indicative age
SeatUnder 13 kg(groups 0 ( b) and 0+)Up to approx 1 year
From 9 to 18 kg(group 1)1 to 3 years approx
From 15 to 25 kg(group 2)
3 to 6 years approx
From 22 to 36 kg(group 3)
6 to 10 years approx

Front passenger seat ( c
) cUUUU
Outer rear seats UUUU
Centre rear seat UUUU














Installing child seats attached using the seat belt
In accordance with European regulations, this table indicates the options for installing child seats secured using a seat belt and universally approved (a)in accordance with the weight of the child and the seat in the vehicle.
(a)Universal child seat: child seat that can be installed in all vehicles using a seat belt. (b)
Group 0: from bir th to 10 kg. Shells seats and baby carriers cannot be installed in the front passenger seat. (c)Consult the legislation in force in your country before installing your child on this seat. U: Seat suitable for the installation of a child seat secured using a seat belt and universally approved, "rear wards-facing" and/or "forwards-facing".

Child safety
100
As a safety precaution, do not leave:


- a child or children alone andunsuper vised in a vehicle,

- a child or an animal in a vehicle which is exposed to the sun, with the windowsclosed,

- the keys within reach of children insidethe vehicle.
To prevent accidental opening of the doors and rear windows, use the "Child lock".
Take care not to open the rear windows bymore than one third.
To protect young children from the rays of the sun, fit side blinds on the rear windows.
For optimum installation of the "forwards-facing" child seat, ensure that the back of thechild seat is in contact with the back of thevehicle's seat and remove the head restraint. Ensure that the head restraint is stored or attached securely to prevent it from beingthrown around the vehicle in the event of sharp braking. Refit it if an adult uses the seating position.Children under the age of 10 must not travelin the "for wards-facing" position on the front passenger seat, unless the rear seats are already occupied by other children, cannotbe used or are absent. Deactivate the passenger airbag when a "rearwards-facing" child seat is installed on the front seat. Other wise, the child would risk beingseriously injured or killed if the airbag were to inflate.


Installing a booster seat

The chest par t of the seat belt must be
positioned on the child's shoulder without touching the neck.
Ensure that the lap part of the seat belt passes correctly over the child's thighs.
CITROËN recommends the use of a booster seat which has a back, fitted with a seat belt guide at shoulder level.
The incorrect installation of a child seat in a vehicle compromises the child's protection inthe event of an accident.Ensure that there is no seat belt or seat belt buckle under the child seat, as this could destabilise it. Remember to fasten the seat belts or the child seat harnesses keeping the slackrelative to the child's body to a minimum,even for short journeys.When installing a child seat using the seatbelt, ensure that the seat belt is tightened correctly on the child seat and that it securesthe child seat firmly on the seat of your vehicle. If your passenger seat is adjustable,move it for wards if necessary. At rear seating positions, always leave sufficient space between the front seat and: - a "rear wards facing" child seat, - the child's feet for a child seat fitted "forwards facing". To do this, move the front seat for wardsand, if necessary, move its backrest into the upright position.





Advice on child seats

7
Child safety
101
with the ISOFIX regulation.
The seats, represented below, are fitted with
re
gulation ISOFIX mountings:
There are three rin
gs for each seat:


- two rings A
, located between the vehicleseat back and cushion, indicated by a label, This IS
OFIX mounting system provides fast,
reliable and safe fitting of the child seat in your
vehicle.
The ISOFIX child seats
are fitted with two latches which are secured on the two rings A.
When fitting an ISOFIX child seat to the right
hand rear seat, before fixing the seat in place,first move the centre rear seat belt towards the
mi
ddle of the vehicle so as to not interfere with
the operation of the seat belt.

Some seats also have an upper strapwhich is
attached to ring B. To attach this strap, raise the vehicle seat's head restraint then pass the hook between its
rods. Then fix the hook on ring Band tighten
the upper strap.
- a ring B
, behind the seat, referred to as theTOP TETHER
for fixing the upper strap.
For in
formation regarding the ISOFIX child
seats which can be installed in your vehicle,
refer to the table showing the locations for
installing ISOFIX child seats.




















"ISOFIX" mountings

The incorrect installation of a child seatin a vehicle compromises the child's protection in the event of an accident.

Child safety
102














ISOFIX child seat


This child seat can also be used on seats which are not fitted with ISOFIX mountings. In this case, it must be attached to the vehicle seat using the three point seat belt.Follow the instructions for fitting the child seat given in the seat manufacturer's installation guide.
Recommended by CITROËN and approved for your vehicle
RÖMERDuo Plus ISOFIX
(size category B1)
Group 1: from 9 to 18 kg

Installed onl
y in the for wards-facing position. Fitted with an upper strap to be secured on the upper ring B , referred to as the TOP TETHER. Three seat body angles: sitting, reclining, lying.
Adjust the front seat of the vehicle so that the child's feet do not touch the back of the seat.
Can be installed forwards-facing by attaching it to the seat using a three-point seat belt

7
Child safety
103

*
Infant car seats and "car cots" cannot be installed on the front passenger seat.


















Installing ISOFIX child seats
In accordance with European regulations, this table indicates the options for the installation of ISOFIX child seats on the vehicle seats fitted with
ISOFIX mountings.
In the case of the universal and semi-universal ISOFIX child seats, the child seat's ISOFIX size category, determined by a letter between A
and G
, is
indicated on the child seat next to the ISOFIX logo.
IUF:seat suitable for the installation of an Isofix U niversal seat, "F
orward facing" and secured using the "Top Tether" upper strap.IL- SU:seat suitable for the installation an I sofix S emi-U
niversal seat which is:


- "rear facing" fitted with a "Top Tether" upper strap or a stay,

- "forward facing" fitted with a stay,
For the securing of the "Top Tether" upper strap, refer to the "ISOFIX Mountings" section.X:seat which is not suitable for the installation of an ISOFIX seat of the size category indicated.
Weight of the child
/ indicative age
Less than 10 kg (group 0)Up to 6 months approx
Less than 10 kg(group 0)Less than 13 kg (group 0+)Up to 1 year approx
From 9 to 18 kg (group 1)From 1 to 3 years approx
Type of ISOFIX child seatInfant car seat*"rear facing""rear facing" "for ward facing"
ISOFIX size categoryFGCDECDABB1
Universal and semi-universal ISOFIX child seats which can be installed on the outer rear seatsXXIL-SUXIL-SUIUF
IL-SU

Child safety
104








Manual child lock
Locking
)With the ignition key, turn the red control
one quarter of a turn:
- to the right on the le
ft-hand rear door,
- to the left on the right-hand rear door.


Unlocking
)With the ignition key, turn the red control
one quar ter of a turn:
- to the left on the left-hand rear door,
- to the ri
ght on the right-hand rear door.




Electric child lock

Activation
)
Press this button. The indicator lamp on the button comes on, accompanied by a message in the multifunction screen.
This indicator lamp remains on until the childlock is deactivated.


Deactivation
)Press the button again.
The indicator lamp on the button switches off,
accompanied by a message in the multifunction screen. This indicator lamp remains off until the childlock is activated.

This system is independent and in nocircumstances does it take the place of the central locking control. Check the status of the child lock eachtime you switch on the ignition.

Always remove the key from the ignition when leaving the vehicle, even for a short time. Remote control system to prevent opening o
f
the rear doors using their interior controls and use of the rear electric windows.
The control is located on the driver's door, with
th
e electric window controls. Mechanical system to prevent opening o
f the rear door using its interior control.
The control is located on the edge of each rear door.

8
Safety
105











Direction indicators Selection of the left or right direction indicators
to signal a change of direction of the vehicle.
)Left: lower the lighting stalk beyond the point of resistance.)Right: raise the lighting stalk beyond thepoint of resistance.
"Motorway" function
)Press briefly upwards or downwards,
without going beyond the point of resistance; the direction indicators will flash 3 times.







Hazard warning lamps
)
Press this button, the direction indicators flash.
They can operate with the ignition off.
Automatic operation of
hazard warning lamps
When braking in an emergency, depending on
the deceleration, the hazard warning lamps come on automatically.
They switch off automatically the first time you accelerate.)
You can also switch them off by pressingthe button. A visual warnin
g by means of the directionindicators to alert other road users to a vehiclebreakdown, towing or accident.

Safety
106








Horn
imminent danger.
)Press one of the spokes of the steering
wheel.

Use the horn moderately and only in the following cases:


- immediate danger,

- over taking a cyclist or pedestrian,

- when approaching an area where there is no visibility.










Emergency or
assistance call
This system allows you to make an emergencyor assistance call to the emergency ser vices or
to the dedicated CITRO

8
Safety
107
Operating fault
You must stop as soon as it is safe to do so.
In either case, contact a CITROËN dealer or aqualified workshop. If this warnin
g lamp comes on,
accompanied b
y an audible signal
and a message in the screen, it
indicates a malfunction of the anti-lock braking system which couldresult in loss of control of the vehicle
when braking.
If this warnin
g lamp comes on,
together with the STOPand ABSwarning lamps, accompanied by an
audible signal and a message in the screen, it indicates a malfunction of
the electronic brake force distribution
which could result in loss of control of
the vehicle when braking.
Emergency braking assistance
System which, in an emergency, enables you
to obtain the optimum braking pressure more quickly, thus reducing the stopping distance.

Activation

It is triggered by the speed at which the brake
pedal is pressed.
Th
e effect of this is a reduction in theresistance of the pedal and an increase in
braking efficiency.
When replacing wheels (tyres andrims), ensure that they conform to the manufacturer's recommendations.
When braking in an emergency, press firmly without releasing the pressure.
















Braking assistance systems


Anti-lock braking system
and electronic brake force
distribution

Linked systems which improve the stability andmanoeuvrability of your vehicle when braking,
in par ticular on poor or slippery surfaces.

Activation

The anti-lock braking system comes into
operation automatically when there is a risk of
wheel lock.
Normal operation of the ABS may make itself felt by slight vibration of the brake pedal.

When braking in an emergency, press very firmly without releasing thepressure. Group of supplementar
y systems which helpyou to obtain optimum braking in completesafety in emergency situations:


- anti-lock braking system (ABS),

- electronic brake force distribution (EBFD),

- emergency braking assistance (EBA).

Safety
108














Trajectory control systems
Anti-slip regulation (ASR)
and electronic stability
programme (ESP)
The anti-slip regulation (also known as Traction Control) optimises traction to prevent skidding
of the wheels, by acting on the brakes of the
driving wheels and on the engine.
The electronic stability programme acts on the
brake of one or more wheels and on the engine to
keep the vehicle on the trajectory required by the
driver, within the limits of the laws of physics.
Activation
These systems are activated automatically each time the vehicle is started.
They come into operation in the event of a grip
or trajectory problem.
This is indicated b
y flashing of this
warning lamp in the instrument panel.


Deactivation

In exceptional conditions (starting a vehicle
which is bogged down, stuck in snow, on soft ground...), if you are unable to make progress,
it may be advisable to temporarily deactivate
these systems, so that the wheels can spin freely and allow the vehicle to move. ) Press the "ESP OFF"
button, located near
the steering wheel.
If this warning lamp comes on in the instrument panel and the indicator lamp in the button comes on, thisindicates that these systems are deactivated. It is recommended that the systems be reactivated as soon as possible.

Reactivation
These systems are reactivated automatically each time the ignition is switched back on or from 30 mph (50 km/h).)
Press the "ESP OFF"
button again to
reactivate them manually.

Operating fault

If this warning lamp comes on,
accompanied by an audible signal
and a message in the screen, this
indicates a
fault with these systems.
Have it checked by a CITROËN
dealer or a qualified workshop.
The trajectory control systems offer increased safety in normal driving, butthis should not encourage the driver to take extra risks or drive at high speed.
The correct functioning of these systems is assured provided thatmanufacturer's recommendations areobserved on:


- wheels (tyres and rims),

- braking components,

- electronic components,

- assembly and repair procedures.
After an impact, have these systems checked by a CITROËN dealer or a qualified workshop.
