6
Fittings
93








Boot fi ttings
1.Rear parcel shelf (see following page for details)2.Hooks
(see following page for details)3.Location for Hi- Fi amplifier4.Stowing rings5.Storage box (version equipped with a
temporary puncture repair kit)
(see following page for details) or Tool box (version equipped with a spare
wheel) (refer to section "Practical Information -§ Changing a wheel")

8
Safety
105











Direction indicators Selection of the left or right direction indicators
to signal a change of direction of the vehicle.
)Left: lower the lighting stalk beyond the point of resistance.)Right: raise the lighting stalk beyond thepoint of resistance.
"Motorway" function
)Press briefly upwards or downwards,
without going beyond the point of resistance; the direction indicators will flash 3 times.







Hazard warning lamps
)
Press this button, the direction indicators flash.
They can operate with the ignition off.
Automatic operation of
hazard warning lamps
When braking in an emergency, depending on
the deceleration, the hazard warning lamps come on automatically.
They switch off automatically the first time you accelerate.)
You can also switch them off by pressingthe button. A visual warnin
g by means of the directionindicators to alert other road users to a vehiclebreakdown, towing or accident.

9
Driving
133
You can activate or deactivate the system bymeans of the multifunction screen configuration menu. The system state is memorised whenswitching off the ignition.
For more information on access to the parkingsensors menu, refer to "Configuration / Vehicleparameters" in the "Multifunction screens"section corresponding to your screen.
Operating faults

If there is an operating fault, when
reverse gear is engaged this
warnin
g lamp comes on in the
instrument panel, accompanied byan audible signal (short beep) and a message in the multifunction screen.

Programming
The system will be deactivated automatically when towing a trailer or when a bicycle carrier is fitted (vehiclefitted with a towbar or bicycle carrier recommended by CITROËN).
In bad or wintry weather, ensure that the sensors are not covered with mud,frost or snow.

Practical information
176





Towing the vehicle
Access to the tools
The towing eye is installed in the boot under
the floor.
To gain access to it:)open the boot, )raise the floor,)remove the polystyrene storage box,)remove the towing eye from the holder. Procedure for havin
g your vehicle towed or for towing another vehicle using a removable towing eye.
General recommendations
Obser ve the legislation in force in your country. Ensure that the weight of the towing vehicle is higher than that of the towed vehicle. The person at the wheel of the towed vehicle must have a valid driving licence.When towing a vehicle with all four wheels on the ground, always use an approved towing bar; rope and straps are prohibited. When towing a vehicle with the engine off, there is no longer any power assistance for braking or steering. In the following cases, you must always call on a professional recovery service: - vehicle broken down on a motor way or fast road, - 4 wheel drive vehicle, - when it is not possible to put the gearbox into neutral, unlock the steering, or release theparking brake, - towing with only two wheels on the ground, - where there is no approved towing bar available...

11
Practical information
177

To w i ng your vehicle
)On the front bumper, unclip the cover bypressing at the bottom. )Screw the towing eye in fully. )Install the towing bar. )Place the gear lever in neutral (position N
for an electronic or automatic gearbox).
) On the rear bumper, unclip the cover bypressing at the bottom. )
Screw the towing eye in fully. )
Install the towing bar. )
Switch on the hazard warning lamps on both vehicles.)
Move off gently and drive for a shor t distance only.



To w i ng another vehicle
Failure to obser ve this special condition could result in damage to cer tain components (braking, transmission...) and the absence of braking assistance the next time the engine is star ted.
)
Unlock the steering by turning the key one
notch in the ignition switch and release the
parkin
g brake. ) Switch on the hazard warning lamps onboth vehicles. )
Move off gently and drive for a shor t
distance only.

Practical information
178








Towing a trailer


Driving advice


Side wind
)Take into account the increased sensitivity
to side wind. T
owbar suitable for the attachment of atrailer or installation of a bicycle carrier, with additional lighting and signalling.

Distribution of loads
)Distribute the load in the trailer so that the heaviest items are as close as possible to
the axle and the nose weight approaches the maximum permitted without exceeding it.
Air density decreases with altitude, thus
reducing engine performance. Above
1 000 metres, the maximum towed load must
be reduced b
y 10 % for every 1 000 metres of altitude.We recommend the use of genuineCITROËN towbars and their harnessesthat have been tested and approvedfrom the design stage of your vehicle, and that the fitting of the towbar is entrusted to a CITROËN dealer or a qualified workshop.If the towbar is not fitted by a CITROËNdealer, it is imperative that it is fitted in accordance with the vehicle manufacturer's instructions.

Drivin
g with a trailer places greater demands
on the towing vehicle and the driver must take
particular care.
Your vehicle is primaril
y designed for
transporting people and luggage, but it mayalso be used for towing a trailer.

R
efer to the "Technical data" section for details
of the weights and towed loads which apply to your vehicle.

11
Practical information
179
Braking
To w i ng a trailer increases the braking distance.
To avoid overheating of the brakes on a long
mountain type of descent, the use of engine braking is recommended.
Tyres
)
Check the tyre pressures of the towing
vehicle and of the trailer, obser ving therecommended pressures.
Lighting
) Check the electrical lighting and signallingon the trailer.
The rear parking sensors will bedeactivated automatically if a genuine CITROËN towbar is used.


Cooling

To w i ng a trailer on a slope increases the
temperature of the coolant.

As the fan is electrically controlled, its coolingcapacity is not dependent on the engine speed. )To lower the engine speed, reduce your speed.
The maximum towed load on a long incline
depends on the
gradient and the ambient
temperature.
In all cases, keep a check on the coolant
temperature.
)
If the warning lamp and the STOP
warning lamp come on,stop the vehicle and switch off
the engine as soon as possible.

12
Technical data
185
The GTW and towed load values indicated are valid up to a maximum altitude of 1 000 metres; the towed load mentioned must be reduced by 10 % for each additional 1 000 metres of altitude.
The speed of a towing vehicle must not exceed 60 mph (10 0 km/h) (comply with the legislation in force in your country).
High ambient temperatures may result in a reduction in the performance of the vehicle to protect the engine; if the ambient temperature is above 37 °C,
limit th
e towed load.

Petrol weights and towed loads (in kg)
EnginesVTi 68VTi 82e-VTi 82
GearboxesManualManualElectronicElectronic
Model codes:SC...ZMZ0HMZ0HMZ0/PHMZ0/PS



- Unladen weight 973
975
1 060
980



- Kerb wei
ght 1 048
1 0501 135 1 055


- Gross vehicle wei
ght (GV W)

1 500

1 511 1 515

1 540



-
Gross train weight (GTW)

on a 12 % gradient 1 950
2 3112 315 2 340



- Braked trailer
(within GTW limit) on a 12 % gradient
450
800
800800



- Braked trailer * (with load transfer within the
GTW limit) 7751 100 1 100

1 100



-
Unbraked trailer
450
520
520520



- Recommended nose weight
46

46

4646

* The weight of the braked trailer can be increased, within the GTW limit, if the GVW of the towing vehicle is reduced by an equal amount. Warning:
towing using a lightly loaded towing vehicle may have an adverse effect on its road holding.

Technical data
186
The GTW and towed load values indicated are valid up to a maximum altitude of 1 000 metres; the towed load mentioned must be reduced by 10 % for each additional 1 000 metres of altitude.
The speed of a towing vehicle must not exceed 60 mph (10 0 km/h) (comply with the legislation in force in your country).
High ambient temperatures may result in a reduction in the performance of the vehicle to protect the engine; if the ambient temperature is above 37 °C,
limit the towed load.

Petrol weights and towed loads (in kg)
Petrol enginesVTi 95VTi 120
GearboxesElectronicManualAutomatic
Model codes: SC...8FP0/P5FS05FS9



- Unladen weight 1 079
1 075
1 089



- Kerb weight 1 154 1 150
1 164


- Gross vehicle wei
ght (GV W)
1 581
1 5791 612


-
Gross train weight (GTW)
on a 12 % gradient2 481 2 479
2 512



- Braked trailer
(within the GTW limit)
on a 12 % gradient 900
900
900



- Braked trailer *
(with load transfer within the
GTW limit) 1 150
1 150
1 150



- Unbraked trailer
570570
570



- Recommended nose wei
ght
46

46
46
* The weight of the braked trailer can be increased, within the GTW limit, if the GVW of the towing vehicle is reduced by an equal amount. Warning:
towing using a lightly loaded towing vehicle may have an adverse effect on its road holding.

Technical data
188
The GTW and towed load values indicated are valid up to a maximum altitude of 1 000 metres; the towed load mentioned must be reduced by 10 % for each additional 1 000 metres of altitude.
The speed of a towing vehicle must not exceed 60 mph (10 0 km/h) (comply with the legislation in force in your country).
High ambient temperatures may result in a reduction in the performance of the vehicle to protect the engine; if the ambient temperature is above 37 °C,
limit the towed load.
LPG weights and towed loads (in kg)
Engines1.4 i
GearboxeManual
Model codes:SC...KFT0/GPLKFT0/1GPL



- Unladen weight1 070



- Kerb wei
ght
1 145


- Gross vehicle wei
ght (GV W)

1 529



-
Gross train weight (GTW)

on a 12 % slope 2 329



- Braked trailer (within GTW limit) on a 12 % slope
1 000



- Braked trailer *
(with load transfer within the
GTW limit)
1 000



-
Unbraked trailer
500



- Recommended nose wei
ght 44
* The weight of the braked trailer can be increased, within the GTW limit, if the GVW of the towing vehicle is reduced by an equal amount; warning,
towing using a lightly loaded towing vehicle may have an adverse effect on its road holding.
