11
Practical information
175
Fuse N°RatingFunctions
F
820 A Multifunction screen, audio system, navigation radio.
F
930 A Audio system (aftermarket), 12 V socket.
F1
015 A Steering wheel controls.
F1115 A
Ignition, diagnostic socket.
F12 15 A
Rain / sunshine sensor, trailer rela
y unit.
F1
35 A Main stop switch, engine relay unit.
F1415 A Parking assistance control unit, seat belt unfastened warninglamp, airbag control unit, instrument panel, air conditioning,USB Box.
F1
530 A Locking.
F1
6- Not used.
F1740 A
Rear screen and door mirrors demist/defrost.
S
H- PA RC shunt.

11
Practical information
177
Fuse table
Fuse N°RatingFunctions
F
120 AEngine control unit supply, cooling fan unit control,multifunction engine control main relay.
F
215 AHorn.
F
310 AFront / rear wash-wipe.
F4 20
ADaytime running lamps.
F
515 ADiesel heater (Diesel engine), fuel pump(petrol engine)
F
610 A ABS/ESP control unit, ABS/ESP cut-off relay,secondary stop switch.
F7
10 AElectric power steering.
F
825 AStarter motor control.
F9
10 ASwitching and protection unit (Diesel).
F10
30 ADiesel engine injection pump valve, injectors and ignition coils (petrol engine) .
F1140 A Air conditioning fan.

Practical information
178
Fuse N°RatingFunctions
F1230 A Windscreen wipers slow / fast speed.
F13
40 A Built-in systems inter face supply (ignition positive).
F14
30 A Valvetronic supply (petrol).
F1
510 A Right-hand main beam headlamp.
F1
610 A
Left-hand main beam headlamp.
F17 15 A
Left-hand dipped beam headlamp.
F18 15 A
Ri
ght-hand dipped beam headlamp.
F1
915 A Multifunction engine management supply (petrol engine),
air cooling electrovalves (Diesel).
F20 10 A Multi
function engine management supply (petrol engine),
Turbo pressure regulation electrovalve (Diesel), engine coolantlevel sensor (Diesel).
F2
15 A Fan assembly control supply, APC, ABS ESP relays.
