Citroen C3 PICASSO RHD 2014 1.G Owner's Manual

159
List of operations
F Put the wheel in place on the hub.
F S crew in the bolts by hand as far as
possible.
F

P
re-tighten the security bolt (if your vehicle
has them) using the wheelbrace 1 fitted
with the security socket 4 .
F

P
re-tighten the other bolts using the
wheelbrace 1 o n l y.
Fitting a wheel
After changing a wheel
To store the punctured wheel in the
boot correctly, first remove the central
c ove r.
When using the "space-saver" type
spare wheel, do not exceed 50 mph
(80
km/h).
Have the tightening of the bolts and the
pressure of the spare wheel checked
by a CITR
oËn

dealer or a qualified
workshop without delay.
Have the punctured wheel repaired and
replace it on the vehicle as soon as
possible.
11
Practical information

160
F Tighten the security bolt (if your vehicle has them) using the wheelbrace 1 fitted with
the security socket 4 .
F

T
ighten the other bolts using the
wheelbrace 1 o n l y.
F

R
efit the bolt covers on each of the bolts
(with alloy wheels only).
F

S
tore the tools in the box.
F
L
ower the vehicle fully.
F
F
old the jack 2 and detach it.
Practical information

161
Snow chains
original tyre sizeMaximum link size.
195 / 60 R15 9 mm
195 / 55 R16 9 mm
205 / 45 R17 7 mm
For more information on snow chains,
contact a CITR
oËn

dealer or a
qualified workshop.
In wintry conditions, snow chains improve traction as well as the behaviour of the vehicle when
braking.
The snow chains must be fitted only
to the front wheels. They must never
be fitted to "space-saver" type spare
wheels.
Take account of the legislation in force
in your country on the use of snow
chains and the maximum running speed
authorised.
Advice on installation
F If you have to fit the chains during a journey, stop the vehicle on a flat sur face
on the side of the road.
F
a
p
ply the parking brake and position any
wheel chocks to prevent movement of your
vehicle.
F

F
it the chains following the instructions
provided by the manufacturer.
F

M
ove off gently and drive for a few
moments, without exceeding 30 mph
(50
km/h).
F

S
top your vehicle and check that the snow
chains are correctly tightened.
Avoid driving with snow chains on roads
that have been cleared of snow, to
avoid damaging your vehicle's tyres and
the road sur face. If your vehicle is fitted
with alloy wheels, check that no part of
the chain or its fixings is in contact with
the wheel rim.
All original tyre sizes (15", 16", 17") can be
fitted with chains.
Use only the chains designed to be fitted to the
type of wheel fitted to your vehicle:
It is strongly recommended that before
you leave, you practise fitting the snow
chains on a level and dry sur face.
11
Practical information

162
Changing a bulbProcedure for replacing a faulty bulb with a new bulb.1.
D
irection indicators (H21W amber).
2.
D

ipped beam headlamps (H7-55W).
3.
M

ain beam headlamps (H1-55W).
4.
S

idelamps (W5W).
5.
F

oglamps (PSX24W).
6.
L

ED daytime running lamps.
Front lampsThe headlamps are fitted with
polycarbonate glass with a protective
coating:
F
d
o not clean them using a dr y
or abrasive cloth, nor with a
detergent or solvent product,
F

u
se a sponge and soapy water or a
pH neutral product,
F

w
hen using a high pressure washer
on persistent marks, do not keep
the lance directed towards the
lamps or their edges for too long,
so as not to damage their protective
coating and seals. Changing a bulb should only be done
after the headlamp has been switched
off for several minutes (risk of serious
burns).
F

D
o not touch the bulb directly with
your fingers, use a lint-free cloth.
It is imperative to use only anti-
ultraviolet (UV) type bulbs to avoid
damaging the headlamp.
Always replace a failed bulb with a
new bulb with the same type and
specification.
Practical information

163
Changing direction indicator
bulbs
F Remove the plastic protective cover.
F P ull the bulb-holder and replace the bulb.
To refit, carry out these operations in reverse
o r d e r.
Changing dipped headlamp
bulbs
F Remove the protective plastic cover by pulling on the tab.
F

T
urn the bulb-holder by a quarter turn.
F

R
emove the bulb and change it.
To refit, carry out these operations in reverse
o r d e r.
If either of the direction indicator
warning lamps is flashing quickly, one
of the bulbs is faulty.
When refitting, close the plastic cover
carefully to ensure the sealing of the
headlamp.am
ber coloured bulbs, such as the
direction indicators, must be replaced
with bulbs of identical specifications
and colour.
11
Practical information

164
Changing main beam headlamp bulbs
F Remove the protective plastic cover by pulling on the tab.
F
d
i
sconnect the bulb connector.
F

M
ove the springs to release the bulb.
F

R
emove the bulb and change it.
To refit, carry out these operations in reverse
o r d e r.
Changing sidelamp bulbs
F Remove the protective plastic cover by pulling on the tab.
F

P
ull the bulb-holder.
F

R
emove the bulb and replace it.
To refit, carry out these operations in reverse
o r d e r.
Practical information

165
Changing front foglamp bulbs
F Remove the grille located under the foglamp.
If you experience any difficulty in
replacing bulbs, contact your CITR
oËn


dealer or a qualified workshop.
F

T
hrough the cover, remove the lamp
finisher by pulling it towards you. F

U
nscrew the two fixing screws of the
module and remove it from its housing.
F
d
i
sconnect the bulb holder connector.
F

R
emove the bulb and change it.
To refit, carry out these operations in reverse
o r d e r.
11
Practical information

166
Changing the LED lamps
For the replacement of this type of LEd lamp,
contact a CITRoËn dealer or a qualified
workshop.
Changing integral direction
indicator side repeaters
To obtain a new module, contact
a CITRoËn dealer or a qualified
workshop. If you experience any difficulty in
replacing these lamps, you can contact
a CITR
oËn

dealer or a qualified
workshop.
While removing the module:
-

t
ake care not to damage your vehicle's
paintwork with the screwdriver,
-
d
o not allow the wiring and connector to
slip behind the wing.
To refit, carry out these operations in reverse
o r d e r.
F

I

nsert a screwdriver in the edge of the
repeater.
F

L

ever with the screwdriver to extract the
repeater and pull it out.
F

D

isconnect the wiring from the repeater.
F

R

eplace the module.
Practical information

167
Rear lamps
1. Brake lamps / sidelamps (12VP21/5W).
2. Foglamp, right-hand side (PR21W)
R

eversing lamp, left-hand side (P21W).
3.
D

irection indicators (P21W)Changing brake lamp / sidelamp
and direction indicator bulbs
F turn the bulb holder a quarter turn,
F r emove the failed bulb and replace it.
To refit, carry out these operations in reverse
o r d e r.
F
u
nscrew the two lamp fixing bolts,
F
e
xtract the lamp carefully pulling it straight
out,
11
Practical information

168
Changing foglamp / reversing
lamp bulbs
F open the boot,
F p ress on the tabs using 2 screwdrivers,
F

d
isconnect the lamp connector,
F

t
urn the bulb holder by a quarter turn,
F

r
emove the bulb and replace it.
To refit, carry out these operations in reverse
o r d e r.
Changing the third brake lamp
bulbs (4 W5W bulbs)
F open the boot,
F r emove the two plugs located on the boot
inner panel,
F

p
ress on the body of the lamp with 2
screwdrivers to remove it from its housing,
F

t
urn the corresponding bulb-holder a
quarter turn,
F

p
ull the bulb out and replace it.
To refit, carry out these operations in reverse
o r d e r.
Changing the number plate lamp
bulbs (W5W)
F insert a thin screwdriver into one of the lens' exterior holes,
F

p
ush it outwards to unclip.
F

r
emove the lens.
F

p
ull the bulb out and replace it.
To refit, carry out these operations in reverse
o r d e r.
