Page 36 of 279
49
III
C O M F O R T
FRONT SEATS
MANUAL ADJUSTMENTS
1 . F o r w a r d s - b a c k w a r d s
Raise the control bar, then slide the
seat to the position desired.
2 . L u m b a r s u p p o r t
Rotate the control until you attain
the position desired. 3 . D r i v e r ' s s e a t h e i g h t
adjustment
Raise or lower the the control the
number of times necessary to obtain
the position desired. 4 . B a c k r e s t a n g l e
Operate the control and adjust the
angle of the backrest.
It is possible to incline the back-
rest 45° rearwards by tilting it until it
locks; to unlock it, lift the control.
5 . A c c e s s t o t h e r e a r s e a t s
To gain access to or exit from the
rear seats, tilt the control forwards to
fold the backrest and move the seat
forward.
When repositioning, the seat returns
to its initial position.
Ensure that the seat is locked securely.
Never drive without the head re-
s t r a i n t s fi t t e d . T h e y m u s t b e i n p l a c e
and adjusted correctly.
6. Head restraint
To raise it, pull it upwards. To lower
it, press on the control as well as on
the head restraint.
The adjustment is correct when the
top of the head restraint is level with
the top of the head.
It can also be adjusted for tilt.
To remove it, press on the unlocking
button and pull it upwards.
To adjust the head restraint forwards/
backwards, move the base of the
head restraint to obtain the position
desired.
Page 38 of 279
51
III
C O M F O R T
S t o r i n g d r i v i n g p o s i t i o n s
System which takes into account the
electrical settings of the driver's seat
and exterior mirrors. It enables you to
store up to two positions using the but-
tons on the side of the driver's seat. S t o r i n g a p o s i t i o n
Using buttons M/1/2
Switch on the ignition.
Adjust your seat and the exterior
mirrors.
Press button M , then press button 1
or 2 within four seconds.
An audible signal is heard indicating
that the position has been stored.
Storing a new position cancels the
previous position. R e c a l l i n g a s t o r e d p o s i t i o n
Ignition on or engine running
B r i e fl y p r e s s b u t t o n 1 or 2 to re-
call the corresponding position.
An audible signal is heard indicating
the end of the adjustment.
When the ignition is on, after a few
consecutive position recalls, the
function will be deactivated until the
engine is started, to prevent dis-
charging of the battery.
V e h i c l e m o v i n g
Press and hold button 1 or 2 until
the audible signal is heard indi-
cating the end of the adjustment.
Do not try to store a driving position
while driving.
Page 76 of 279
83
VI
F I T T I N G S
Oddments tray on front
central console
Grab handles/Coat hooks
MATS
Removable component which pro-
t e c t s t h e c a r p e t a g a i n s t e x t e r i o r d i r t .
Fitting
W h e n fi t t i n g t h e m a t f o r t h e fi r s t t i m e ,
o n t h e d r i v e r ' s s i d e , u s e o n l y t h e fi x -
ings provided in the wallet attached.
The other mats are simply placed on
the carpet.
Removal
T o r e m o v e t h e m a t o n t h e d r i v e r ' s s i d e :
m o v e t h e s e a t a s f a r b a c k a s p o s s i b l e ,
u n c l i p t h e fi x i n g s ,
remove the mat. Refitting
T o r e fi t t h e m a t o n t h e d r i v e r ' s s i d e :
p o s i t i o n t h e m a t c o r r e c t l y ,
r e fi t t h e fi x i n g s b y p r e s s i n g ,
check that the mat is secured
correctly.
To avoid any risk of jamming of the
p e d a l s :
- only use mats which are suited t o t h e fi x i n g s a l r e a d y p r e s e n t i n
t h e v e h i c l e ; i t i s i m p e r a t i v e t h a t
t h e s e a r e u s e d ,
- n e v e r fi t o n e m a t o n t o p o f a n - other.
Page 77 of 279
84
VI
F I T T I N G S
REAR ARMREST
Comfort and storage device for the
rear passengers.
Lower the rear armrest for a
more comfortable position.
Raise the cover to gain access
to its storage compartment.
T h i s h a s a s t o r a g e t r a y , t w o c a n
holders and two pen holders.
LUGGAGE SECURING RINGS
U s e t h e 2 r e a r s i d e fi x i n g s a n d t h e
6 s e c u r i n g r i n g s o n t h e b o o t fl o o r
and the back of the rear bench
seat to secure your luggage.
For safety reasons in the event of
s h a r p b r a k i n g , y o u a r e a d v i s e d t o
p l a c e h e a v y o b j e c t s o n t h e fl o o r a s
close as possible to the back of the
bench seat.
Hooked onto the stowing rings by
m e a n s o f r e a r s i d e fi x i n g s , t h i s e n a -
bles you to secure your luggage.
Luggage retaining net
Page 82 of 279
83
VI
F I T T I N G S
Oddments tray on front
central console
Grab handles/Coat hooks
MATS
Removable component which pro-
t e c t s t h e c a r p e t a g a i n s t e x t e r i o r d i r t .
Fitting
W h e n fi t t i n g t h e m a t f o r t h e fi r s t t i m e ,
o n t h e d r i v e r ' s s i d e , u s e o n l y t h e fi x -
ings provided in the wallet attached.
The other mats are simply placed on
the carpet.
Removal
T o r e m o v e t h e m a t o n t h e d r i v e r ' s s i d e :
m o v e t h e s e a t a s f a r b a c k a s p o s s i b l e ,
u n c l i p t h e fi x i n g s ,
remove the mat. Refitting
T o r e fi t t h e m a t o n t h e d r i v e r ' s s i d e :
p o s i t i o n t h e m a t c o r r e c t l y ,
r e fi t t h e fi x i n g s b y p r e s s i n g ,
check that the mat is secured
correctly.
To avoid any risk of jamming of the
p e d a l s :
- only use mats which are suited t o t h e fi x i n g s a l r e a d y p r e s e n t i n
t h e v e h i c l e ; i t i s i m p e r a t i v e t h a t
t h e s e a r e u s e d ,
- n e v e r fi t o n e m a t o n t o p o f a n - other.
Page 83 of 279
83
VI
F I T T I N G S
Oddments tray on front
central console
Grab handles/Coat hooks
MATS
Removable component which pro-
t e c t s t h e c a r p e t a g a i n s t e x t e r i o r d i r t .
Fitting
W h e n fi t t i n g t h e m a t f o r t h e fi r s t t i m e ,
o n t h e d r i v e r ' s s i d e , u s e o n l y t h e fi x -
ings provided in the wallet attached.
The other mats are simply placed on
the carpet.
Removal
T o r e m o v e t h e m a t o n t h e d r i v e r ' s s i d e :
m o v e t h e s e a t a s f a r b a c k a s p o s s i b l e ,
u n c l i p t h e fi x i n g s ,
remove the mat. Refitting
T o r e fi t t h e m a t o n t h e d r i v e r ' s s i d e :
p o s i t i o n t h e m a t c o r r e c t l y ,
r e fi t t h e fi x i n g s b y p r e s s i n g ,
check that the mat is secured
correctly.
To avoid any risk of jamming of the
p e d a l s :
- only use mats which are suited t o t h e fi x i n g s a l r e a d y p r e s e n t i n
t h e v e h i c l e ; i t i s i m p e r a t i v e t h a t
t h e s e a r e u s e d ,
- n e v e r fi t o n e m a t o n t o p o f a n - other.
Page 84 of 279
84
VI
F I T T I N G S
REAR ARMREST
Comfort and storage device for the
rear passengers.
Lower the rear armrest for a
more comfortable position.
Raise the cover to gain access
to its storage compartment.
T h i s h a s a s t o r a g e t r a y , t w o c a n
holders and two pen holders.
LUGGAGE SECURING RINGS
U s e t h e 2 r e a r s i d e fi x i n g s a n d t h e
6 s e c u r i n g r i n g s o n t h e b o o t fl o o r
and the back of the rear bench
seat to secure your luggage.
For safety reasons in the event of
s h a r p b r a k i n g , y o u a r e a d v i s e d t o
p l a c e h e a v y o b j e c t s o n t h e fl o o r a s
close as possible to the back of the
bench seat.
Hooked onto the stowing rings by
m e a n s o f r e a r s i d e fi x i n g s , t h i s e n a -
bles you to secure your luggage.
Luggage retaining net
Page 85 of 279
84
VI
F I T T I N G S
REAR ARMREST
Comfort and storage device for the
rear passengers.
Lower the rear armrest for a
more comfortable position.
Raise the cover to gain access
to its storage compartment.
T h i s h a s a s t o r a g e t r a y , t w o c a n
holders and two pen holders.
LUGGAGE SECURING RINGS
U s e t h e 2 r e a r s i d e fi x i n g s a n d t h e
6 s e c u r i n g r i n g s o n t h e b o o t fl o o r
and the back of the rear bench
seat to secure your luggage.
For safety reasons in the event of
s h a r p b r a k i n g , y o u a r e a d v i s e d t o
p l a c e h e a v y o b j e c t s o n t h e fl o o r a s
close as possible to the back of the
bench seat.
Hooked onto the stowing rings by
m e a n s o f r e a r s i d e fi x i n g s , t h i s e n a -
bles you to secure your luggage.
Luggage retaining net
Page 90 of 279
88
C H I L D S A F E T Y
Passenger air bag OFF
CHILD SEATS RECOMMENDED BY CITROËN
C I T R O Ë N o f f e r s a c o m p l e t e r a n g e o f r e c o m m e n d e d c h i l d s e a t s w h i c h a r e
secured using a three point seat belt :
Group 0: from birth to 10 kg
Group 0+: from birth to 13 kg
Groups 1, 2 and 3: from 9 to 36 kg
L1
" R Ö M E R
B a b y - S a f e P l u s "
Installed in the
r e a r w a r d s - f a c i n g p o s i t i o n .
L2
"KIDDY Life"
The use of the
restraining cushion i s c o m p u l s o r y f o r
the transportation o f y o u n g c h i l d r e n ( f r o m 9 t o 1 8 k g ) .
Groups 2 and 3: from 15 to 36 kg
L3
" R E C A R O S t a r t ' '
L4
" K L I P P A N O p t i m a " F r o m t h e a g e o f 6 y e a r s
( a p p r o x i m a t e l y
2 2 k g ) , t h e b o o s t e r i s u s e d o n i t s o w n .
Page 91 of 279
88
C H I L D S A F E T Y
Passenger air bag OFF
CHILD SEATS RECOMMENDED BY CITROËN
C I T R O Ë N o f f e r s a c o m p l e t e r a n g e o f r e c o m m e n d e d c h i l d s e a t s w h i c h a r e
secured using a three point seat belt :
Group 0: from birth to 10 kg
Group 0+: from birth to 13 kg
Groups 1, 2 and 3: from 9 to 36 kg
L1
" R Ö M E R
B a b y - S a f e P l u s "
Installed in the
r e a r w a r d s - f a c i n g p o s i t i o n .
L2
"KIDDY Life"
The use of the
restraining cushion i s c o m p u l s o r y f o r
the transportation o f y o u n g c h i l d r e n ( f r o m 9 t o 1 8 k g ) .
Groups 2 and 3: from 15 to 36 kg
L3
" R E C A R O S t a r t ' '
L4
" K L I P P A N O p t i m a " F r o m t h e a g e o f 6 y e a r s
( a p p r o x i m a t e l y
2 2 k g ) , t h e b o o s t e r i s u s e d o n i t s o w n .
