Page 152 of 279
147
XI
P R A C T I C A L I N F O R M A T I O N
CHANGING A FUSE
P r o c e d u r e f o r r e p l a c i n g a f a u l t y f u s e
w i t h a n e w f u s e t o r e c t i f y a f a i l u r e o f
t h e c o r r e s p o n d i n g f u n c t i o n .
There are two fuseboxes under the
dashboard, one fusebox in the en-
gine compartment and another on
t h e b a t t e r y .
Changing a fuse
Before replacing a fuse, it is essen-
t i a l t o fi n d t h e c a u s e o f t h e i n c i d e n t
a n d t o h a v e i t r e c t i fi e d . T h e f u s e
i d e n t i fi c a t i o n n u m b e r s a r e i n d i c a t e d
i n s i d e t h e f u s e b o x .
Replace a blown fuse with one of the
s a m e r a t i n g ( t h e s a m e c o l o u r ) . Use the special tool
A that is pro-
v i d e d i n t h e f u s e h o u s i n g fl a p , w h i c h
a l s o c o n t a i n s s p a r e f u s e s .
Correct Incorrect
Tool A
A c c e s s t o t h e fi r s t d a s h b o a r d
fusebox
Fuses under the dashboard
Your vehicle’s electrical
s y s t e m i s d e s i g n e d t o o p e r -
ate with either standard or
o p t i o n a l e q u i p m e n t .
Before installing electrical equipment
o r a c c e s s o r i e s o n y o u r v e h i c l e , c o n -
s u l t a C I T R O Ë N d e a l e r .
CITROËN declines all responsibil-
i t y f o r t h e c o n s e q u e n c e s a n d c o s t s
t h a t a r e c a u s e d b y f a u l t s o r r e p a i r s
o n y o u r v e h i c l e r e s u l t i n g f r o m t h e
installation of accessories that
are not supplied and/or not rec-
o m m e n d e d b y C I T R O Ë N a n d n o t
installed according to its instruc-
t i o n s , p a r t i c u l a r l y w h e n t h e e n e r g y
consumption of all of the additional
accessories connected exceeds
1 0 m i l l i a m p e r e s ( M a ) .
Page 153 of 279
148
XI
P R A C T I C A L I N F O R M A T I O N
Fuses under the dashboard Access to the fuses
O p e n t h e g l o v e b o x .
U n d o t h e s c r e w b y a q u a r t e r t u r n
a n d p i v o t t h e h o u s i n g .
Table of fuses
Fuse N° Rating
Functions
F1 15 A Rear screen wipe
F2 30 A C e n t r a l l o c k i n g - D e a d l o c k i n g
F3 5 A Airbags and pretensioners
F4 10 A D i a g n o s t i c s o c k e t - B r a k e s w i t c h - P h o t o c h r o m i c r e a r v i e w m i r r o r - E S P - C o o l
a n t l e v e l
s e n s o r - D i e s e l a d d i t i v e - C l u t c h p e d a l s w i t c h ( E S P , c r u i s e c o n t r o l a n d s p e e d l i m i t e r )
F5 30 A Front windows, Heated exterior rear view mirrors
F6 30 A Rear windows
F7 5 A Interior lighting
F8 20 A M u l t i f u n c t i o n s c r e e n , r a d i o , s t e e r i n g w h e e l c o n t r o
l s , D i s p l a y s - A l a r m - F r o n t 1 2 V s o c k e t -
T r a i l e r u n i t - D r i v i n g s c h o o l m o d u l e
F9 30 A Lighter - Rear 12 V socket
F10 15 A D e fl a t i o n d e t e c t i o n - A u t o m a t i c g e a r b o x - S T O P s w i t c h
F11 15 A I g n i t i o n s w i t c h - D i a g n o s t i c s o c k e t - P a r t i c l e fi l t e r
F12 15 A E l e c t r i c s e a t - L a n e d e p a r t u r e w a r n i n g s y s t e m - P a r k i n g a s s i s t a n c e
F13 5 A R a i n s e n s o r - B r i g h t n e s s s e n s o r - E l e c t r o n i c g e a r b o x s y s t e m ( 6 - s p e e d ) - E n g i n e r e l a y u n i t
F14 15 A Air conditioning - Instrument panel - Rev counter - Airbags and p
retensioners - Trailer unit -
Bluetooth ®
telephone
F15 30 A C e n t r a l l o c k i n g - D e a d l o c k i n g
F16 - SHUNT
F17 40 A Heated rear screen
Page 154 of 279
149
XI
P R A C T I C A L I N F O R M A T I O N Fuses in the engine
compartment Access to the fuses
D e t a c h a n d r e m o v e t h e c o v e r .
Access to the second dashboard
fusebox
After any operation on the fuses
in the fusebox, check that the
fusebox cover is put back cor-
rectly for their protection. Table of fuses
Fuse N° Rating Functions
F36 30 A H i - F i a m p l i fi e r
F37 30 A D r i v e r ’ s e l e c t r i c s e a t
F39 20 A Heated seats
A f t e r a n y o p e r a t i o n , c a r e f u l l y r e fi t
the cover. If the cover is not cor-
rectly positioned or not properly
closed, this could cause serious
problems on your vehicle. For
the same reason, take care not to
spill any liquid in the fusebox. All work on the maxi-fuses,
which are located in these
fuseboxes and which give
extra protection, must be carried
o u t b y C I T R O Ë N t e c h n i c i a n s .
Page 155 of 279
149
XI
P R A C T I C A L I N F O R M A T I O N Fuses in the engine
compartment Access to the fuses
D e t a c h a n d r e m o v e t h e c o v e r .
Access to the second dashboard
fusebox
After any operation on the fuses
in the fusebox, check that the
fusebox cover is put back cor-
rectly for their protection. Table of fuses
Fuse N° Rating Functions
F36 30 A H i - F i a m p l i fi e r
F37 30 A D r i v e r ’ s e l e c t r i c s e a t
F39 20 A Heated seats
A f t e r a n y o p e r a t i o n , c a r e f u l l y r e fi t
the cover. If the cover is not cor-
rectly positioned or not properly
closed, this could cause serious
problems on your vehicle. For
the same reason, take care not to
spill any liquid in the fusebox. All work on the maxi-fuses,
which are located in these
fuseboxes and which give
extra protection, must be carried
o u t b y C I T R O Ë N t e c h n i c i a n s .
Page 165 of 279
158
XI
P R A C T I C A L I N F O R M A T I O N
Radio option
See the separate instruction booklet
i n t h e v e h i c l e d o c u m e n t p a c k . Fitting of front and rear
loudspeakers
C o n s u l t a C I T R O Ë N d e a l e r . On the dashboard
Two tweeters located at each end of
the dashboard:
detach and pull off the grille,
connect the tweeters,
fi t t h e m o n t h e g r i l l e , r o t a t i n g
them a quarter turn,
r e fi t t h e g r i l l e s .
RADIO PRE-EQUIPMENT
Radio connections
C o n s u l t a C I T R O Ë N d e a l e r .
