Page 30 of 332
1
MONITORING
28
TWO-TONE INSTRUMENT PANEL WITHOUT AUDIO SYSTEM
Dials and screens
1.
Rev counter (x 1 000 rpm or tr/min).
2.
Gear shift indicator with manual
gearbox or gear lever position and
gear for the electronic gearbox sys-
tem or automatic gearbox.
3.
Cruise control or speed limiter setting.
4.
Digital speedometer (mph or km/h).
5.
Engine oil level indicator.
6.
Service indicator
(miles or km) then,
total mileage recorder.
These two functions are displayed
successively on switching on the
ignition.
Lighting dimmer setting (when making
an adjustment).
7.
Trip mileage recorder (miles or km).
8.
Fuel gauge and associated low fuel
level warning lamp ( a
or b
accord-
ing to version).
9.
Time.
Control buttons
A.
Lighting dimmer (available in night
mode).
B.
Reminder of servicing information
Reset service indicator or trip mile-
age recorder.
A
and B.
Setting the time and selecting
units.
Page 31 of 332
1
MONITORING
29
TWO-TONE INSTRUMENT PANEL WITH AUDIO SYSTEM
Dials and screens
A.
Lighting dimmer (available in night
mode).
B.
Reminder of the servicing information.
Reset the service indicator or the
trip mileage recorder.
7.
Service indicator
(miles or km) then,
total mileage recorder.
These two functions are displayed
successively on switching on the
ignition.
Lighting dimmer setting (when making
an adjustment).
8.
Trip mileage recorder (miles or km).
9.
Fuel gauge and associated low fuel
level warning lamp ( a
or b
accord-
ing to version).
10.
Range (miles or km).
Control buttons
1.
Rev counter (x 1 000 rpm or tr/min).
2.
Gear shift indicator for manual gear-
box or gear lever position and gear
for the electronic gearbox system or
automatic gearbox.
3.
Analogue speedometer (mph or km/h).
4.
Cruise control or speed limiter setting.
5.
Digital speedometer (mph or km/h).
6.
Engine oil level indicator.
Page 32 of 332
1
MONITORING
30
CUSTOMISABLE COLOUR INSTRUMENT PANEL WITH AUDIO SYSTEM
1.
Rev counter (x 1 000 rpm or tr/min).
2.
Gear shift indicator with manual
gearbox or gear lever position and
gear for the electronic gearbox sys-
tem or automatic gearbox.
3.
Analogue speedometer (mph or km/h).
4.
Cruise control or speed limiter setting.
5.
Digital speedometer (mph or km/h).
A.
Dial COLOUR: customisation of the
background colour of the dials.
B.
Screen COLOUR: customisation of
the background colour of the screens.
C.
Lighting dimmer (available in night
mode).
D.
Reminder of the servicing information.
Reset the service indicator or the
trip mileage recorder.
Dials and screens
6.
Engine oil level indicator.
7.
Service indicator
(miles or km) then,
total mileage recorder.
These two functions are displayed
successively on switching on the
ignition.
Lighting dimmer setting (when making
an adjustment).
8.
Trip mileage recorder (miles or km).
9.
Fuel gauge and associated low fuel
level warning lamp.
10.
Range (miles or km).
Control buttons
Page 33 of 332
1
MONITORING
31
CUSTOMISABLE COLOUR INSTRUMENT PANEL ASSOCIATED WITH THE SATELLITE NAVIGATION
SYSTEM
1.
Rev counter (x 1 000 rpm or tr/min).
2.
Gear shift indicator with manual
gearbox or gear lever position and
gear for the electronic gearbox sys-
tem or automatic gearbox.
3.
Speedometer (mph or km/h).
Dials and screens
4.
Central screen associated with the
satellite navigation system.
5.
Fuel gauge and associated low fuel
level warning lamp.
6.
Trip mileage recorder (miles or km).
7.
Service spanner (if a service is due
or missed),
total mileage recorder.
(miles or km)
A.
Dial COLOUR: customisation of the
background colour of the dials.
B.
Screen COLOUR: customisation
of the background colour of the
screens.
C.
Dashboard lighting dimmer (in night
mode).
D.
Start a manual test (procedure for
checking the status of systems and
display of vehicle alerts).
Reset service indicator or trip mileage
recorder.
Control buttons
Page 47 of 332
1
MONITORING
45
Service indicator
This information is displayed for a few
seconds after switching on the igni-
tion. It informs the driver when the next
service is due, in accordance with the
manufacturer's servicing schedule.
The point at which the service is due is
calculated from the last service indica-
tor zero reset. It is determined by two
parameters:
- the distance travelled,
- the time elapsed since the last service.
More than 1 800 miles (3 000 km)
remain before the next service is due
When the ignition is switched on, no
service information appears in the in-
strument panel central screen.
Between 600 miles (1 000 km) and
1 800 miles (3 000 km) remain
before the next service is due
For a few seconds after the ignition is
switched on, the spanner symbolising
the service operations comes on. The
distance recorder display line or a spe-
cifi c message in the instrument panel
central screen indicates the distance re-
maining before the next service is due.
For example:
1 700 miles (2 800 km)
remain before the next service is due.
For a few seconds after the ignition is
switched on, the screen indicates:
Less than 600 miles (1 000 km) remain
before the next service is due
Example:
560 miles (900 km) remain
before the next service is due.
For a few seconds after the ignition is
switched on, the screen indicates:
A few seconds after the ignition is
switched on, the spanner goes off
; the
distance recorder resumes its normal
operation. The screen then indicates
the total and trip distances. A few seconds after the ignition is
switched on, the distance recorder
resumes its normal operation. The
spanner remains on
to indicate that a
service must be carried out soon.
Page 48 of 332
1
MONITORING
46
Service overdue
For a few seconds after the ignition is
switched on, the spanner fl ashes
to
indicate that the service must be car-
ried out as soon as possible.
Example:
the service is overdue by
180 miles (300 km).
For a few seconds after the ignition is
switched on, the screen indicates:
A few seconds after the ignition is
switched on, the distance recorder re-
sumes its normal operation. The span-
ner remains on
.
The distance remaining may be
weighted by the time factor, de-
pending on the type of driving.
Therefore, the spanner may also
come on if you have exceeded
the two year service interval.
Service indicator zero reset
This operation cannot be carried
out while a reminder of the ser-
vicing information is being dis-
played.
Following this operation, if you
wish to disconnect the battery,
lock the vehicle and wait at least
fi ve minutes for the zero reset to
be registered.
Recalling the service information
You can recall the service information
at any time.
)
Briefl y press the ".../000"
trip dis-
tance recorder zero reset button.
The service information is displayed
for a few seconds, in the total dis-
tance recorder line or in the instru-
ment panel central screen associated
with the satellite navigation system.
After each service, the service indicator
must be reset to zero.
The procedure for resetting to zero is
as follows:
)
switch off the ignition,
)
press and hold the ".../000"
trip dis-
tance recorder zero reset button,
)
switch on the ignition; the distance re-
corder display begins a countdown,
)
when the screen indicates "=/0"
and
the spanner disappears, release the
button.
Page 50 of 332
1
MONITORING
48
Distance recorders
The total and trip distances are dis-
played for thirty seconds when the ig-
nition is switched off, when the driver's
door is opened and when the vehicle is
locked or unlocked.
Trip distance recorder
Total distance recorder
Setting the time and the time
format in the instrument panel
without audio system
On the two-tone instrument panel with-
out audio system, to adjust the time,
use buttons A
and B
then carry out the
operations in the following order:
)
press buttons A
and B
simultane-
ously: the minutes fl ash,
)
press A
to increase the minutes or
B
to reduce the minutes,
)
press buttons A
and B
simultane-
ously: the hours fl ash,
)
press A
to increase the hours or B
to reduce the hours,
)
press buttons A
and B
simultane-
ously: 24 H or 12 H is displayed and
fl ashes,
)
press button A
or B
to change the
format,
)
press buttons A
and B
simultane-
ously to exit from time setting.
After approximately 30 seconds without any ac-
tion, the screen returns to the normal display.
Measures the total distance travelled by
the vehicle since its fi rst registration.
Measures a distance travelled since it
was reset to zero by the driver.
)
With the ignition on, press and hold
this button until zeros appear.
On the two-tone instrument panel with-
out audio system, to change the display
units, use buttons A
and B
then carry out
the operations in the following order:
)
press buttons A
and B
simultane-
ously for three seconds: km/h or
mph fl ashes,
)
press button A
or B
to change the
units,
)
press buttons A
and B
simultane-
ously to exit from setting units.
After approximately 30 seconds without
any action, the screen returns to the
normal display
Setting units in the instrument
panel without audio system
Setting the time and units in the
multifunction screen
The other instrument panels are associated
with an audio system and a multifunction
screen. Refer to the corresponding section
in "Audio and Telematics".
Page 82 of 332
4
ACCESS
80
REMOTE CONTROL KEY
System which permits central unlocking
or locking of the vehicle using the door
lock or from a distance. It is also used
to locate and start the vehicle, as well
as providing protection against theft.
)
Press the open padlock
once to unlock the driver's
door only.
)
Press the open padlock again to un-
lock the other doors and the boot.
Selective unlocking using the
remote control
)
Turn the key towards the front in the
driver's door lock to unlock the ve-
hicle completely.
Complete unlocking using the
remote control
)
Press the open padlock
to unlock the vehicle com-
pletely.
Opening the vehicle using the
2-button remote control
Unfolding the key
)
Press this button to unfold the key.
Unlocking using the key
Unlocking is confi rmed by rapid fl ash-
ing of the direction indicators for ap-
proximately two seconds.
According to the version of your vehi-
cle, the door mirrors unfold at the same
time.
In low light, the unlocking also brings on
the exterior and interior welcome light-
ing (see the "Visibility section).
Programming unlocking
Setting the total or selective un-
locking is done via the vehicle
confi guration menu.
Complete unlocking is activated by
default.
Page 181 of 332
10
CHECKS
179
TOTAL & CITROËN
Partners in performance and
protecting the environment
Innovation in the search for
performance
For over 40 year, the TOTAL Research and
Development departments have developed
for CITROËN, lubricants to match the latest
technical innovations on CITROËN vehi-
cles, both for competition and for everyday
motoring.
For you, this is an assurance that you will
obtain of the best performance for your en-
gine.
Optimum protection for your
engine
By having your CITROËN ve-
hicle serviced with TOTAL lu-
bricants, you are contributing
towards improving the life and
performances of your engine,
while also protecting the envi-
ronment.
prefers
Page 326 of 332
324
ALPHABETICAL INDEX
S Screen menu map ...... 274, 310-312
Screenwash, front ......................109
Seat, rear bench ...........................76
Seat adjustment .....................71, 72
Seat belts ............................140-142
Seats, electric ...............................72
Seats, rear ....................................76
Serial number, vehicle ................228
Service indicator .....................45, 47
Servicing ......................................26
Setting the clock ...................48, 273
Short-cut menus .........................236
Sidelamps ....99, 102, 197, 199, 201
Side repeater ..............................200
Ski fl ap .......................................121
Spare wheel ...............................193
Speakers (fi tting) ........................214
Speed limiter ......................170, 171
Speedometer ...........................28-31
Spotlamps, side ..................104, 200
Starting the vehicle .......83, 156, 159
Steering mounted
controls .............................234, 285
Stopping the vehicle .....83, 156, 159
Stop & Start ............... 62, 68, 70, 96,
163, 180, 186, 207, 309
Storage .........113, 114, 116-118, 122
Storage compartments ............... 116
Storage drawer ...........................120
Storage net .................................122
Storing driving positions ...............75
Stowing rings ..............................122
Sun visor .................................... 114
Synchronising the remote
control ..................................84, 85
Synthesiser, voice ......................248
System, navigation .....................238T Table of weights .........217, 221, 223
Tables of engines .......217, 221, 223
Tables of fuses ...........................203
Tank, fuel ......................................98
Technical data ............217, 221, 223
Telephone ...................254, 258, 299
Temperature control
for heated seats .........................73
Temporary tyre repair kit ............188
Ticket holder ............................... 113
Time ...........................................308
TMC (Traffi c info) .......................251
Tools ...........................................193
Torch ..........................................124
Total distance recorder .................48
Towbar ........................................213
Towed loads ...............217, 221, 223
Towing another vehicle ............... 211
Traction control (ASR) ................138
Traffi c information
(TA) ..........................252, 265, 288
Traffi c information
(TMC) ...............................251, 252
Trajectory control systems .........138
Trip computer ..........................59-62
Trip distance recorder ..................48
Tyre pressures ...........................228
Tyres ............................................26
Tyre under-infl ation
detection .............................47, 136
U Under-infl ation (detection) ..........136
Under fl oor storage ....................124
Unlocking from the inside .............87
Unlocking the boot ...........80, 81, 92
Unlocking the doors ...............80, 81
Update risk areas .......................242U Updating the date .......................273
Updating the time .................48, 273
USB Box ..................................... 115
V Vehicle
confi guration .............51, 53, 56, 57
Ventilation ................................63-65
W Warning lamps ...........33, 35, 41, 47
Wash-wipe, rear ......................... 110
Weights ......................217, 221, 223
Welcome lighting ........................104
Window controls ...........................93
Wiper, rear .................................. 110
Wiper control stalk ............... 108-110
Wipers ..........................42, 108, 109
X Xenon headlamps ......................197
