Practical information

Engine compartment fuses


Access to the fuses
)Unclip the cover and remove it completely.
Fuse N°RatingFunctions
115 A
Front foglamps.
410 A
Horn.
57.5
A Alternator.
620 A Headlamp wash.
7 10 A
Air conditionin
g.
920 A
Alarm.
1015 A
Demisting, wipers.
11- Not used.
12-
Not used. The fusebox is placed in the en
gine compartment (left-hand side).

190
Practical information
Fuse N°RatingFunctions
1
310 A
Daytime running lamps.
14 10 A
Left-hand main beam headlamp.
1510 A Right-hand main beam headlamp.
1
620 A Left-hand dipped beam headlamp (xenon).
1
720 A Right-hand dipped beam headlamp (xenon).
1810 A Left-hand dipped beam headlamp (halogen), manual and
automatic headlamp adjustment.
1
910 A
Right-hand dipped beam headlamp (halogen).
3130 A
Audio amplifier.


The maxi-fuses provide additional protection for the electrical systems. All work on the maxi-fuses must be carried out by a CITROËN dealer or a qualified workshop.


Carefully close the cover after replacinga fuse so as to ensure the correctsealing of the fusebox.

195
7
Practical information

Removing a front or rear
wiper blade
) Raise the corresponding wiper arm.)
Remove the wiper blade, sliding it towards
the outside.










Changing a wiper
blade

Fitting a front or rear wiper
blade
) At the front, check the size of the wiper blade as the shorter blade is fitted on the
right-hand side of the vehicle.) Put the corresponding new wiper blade in
place and fix it. )
Fold down the wiper arm carefully.


Automatic power cut-off to accessories

After the engine has stopped, when the ignition switch is in the "ACC" position(or the vehicle in "ACC" mode)
you can still use functions such as the audio equipment, windscreen wipers, dipped beamheadlamps, cour tesy lamps, etc. for about
t
hirty minutes.
Cutting off
Once the thir ty minutes have expired, thepower supply to the accessories will be automatically cut off.
Restoring power
The power supply will be restored the next time
the ignition is switched on.

The period before cut-off can beextended up to about sixty minutes or deactivated, via the colour screen"Equipment" menu.

206
Checks
fluids and the replacement of cer taincomponents.














Petrol engines
1.
Screenwash and headlamp wash fluidreservoir.2.
Coolant header tank.3.
Brake fluid reservoir.4.
Battery. 5.
Fusebox.
6.Air filter.
7. Engine oil dipstick. 8.Engine oil filler cap.
1.6 litre 115
2.0 litre 150

207
8
Checks
checking the levels of the various fluids, for
replacing cer tain components and for primingthe fuel system.














Diesel engines
1.
Screenwash and headlamp wash fluidreservoir.2.Coolant reservoir.3.Brake fluid reservoir.4.
Battery.
5. Fusebox.
6.Air filter.
7. Engine oil dipstick.8.Engine oil filler cap.9.
Priming pump * . 1.6HDi 110
1.8 HDi 150
*

According to engine.

213
8
Checks
Avoid prolonged contact of used oil or fluids with the skin.
Most of these fluids are harmful to
health or indeed very corrosive.

Do not discard used oil or fluids into sewers or onto the ground.
Take used oil to a CITROËN dealer or a qualified workshop (France) or to anauthorised waste disposal site.








Used products
To p p i ng up
The reser voir must be topped up without delay
by a CITROËN dealer or a qualified workshop.

Additive level
(1.6 HDi 110 Diesel versions
with particle emissions filter
)
The additive reser voir low level is indicated bythe display of this message.

Fluid specifi cation

For optimum cleaning and to avoid freezing,
this fluid must not be topped up with or
replaced with plain water.
Screenwash and headlamp
wash fluid
In the case of vehicles fitted withheadlamp washers, the low fluid level
is indicated by an audible signal and
a messa
ge in the instrument panelscreen.
Top up the reser voir when you next stop the
vehicle.

.
