Te c h n i c a l d a t a













For: Australia, New-Zealand.


PETROL ENGINES



2.0 litre 150



Gearboxes


Manual (5-speed)



CVT (6- speed)



Model codes:
BU...


AFZ7



AFZM



AFZH



AFZP



Tr a n s m i s s i o n m o d e


2WD



4WD



2WD



4WD




- Unladen weight
1 350
1 415
1 380
1 445


- Kerb weight
1 425
1 490
1 455
1 520


- Gross vehicle weight (GV W)
1 970
1 970
1 970
1 970


- Gross vehicle weight (GV W) when towing
2 035
2 035
2 035
2 035


- Gross train weight (GTW)
on a 12% gradient
3 020
3 020
3 020
3 020


- Braked trailer (within GTW limit)

on a 10% or 12% gradient
1 050
1 050
1 050
1 050


- Unbraked trailer
750
750
750
750


- Recommended nose weight
65
65
65
65

230
Te c h n i c a l d a t a













For: South Africa.


PETROL ENGINES



2.0 litre 150



Gearboxes


Manual (5-speed)



CVT (6- speed)



Model codes:
BU...


AFYR



AFYV



AFYT



AFYW



Tr a n s m i s s i o n m o d e


2WD



4WD



2WD



4WD




- Unladen weight
1 350
1 415
1 390
1 455


- Kerb weight
1 425
1 490
1 465
1 530


- Gross vehicle weight (GV W)
1 970
1 970
1 970
1 970


- Gross vehicle weight (GV W) when towing
2 035
2 035
2 035
2 035


- Gross train weight (GTW)
on a 12% gradient
3 075
3 075
2 760
2 760


- Braked trailer (within GTW limit)

on a 10% or 12% gradient
1 050
1 050
750
750


- Unbraked trailer
1 050
1 050
750
750


- Recommended nose weight
65
65
65
65

9
231
Te c h n i c a l d a t a

*
Vehicle not for towing.














For other countries of sale.


PETROL ENGINES



2.0 litre 150



Gearboxes


Manual (5-speed)



CVT (6- speed)



Model codes:
BU...


AFYR

AFZ7



AFYV

AFZM



AFYT

AFZH



AFYW

AFZP



Tr a n s m i s s i o n m o d e


2WD



4WD



2WD



4WD




- Unladen weight
1 340
1 405
1 370
1 435


- Kerb weight
1 415
1 480
1 445
1 510


- Gross vehicle weight (GV W)
1 970
1 970
1 970
1 970


- Gross vehicle weight (GV W) when towing
2 035
2 035
2 035

2 035


- Gross train weight (GTW)
on a 12% gradient
2 655
2 655
- *

- *



- Braked trailer (within GTW limit)
on a 10% or 12% gradient
650
650
- *

- *



- Unbraked trailer
650
650
- *

- *



- Recommended nose weight
65
65
- *

- *

232
Te c h n i c a l d a t a

*
The maximum power corresponds to the value type-approved on a test bed, under conditions defined in European legislation (Directive 1999/99/EC).
DIESEL ENGINES


1.6 HDi 110



1.8 HDi 150



Model codes :

BU...


9HD8/S



9HDB/S



6HZ8/S



6HZB

6HZB/S



Tr a n s m i s s i o n m o d e


2WD



4WD



2WD



4WD


Cubic capacity (cc)
1 560
1 798
Bore x stroke (mm)
77 x 88.3
83 x 83.1
Max power * : EU standard (kW)
84
11 0
Max power engine speed (rpm)
3 600
4 000
Max torque: EU standard (Nm)
270
300
Max torque engine speed (rpm)
1 750
2 000 to 3 000
Fuel
Diesel
Diesel
Catalytic conver ter
Ye s
Ye s
Particle emission filter (PEF)
Ye s
Ye s

GEARBOXES

Manual
(6-speed)
Manual
(6-speed)

OIL CAPACITY (in litres)









Engine (with filter replacement)
3.75
5.3














Engines and gearboxes


.../S
: model fitted with the Stop & Start (AS&G) function.

9
233
Te c h n i c a l d a t a















Diesel weights and towed loads (kg)


The values for maximum towed weights type
approved according to the sales zone (see the
tables on the following pages).
The exact values are given in your vehicle's
registration document as well as on the
manufacturer's plate.
They are also mentioned in sales brochures.
For more details, contact a CITROËN dealer or
a qualified workshop.
The kerb weight is equal to the unladen
weight + driver (75 kg).
The GTW and towed load values indicated are
valid up to a maximum altitude of 1 000 metres;
the towed load mentioned must be reduced
by 10 % for each additional 1 000 metres of
altitude.
The speed of a towing vehicle must not exceed
60 mph (100 km/h) (comply with the legislation
in force in your country).
High ambient temperatures may result in a
reduction in the per formance of the vehicle to
protect the engine; if the ambient temperature
is above 37 °C, limit the towed load.

The weight of the braked trailer can be
increased, within the GTW limit, if the
GV W of the towing vehicle is reduced
by an equal amount. Please note that
towing using a lightly loaded towing
vehicle may have an adverse effect
on its road holding.

234
Te c h n i c a l d a t a

DIESEL ENGINES


1.6 HDi 110



1.8 HDi 150



Gearboxes


Manual (6-speed)



Manual (6-speed)



Model codes:
BU...


9HD8/S



9HDB/S



6HZ8/S



6HZB/S



Tr a n s m i s s i o n
mode


2WD



4WD



2WD



4WD




- Unladen weight
1 315
1 425
1 430
1 495


- Kerb weight
1 390
1 500
1 505
1 570


- Gross vehicle weight (GV W)
2 060
2 060
2 060


- Gross vehicle weight (GV W) when towing
2 130
2 130
2 130


- Gross train weight (GTW)
on a 12% gradient
3 260
3 260
3 530


- Braked trailer (within GTW limit)
on a 10% or 12% gradient
1 130
1 130
1 400


- Braked trailer (with transfer of load within
the GTW limit)
1 300
1 300
-


- Unbraked trailer
695
750
750


- Recommended nose weight
70
70
70














For zones: Europe, Turkey, French overseas dominions and territories.

9
235
Te c h n i c a l d a t a

DIESEL ENGINES


1.6 HDi 110



1.8 HDi 150



Gearboxes


Manual (6-speed)



Manual (6-speed)



Model codes:
BU...


9HD8/S



9HDB/S



6HZ8/S



6HZB/S



Tr a n s m i s s i o n
mode


2WD



4WD



2WD



4WD




- Unladen weight
1 410
1 475
1 480
1 545


- Kerb weight
1 485
1 550
1 555
1 620


- Gross vehicle weight (GV W)
2 060
2 060
2 060


- Gross vehicle weight (GV W) when towing
2 130
2 130
2 130


- Gross train weight (GTW)
on a 12% gradient
3 260
3 260
3 530


- Braked trailer (within GTW limit)
on a 10% or 12% gradient
1 130
1 130
1 400


- Braked trailer (with transfer of load within
the GTW limit)
1 300
1 300
-


- Unbraked trailer
695
750
750


- Recommended nose weight
70
70
70














For: Russia, Ukraine, Morocco, Argentina, Chile.

236
Te c h n i c a l d a t a

DIESEL ENGINES


1.6 HDi 110



1.8 HDi 150



Gearboxes


Manual (6-speed)



Manual (6-speed)



Model codes:
BU...


9HD8/S



9HDB/S



6HZB

6HZB/S



Tr a n s m i s s i o n
mode


2WD



4WD



4WD




- Unladen weight
1 410
1 475
1 530


- Kerb weight
1 485
1 550
1 605


- Gross vehicle weight (GV W)
2 060
2 060
2 060


- Gross vehicle weight (GV W) when towing
2 130
2 130
2 130


- Gross train weight (GTW)
on a 12% gradient
3 110
3 110
3 110


- Braked trailer (within GTW limit)
on a 10% or 12% gradient
1 050
1 050
1 050


- Unbraked trailer
750
750
750


- Recommended nose weight
70
70
70














For: Australia, New Zealand.

9
237
Te c h n i c a l d a t a

DIESEL ENGINES



1.6 HDi 110



Gearboxes



Manual (6-speed)



Model codes:
BU...


9HD8/S



9HDB/S



Tr a n s m i s s i o n
mode


2WD



4WD




- Unladen weight
1 420
1 485


- Kerb weight
1 495
1 560


- Gross vehicle weight (GV W)
2 060
2 060


- Gross vehicle weight (GV W) when towing
2 130
2 130


- Gross train weight (GTW)
on a 12% gradient
3 321
3 321


- Braked trailer (within GTW limit)
on a 10% or 12% gradient
1 200
1 200


- Unbraked trailer
750
750


- Recommended nose weight
70
70














For: South Africa.

238
Te c h n i c a l d a t a

DIESEL ENGINES



1.6 HDi 110



Gearboxes



Manual (6-speed)



Model codes:
BU...


9HD8/S



9HDB/S



Tr a n s m i s s i o n
mode


2WD



4WD




- Unladen weight
1 420
1 485


- Kerb weight
1 495
1 560


- Gross vehicle weight (GV W)
2 060
2 060


- Gross vehicle weight (GV W) when towing
2 130
2 130


- Gross train weight (GTW)
on a 12% gradient
2 745
2 745


- Braked trailer (within GTW limit)
on a 10% or 12% gradient
650
650


- Unbraked trailer
650
650


- Recommended nose weight
70
70














For other countries of sale.
