Page 5 of 368
Contents
Direction indicators 147
Hazard warning lamps 147
Horn 147
Braking assistance systems 148
Trajectory control systems 150
Front seat belts 152
Airbags 156
Child seats 161
Deactivating the passenger's front airbag 163
ISOFIX child seats 170
Child lock 176
Safety
Temporary puncture repair kit 177
Changing a wheel 181
Snow chains 187
Changing a bulb 188
Changing a fuse 194
12 V battery 200
Automatic power cut-off to accessories 203
Changing a wiper blade 203
Recovering the vehicle 204
Towing a trailer 207
Fitting roof bars 209
Accessories 210
Practical information
Bonnet 213
Petrol engines 214
Diesel engines 215
Fuel tank 216
Running out of fuel (Diesel) 218
Checking levels 219
Checks 222
Checks
Petrol engines 225
Petrol weights 226
Diesel engines 232
Diesel weights 233
Dimensions 239
Identifi cation markings 241
Te c h n i c a l d a t a
Bluetooth® telephone
with voice recognition 243
TOUCH SCREEN AUDIO -TELEMATIC
system 255
TOUCH SCREEN AUDIO - CD system 293
AUDIO - CD system 313
Audio and telematics
Alphabetical index
Visual search
Page 25 of 368
23
.Familiarisation
Limit the causes of excess consumption
Spread loads throughout the vehicle; place the heaviest items in the
bottom of the boot, as close as possible to the rear seats.
Limit the loads carried in the vehicle and reduce wind resistance (roof
bars, roof rack, bicycle carrier, trailer...). Use a roof box in preference.
Remove roof bars and roof racks after use.
At the end of winter, remove snow tyres and refit your summer tyres.
Observe the recommendations on
maintenance
Check the tyre pressures regularly, when cold, referring to the label in
the door aperture, driver's side.
Carry out this check in particular:
- before a long journey,
- at each change of season,
- after a long period out of use.
Don't forget the spare wheel and the tyres on any trailer or caravan.
Have your vehicle ser viced regularly (engine oil, oil filter, air filter...) and
obser ve the schedule of operations recommended by the manufacturer.
When refuelling, do not continue after the third cut-off of the nozzle to
avoid any over flow.
At the wheel of your new vehicle, it is only after the first 1 800 miles
(3 000 kilometres) that you will see the fuel consumption settle down to
a consistent average.
Page 28 of 368
26
Monitoring
Warning lamps
When the engine is running or the vehicle is
being driven, the illumination of one of the
following warning lamps indicates a malfunction
which requires action on the part of the driver.
The warning comes on in the instrument panel
or appears in the instrument panel screen.
Warning lamp
is on
Cause
Action / Observations
Parking brake /
Brake fluid
level / Electronic
brake force
distribution
fixed. It comes on for a few seconds, then
goes off when the ignition is switched
to "ON".
The parking brake is on or not fully
released. It is accompanied by a message. Release the parking
brake to make the warning lamp go off.
The brake fluid level is too low. It is accompanied by a message. Top up with brake
fluid and contact a CITROËN dealer or a qualified
workshop.
The electronic brake force distribution
(EBFD) is faulty. You must stop as soon as it is safe to do so.
Have it checked by a CITROËN dealer or a qualified
workshop.
Engine
autodiagnosis
system
flashing. The engine management system has
a fault. Risk of destruction of the catalytic converter.
Have it checked by a CITROËN dealer or a qualified
workshop.
fixed. The emission control system has a
fault.
The warning lamp should go off when the engine is started.
If it does not go off, contact a CITROËN dealer or
qualified workshop without delay. The illumination of a warning lamp may be accompanied by the display of an additional
message, to assist you in identifying the problem.
If you encounter any problems, you should contact a CITROËN dealer or a qualified workshop.
Page 29 of 368
1
27
Monitoring
Warning lamp
is on
Cause
Action / Observations
Battery charge
*
fixed. The battery charging circuit has a
fault (dirty or loose terminals, slack or
cut alternator belt, ...). The warning lamp should go off when the engine is
started.
If it does not go off, contact a CITROËN dealer or a
qualified workshop.
Anti-lock
Braking System
(ABS)
fixed. The anti-lock braking system has a
fault. The vehicle retains conventional braking.
Drive carefully at reduced speed and contact a
CITROËN dealer or a qualified workshop without
delay.
Front seat belt
not fastened /
unfastened
fixed, then flashing,
accompanied by an
audible signal. The driver has not fastened or has
unfastened their seat belt. Pull the strap, then insert the tongue in the buckle.
*
According to destination country.
Airbags and
pretensioners
temporarily. When you switch on the ignition, this
warning lamp comes on for a few
seconds, then goes off. If it does not go off, contact a CITROËN dealer or a
qualified workshop.
fixed. Fault with one of the airbag or seat
belt pretensioner systems. Have it checked by a CITROËN dealer or a qualified
workshop.
Page 31 of 368
1
29
Monitoring
Warning lamp
is on
Cause
Action / Observations
Cruise control
fixed This comes on when the cruise
control has been activated. Press the "ON/OFF" button to activate/deactivate the
cruise control.
Active stability
control and
traction control
(ASC/TCL)
flashing. Operation of the ASC/ TCL systems. The systems optimise traction and improve the
directional stability of the vehicle.
Adapt your driving and moderate your speed.
fixed. Fault in the ASC/ TCL systems. Have it checked by a CITROËN dealer or a qualified
workshop.
Stop & Star t
(Auto Stop & Go)
function
fixed. When the vehicle stops (red lights,
traffic jams, ...) the Stop & Start
(AS&G) function has put the engine
into STOP mode. The warning lamp goes off and the engine restarts
automatically in START mode, as soon as you want to
move off.
flashes for a few
seconds, then goes
off. STOP mode is temporarily
unavailable.
or
START mode is invoked
automatically. See "Stop & Start (AS&G) function" for special cases
with STOP mode and START mode.
Diesel engine
pre-heating
fixed. The engine is cold and:
- the ignition switch is at the ON
position (ignition on), or
- the START/STOP
starting button
has been pressed (ignition on). With key starting, wait until the warning lamp has gone
off before starting.
With the Keyless Entry and Starting system, the engine
will only start after the warning lamp has gone off.
The duration for which the warning lamp is on is
determined by the climatic conditions (up to 30 seconds
in severe weather).
If the engine does not start, switch the ignition off and
then on again and wait again until the warning lamp
goes off, then start the engine.
Page 33 of 368
1
31
Monitoring
Instrument panel screen
Each time the engine is started: warning lamps and/or messages come on, applying a checking self test. They go off after a few seconds.
When you want to see the trip computer information, you can choose to ignore the alerts, by pressing the INFO
button on the dashboard.
The messages displayed may vary according to the type of display screen (type 1 or type 2) in the instrument panel.
Cer tain messages are only displayed in the type 2 screen.
When this symbol appears: make a
shor t press
. When this symbol appears: make
a long press
.
Ignition off.
Ignition on
(with a manual gearbox).
Ignition on
(with a CVT gearbox).
Warnings and alerts
When an alert occurs, the displayed information then disappears. the warning lamp and its associated message appear, accompanied if appropriate by
an audible signal.
When there are several alerts, they are displayed in turn and this symbol appears. It remains displayed while there are still alerts.
You will then be able to display the alerts again by pressing the INFO
button several times to cycle through the trip computer information and return to
the alerts.
Page 37 of 368
1
35
Monitoring
Screen 1
Screen 2
Cause
Solution - Action
Observations
Warning messages (ignition at "ON")
Fault with the electric power
steering. Stop the vehicle, wait few moments
then start the engine again. If the message remains after
restarting, contact a CITROËN
dealer or a qualified workshop.
The battery for the "Keyless Entry
and Starting" system is flat. Replace the battery (see "Changing
the batteries").
The electronic key that you have on
your person is not recognised. Check that you have the correct
electronic key. If the message persists, contact a
CITROËN dealer.
The electronic key is still in the
vehicle and you have tried to lock
the doors or boot from the outside. Ensure that you have the electronic
key on your person before locking
the vehicle.
One of the doors or the boot is not
properly closed when locking the
vehicle from the outside. Close the door or the boot, then
lock the vehicle.
Fault with the "Keyless Entry and
Starting" system. Contact a CITROËN dealer.
Page 38 of 368
36
Monitoring
Screen 1
Screen 2
Cause
Solution - Action
Observations
The brake fluid level is too low. Top up using a brake fluid listed by
CITROËN. If the problem persists, contact
a CITROËN dealer or a qualified
workshop.
Fault with the braking system. You must stop as soon as it is safe
to do so. Have the system checked by a
CITROËN dealer or a qualified
workshop.
Fault with the anti-lock braking
system (ABS). Contact a CITROËN dealer or a
qualified workshop. The vehicle retains conventional
braking without assistance but you
are advised to stop.
One of the doors or the boot is not
properly closed. Close the door or the boot. The opening in question is identified
in the screen.
The bonnet is not properly closed. Close the bonnet.
Fault with the electronic anti-theft
system. Switch off the ignition then start the
engine again. If the problem persists, contact a
CITROËN dealer.
The driver's door is open and the
ignition is still on. Switch off the ignition before leaving
the vehicle.
Page 40 of 368
38
Monitoring
Screen 1
Screen 2
Cause
Solution - Action
Observations
You have moved off with the parking
brake not fully released. Release the parking brake.
The oil pressure is too low or there
is a fault with the engine lubrication
system. Stop the vehicle and contact a
CITROËN dealer or a qualified
workshop.
Battery charge fault. Stop the vehicle and contact a
CITROËN dealer or a qualified
workshop.
Airbag or pretensioner fault. Contact a CITROËN dealer or a
qualified workshop to have the
systems checked.
Fault with automatic headlamp
adjustment system. Contact a CITROËN dealer or a
qualified workshop. Only on vehicles fitted with xenon
headlamps.
Fault with the stability control
system (ASC). Contact a CITROËN dealer or a
qualified workshop.
Fault with the four wheel drive
transmission system. Contact a CITROËN dealer or a
qualified workshop.
Page 42 of 368
40
Monitoring
Screen 1
Screen 2
Cause
Solution - Action
Observations
Engine oil level not correct (below
minimum level or above maximum
level). Stop the vehicle as soon as it is
safe to do so.
Check the level with the dipstick and
top-up if the level low.
If the level is above the maximum
mark, do not restart the engine and
contact a CITROËN dealer or a
qualified workshop.
Never drive with an incorrect oil
level.
*
*
Presence of water in the Diesel fuel
filter. Risk of damage to the injection
system on Diesel engines. Contact a CITROËN dealer or a
qualified workshop as soon as
possible.
The ambient temperature is at or
below 3 °C (37 °F). There may be black ice on the road.
Take care and drive gently.
The clutch pedal is not depressed
while starting the engine. Depress the clutch pedal to start the
engine. For vehicles fitted with a manual
gearbox.
The gear lever is not in position P
or
position N
when starting the engine. Place the gear lever at position P
to
start the engine. For vehicles fitted with a CV T
gearbox.
The brake pedal is not pressed
while starting the engine. Press the brake pedal to start the
engine.
*
Depending on country of sale.
