IX
D R I V I N G
Loading/unloading
assistance
Grand C4
Picasso
C4 Picasso
The pneumatic suspension has an
additional function associated with
it: the possibility to raise or lower
the height of the rear of the vehicle
when stationary, in order to facilitate
loading/unloading of the boot. Increasing the height of the boot
fl o o r
Press continuously at the top of
the control A , which is located in
the boot, on the left-hand side.
This action will be accompanied by
an audible signal. You can stop the
movement at any time by releasing
the control.
3 b e e p s w i l l c o n fi r m t h a t t h e m o v e -
ment has gone as far as it can.
Returning to the
normal
height
P r e s s b r i e fl y t w i c e a t t h e b o t t o m
of the control A .
Decreasing the height of the boot
fl o o r
Press continuously at the bottom
of the control A .
This action will be accompanied by
a sound signal. You can stop the
movement at any time by releasing
the control.
3 b e e p s w i l l c o n fi r m t h a t t h e m o v e -
ment has gone as far as it can.
Returning to the
normal
height
P r e s s b r i e fl y t w i c e a t t h e t o p o f
the control A .
Driving with the boot in a
low position may damage
the components located un-
der the bodyshell.
Special features
- If you start the vehicle without having returned it to the normal
height, automatic correction will
activate as soon as the vehicle
starts to move. During the cor-
rection, the service warning lamp
lights up and a message on the
screen reminds you not to ex-
ceed 10 km/h (6 mph).
- The loading assistance does not function in the following instances:
- If the button B is lit up,
- in power economy mode,
- w h e n y o u fi r s t u s e t h e f u n c t i o n , press for two seconds on the
control A to initialise the system.
All subsequent actions will be
followed immediately by the de-
sired results.
Page 200 of 338
167
XI
P R A C T I C A L I N F O R M A T I O N
PUNCTURE REPAIR KIT Using the kit
The kit is located in the boot under
t h e fl o o r o r u n d e r t h e fl a p i n t h e s e c -
o n d r o w l e f t - h a n d p a s s e n g e r f o o t -
w e l l ( o p e n b y t u r n i n g t h e s c r e w a
quarter of a turn).
T i c k t h e w h e e l t o b e r e p a i r e d
o n t h e s p e e d l i m i t a t i o n s t i c k e r
e n c l o s e d t h e n a f fi x t h e s t i c k e r
t o t h e v e h i c l e ' s s t e e r i n g w h e e l
t o r e m i n d y o u t h a t a w h e e l i s i n
t e m p o r a r y u s e .
S w i t c h o f f t h e i g n i t i o n .
C l i p t h e b o t t l e 1 o n t h e c o m p r e s -
sor 2 .
Check that the switch A is tilted
t o p o s i t i o n "0" .
C o n n e c t t h e p i p e o f t h e b o t t l e 1
t o t h e v a l v e o f t h e t y r e t o b e r e -
p a i r e d .
U n w i n d t h e p i p e o f t h e c o m p r e s -
sor 2 f u l l y b e f o r e c o n n e c t i n g i t t o
the bottle.
C o n n e c t t h e c o m p r e s s o r ' s e l e c -
t r i c p l u g t o t h e v e h i c l e ' s 1 2 V
socket.
Start the vehicle and leave the
e n g i n e r u n n i n g .
C o m p l e t e s y s t e m c o n s i s t i n g o f a
c o m p r e s s o r a n d a b o t t l e o f s e a l a n t
w h i c h p e r m i t s
temporary repair of
t h e t y r e s o t h a t y o u c a n d r i v e t o t h e
n e a r e s t g a r a g e .
T h i s r e p a i r k i t i s a v a i l a b l e f r o m
CITROËN dealers.
I t i s d e s i g n e d t o r e p a i r h o l e s o f
a m a x i m u m d i a m e t e r o f 4 m m ,
l o c a t e d e x c l u s i v e l y o n t h e t y r e
t r e a d o r s h o u l d e r . A v o i d r e m o v -
i n g a n y f o r e i g n b o d i e s w h i c h h a v e
p e n e t r a t e d t h e t y r e .
Page 213 of 338
179
XI
P R A C T I C A L I N F O R M A T I O N
Rear lamps
(Grand C4 Picasso)
1. Direction indicators
(PY21 W)
2. Stoplamps
(P21 W)
3. Reversing lamp
(P21 W)
4. Sidelamps (diodes)
F o r t h i s t y p e o f l a m p , c o n t a c t a CITROËN dealer. Changing bulbs
I d e n t i f y t h e f a u l t y b u l b .
W i t h t h e t a i l g a t e o p e n , u n d o t h e
3 s c r e w s l o c a t e d o n t h e s i d e o f
t h e l e n s u n i t a n d p u l l i t r e a r w a r d s
to detach.
D i s c o n n e c t t h e c o n n e c t o r l i n k i n g
the lens unit to the boot. Do not
disconnect the diodes.
R e m o v e t h e s e a l .
R e m o v e t h e b u l b - h o l d e r .
R e p l a c e t h e b u l b s .
T o r e m o v e a b u l b , r o t a t e i t a quarter turn.
T o fi t t h e b u l b , r o t a t e i t a q u a r t e r turn in the other direction.
R e p o s i t i o n t h e b u l b - h o l d e r .
R e fi t t h e s e a l .
Reconnect the connector to the
lens unit.
A r r a n g e t h e h a r n e s s i n t h e o p e n -
i n g p r o v i d e d i n t h e b o d y .
R e fi t t h e l e n s u n i t t o t h e b o d y
a n d fi t a n d t i g h t e n t h e 3 s c r e w s . Number plate lamps (W 5 W)
Insert a thin screwdriver into one
o f t h e e x t e r n a l h o l e s o f t h e l e n s .
P u s h i t o u t w a r d s t o u n c l i p i t .
R e m o v e t h e l e n s .
C h a n g e t h e f a u l t y b u l b .
Page 214 of 338
1 8 0
XI
P R A C T I C A L I N F O R M A T I O N
Third brake lamp with bulb
