Page 3 of 338
6
F A M I L I A R I S A T I O N
This opening gives you enhanced ac-
cess to the boot, even if you are parked
close to a wall or to another vehicle.
Opening rear screen
Opening
Press on control 2. The handhold 4
is in line with the rear wiper.
Closing
Lower the rear screen.
80
Press on control 1 .
You cannot open the tailgate if the rear
screen is already open.
Lower the tailgate, using one of the
handholds 3 , located on the inside
of the tailgate trim.
Past the balancing point, allow the
tailgate to close itself (do not assist
it or slow it down).
Load: 22 kg maximum.
The Modubox is composed of a shop-
p i n g t r o l l e y a n d a fl e x i b l e b a g w h i c h c a n
be used independently of each other
depending on your needs.
100
O P E N I N G
Opening the tailgate
Closing the tailgate Modubox CITROËN
(C4 Picasso)
Page 4 of 338
7
F A M I L I A R I S A T I O N
CITROËN Grand C4 Picasso
Torch
Pneumatic rear
suspension
Allows the height of the rear
of the vehicle to be adjusted Access to
spare wheel
Puncture repair kit
Depending on model, the puncture repair kit is located eit her in the boot well or in the compartment under
t h e l e f t h a n d s e c o n d - r o w p a s s e n g e r ( o p e n t h e fl a p b y t u r n i n g t h e s c r e w a q u a r t e r t u r n ) .
This puncture repair kit is a complete system for a temporary repair; it is made up of a compressor and
a sealant product. Luggage cover blind
Luggage cover in two
sections
Torch
99
100
171
155
167
104
CITROËN C4 Picasso
Also see section "Practical information - § Changing a wheel ".
170
Page 7 of 338
10
F A M I L I A R I S A T I O N
Folding the seats
From the boot - whilst loading,
for example CITROËN
(Grand C4 Picasso)
Take care to attach the third-row pas-
senger seat belts on the rings provided
for this purpose.
Do not attach the belts on the an-
choring points marked with a red
cross (see illustration above).
Stowing the tongue of the third-row
seat belt
SECOND - ROW SEATS
120
Requirements for third-row
passenger seat belts
From outside
P u l l fi r m l y u p w a r d s o n s t r a p C , as
indicated by the red arrow, to unlock
the seat; maintain the pressure until
the seat is fully folded.
Slide latch A of the plate down-
wards, to unlock it.
Return the plate to the upright posi-
tion, then slide latch A upwards to
lock it.
Before deploying the rigid plates, check
that the second row seats are slid as far
back as possible.
62
I N T E R I O R
THIRD - ROW SEATS – CITROËN GRAND C4 PICASSO
H a v i n g fi r s t l y f o l d e d t h e t h i r d - r o w
seats.
Pull on control D to unlock the re-
q u i r e d s e a t .
Repositioning the seats
Return the rigid plates of the second-
row seats to their initial (upright) position
and lock them in position (CITROËN
Grand C4 Picasso).
Raise the backrest and push it back-
wards until it locks in position. Rigid plate
(CITROËN Grand C4 Picasso)
A rigid plate is attached to each sec-
ond-row seat backrest.
Unlocking/Locking the rigid plate
Page 28 of 338
29
I
I N S T R U M E N T S a n d C O N T R O L S
Lighting is associated
with the display of an-
other warning lamp :
Service If this comes on, it in-
dicates the occurrence
of a problem in one
of the systems which
d o e s n o t h a v e a s p e c i fi c w a r n i n g
lamp.
In order to identify it, consult the mes-
sage on the multifunction screen.
The warning lamp only comes on
temporarily in the case of the follow-
ing minor faults:
- incorrect closing of the doors, boot, rear screen and bonnet,
- fl a t r e m o t e c o n t r o l b a t t e r y ,
- incorrect tyre pressure,
- the end of saturation of the parti- c l e e m i s s i o n fi l t e r ( D i e s e l ) .
In the case of major faults, the
warning lamp remains on until the
o p e r a t i n g f a u l t i s r e c t i fi e d , c o n t a c t
a CITROËN dealer as soon as
possible. Braking
If this comes on, it indicates
the occurrence of a fault in
one of the braking systems:
- s i g n i fi c a n t d r o p i n t h e l e v e l i n t h e circuit,
- electronic brake force distribu- tion (EBFD) faulty (simultane-
ous lighting of the ABS warning
lamp),
stop the vehicle immediately and as
safely as possible.
Consult a CITROËN dealer.
Application/Release of the
automatic electric parking brake
If this warning lamp comes
o n p e r m a n e n t l y , i t i s c o n fi r m -
ing that the parking brake is
applied.
I f i t fl a s h e s , i t i s i n d i c a t i n g a n a p -
plication or release fault. Contact
a CITROËN dealer urgently (see
section "Driving - § Electric parking
brake"). Automatic electric parking brake
fault
This warning lamp comes
on if there is a malfunction in
the automatic electric park-
ing brake.
Deactivation of the automatic
functions of the automatic
electric parking brake
This comes on if the "auto-
matic application" and "auto-
matic release" functions
when you switch off the
engine are deactivated * or
faulty.
Dynamic stability control
(ESP/ASR) The ESP/ASR system is put
into service automatically
when the vehicle is started.
Unless the system has been
deactivated, if this warning lamp
and the indicator lamp on the button
come on continuously, this indicates
the occurrence of a fault in the ESP/
ASR system or in the hill start assist
system.
Engine autodiagnostics system
If this comes on, it indicates
the occurrence of a fault in
the engine management
system.
I f i t fl a s h e s , i t i n d i c a t e s t h e o c -
currence of a fault in the emission
control system.
Central alert
- punctured wheel,
- braking,
- coolant temperature,
stop the vehicle immediately and as
safely as possible.
Consult a CITROËN dealer.
Anti-lock braking system (ABS) If this comes on, it indicates
the occurrence of a fault in
the anti-lock braking sys-
tem.
However, this does not prevent op-
eration of the vehicle’s assisted
braking.
* According to country.
Page 29 of 338
30
I
I N S T R U M E N T S a n d C O N T R O L S Airbags If this comes on, it indicates
the occurrence of a fault in
one of the airbag or seat belt
pretensioner systems.
Maximum coolant temperature
If this comes on, it indicates
that the temperature in the
cooling system is too high.
Stop the vehicle as soon as
it is safe to do so.
Low fuel level When the tank is full, all the
bars are lit up.
If the fuel low warning lamp
comes on accompanied by
an audible signal and a message on
the multifunction screen, there are
approximately 7 litres of fuel remain-
i n g i n t h e t a n k a n d 2 o r 3 b a r s fl a s h
in the instrument panel.
When the last bar goes out, there
are approximately 2 litres of fuel re-
maining in the tank.
Top up with fuel as soon as possible
to avoid running out.
This warning lamp comes on each
time the ignition is switched on, until
s u f fi c i e n t f u e l i s a d d e d .
A control located on the panel to the
right of the steering wheel allows
y o u t o o p e n t h e f u e l fl a p f r o m i n s i d e
the vehicle.
Do not continue driving until you run
out of fuel as this may cause dam-
age to the emisions control and fuel
injection systems. Battery charge
If this comes on, it indi-
cates the occurrence of a
fault in the battery charging
circuit (dirty or loose termi-
nals, slack or cut alternator
belt, ...).
Door open A door, the boot or the rear
screen is open:
- if the speed is below 6 mph (10 km/h), this warning lamp comes on continuously,
-
if the speed is higher than 6 mph (10 km/h),
this warning lamp comes on continuously,
accompanied by an audible signal.
Seat belt not fastened/
unfastened
This warning lamp informs
you if the driver’s or front
passenger’s seat belt is
not fastened (depending
on model), and if the front
passenger’s (depending on
model) or the second row
passengers’ seat belts are
unfastened. The lit up positions repre-
sent those whose seat belts are not
fastened/unfastened. Seat belts unfastened during the
journey:
- the point corresponding to the
seat position with seat belt un-
fastened lights up between 0 and
approximately 12 mph (20 km/h).
A b o v e 1 2 m p h ( 2 0 k m / h ) , i t fl a s h -
es accompanied by an audible
signal for around 120 seconds.
The audible signal stops when
the ignition is switched off or if a
door is opened.
Depending on model, the front pas-
s e n g e r s e a t m a y b e fi t t e d w i t h a
presence sensor; the correspond-
ing warning lamp will only come on
if the seat is occupied and the seat
belt not fastened.
Driver’s or front passenger’s seat belt
not fastened with presence sensor:
- the warning lamp lights up be-
tween 0 and approximately
12 mph (20 km/h). Above 12 mph
( 2 0 k m / h ) , i t fl a s h e s a c c o m p a -
nied by a message on the mul-
tifunction screen and an audible
signal for around 120 seconds.
Second row rear passengers’ or
front passenger’s seat belt not fas-
tened without presence sensor:
- when the ignition is switched on, the points corresponding to the seat po-
sitions with seat belts not fastened
remain lit up for 30 seconds.
Page 67 of 338
61
III
C O M F O R T
SECOND ROW SEATS (C4 PICASSO)
Folding the seat
Each seat can be folded onto the
fl o o r t o e n a b l e y o u t o m o d i f y y o u r
vehicle’s interior space.
P u l l fi r m l y u p w a r d s o n s t r a p C ,
as indicated by the red arrow, to
unlock the seat; keep pulling un-
til the seat is fully folded.
Push the backrest slightly for-
wards so that the backrest pivots,
folding onto the seat base. The
assembly then lowers onto the
fl o o r . Repositioning seat
Raise the backrests and push
them rearwards so that they lock
in position.
Always supervise any movements
of seats by children. Panels behind the second
row seats
Panels below the second row seats
provide the bottom of the boot space
with rigidity. They automatically follow
the seat movements (e.g. forwards-
backwards adjustment, folding).
A storage area is available under-
neath the panels.
Page 68 of 338
62
III
C O M F O R T
SECOND ROW SEATS (GRAND C4 PICASSO)
Each seat can be folded onto the
fl o o r t o f o r m a fl a t s u r f a c e , t h u s e n -
abling you to modify your vehicle’s
interior space.
Folding the seat
From the outside
P u l l fi r m l y u p w a r d s o n s t r a p C ,
as indicated by the red arrow, to
unlock the seat; keep pulling un-
til the seat is fully folded.
Push the backrest slightly for-
wards, so that the backrest
pivots, folding onto the seat
base. The assembly will then
l o w e r o n t o t h e fl o o r . From the boot
(when loading, for example)
You can fold the second-row seat(s)
f r o m t h e b o o t , h a v i n g fi r s t f o l d e d t h e
third-row seats.
Pull on the strap D to unlock the
chosen seat, push the backrest
gently forwards.
To prevent any damage to the mechanism, the strap D unclips
under excessive force. Simply
reclip it to render the system
operational.
Repositioning the seat
Return the second-row seat bas-
es to their initial position and lock
them in that position.
Raise the backrests and push
them rearwards so that they lock
in position.
Before moving the third-row seats,
return the second-row rigid panels to
their initial position and lock them.
E m e r g e n c y e x i t : s h o u l d t h e fi r s t
system fail (strap C ), the strap D
can be used by third-row passen-
gers to facilitate their exit.
Always supervise any movements
of seats by children. Rigid panel
Each second-row seat backrest has
a rigid panel attached.
This panel enables you:
- to have a continuous load sur-
face in the boot, whatever the
positions of the seats,
- to avoid having objects sliding under the second-row seats.
Unlocking/Locking the rigid panel
Slide the latch 1 on the plate
downwards, to unlock.
Return the panel to the upright
position, then slide the latch 1
upwards, to lock.
Before deploying the rigid panels,
check that the second-row seats are
in the fully back position.
5 - s e a t e r c o n fi g u r a t i o n s d o n o t h a v e
these rigid panels.
Page 74 of 338
68
A C C E S S
REMOTE CONTROL KEY
System which permits central
unlocking or locking of the vehicle
using the lock or remotely. It is also
used to locate the vehicle, activate
the guide-me-home lighting and
start the engine, as well as providing
protection against theft.
Unlocking the vehicle
Complete unlocking using the
remote control
Unfolding the key
First press button A to unfold the
key.
Press the open padlock
to unlock the vehicle. Complete unlocking using the key
Turn the key to the left in the
driver's door lock to unlock the
vehicle.
U n l o c k i n g i s c o n fi r m e d b y r a p i d
fl a s h i n g o f t h e d i r e c t i o n i n d i c a t o r s
for approximately two seconds.
According to version, the exterior
mirrors unfold at the same time.
This also triggers the timed switching
on of the welcome lighting, courtesy
lamps and exterior side spotlamps
for approximately thirty seconds.
Selective unlocking using the
remote control
Press the open pad-
lock once to unlock the
driver's door only.
Press the open pad-
lock again to unlock
the other doors and
the boot. According to version, the exterior
mirrors unfold at the same time as
t h e fi r s t u n l o c k i n g a c t i o n .
It also triggers the timed switching on
of the welcome lighting, the courtesy
lights and the exterior side spotlamps
for approximately thirty seconds.
The complete or selec-
tive unlocking parameter
is set via the multifunc-
t i o n s c r e e n c o n fi g u r a t i o n
menu.
Complete unlocking is activated by
default.
E a c h u n l o c k i n g i s c o n fi r m e d b y r a p i d
fl a s h i n g o f t h e d i r e c t i o n i n d i c a t o r s f o r
approximately two seconds. Selective unlocking is not available
using the key.
Page 75 of 338
69
IV
A C C E S S
Normal locking using the key
Turn the key to the right in the
driver's door lock to lock the ve-
hicle completely.
L o c k i n g i s c o n fi r m e d b y fi x e d l i g h t -
ing of the direction indicators for ap-
proximately two seconds.
According to version, the exterior
mirrors fold at the same time.
It also triggers the timed switching
on of the exterior side spotlamps
and the guide-me-home lighting, if
this is activated. If one of the doors, the rear screen
or the boot is still open, the central
locking does not take place.
To permit the transportation of
bulky objects, the vehicle can be
locked from the inside, using the
centralised control on the dash-
board, even if the tailgate or rear
screen is open.
When the vehicle is locked, if it is
unlocked inadvertently, it will relock
automatically after thirty seconds
unless a door is opened.
When closing the windows and/or
glass panoramic roof shutter us-
ing the remote control, you must
ensure that no one prevents them
from closing correctly.
The folding and unfolding of the
exterior mirrors using the remote
control can be deactivated by a
CITROËN dealer.
Deadlocking using the remote
control
Press the closed pad-
lock to lock the vehicle
completely or press the
closed padlock for more
than two seconds to
close the windows and
the glass panoramic
roof blind automatically
in addition to locking.
Press the closed padlock again
w i t h i n fi v e s e c o n d s t o d e a d l o c k
the vehicle.
Locking the vehicle
Normal locking using the remote
control
Press the closed pad-
lock to lock the vehicle
completely.
Press the closed padlock for
more than two seconds to close
the windows and the glass pano-
ramic roof blind automatically in
addition to locking.
Page 84 of 338
74
IV
A C C E S S
ALARM
System which protects and provides
a deterrent against the theft of your
vehicle. It provides two types of pro-
tection, exterior and interior, as well
as an anti-tamper function.
Exterior perimiter protection
The system detects opening of the
vehicle.
The alarm is triggered if anyone tries
to enter the vehicle by forcing a door,
the boot or the bonnet.
Interior volumetric protection
The system detects any variation in the
volume in the passenger compartment.
The alarm is triggered if anyone
breaks a window or moves inside
the vehicle.
If you wish to leave a pet in the vehicle
or a window partially open, deactivate
the interior volumetric protection.
Anti-tamper function
The system detects the putting out
of service of its components.
The alarm is triggered if anyone
tries to put the wires of the siren, the
central control or the battery out of
service.
D o n o t m a k e a n y m o d i fi c a t i o n s t o
the alarm system, this could cause
malfunctions. Locking the vehicle with full
alarm
Activation
Switch off the ignition and get out
of the vehicle.
Lock or deadlock the vehicle
using the locking button on the
remote control.
The alarm is activated; the indicator
lamp on button A fl a s h e s o n c e p e r
second.
Deactivation
Unlock the vehicle using the
unlocking button on the remote
control.
The alarm is deactivated; the indica-
tor lamp on button A switches off. Locking the vehicle with
exterior protection alarm only
Deactivation of the interior
volumetric protection
Switch off the ignition.
Within ten seconds, press but-
ton A until the indicator lamp is lit
continuously.
Get out of the vehicle.
Lock or deadlock the vehicle
using the locking button on the
remote control.
The exterior protection alarm alone
remains activated; the indicator
lamp on button A fl a s h e s o n c e p e r
second.
To be effective, this deactivation
must be carried out each time the
ignition is switched off.
Reactivation of the interior
volumetric protection
Unlock the vehicle using the
unlocking button on the remote
control.
Relock the vehicle using the
remote control.
The alarm is activated again with
both types of protection; the indica-
tor lamp on button A switches off.
