Page 323 of 420
321
8
Checks
Checks
12 V battery
The battery does not require any maintenance.
However, check that the terminals are clean
and correctl
y tightened, particularly in summer and winter.
Refer to the maintenance andwarranty guide for details of the
replacement inter vals for these
components.
Air filter and passenger compartment filter
Replace the oil filter each time theengine oil is changed.
Refer to the maintenance andwarranty guide for details of the
replacement interval for this component.
Oil filter The presence of this label, in particular with
the Stop & Start system, indicates the use of a specific 12 V lead-acid battery with special
technology and specification. The involvement
of a CITROËN dealer or a qualified workshop is
essential when replacing or disconnecting the
battery.
Unless other wise indicated, check these components in accordance with the maintenance and warrant
y guide and according to your engine.
Other wise, have them checked by a CITROËN dealer or a qualified workshop.
Dependin
g on the environment (e.g. dustyatmosphere) and the use of the vehicle(e.g. city driving), replace them twiceas often if necessar y.y
A clogged passenger compar tment filter may have an adverse effect on the performance
of the air conditioning system and generateundesirable odours.
Particle emissions filter (Diesel)
The start of saturation of thepar ticle filter is indicated by the
fixed illumination of this warning lamp accompanied by a warning
message.
As soon as the traffic conditions permit, regenerate the filter by driving at aspeed of at least 40 mph (60 km/h) until the warning lamp goes off.
If the warning lamp stays on, thisindicates a low additive level.
On a new vehicle, the first par ticlefilter regeneration operations may beaccompanied by a "burning" smell,
which is perfectly normal.
Following prolonged operation of thevehicle at very low speed or at idle, you may, in exceptional circumstances, notice the emission of water vapour atthe exhaust on acceleration. This does not affect the behaviour of the vehicle or the environment. When carrying out work on the battery, re
fer
to the "12 V battery" section for details of theprecautions to be taken before disconnecting
the battery and following its reconnection.
Page 324 of 420
322
Checks
Brake wear depends on the styleof driving, par ticularly in the case of vehicles used in town, over shor t
distances. It may be necessary to
have the condition of the brakes checked, even between vehicle services.
Unless there is a leak in the circuit, a drop in
the brake fluid level indicates that the brake
pads are worn.
Brake pads
For information on checking brake
disc wear, contact a CITROËN dealer
or a qualified workshop.
Brake disc wear
Only use products recommended by CITROËN or products of equivalent quality and specification.
In order to optimise the operation of units as important as those in the braking system, CITROËN selects and offers very specific products.
After washing the vehicle, dampness,or in wintry conditions, ice can form on the brake discs and pads: braking efficiency may be reduced. Make lightbrake applications to dry and defrost the brakes.
Electric parking brake
For more information, refer to the "Electric parking brake - Operating faults" section. This s
ystem does not require any routine servicing. However, in theevent of a problem, have the systemchecked by a CITROËN dealer or a qualified workshop.
Manual gearbox
The gearbox does not require anymaintenance (no oil change).
Refer to the maintenance and
warranty guide for the details of
the level checking inter val for thiscomponent.
6-speed electronic gearbox
The gearbox does not require anymaintenance (no oil change).
Refer to the maintenance and
warranty guide for details of the checking interval for this component.
Automatic gearbox
The gearbox does not require anymaintenance (no oil change).
Refer to the maintenance and
warranty guide for details of the levelchecking interval for this component.
To avoid damaging the electrical units, the use of a high pressure washer in the engine compar tment is strictlyprohibited.
Page 325 of 420
9
323
Technical data
Petrol enginesVTi 120THP155
Gearboxes
Manual(5-speed)
Manual(6-speed)
Model codes:3D... 3E... 3A...5FS0/1
5FV8 - 8/1
Cubic capacity (cc)
1 598
1 598
Bore x stroke (mm)
77 x 85.8
77 x 85.8
Max power * : EU standard (kW)
88
115
Max power en
gine speed (rpm) 6 000
6 000
Max torque: EU standard
(Nm)
160240
Max torque en
gine speed (rpm) 4 2501 400
F
uel Unleaded Unleaded
Catal
ytic converter yes
yes
Oil capacities (in litres)
Engine (with filter replacement)
4.25
4.25
* The maximum power corresponds to the value type-approved on a test bed, under conditions defined in European legislation (Directive 1999/99/EC).
Petrol engines and gearboxes
3D...:CITROËN C4 Picasso (5-seat).3A...:CITROËN Grand C4 Picasso (7- s e at).3E...:
CITROËN Grand C4 Picasso (5-seat).
Page 326 of 420
324
Technical data
* The kerb weight is equal to the unladen weight + driver (75 kg). **
The weight of the braked trailer can be increased, within the GTW limit, if the GVW of the towing vehicle is reduced by an equal amount; warning,
towing using a lightly loaded towing vehicle may have an adverse effect on its road holding.
Petrol enginesVTi 120THP155
Gearboxes
Manual(5-speed)
Manual (6-speed)
Model codes:3D... 3E... 3A ... 5FS0/1 3D... 3E... 3A ...5FV8 - 8/1
-
Unladen weight1 252 - 1 276 - 1 278
1 296 - 1 311 - 1 313
- Kerb wei
ght *
1 327 - 1 351 - 1 353
1 371 - 1 386 - 1 388
- Gross vehicle wei
ght (GV W)
1 900 - 2 060 - 2 1101 940 - 2 100 - 2 150
- Gross train weight (GT W)
on a 12 % gradient2 900 - 2 860 - 2 860 3 360 - 3 350 - 3 350
- Braked trailer
(within GTW limit) on a 10 % or 12 % gradient
1 000 - 800 - 750
1 420 - 1 250 - 1 200
- Braked trailer
**
(with load transfer within the GTW limit)
1 200 - 1 100 - 1 050
1 620 - 1 550 - 1 500
- Unbraked trailer
660 - 675 - 675 685 - 690 - 690
- Recommended nose weight
70 - 70 - 70
70 - 70 - 70
Petrol weights and towed loads (in kg)
The GTW and towed load values indicated are valid up to a maximum altitude of 1 000 metres; the towed load mentioned must be reduced by 10 % for each additional 1 000 metres of altitude.
The speed of a towing vehicle must not exceed 60 mph (10 0 km/h) (comply with the legislation in force in your country).
High ambient temperatures may result in a reduction in the performance of the vehicle to protect the engine; if the ambient temperature is above 37 °C,
limit th
e towed load.
Page 327 of 420
9
325
Technical data
Diesel enginesHDi 90e-HDi 90 Airdream
Gearboxes
Manual(5-speed)
Electronic gearbox system(6-speed)
Model codes:3D... 3E... 3A...
9HP0/1 9HP8/2PS
Cubic capacity (cc) 1 560
Bore x stroke
(mm)
75 x 88.3
Max power * : EU standard (kW)
68
Max power engine speed (rpm)
4 000
Max torque: EU standard
(Nm)
230
Max torque engine speed (rpm) 1 750
F
uel
Diesel
Catalytic converter
yes
Particle emission filter
yes
Oil capacities (in litres)
Engine (with filter replacement) 3.75
.../S: e-HDi model fitted with Stop & Star t.3D...:CITROËN C4 Picasso (5-seat).
Diesel engines and gearboxes
* The maximum power corresponds to the value type-approved on a test bed, under conditions defined in European legislation (Directive 1999/99/EC).
3E...:CITROËN Grand C4 Picasso (5-seat). 3A...:CITROËN Grand C4 Picasso (7-seat).
Page 328 of 420
326
Technical data
* The maximum power corresponds to the value type-approved on a test bed, under conditions defined in European legislation (Directive 1999/99/EC).
Diesel engines and gearboxes
.../S: e-HDi model fitted with Stop & Star t.3D...:CITROËN C4 Picasso (5-seat). 3E...:
CITROËN Grand C4 Picasso (5-seat). 3A...:
CITROËN Grand C4 Picasso (7-seat).
Diesel enginesHDi 115e- HDi 115 Airdream
GearboxesManual (6-speed)
Manual(6-speed)Electronic gearbox system(6-speed)
Model codes:3D... 3E... 3A...9HC8/1
9HC8/1S
9HC8/1PS - 8/2PS
Cubic capacity (cc)
1 5601 560
Bore x stroke
(mm)75 x 88.3
75 x 88.3
Max power * : EU standard (kW)
8585
Max power engine speed
(rpm) 3 6003 600
Max torque: EU standard
(Nm)
270270 - 285
Max torque en
gine speed (rpm) 1 7501 750
F
uel
Diesel
Diesel
Catalytic conver ter yes yes
Particle emission filter no
yes
Oil capacities (in litres)
Engine (with filter replacement) 3.75
3.75
Page 329 of 420
9
327
Technical data
* The maximum power corresponds to the value type-approved on a test bed, under conditions defined in European legislation (Directive 1999/99/EC).
Diesel engines and gearboxes
.../S: e-HDi model fitted with Stop & Start.3D...:CITROËN C4 Picasso (5-seat).3E...:
CITROËN Grand C4 Picasso (5-seat). 3A...:
CITROËN Grand C4 Picasso (7- s e at).
Diesel enginese-HDi 150 Airdream
Gearboxes
Manual(6-speed)
Automatic
(6-speed)
Model codes:3D... 3E... 3A...
AHXM/S - M/1S
AHXT/S - T/1S
Cubic capacity (cc)
1 997
Bore x stroke
(mm) 85 x 88
Max power * : EU standard
(kW)
11 0
Max power engine speed (rpm) 3 750
Max torque: EU standard
(Nm)370
Max torque en
gine speed (rpm) 1 750
F
uel
Diesel
Catalytic converter
yes
Particle emission filter
yes
Oil capacities (in litres)
Engine (with filter replacement) 6.1
Page 330 of 420
328
Technical data
* The kerb weight is equal to the unladen weight + driver (75 kg).
**
The weight of the braked trailer can be increased, within the GTW limit, if the GV W of the towing vehicle is reduced by an equal amount; warning,
towin
g using a lightly loaded towing vehicle may have an adverse effect on its road holding.
Diesel enginesHDi 90e-HDi 90 Airdream
Gearboxes
Manual(5-speed)
Electronic gearbox system (6-speed)
Model codes:
3D9HP0/1
3D... 3E... 3A
9HP8/2PS
- Unladen weight
1 2791 289 - 1 314 - 1 316
- Kerb weight *
1 354
1 364 - 1 389 - 1 391
- Gross vehicle wei
ght (GV W)
1 920
1 940 - 2 11 0 - 2 160
- Gross train weight (GT W)
on a 12% gradient 3 170 3 140 - 3 160 - 3 160
- Braked trailer
(within GTW limit) on a 10% or 12% gradient 1 250
1 200 - 1 050 - 1 000
- Braked trailer **
(with load transfer with the GTW limit)
1 450
1 400 - 1 350 - 1 300
- Unbraked traile
r
675 680 - 690 - 695
-
Recommended nose weight 70
70 - 70 - 70
Diesel weights and towed loads (in kg)
The GTW and towed load values indicated are valid up to a maximum altitude of 1 000 metres; the towed load mentioned must be reduced by 10 % for each additional 1 000 metres of altitude.
The speed of a towing vehicle must not exceed 60 mph (10 0 km/h) (comply with the legislation in force in your country).
High ambient temperatures may result in a reduction in the per formance of the vehicle to protect the engine; if the ambient temperature is above 37 °C,
limit the towed load.
Page 331 of 420
9
329
Technical data
Diesel weights and towed loads (in kg)
The GTW and towed load values indicated are valid up to a maximum altitude of 1 000 metres; the towed load mentioned must be reduced by 10 % for each additional 1 000 metres of altitude.
The speed of a towing vehicle must not exceed 60 mph (10 0 km/h) (comply with the legislation in force in your country).
High ambient temperatures may result in a reduction in the per formance of the vehicle to protect the engine; if the ambient temperature is above 37 °C,
limit the towed load.
*
The kerb weight is equal to the unladen weight + driver (75 kg).
**
The weight of the braked trailer can be increased, within the GTW limit, if the GVW of the towing vehicle is reduced by an equal amount; warning,
towing using a lightly loaded towing vehicle may have an adverse effect on its road holding.
Diesel enginesHDi 115e-HDi 115 Airdream
GearboxesManual
(6-speed)
Manual(6-speed)Electronic gearbox system (6-speed)
Model codes:
3D... 3E... 3A ...9HC8/1 3D... 3E... 3A ... 9HC8/1S
3D... 3E... 3A ...9HC8/1PS - 8/2PS
-
Unladen weight 1 298 - 1 318 - 1 320
1 298 - 1 318 - 1 320
1 295 - 1 318 - 1 320
- Kerb weight *
1 373 - 1 393 - 1 395
1 373 - 1 393 - 1 3951 370 - 1 393 - 1 395
- Gross vehicle wei
ght (GV W)
1 940 - 2 11 0 - 2 15 0
1 940 - 2 11 0 - 2 15 01 940 - 2 11 0 - 2 15 0
- Gross train wei
ght (GT W)
on a 12% gradient 2 740 - 2 910 - 2 950 3 340 - 3 350 - 3 3503 340 - 3 350 - 3 350
- Braked trailer
(within GTW limit) on a 10% or 12% gradient 800 - 800 - 8001 400 - 1 240 - 1 200
1 400 - 1 240 - 1 200
- Braked trailer **
(with load transfer with theGTW limit)
800 - 800 - 8001 600 - 1 540 - 1 500
1 600 - 1 540 - 1 500
- Unbraked trailer 685 - 695 - 695 685 - 695 - 695685 - 695 - 695
-
Recommended nose weight 70 - 70 - 70
70 - 70 - 7070 - 70 - 70
Page 332 of 420
330
Technical data
Diesel weights and towed loads (in kg)
*
The kerb weight is equal to the unladen weight + driver (75 kg).
**
The weight of the braked trailer can be increased, within the GTW limit, if the GV W of the towing vehicle is reduced by an equal amount; warning,
towin
g using a lightly loaded towing vehicle may have an adverse effect on its road holding. The
GTW and towed load values indicated are valid up to a maximum altitude of 1 000 metres; the towed load mentioned must be reduced by 10 % for each additional 1 000 metres of altitude.
The speed of a towing vehicle must not exceed 60 mph (10 0 km/h) (comply with the legislation in force in your country).
High ambient temperatures may result in a reduction in the per formance of the vehicle to protect the engine; if the ambient temperature is above 37 °C,
limit the towed load.
Diesel enginese-HDi150Airdream
Gearboxes
Manual(6-speed)Electronic gearbox system (6-speed)
Model codes:3D... 3E... 3A ... AHXM/S - M/1S
3E... 3A ... AHXT/S - T/1S
-
Unladen weight
1 415 - 1 428 - 1 430
1 474 - 1 476
- Kerb wei
ght *
1 490 - 1 503 - 1 505
1 549 - 1 551
- Gross vehicle wei
ght (GV W)
2 030 - 2 200 - 2 2502 200 - 2 280
- Gross train weight (GT W)
on a 12% gradient3 530 - 3 560 - 3 650 3 580 - 3 580
- Braked trailer
(within GTW limit) on a 10% or 12% gradient 1 500 - 1 450 - 1 400 1 380 - 1 300
- Braked trailer **
(with load transfer with the GTW limit)
1 700 - 1 750 - 1 7001 680 - 1 600
- Unbraked trailer
745 - 750 - 750
750 - 750
-
Recommended nose weight
70 - 70 - 7070 - 70
