Page 31 of 338
32
I
I N S T R U M E N T S a n d C O N T R O L S
Service indicator zero reset Engine oil level indicator
After each service, the service indi-
cator must be reset to zero.
The procedure for resetting to zero
is as follows:
switch off the ignition,
press and hold the trip distance
recorder zero reset button,
switch on the ignition; the distance
recorder display begins a count-
down,
when the display indicates "=0" ,
release the button; the spanner
disappears. System which informs the driver
whether the engine oil level is cor-
rect or not.
This information is displayed for a
few seconds when the ignition is
switched on, after the service infor-
mation.
The level read will only be correct if
the vehicle is on level ground and
the engine has been off for more
than 15 minutes.
Oil level correct
Oil level low
T h i s i s i n d i c a t e d b y t h e fl a s h i n g o f
"OIL" , accompanied by an audible
signal and a message on the multi-
function screen.
I f t h e l o w o i l l e v e l i s c o n fi r m e d b y a
check using the dipstick, it is essential
that the level is topped up to prevent
damage to the engine. Oil level gauge fault
T h i s i s i n d i c a t e d b y t h e fl a s h i n g o f
"OIL
--" . Contact a CITROËN dealer.
Dipstick
Refer to the "Checks" section to lo-
c a t e t h e d i p s t i c k a n d t h e o i l fi l l e r c a p
on your engine. There are 2 marks on
the dipstick:
- A = max; never ex-
ceed this level,
- B = min; top up the
l e v e l v i a t h e o i l fi l l e r
cap, using the type
of oil suited to your
engine.
Following this operation, if you wish
to disconnect the battery, lock the
v e h i c l e a n d w a i t a t l e a s t fi v e m i n u t e s
for the zero reset to be taken into ac-
count.
Page 32 of 338
32
I
I N S T R U M E N T S a n d C O N T R O L S
Service indicator zero reset Engine oil level indicator
After each service, the service indi-
cator must be reset to zero.
The procedure for resetting to zero
is as follows:
switch off the ignition,
press and hold the trip distance
recorder zero reset button,
switch on the ignition; the distance
recorder display begins a count-
down,
when the display indicates "=0" ,
release the button; the spanner
disappears. System which informs the driver
whether the engine oil level is cor-
rect or not.
This information is displayed for a
few seconds when the ignition is
switched on, after the service infor-
mation.
The level read will only be correct if
the vehicle is on level ground and
the engine has been off for more
than 15 minutes.
Oil level correct
Oil level low
T h i s i s i n d i c a t e d b y t h e fl a s h i n g o f
"OIL" , accompanied by an audible
signal and a message on the multi-
function screen.
I f t h e l o w o i l l e v e l i s c o n fi r m e d b y a
check using the dipstick, it is essential
that the level is topped up to prevent
damage to the engine. Oil level gauge fault
T h i s i s i n d i c a t e d b y t h e fl a s h i n g o f
"OIL
--" . Contact a CITROËN dealer.
Dipstick
Refer to the "Checks" section to lo-
c a t e t h e d i p s t i c k a n d t h e o i l fi l l e r c a p
on your engine. There are 2 marks on
the dipstick:
- A = max; never ex-
ceed this level,
- B = min; top up the
l e v e l v i a t h e o i l fi l l e r
cap, using the type
of oil suited to your
engine.
Following this operation, if you wish
to disconnect the battery, lock the
v e h i c l e a n d w a i t a t l e a s t fi v e m i n u t e s
for the zero reset to be taken into ac-
count.
Page 33 of 338
33
I
I N S T R U M E N T S a n d C O N T R O L S
Total distance recorder
System which measures the total
distance travelled by the vehicle
during its life.
The total and trip distances are dis-
played for thirty seconds when the
ignition is switched off, when the
driver's door is opened and when
the vehicle is locked or unlocked.
Trip distance recorder
System which measures a distance
travelled during a day or other pe-
riod since it was reset to zero by the
driver.
With the ignition on, press the
button until zeros appear. Lighting rheostat
System for manual adjustment of the brightness of the instruments and controls in relation to the exteriorbrightness.
Activation
When the vehicle lighting is on:
press the button to change the brightness of the instruments and controls,
when the lighting reaches the minimum setting, release the button, then press again to in-crease it,
or
when the lighting reaches the maximum setting, release the but-ton, then press again to reduce it,
when the lighting reaches the level of brightness required, re-lease the button.
Deactivation
When the vehicle lighting is off, or
i n d a y m o d e o n v e h i c l e s fi t t e d w i t h
daytime running lamps, pressing the
button does not have any effect.
Page 34 of 338
34
II
M U L T I F U N C T I O N S C R E E N S
MULTIFUNCTION SCREEN A
Presentation
1. Time
2. Date and display zone
3. Ambient temperature
When the ambient temperature is
between +3 °C and -3 °C, the tem-
p e r a t u r e d i s p l a y fl a s h e s ( i c e r i s k ) .
The ambient temperature displayed
m a y b e g r e a t e r t h a n t h e a c t u a l t e m -
p e r a t u r e , i f t h e v e h i c l e i s p a r k e d i n
b r i g h t s u n l i g h t .
T h e d i s p l a y o f c e r t a i n t y p e s o f i n -
f o r m a t i o n i s s o m e t i m e s b y s c r o l l i n g
a n d s o m e t i m e s b y a l t e r n a t i o n .
A. A c c e s s t o t h e " M a i n M e n u "
B. S c r o l l i n g i n t h e s c r e e n m e n u s
C. S e l e c t i o n a n d c o n fi r m a t i o n i n t h e
m e n u s o f t h e f u n c t i o n c h o s e n o r
t h e v a l u e m o d i fi e d
D. C a n c e l l a t i o n o f t h e o p e r a t i o n o r
return to the previous display
E. S e l e c t i o n o f t h e t y p e o f i n f o r m a t i o n
to be displayed in zone 2 ( d a t e ,
r a d i o - C D a n d t r i p r e c o r d e r )
B or F. W i t h i n t h e m e n u s , c h o i c e
o f a c t i v a t i o n / d e a c t i v a t i o n o f
f u n c t i o n s a n d s e l e c t i o n o f
adjustments By pressing on the button
A , then
using button B , y o u h a v e a c c e s s t o
t h e f o l l o w i n g f u n c t i o n s :
Page 35 of 338
35
II
M U L T I F U N C T I O N S C R E E N S D i s p l a y i n g t h e l o g o f a l e r t s
Press on A .
Use B t o s e l e c t t h e s u b m e n u f o r
o p t i o n s . C o n fi r m w i t h t w o p r e s s e s
on C .
Y o u c a n c a n c e l t h e s t a r t o f t h e d i s -
play by pressing button E to abandon
and validating by pressing C .
Alerts signalled previously but not
r e s o l v e d , w i l l s c r o l l i n t h e d i s p l a y f o r
r e c a l l .
T o c l e a r t h e d i s p l a y i n g o f a n a l e r t ,
press D .
A d j u s t i n g t h e d a t e a n d t h e
t i m e
Press on A .
Use B t o s e l e c t t h e s u b m e n u f o r
d i s p l a y a d j u s t m e n t s , t h e n c o n -
fi r m b y p r e s s i n g C .
Press B t o s e l e c t w h a t y o u w a n t
t o m o d i f y : y e a r , m o n t h , d a y , h o u r ,
m i n u t e s , m o d e o f d i s p l a y .
M a k e y o u r a d j u s t m e n t b y p r e s s -
ing F . Y o u c a n c o n t i n u e y o u r a d -
j u s t m e n t s b y s e l e c t i n g a d i f f e r e n t
element by presses on B . W h e n
y o u h a v e fi n i s h e d y o u r a d j u s t -
ments, press C .
C o n f i g u r i n g t h e v e h i c l e
f u n c t i o n s
Press on A .
Use B t o s e l e c t t h e s u b - m e n u f o r
p e r s o n a l i s a t i o n c o n fi g u r a t i o n o f
y o u r v e h i c l e , t h e n c o n fi r m y o u r
c h o i c e w i t h a p r e s s o n C .
S e l e c t t h e f u n c t i o n t o b e c o n fi g -
ured by pressing B .
The system tells you whether
t h e f u n c t i o n s t a t u s i s a c t i v e o r i n -
a c t i v e . M o d i f y t h i s s t a t u s w i t h a
press on F .
Validate with a press on C . C h o o s i n g t h e l a n g u a g e
Press on A .
Use B t o s e l e c t t h e s u b m e n u f o r
l a n g u a g e s . C o n fi r m y o u r c h o i c e
with a press on C .
With presses on F , s e l e c t t h e
l a n g u a g e o f y o u r c h o i c e , t h e n
validate with a press on C .
C h o o s i n g t h e u n i t s
Press on A .
Press B t o s e l e c t t h e s u b - m e n u
f o r U n i t s . C o n fi r m y o u r c h o i c e
with a press on C .
Press B t o s e l e c t t h e t y p e o f u n i t
y o u w i s h t o m o d i f y ( T e m p e r a t u r e
o r F u e l C o n s u m p t i o n ) .
With presses on F , s e l e c t t h e
u n i t o f y o u r c h o i c e , t h e n v a l i d a t e
with a press on C .
T h i s c h o i c e c o n c e r n s a l l t h e i n f o r -
m a t i o n ( C o n s u m p t i o n - S p e e d ) a p -
p e a r i n g o n t h e s c r e e n s .
Page 36 of 338
36
II
M U L T I F U N C T I O N S C R E E N S
MULTIFUNCTION SCREEN C M a i n M e n u
Presentation
Radio-CD
( s e e " A u d i o a n d
T e l e m a t i c s " )
T r i p c o m p u t e r
T h i s p e r m i t s :
B l u e t o o t h
®
h a n d s - f r e e k i t
( s e e " A u d i o " a n d
T e l e m a t i c s )
Controls
1. Time
2. Ambient temperature
3. Date and display zone
When the ambient temperature is be-
tween +3 °C and -3 °C, the tempera-
t u r e d i s p l a y fl a s h e s ( r i s k o f i c e ) .
The ambient temperature displayed
m a y b e g r e a t e r t h a n t h e a c t u a l t e m -
p e r a t u r e , i f t h e v e h i c l e i s p a r k e d i n
b r i g h t s u n l i g h t .
I t i s r e c o m m e n d e d t h a t t h e d r i v e r
s h o u l d n o t m a n i p u l a t e t h e c o n t r o l s
w h i l e t h e v e h i c l e i s i n m o t i o n .
A. A c c e s s t o t h e " M a i n M e n u "
B. S c r o l l i n g i n t h e s c r e e n m e n u s
C. S e l e c t i o n a n d c o n fi r m a t i o n i n t h e
m e n u s o f t h e f u n c t i o n c h o s e n o r
t h e v a l u e m o d i fi e d
D. C a n c e l l a t i o n o f t h e o p e r a t i o n o r
return to the previous display
E. S e l e c t i o n o f t h e t y p e o f i n f o r m a -
tion to be displayed permanently
( d a t e , r a d i o - C D , t r i p c o m p u t e r )
o n t h e r i g h t o f t h e s c r e e n Press on the button
A to view the
" M a i n M e n u " o f t h e m u l t i f u n c t i o n
s c r e e n . T h i s m e n u g i v e s y o u a c c e s s
t o t h e f o l l o w i n g f u n c t i o n s :
- e n t e r i n g t h e d i s t a n c e t o y o u r destination,
- a c c e s s t o t h e l o g o f a l e r t s ( r e c a l l o f a l e r t s s i g n a l l e d p r e v i o u s l y ) ,
- a c c e s s t o t h e s t a t u s o f f u n c t i o n s , s u c h a s t h e a c t i v a t i o n / d e a c t i v a -
t i o n o f a u t o m a t i c h e a d l a m p s ,
a u t o m a t i c w i n d s c r e e n w i p e r s ,
E S P . . .
Page 37 of 338
37
II
M U L T I F U N C T I O N S C R E E N S
Personalisation -
C o n f i g u r a t i o n
T h i s p e r m i t s a c t i v a t i o n / d e a c t i v a t i o n
o f c e r t a i n f u n c t i o n s w h i c h m a y b e
present or not depending on the trim
l e v e l o f y o u r v e h i c l e :
- operation of the rear wiper,
- a u t o m a t i c g u i d e - m e - h o m e l i g h t i n g ,
- d i r e c t i o n a l h e a d l a m p s ,
- e l e c t r i c p a r k i n g b r a k e a u t o m a t i c f u n c t i o n s ( a p p l i c a t i o n / r e l e a s e ) ( d e -
p e n d i n g o n d e s t i n a t i o n c o u n t r y )
- d o o r s e l e c t i v i t y ,
- lighting of daytime-running lamps ( d e p e n d i n g o n c o u n t r y ) ,
- r e a r p a r k i n g a s s i s t a n c e ,
a n d s e t t i n g o f t h e :
- brightness intensity, time, date and units,
- s c r e e n l a n g u a g e . A c t i v a t i n g / d e a c t i v a t i n g
r e a r s c r e e n w i p e w h e n y o u
e n g a g e r e v e r s e g e a r
Press on A .
Use B t o s e l e c t " P e r s o n a l i s a t i o n -
C o n fi g u r a t i o n " , t h e n c o n fi r m y o u r
c h o i c e w i t h a p r e s s o n C .
T h e n s e l e c t " D e fi n e v e h i c l e p a -
r a m e t e r s " . C o n fi r m y o u r c h o i c e
with a press on C .
Using B , s e l e c t " P a r k i n g a s s i s t -
a n c e " . C o n fi r m y o u r c h o i c e w i t h
a press on C .
Then by pressing C , s e l e c t /
d e s e l e c t " A c t i v a t i o n o f r e a r w i p e r
i n r e v e r s e g e a r " t o a c t i v a t e / d e -
a c t i v a t e t h i s .
C o n fi r m w i t h "OK" o n t h e s c r e e n .
A c t i v a t i n g / d e a c t i v a t i n g
a u t o m a t i c g u i d e - m e - h o m e
l i g h t i n g
Press on A .
Use B t o s e l e c t " P e r s o n a l i s a t i o n -
C o n fi g u r a t i o n " , t h e n c o n fi r m y o u r
c h o i c e w i t h a p r e s s o n C .
T h e n s e l e c t " D e fi n e v e h i c l e p a -
r a m e t e r s " . C o n fi r m y o u r c h o i c e
with a press on C .
Using B , s e l e c t " L i g h t i n g a n d
s i g n a l l i n g " . C o n fi r m y o u r c h o i c e
with a press on C .
Then by pressing C , s e l e c t / d e s e -
l e c t " G u i d e - m e - h o m e h e a d l a m p s "
t o a c t i v a t e / d e a c t i v a t e t h i s . A f t e r
a c t i v a t i o n , c h o o s e i t s d u r a t i o n :
press on C , then use B t o s e l e c t
the duration and then press on C .
C o n fi r m w i t h "OK" o n t h e s c r e e n .
A c t i v a t i n g / d e a c t i v a t i n g
X e n o n d u a l - f u n c t i o n
d i r e c t i o n a l h e a d l a m p s
Press on A .
Use B t o s e l e c t " P e r s o n a l i s a t i o n -
C o n fi g u r a t i o n " , t h e n c o n fi r m y o u r
c h o i c e w i t h a p r e s s o n C .
T h e n s e l e c t " D e fi n e v e h i c l e p a -
r a m e t e r s " . C o n fi r m y o u r c h o i c e
with a press on C .
Using B , s e l e c t " D r i v i n g a s s i s t -
a n c e " . C o n fi r m y o u r c h o i c e w i t h
a press on C .
Then by pressing C , s e l e c t / d e s e -
l e c t " D i r e c t i o n a l h e a d l a m p s " t o
a c t i v a t e / d e a c t i v a t e t h e m .
C o n fi r m w i t h "OK" o n t h e s c r e e n .
Page 38 of 338
38
II
M U L T I F U N C T I O N S C R E E N S
A c t i v a t i n g / d e a c t i v a t i n g
e l e c t r i c p a r k i n g b r a k e
a u t o m a t i c f u n c t i o n s
( a p p l i c a t i o n / r e l e a s e ) *
Press on A .
Use B t o s e l e c t " P e r s o n a l i s a t i o n -
C o n fi g u r a t i o n " , t h e n c o n fi r m y o u r
c h o i c e w i t h a p r e s s o n C .
T h e n s e l e c t " D e fi n e v e h i c l e p a -
r a m e t e r s " . C o n fi r m y o u r c h o i c e
with a press on C . A c t i v a t i n g / d e a c t i v a t i n g d o o r
s e l e c t i v i t y
Press on A .
Use B t o s e l e c t " P e r s o n a l i s a t i o n - C o n fi g u r a t i o n " , t h e n c o n fi r m y o u r
c h o i c e w i t h a p r e s s o n C .
T h e n s e l e c t " D e fi n e v e h i c l e p a -
r a m e t e r s " . C o n fi r m y o u r c h o i c e
with a press on C .
Using B , s e l e c t " A c c e s s t o t h e v e -
h i c l e " . C o n fi r m y o u r c h o i c e w i t h a
press on C .
Then by pressing C , s e l e c t t h e
l e v e l o f v e h i c l e a c c e s s d e s i r e d .
C o n fi r m w i t h "OK" o n t h e s c r e e n . A d j u s t i n g t h e d a t e a n d t i m e
Press on A .
Use B t o s e l e c t " P e r s o n a l i s a t i o n - C o n fi g u r a t i o n " , t h e n c o n fi r m y o u r
c h o i c e w i t h a p r e s s o n C .
S e l e c t " D i s p l a y c o n fi g u r a t i o n " u s -
ing B . C o n fi r m w i t h a p r e s s o n C .
S e l e c t " D a t e a n d t h e t i m e a d j u s t -
m e n t " u s i n g B . C o n fi r m w i t h a
press on C .
Press B t o s e l e c t t h e v a l u e s y o u
w i s h t o m o d i f y . C o n fi r m y o u r
c h o i c e w i t h a p r e s s o n C .
M a k e y o u r a d j u s t m e n t s b y p r e s s -
ing B , c o n fi r m i n g e a c h a d j u s t -
m e n t c h o i c e b y p r e s s i n g C .
C o n fi r m w i t h "OK" o n t h e s c r e e n .
Using B , s e l e c t " D r i v i n g a s s i s t -
a n c e " . C o n fi r m y o u r c h o i c e w i t h
a press on C .
Then by pressing C , s e l e c t /
d e s e l e c t " A u t o m a t i c h a n d b r a k e "
t o a c t i v a t e / d e a c t i v a t e t h e e l e c t r i c
p a r k i n g b r a k e a u t o m a t i c f u n c -
t i o n s ( a p p l i c a t i o n / r e l e a s e ) .
C o n fi r m w i t h "OK" o n t h e s c r e e n .
* D e p e n d i n g o n c o u n t r y .
Page 39 of 338
39
II
M U L T I F U N C T I O N S C R E E N S
C h o o s i n g t h e u n i t s
Press on A .
Use B t o s e l e c t " P e r s o n a l i s a t i o n - C o n fi g u r a t i o n " , t h e n c o n fi r m y o u r
c h o i c e w i t h a p r e s s o n C .
S e l e c t " D i s p l a y c o n fi g u r a t i o n " u s -
ing B . C o n fi r m w i t h a p r e s s o n C .
T h e n s e l e c t " C h o i c e o f u n i t s " .
C o n fi r m y o u r c h o i c e w i t h a p r e s s
on C . C h o o s i n g t h e l a n g u a g e
Press on A .
Use B t o s e l e c t " P e r s o n a l i s a t i o n -
C o n fi g u r a t i o n " , t h e n c o n fi r m y o u r
c h o i c e w i t h a p r e s s o n C .
S e l e c t " C h o i c e o f l a n g u a g e " u s -
ing B . C o n fi r m w i t h a p r e s s o n C .
Using B , s e l e c t t h e l a n g u a g e
a n d v a l i d a t e y o u r c h o i c e w i t h a
press on C .
C o n fi r m w i t h "OK" o n t h e s c r e e n .
Using B , s e l e c t t h e u n i t y o u w i s h
t o m o d i f y ( T e m p e r a t u r e o r F u e l
c o n s u m p t i o n ) , t h e n c o n fi r m b y
pressing C .
C o n fi r m w i t h "OK" o n t h e s c r e e n .
T h i s c h o i c e a f f e c t s a l l t h e i n f o r m a t i o n
( F u e l c o n s u m p t i o n - S p e e d ) a p p e a r -
i n g o n t h e s c r e e n s .
Page 40 of 338
40
II
M U L T I F U N C T I O N S C R E E N S
NAVIDRIVE MULTIFUNCTION COLOUR SCREEN
Presentation
1. Ambient temperature
2. D i r e c t o r y
3. Date
4. Telephone
5. Time
When the ambient temperature is be-
tween +3 °C and -3 °C, the tempera-
t u r e d i s p l a y fl a s h e s ( r i s k o f i c e ) .
The ambient temperature displayed
m a y b e g r e a t e r t h a n t h e a c t u a l t e m -
p e r a t u r e , i f t h e v e h i c l e i s p a r k e d i n
b r i g h t s u n l i g h t .
I t i s r e c o m m e n d e d t h a t t h e d r i v e r
s h o u l d n o t o p e r a t e t h e c o n t r o l s
w h i l e t h e v e h i c l e i s i n m o t i o n . Controls
M a i n M e n u
T r a f fi c I n f o r m a t i o n
N a v i g a t i o n / G u i d a n c e
Map
A u d i o F u n c t i o n s
T e l e m a t i c s
C o n fi g u r a t i o n ,
for adjusting various parame-
t e r s ( d a t e , t i m e , u n i t s )
Video
V e h i c l e D i a g n o s t i c s
A. A c c e s s t o t h e " M a i n M e n u "
B. S c r o l l i n g i n t h e s c r e e n m e n u s
C. S e l e c t i o n a n d c o n fi r m a t i o n i n t h e
m e n u s o f t h e f u n c t i o n c h o s e n o r
t h e v a l u e m o d i fi e d
D. C a n c e l l a t i o n o f t h e o p e r a t i o n o r
return to the previous display
E. S e l e c t i o n o f t h e t y p e o f i n f o r m a -
tion to be displayed permanently
( d a t e , r a d i o - C D , t r i p c o m p u t e r )
o n t h e r i g h t o f t h e s c r e e n Press on the button
A to view the
" M a i n M e n u " o f t h e m u l t i f u n c t i o n
s c r e e n .
T h i s m e n u g i v e s y o u a c c e s s t o t h e
f o l l o w i n g f u n c t i o n s ( s e e " N a v i D r i v e
I n s t r u c t i o n s " ) :
