Page 111 of 352
VI
109
FITTINGS
AIRCRAFT-STYLE REARTABLES
Rear table stowed
Rear table opened
The backrests of the front seats are
fi tted with aircraft-style tables. These
incorporate a cup-holder A
and a
retaining strap B
, for the placing of
objects.
)
Pull the table downwards to
open.
)
To stow the table, raise it until
the latch locks.
For safety reasons, these tables col-
lapse downwards if excessive pressure
is exerted on them.
Reading lamps C
may be fi tted in
the front seat backrests, behind the
tables. They illuminate the surface
of the tables without disturbing the
other passengers.
They can be used only while the table
is down.
)
Press the "on/off" button to turn
the lamp on or off.
SECOND ROW FOOTWELL
Depending on the confi guration, the
vehicle has one or two storage com-
partments under the footwell, located
between the seats of the fi rst and
second rows. They can be accessed
via clipped fl aps with a handle A
.
The compartment on the left-hand
side may contain the temporary
puncture repair kit and the tool kit
may be stored in the compartment
on the right-hand side. In this case
the fl ap is secured by means of a
screw B
. To gain access to the com-
partment, turn the screw a quarter
turn anticlockwise using a coin.
On vehicles fi tted with pneumatic sus-
pension, the left-hand fl ap is locked.
Individual reading lamps
Page 112 of 352
VI
110
FITTINGS
SIDE BLINDS(C4 PICASSO)
Fitted on the 2nd row rear windows,
these protect young children from
the sun's rays.
)
Pull on the tab A
and anchor the
blind on the hook B
.
SIDE BLINDS(GRAND C4 PICASSO)
Fitted on the 2nd and 3rd row rear
windows, these protect young children
from the sun's rays.
Second row
)
Pull on the tab A
and anchor the
blind on the hooks B
.
Third-row
The blinds are fi tted in the third-row
trim panels.
)
Pull on the tab and anchor the
blind on the hooks.
(GRAND C4 PICASSO)
)
Pull on the tab and anchor the
blind on the hooks.
Do not attach or suspend heavy
objects in the environs of the sun
visors (blind housings and hooks...).
THIRD ROW STORAGE
Third-row passengers may have
storage pockets in the side panel
and each of them will have a cup-
holder (7 seater model).
Page 113 of 352
VI
111
FITTINGS
LUGGAGE COVER(C4 PICASSO)
This is in two parts.
Rear parcel shelf
Removal
)
Unhook the cords.
)
Push upwards, then lift on each
side of the luggage cover.
Front parcel shelf
Removal
)
First remove the rear shelf.
)
Push upwards, then lift on each
side.
Fitting
)
Offer up the shelf to its housings
and push fi rmly down until it en-
gages.
)
For the shelf to rise with the tail-
gate, take the cords and attach
them on the tailgate.
Refi tting
)
Direct the fl ap downwards.
)
Offer up the shelf to its housings
and push fi rmly down until it en-
gages.
Page 114 of 352
VI
112
FITTINGS
MODUBOX (C4 PICASSO)
Equipment for use both inside the
vehicle and away from the vehicle.
It comprises a shopping trolley and
a fl exible bag (insulated on some
versions) which can be used inde-
pendently of each other depending
on your needs (by detaching the fas-
tenings on each side at the top and
bottom).
To use
)
Unhook the red strap to free the
Modubox.
)
Unhook the black strap then
press on the round buttons on
either side of the Modubox si-
multaneously to unfold it.
Use outside the vehicle
Stowing inside the vehicle
)
Perform the operations in re-
verse to fold and stow inside the
vehicle.
)
If you have used your Modubox
away from the vehicle, take care
to reposition it correctly in the
housings provided for this pur-
pose.
BAG HOOK
LUGGAGE COVER ROLLER(GRAND C4 PICASSO)
Position 1
5-seat confi guration; installed be-
hind the second-row seats, with the
third-row seats folded away.
)
Press on the recess on the left
hand side of the Modubox to
raise (or lower) the handle.
Located on the left-hand interior wall
of the boot, this can be used to se-
cure shopping bags.
Installing the roller
)
Position the left-hand end of the
roller in notch A
.
)
Compress the right-hand end of
the roller and place it in notch B
.
)
Pull out the blind until it reaches
the boot pillars.
)
Insert the guides of the blind into
the rails on the pillars.
Removing the roller
)
Carry out these operations in
reverse order.
Page 115 of 352
VI
11 3
FITTINGS
The roller has a moving fl ap to
avoid interference with the second-
row passengers when the seats
are in the "reclined" position.
)
Engage the lug on the left of the
roller in notch C
.
)
Pass the right-hand end above
the third-row armrest.
)
Engage the lug in notch D
.
)
Pull the seat belt(s) so that they
reel out without locking.
)
Pull out the blind and engage
the guides into the rails on the
pillars.
)
Lock the seat(s) in position.
Installing the roller
)
Reel in the blind, then remove
the roller from its initial position.
)
Position the roller, with the blind
pull bar uppermost, fl ap down-
ward.
)
Fold the concertina boards.
Removing the roller
)
Push the fl ap towards the seat
backrest.
)
Lift the concertina board by tak-
ing it at the side, then position it
vertically.
)
Release the seat by pulling the
strap E
.
)
Push the backrest towards the front.
)
Proceed in reverse order to in-
stalling.
Position 3
7-seat confi guration; stowed behind
the third row seats when these are
folded away.
Installing the roller
)
Fold the concertina boards.
)
Position the roller, with the blind
pull bar uppermost, fl ap down-
ward.
)
Engage the lug on the left of the
roller in notch C
.
)
Pass the right-hand end above
the third-row armrest.
)
Engage the lug in notch D
.
Removing the roller
)
Proceed in reverse order to in-
stalling.
Position 2
7-seat confi guration; installed be-
hind the third-row seats when these
are folded away. This position con-
ceals objects stowed in the boot
from outside view.
The roller can only be stored when
the seats are folded away.
You can position the concertina
board vertically to lodge a bulky ob-
ject in the boot well.
Page 116 of 352
VI
114
FITTINGS
CARGO NET(GRAND C4 PICASSO)
This enables you to maximise the
vehicle’s loadspace.
It retains objects, preventing them
from sliding towards the front of the
passenger compartment.
You insert it under the luggage-
cover roller securing it on the
third-row side mouldings.
Position 1
5-seat confi guration: installed behind
the second row.
Installing the roller
)
Remove the protective covers
located under the blind roller
notches.
)
Position the roller under that of
the luggage-cover blind.
)
Raise the fl ap on the blind, posi-
tioning it on top of the blind.
)
Deploy the net, passing it be-
tween the rollers and the seats.
)
Pull the net upwards.
)
Anchor it to the roof by means of
the fi xing points (after you have
removed their covers).
Removing the roller
)
Carry out these operations in re-
verse order.
Position 2
2-seat confi guration; installed behind
the fi rst row.
Removing the roller
)
Carry out these operations in re-
verse order.
Installing the roller
)
With the second-row seats folded
away, remove the covers of the
Isofi x mounting points located on
the seat backrests.
)
Secure the roller on the Isofi x
mounting points.
)
Deploy the net and pull it up-
wards.
)
Anchor it to the roof by means of
the fi xing points (after you have
removed their covers).
Page 117 of 352
VI
11 5
FITTINGS
LUGGAGE ANCHORING
RINGS (C4 PICASSO)
There are 4 anchoring rings in the
boot to enable you to secure your
luggage:
- 1, 2, 3
and 4
on the boot fl oor.
LUGGAGE ANCHORINGRINGS (GRAND C4 PICASSO)
There are 4 anchoring rings in the
boot to enable you to secure your
luggage:
- 1, 2, 3
and 4
on the boot fl oor.
For reasons of safety in the event of
sudden braking, it is recommended
that you place heavy objects on
the fl oor as:m! close as possible
to the backrests of the second-row
seats.
LUGGAGE RETAINING NET (GRAND C4 PICASSO)
Attached to the luggage anchoring
rings, it allows objects to be held on
the boot fl oor.
Page 118 of 352
VI
116
FITTINGS
TORCH
This is a portable lamp, fi tted in the
boot wall, which can be used to illu-
minate the boot or as a torch.
Grand C4 Picasso
C4 Picasso
Boot lamp
The boot lamp A
comes on automat-
ically when the boot is opened and
switches off automatically when the
boot is closed.
Various lighting durations are avail-
able:
- ignition off, approximately ten minutes,
- in energy economy mode, approxi-
mately thirty seconds,
- engine running, no limit.
Operation of the torch
This torch operates with NiMH re-
chargeable batteries.
It has a battery life of approximately
45 minutes and recharges while you
are driving.
)
Extract the torch from its location
pulling it upwards, as indicated
by the arrow.
)
Press the switch B
, located on
the back, to switch the torch on
or off.
)
Unfold the support C
, located on
the back, to set down and raise
the torch; for example, when
changing a wheel.
Stowing the torch
)
Put the torch back in place in its
location, starting at the bottom.
If you have forgotten to switch off
the torch, this switches it off auto-
matically. Observe the polarities when fi tting
the batteries.
Never replace the rechargeable
batteries with normal single-use
batteries.
For replacement of the batteries,
see the "Practical information -
Changing a bulb" section.
It the torch is not engaged correctly,
it may not charge and may not come
on when the boot is opened.
Using the torch
Page 119 of 352
VII
11 7
CHILD SAFETY
*
The rules for carrying children are
specifi c to each country. Refer to the
current legislation in your country.
GENERAL POINTS RELATINGTO CHILD SEATS
Although one of CITROËN's main
criteria when designing your vehicle,
the safety of your children also de-
pends on you.
For maximum safety, please observe
the following recommendations:
- in accordance with European
regulations, all children under
the age of 12 or less than one
and a half metres tall must
travel in approved child seats
suited to their weight
, on seats
fi tted with a seat belt or ISOFIX
mountings * ,
- statistically, the safest seats in
your vehicle for carrying chil-
dren are the rear seats,
- a child weighing less than 9 kg
must travel in the "rearwards-
facing" position both in the
front and in the rear.
CITROËN recommends
that chil-
dren should travel in the rear seats
of your vehicle:
- "rearwards-facing"
up to the
age of 2,
- "forwards-facing"
over the
age of 2.
CHILD SEAT IN THE FRONT
"Rearwards-facing"
When a "rearwards-facing" child seat
is installed on the front passenger
seat
, it is essential that the passenger
airbag is deactivated. Otherwise, the
child would risk being seriously in-
jured or killed if the airbag were to
infl ate
.
Intermediate longitudinal
position
"Forwards-facing"
When a "forwards-facing" child seat
is installed on the front passenger
seat
, adjust the vehicle's seat to the
intermediate longitudinal position
with the seat back upright and leave
the passenger airbag activated.
Page 120 of 352
VII
118
CHILD SAFETY
Passenger airbag OFF
Refer to the advice given on the label
present on both sides of the passen-
ger's sun visor.
To assure the safety of your child, you must deactivate the passenger's front
airbag when you install a child seat in the rearwards facing position on the
front passenger's seat.
Otherwise, there is a risk that the child could be seriously injured or killed if
the airbag were deployed.
