7-inch touch screen tablet
The 7-inch touch screen tablet gives access to:
-  t he   heating/air   conditioning   controls,
-

m
enus   for   adjusting   settings   for   vehicle
f

unctions   and   systems,
-

a
udio   and   display   configuration   menus,
-

a
udio   system   and   telephone   controls   and
t

he   display   of   associated   information,
and,
  depending   on   equipment,   allows:
-

t
he   display   of   alert   messages   and   the
v

isual
 par
king
 s
ensors
 in
formation,
-

t
he   permanent   display   of   the   time   and   the
a

mbient   temperature   (a   blue   warning   lamp
a

ppears   when   there   is   a   risk   of   ice),
-

a
ccess   to   the   controls   for   the   navigation
s

ystem   and   Internet   services,   and   the
d

isplay   of   associated   information.
For reasons of safety, the driver
should only carr y out operations
that require close attention, with the
vehicle stationary.
Some
  functions   are   not   accessible
w

hen
 d
riving.General operation
Recommendations
It is necessary to press firmly, particularly for "flick"   gestures   (scrolling   through   lists,   moving
t

he
 m
ap...).
A
  light   wipe   is   not   enough.
The
  tablet   does   not   recognise   pressing   with
m

ore   than   one   finger.
This
  technology   allows   use   at   all   temperatures
a

nd   when   wearing   gloves.
Do
  not   use   pointed   objects   on   the   touch   screen
t

ablet.
Do
  not   touch   the   tablet   screen   with   wet   hands.
Uses a soft clean cloth to clean the tablet touch
screen. Use
  this   button   to   go   to   the
s

econdary
 pag
e.
Use this button to return to the
primary
 pag

e.
Use this button for access to
additional
  information   and   to   the
s

ettings   for   certain   systems.
Use
  this   button   to   confirm.
Use
  this   button   to   quit.
Principles
Use the buttons on either side of the screen for   access   to   the   menus,   then   press   the   virtual
b

uttons   in   the   touch   screen.
Each
  menu   is   displayed   over   one   or   two   pages
(

primary   page   and   secondary   page).
After
  a   few   moments   with   no   action   on
t

he   secondary   page,   the   primary   page
i

s   displayed   automatically.
1
Monitoring

12
1. access the the "Air conditioning"   menu. A
llows   adjustment   of   the   various   settings
f

or   temperature,   air   flow...   See   the   sections
o

n   "Heating",   "Manual   air   conditioning"   and
"

Automatic   air   conditioning".
2.


a
c
cess to the " Driving assistance "
  menu.
 A

llows   certain   functions   to   be   switched   on
a

nd   off   and   their   settings   adjusted.
3.


a
c
cess to the " Media"
  menu.
 S

ee   the   Audio   and   telematics   section.
4.


a
c
cess to the " Navigation"*
  menu.
 S

ee   the   Audio   and   telematics   section.
Touch screen tablet menus
5. access to the "Configuration"   menu. A
llows   configuration   of   the   display   and   the
s

ystem.
6.


a
c
cess to the " Connected services "*
  menu.
  S

ee   the   Audio   and   telematics   section.
7.


a
c
cess to the " Telephone"
  menu.
  S

ee   the   Audio   and   telematics   section.
*
  Depending   on   equipment.
8.
 V

olume   /   mute.
 S

ee   the   "Audio   and   telematics"   section.
Monitoring

13
State of adjustable systems
Some systems have a dedicated button, to which   is   associated   an   indicator   lamp.
Illumination
  of   this   lamp   indicates   whether   the
s

ystem   is   activated   or   deactivated   compared   to
t

he   default   (factory)   setting.
Green
  indicator:   you   have   switched   on   the
c

orresponding   system.
Orange
  indicator:   you   have   switched   off   the
c

orresponding   system. Operating fault
In the event of a fault with one of these
systems,
  the   indicator   lamp   in   the   activation/
deactivation
  button   flashes   for   a   few   moments.
An
  alert   symbol   is   displayed   to   the   right   of   the
b

utton   symbol,   then,   in   the   case   of   systems   that
a

re   activated   by   default,   the   orange   indicator
c

omes   on   permanently.
Every
  time   the   button   is   pressed,   the   indicator
f

lashes   for   a   few   moments.Example:
●

F
unction   not   activated.
●

O
perating   fault   alert.
then
"Driving assistance" menu
1
Monitoring

19
ButtonCorresponding function Comments
System settings Choice
  of   units:
-

t
emperature   (°Celsius   or   °Fahrenheit)
-

d
istance   and   fuel   consumption   (l/100   km,   mpg   or   km/l).
Time/Date Setting
  the   date   and   time.
Languages Choice
  of   language   used   for   the   touch   screen   tablet   and   the   type   2   instrument   panel:   French,
E

nglish,   Italian,   Spanish,   German,   Dutch,   Portuguese,   Polish,   Turkish,   Russian.
Choice
  of   language   used   for   the   touch   screen   tablet   only:   Serb,   Croat,   Hungarian.
Screen settings Adjustment
  of   the   display   settings   (scrolling   of   text,   animations...)
Calculator Displays
  the   calculator.
Calendar Displays
  the   calendar.
1
Monitoring

20
Type 1 instrument panel
1. Rev  counter   (x   1   000   rpm   or   tr/min),  g
raduation   according   to   engine   (petrol   or
D

iesel).
2.
 G

ear   efficiency   indicator,   selector   position
a

nd   gear   for   an   electronic   or   automatic
g

earbox.
3.
 D

igital   speedometer   (mph   or   km/h).
4.
 C

ruise   control   or   speed   limiter   settings.
Dials and screens
5. Fuel  gauge.
6. S ervice   indicator,   then   total   mileage
r

ecorder   (miles   or   km).
 T

hese   functions   are   displayed   in   turn   when
t

he   ignition   is   switched   on.
7.
 T

rip   mileage   recorder   (miles   or   km).
8.
 R

epeat   of   air   conditioning   settings.A. M
ain   lighting   dimmer   buttons.
B. R ecall   servicing   information.
 R

eset   the   function   selected   to   zero
(service
  indicator   or   trip   recorder).
Control buttons
Monitoring

21
This instrument panel is presented in the form of a 12-inch panoramic HD screen.
I t   can   be   personalised.   Depending   on   the   display   mode   selected,   some   information   can   be   hidden.
See
  the   "Personalisation   of   the   instrument   panel"   section.
Type 2 instrument panel
1. Rev  counter   (x   1000   tr/min   or   rpm)  (
"DIALS"   mode).
2.
 G

ear   efficiency   indicator,   position   of
t

he   selector   lever   and   the   gear   with   an
e

lectronic   or   automatic   gearbox.
3.
 D

igital   speedometer   (mph   or   km/h).
4.
 C

ruise   control   or   speed   limiter   setting.
5.
 F

uel   gauge. A. R
ecall   servicing   information. R
ecall   the   remaining   driving   range   with   the
S

CR   system   and   the   AdBlue
® additive. R
eset

the

function

selected

to   zero
(service

indicator

or

trip

recorder).
Control button
Dials and screens
6. Total   distance   recorder   (miles   or   km).
7. T rip   distance   recorder   (miles   or   km).
8.
 R

epeat   of   the   air   conditioning   settings.
9.
 R

epeat   of   the   current   media   or   telephone
i

nformation.
10.
 R

epeat   of   the   navigation   information.
11.
 A

mbient   temperature   (a   blue   warning   lamp
c

omes   on   if   there   is   a   risk   of   ice).
1
Monitoring

22
You can modify the appearance of the instrument   panel,   by   choosing:
-

a
  colour   scheme,
-

a
  display   mode.
Choosing the language
This depends on the setting in the touch screen tablet.
Certain
  languages   are   not   available   for   the   type   2
 i

nstrument   panel;   English   is   selected   by   default.Each
  mode   corresponds   to   the   type   of
i

nformation   displayed   in   the   configurable   area.
Personalisation of the
type
2 instrument panel
Choice of display mode
- "DIALS":   permanent   display   of   the  t
rip   computer,   rev   counter   and   coolant
t

emperature
 i
ndicator.
Display zones
Whatever the display mode or colour scheme chosen,   the   instrument   panel   contains
-

a
  fixed   display   zone   A
w
ith:
●

t
he   speedometer,
●

t
he   warning   lamps,
●

t
he   fuel   gauge,
●

t
he   various   repeated   information   and
a

lert
 m
essages.
-

a
  configurable   display   zone   B.
Most
  of   the   warning   lamps   do   not   have   a   fixed
p

osition.
The
  warning   and   indicator   lamps   in   the   right
h

and   column   are   displayed   from   top   to   bottom
i

n   order   of   importance.
For
  certain   functions   that   have   indicator   lamps
f

or   both   on   and   off,   there   is   just   one   dedicated
lo

cation.
Choosing a colour scheme
It depends on the colour scheme chosen for the   touch   screen   tablet.   To   modify   it   with   the
v

ehicle
 s
tationary:
F

s
elect the " Configuration "
  menu   of   the
t

ouch screen tablet,
F

p
ress the " Color schemes " button,
F

c
hoose   a   colour   scheme,
F

c
onfirm.
 T

he   system   restarts   to   take   account   of   the
m

odifications   to   the   touch   screen   tablet
a

nd   the   instrument   panel.
Monitoring

23
- "MEDIA":  display   of   information   related   to  t
he   media   being   played   or   the   radio.-
 " NAVIGATION":   display   of   information  r
elated   to   the   navigation   in   progress
(map
  and   instructions).-
 " PHOTOS":   display   of   the   photo   selected  i
n   the   "Media"   menu   of   the   touch   screen
t

ablet.
1
Monitoring
