Page 5 of 316
CONTENTS
3
Direction indicators 126Hazard warning lamps 126Horn 126Tyre under-infl ation detection 127Braking assistance systems 128Trajectory control systems 129Emergency or assistance call 130Front seat belts 131Airbags 134
8 - SAFETY 126 Î137
Electric parking brake 138Manual parking brake 145Manual gearbox 145Gear effi ciency indicator 1466-speed electronic gearbox system 147Automatic gearbox 150Hill start assist 153Stop & Start 154
Blind spot sensors 157Speed limiter 161Cruise control 163Parking space sensors 165Parking sensors 167
9 - DRIVING 138 Î168
Bonnet 170Running out of fuel (Diesel) 171Petrol engines 172Diesel engines 173Checking levels 174Checks 176
10 - CHECKS 169 Î 177
Temporary puncture repair kit 178Changing a wheel 183Changing a bulb 187Changing a fuse 193Battery 197Energy economy mode 199Changing a wiper blade 200Very cold climate screen 200Towing the vehicle 201Towing a trailer 203Audio pre-equipment 204Accessories 205
11 - PRACTICAL
INFORMATION 178 Î 206
Petrol engines 207Petrol weights 209Diesel engines 211Diesel weights 212Dimensions 213Identifi cation markings 214
12 - TECHNICAL DATA 207 Î214
Emergency or assistance 215eMyWay 217Audio system 269
AUDIO and TELEMATICS 215 Î302
ALPHABETICAL
INDEX 307 Î 310
VISUAL
SEARCH 303 Î 306
Page 10 of 316
8
INTERIOR
Interior mood lighting
This dimmed lighting of the passenger
compartment improves visibility inside
the vehicle when the light is poor.
105
6-speed electronic gearbox system
This system offers driving combining
a fully automatic mode and a manual
mode.
147
Electric parking brake
It combines the functions of auto-
matic application on switching off the
engine and automatic release when
moving off.
Manual application and release re-
mains possible.
138
Audio and communication systems
These systems benefi t from the following
technologies: radio, CD player, USB player,
Bluetooth system, satellite navigation sys-
tem with colour screen, auxiliary sockets.
Radio
269
eMyWay satellite navigation system
217
Massage function
This system provides a lumbar mas-
sage for a period of 60 minutes.
The massage is done in 6 cycles of
10 minutes.
73
Page 12 of 316
10
INSTRUMENTS AND CONTROLS
1.
Steering wheel adjustment control.
2.
Steering mounted control paddles
for the 6-speed electronic gearbox
system.
3.
Lighting and direction indicators
control stalk.
4.
Speaker (tweeter).
5.
Windscreen demisting vent.
6.
Sunshine sensor.
7.
Passenger’s airbag.
8.
Glove box/Audio/video sockets/
Passenger’s airbag deactivation
switch/Fusebox.
9.
Bonnet release.
10.
Heated seat control.
11 .
Lumbar massage control.
12.
Electric parking brake.
13.
Gear lever, 6-speed electronic
gearbox system.
14.
Large multifunctional storage unit.
Page 13 of 316
11
FAMILIARISATION
A.
Rear view mirror.
B.
Emergency call/Warning lamps
display for front passenger’s airbag
and seat belt/Assistance call.
C.
Courtesy lamp/Map reading lamps/
Interior mood lighting.
D.
Microphone for audio and telematic
system.
E.
Panoramic sunroof blind control.
1.
Central adjustable air vents.
2.
Monochrome screen and small
storage box with fl ap or colour and
mapping screen.
3.
Audio or eMyWay satellite
navigation system.
4.
Central switch panel.
5.
Heating/air conditioning controls.
6.
USB port/auxiliary Jack socket and
cigarette lighter/12 V accessory
socket.
7.
Gear lever, manual or automatic
gearbox.
8.
Manual parking brake.
9.
Portable ashtray.
10.
Large open storage or front
armrest.
Page 22 of 316
20
DRIVING SAFELY
Electric parking brake
Manual application/release
Automatic application/release
Before leaving the ve-
hicle, check that the
brake warning lamp in
the instrument panel
and the P
warning lamp in the control
lever A
are on fi xed (not fl ashing)
.
Manual application
of the parking
brake is possible by pulling
the control
lever A
.
With the ignition on, manual release
of
the parking brake is possible by press-
ing the brake pedal
and pulling then
releasing
the control lever A
. Press the accelerator pedal and let the
clutch pedal up (manual gearbox), the
parking brake is released automatically
and progressively as you move off.
With the vehicle at rest, on switching off
the engine the parking brake is applied
automatically.
138
With the engine running, on
opening the driver’s door there
is an audible warning; apply the
parking brake manually.
Do not leave a child alone inside
the vehicle with the ignition on;
they might release the parking
brake. If you are towing a trailer or
caravan or if the slope might
vary (transport on a ferry, lorry,
towing...) make a maximum
manual application with a long
pull on the control lever A
to im-
mobilise the vehicle. If this warning lamp is on in the
instrument panel, the automa-
tic application/release
is de-
activated
; apply and release
the parking brake manually.
Page 23 of 316
21
FAMILIARISATION
DRIVING SAFELY
6-speed electronic gearbox
system
Displays in the instrument panel
Moving off
This 6-speed gearbox offers a choice
between the comfort of fully automatic
operation or the pleasure of manual
gear changing.
1.
Gear lever.
2.
Steering mounted "-"
control paddle.
3.
Steering mounted "+"
control paddle.
The gear engaged or the driving mode
selected appears on the instrument
panel screen.
N
.
Neutral.
R
.
Reverse.
1 to 6
.
Gears engaged.
AUTO
.
Automated mode.
)
Select position N
and press the
brake pedal fi rmly while starting the
engine.
)
Engage fi rst gear by pulling the gear
lever 1
towards position A
or M
,
or
Engage reverse by pushing the gear
lever 1 towards position R
.
)
Release the parking brake.
)
Take your foot off the brake pedal
then accelerate.
147
Page 24 of 316
22
DRIVING SAFELY
Automatic gearbox
This six-speed gearbox offers the
choice between the comfort of automa-
tic operation or the pleasure of manual
gear changing.
1.
Gear lever.
2.
"S"
(sport)
button.
3.
" 7
"
(snow)
button.
Displays in the instrument panel
Moving off
)
With your foot on the brake, select
position P
or N
.
)
Start the engine.
)
Then select position R
, D
or M
.
)
Take your foot off the brake pedal,
then accelerate away.
150
Hill start assist
The driving mode selected and/or the
gear engaged appear in the left hand
instrument panel screen.
P.
Park.
R.
Reverse.
N.
Neutral.
D.
Drive (automatic operation).
S.
S
port
programme.
7
.
Snow
programme.
1 to 6.
Gear engaged.
-.
Invalid value in manual operation. Your vehicle is fi tted with a system
which holds your vehicle stationary mo-
mentarily, the time to move your foot
from the brake to the accelerator, to
help with moving off on a gradient.
This function is only active when:
- the vehicle is completely stationary with
your foot on the brake pedal,
- certain conditions of gradient are
met,
- the driver’s door is closed.
153
Do not get out of the vehicle du-
ring the hill start assist tempo-
rary holding phase.
Page 25 of 316
23
FAMILIARISATION
DRIVING SAFELY
Stop & Start
Engine going into STOP mode
Engine going into START mode
Deactivation/Reactivation
In certain circumstances the STOP
mode may not be available; the "ECO"
warning lamp fl ashes for a few seconds
then goes off.
- with a manual gearbox;
at speeds
below 12 mph (20 km/h), when you
put the gear lever into neutral, and
you release the clutch pedal,
- with the 6-speed electronic gear-
box system;
at speeds below
5 mph (8 km/h), when you press the
brake pedal or you put the gear le-
ver in position N
.
154
- with a manual gearbox;
when you
depress the clutch pedal,
- with the 6-speed electronic gear-
box system;
●
with the gear lever in position A
or M
, when you release the brake
pedal,
●
or gear lever in position N
and
brake pedal released, when you
change to position A
or M
,
●
or engage reverse.
In certain circumstances, START mode
may engage automatically; the "ECO"
warning lamp fl ashes then goes off.
155
You can deactivate the system at any
time by pressing the "ECO OFF"
button;
the button’s warning lamp comes on.
155
The "ECO"
warning lamp goes
off and the engine restarts: The "ECO"
warning lamp comes
on in the instrument panel and the
engine is put into standby:
The system is reactivated auto-
matically every time you start the
engine with the key.
Before refuelling or doing any-
thing under the bonnet, you
must switch off the ignition with
the key.
Page 35 of 316
1
MONITORING
33
Engine oil
pressure
fi xed. There is a fault with the
engine lubrication system. You must stop as soon it is safe to do so.
Park, switch off the ignition and contact a
CITROËN dealer or a qualifi ed workshop.
Warning lamp
is on
Cause
Action/Observations
Battery charge
fi xed. The battery charging circuit
has a fault (dirty or loose
terminals, slack or cut
alternator belt, ...). The warning lamp should go off when the
engine is started.
If it does not go off, contact a CITROËN
dealer or a qualifi ed workshop.
Braking
fi xed, associated
with the STOP
warning lamp. The braking system fl uid level
has dropped signifi cantly. You must stop as soon as it is safe to do so.
Top up with brake fl uid recommended by
CITROËN.
If the problem persists, have the system
checked by a CITROËN dealer or a
qualifi ed workshop.
+
fi xed, associated
with the electric
parking brake
malfunction
warning lamp,
if the parking
brake is released. The braking system has a
fault. You must stop as soon as it is safe to do so.
Park, switch off the ignition and contact a
CITROËN dealer or a qualifi ed workshop.
+
fi xed, associated
with the STOP
and ABS warning
lamps. The electronic brake force
distribution (EBFD) system
has a fault. You must stop as soon as it is safe to do so.
Have it checked by a CITROËN dealer or
a qualifi ed workshop.
Page 36 of 316
1
MONITORING
34
Electric
parking brake
fl ashing. The application or release of
the electric parking brake was
interrupted. You must stop as soon as it is safe to do so.
Park on level ground, switch off the
ignition and contact a CITROËN dealer
or a qualifi ed workshop.
+
Electric
parking brake
malfunction
fi xed. The electric parking brake
has a fault. Automatic application/release is no
longer possible.
Contact a CITROËN dealer or a qualifi ed
workshop without delay.
The parking brake can be released
manually using the emergency release
procedure.
For more information on the electric
parking brake, refer to the "Driving"
section.
Warning lamp
is on
Cause
Action/Observations
Door(s) open
fi xed if the speed
is below 6 mph
(10 km/h).
A door or the boot is still
open. Close the door or boot.
fi xed and
accompanied by
an audible signal
if the speed is
above 6 mph
(10 km/h).
Seat belt not
fastened/
unfastened *
fi xed, then
fl ashing,
accompanied
by an increasing
audible signal. The driver or front passenger
has not buckled or has
unbuckled their seat belt. Pull on the belt in question and insert the
tongue in the buckle.
This warning repeats the seat belt
information given by the roof console
warning lamps. At least one rear passenger
has unbuckled their seat belt.
* According to country.
