1
MONITORING
28
TWO-TONE INSTRUMENT PANEL WITHOUT AUDIO SYSTEM
Dials and screens
1.
Rev counter (x 1 000 rpm or tr/min).
2.
Gear effi ciency indicator with man-
ual gearbox or gear lever position
and gear for the electronic gearbox
system or automatic gearbox.
3.
Cruise control or speed limiter setting.
4.
Digital speedometer (mph or km/h).
5.
Engine oil level indicator.
6.
Service indicator
(miles or km) then,
total mileage recorder.
These two functions are displayed
successively on switching on the
ignition.
Lighting dimmer setting (when making
an adjustment).
7.
Trip mileage recorder (miles or km).
8.
Fuel gauge and associated low fuel
level warning lamp ( a
or b
according
to version).
9.
Time.
Control buttons
A.
Lighting dimmer (available in night
mode).
B.
Reminder of servicing information
Reset service indicator or trip mile-
age recorder.
A
and B.
Setting the time and selecting
units.
Page 31 of 324
1
MONITORING
29
TWO-TONE INSTRUMENT PANEL WITH AUDIO SYSTEM
Dials and screens
A.
Lighting dimmer (available in night
mode).
B.
Reminder of the servicing information.
Reset the service indicator or the
trip mileage recorder.
7.
Service indicator
(miles or km) then,
total mileage recorder.
These two functions are displayed
successively on switching on the
ignition.
Lighting dimmer setting (when making
an adjustment).
8.
Trip mileage recorder (miles or km).
9.
Fuel gauge and associated low fuel
level warning lamp ( a
or b
according
to version).
10.
Range (miles or km).
Control buttons
1.
Rev counter (x 1 000 rpm or tr/min).
2.
Gear effi ciency indicator for manual
gearbox or gear lever position and
gear for the electronic gearbox sys-
tem or automatic gearbox.
3.
Analogue speedometer (mph or km/h).
4.
Cruise control or speed limiter setting.
5.
Digital speedometer (mph or km/h).
6.
Engine oil level indicator.
Page 32 of 324
1
MONITORING
30
CUSTOMISABLE COLOUR INSTRUMENT PANEL WITH AUDIO SYSTEM
1.
Rev counter (x 1 000 rpm or tr/min).
2.
Gear effi ciency indicator with man-
ual gearbox or gear lever position
and gear for the electronic gearbox
system or automatic gearbox.
3.
Analogue speedometer (mph or km/h).
4.
Cruise control or speed limiter setting.
5.
Digital speedometer (mph or km/h).
A.
Dial COLOUR: customisation of the
background colour of the dials.
B.
Screen COLOUR: customisation of
the background colour of the screens.
C.
Lighting dimmer (available in night
mode).
D.
Reminder of the servicing information.
Reset the service indicator or the
trip mileage recorder.
Dials and screens
6.
Engine oil level indicator.
7.
Service indicator
(miles or km) then,
total mileage recorder.
These two functions are displayed
successively on switching on the
ignition.
Lighting dimmer setting (when making
an adjustment).
8.
Trip mileage recorder (miles or km).
9.
Fuel gauge and associated low fuel
level warning lamp.
10.
Range (miles or km).
Control buttons
Page 33 of 324
1
MONITORING
31
CUSTOMISABLE COLOUR INSTRUMENT PANEL ASSOCIATED WITH THE SATELLITE NAVIGATION
SYSTEM
1.
Rev counter (x 1 000 rpm or tr/min).
2.
Gear effi ciency indicator with manual
gearbox or gear lever position and
gear for the electronic gearbox sys-
tem or automatic gearbox.
3.
Speedometer (mph or km/h).
Dials and screens
4.
Central screen associated with the
satellite navigation system.
5.
Fuel gauge and associated low fuel
level warning lamp.
6.
Trip mileage recorder (miles or km).
7.
Service spanner (if a service is due
or missed),
total mileage recorder.
(miles or km)
A.
Dial COLOUR: customisation of the
background colour of the dials.
B.
Screen COLOUR: customisation of
the background colour of the screens.
C.
Dashboard lighting dimmer (in night
mode).
D.
Start a manual test (procedure for
checking the status of systems and
display of vehicle alerts).
Reset service indicator or trip mileage
recorder.
Control buttons
Page 47 of 324
1
MONITORING
45
Service indicator
This information is displayed for a few
seconds after switching on the igni-
tion. It informs the driver when the next
service is due, in accordance with the
manufacturer's servicing schedule.
The point at which the service is due is
calculated from the last service indica-
tor zero reset. It is determined by two
parameters:
- the distance travelled,
- the time elapsed since the last service.
More than 1 800 miles (3 000 km)
remain before the next service is due
When the ignition is switched on, no
service information appears in the in-
strument panel central screen.
Between 600 miles (1 000 km) and
1 800 miles (3 000 km) remain
before the next service is due
For a few seconds after the ignition is
switched on, the spanner symbolising
the service operations comes on. The
distance recorder display line or a spe-
cifi c message in the instrument panel
central screen indicates the distance re-
maining before the next service is due.
For example:
1 700 miles (2 800 km)
remain before the next service is due.
For a few seconds after the ignition is
switched on, the screen indicates:
Less than 600 miles (1 000 km) remain
before the next service is due
Example:
560 miles (900 km) remain
before the next service is due.
For a few seconds after the ignition is
switched on, the screen indicates:
A few seconds after the ignition is
switched on, the spanner goes off
; the
distance recorder resumes its normal
operation. The screen then indicates
the total and trip distances.
A few seconds after the ignition is switched
on, the distance recorder resumes its normal
operation. The spanner remains on
to indi-
cate that a service must be carried out soon.
Page 48 of 324
1
MONITORING
46
Service overdue
For a few seconds after the ignition is
switched on, the spanner fl ashes
to
indicate that the service must be car-
ried out as soon as possible.
Example:
the service is overdue by
180 miles (300 km).
For a few seconds after the ignition is
switched on, the screen indicates:
A few seconds after the ignition is switched
on, the distance recorder resumes its nor-
mal operation. The spanner remains on
.
The distance remaining may be
weighted by the time factor, de-
pending on the type of driving.
Therefore, the spanner may also
come on if you have exceeded
the two year service interval.
Service indicator zero reset
This operation cannot be carried
out while a reminder of the ser-
vicing information is being dis-
played.
Following this operation, if you
wish to disconnect the battery,
lock the vehicle and wait at least
fi ve minutes for the zero reset to
be registered.
Recalling the service information
You can recall the service information
at any time.
)
Briefl y press the ".../000"
trip dis-
tance recorder zero reset button.
The service information is displayed
for a few seconds, in the total dis-
tance recorder line or in the instru-
ment panel central screen associated
with the satellite navigation system.
After each service, the service indicator
must be reset to zero.
The procedure for resetting to zero is
as follows:
)
switch off the ignition,
)
press and hold the ".../000"
trip dis-
tance recorder zero reset button,
)
switch on the ignition; the distance re-
corder display begins a countdown,
)
when the screen indicates "=/0"
and
the spanner disappears, release the
button.
Page 319 of 324
317
ALPHABETICAL INDEX
L Level, brake fl uid ........................178
Level, power steering fl uid .........178
Levels and checks ...............176-179
Lighting, guide-me home ......99, 100
Lighting, interior ..................108, 109
Lighting bulbs (replacement) ....191, 195
Lighting control stalk ..............96, 99
Lighting dimmer .................28-31, 49
Loading ................................26, 204
Load reduction mode .................203
Locating your vehicle ...................81
Locking from the inside ................84
Locking the boot ...........................89
Long objects, transporting .......... 117
LPG ............................................215
Luggage retaining strap ............. 118
M Main beam ...................96, 191, 193
Maintenance .................................26
Map reading lamps .....................108
Markings, identifi cation ...............221
Massage function ........................74
Mat ............................................. 116
Menu, main ................................280
Mini fuel level ...............................93
Mirror, rear view ...........................78
Mirrors, door ...................76, 77, 161
Misfuel prevention ........................95
Motorway function
(direction indicators) .................130
Mountings for ISOFIX seats .......126
MP3 CD ..............................285, 286
Music media players ..................260
N Navigation ..........................231, 232
Number plate lamps ...................196O Oil fi lter .......................................180
Oil level ................................44, 178
Opening the bonnet ....................174
Opening the boot ..........................89
Opening the doors ........................88
Opening the panoramic
sunroof blind ...............................92
Operation
indicator lamps .........35, 40, 41, 43
P Paint colour code .......................221
Panoramic glass sunroof ..............92
Parcel shelf, rear ........................ 119
Parking brake .....................149, 181
Parking brake, electric ........142, 145
Parking lamps ..............................99
Parking sensors, front ................172
Parking sensors, rear .................171
Parking space sensor ................169
Particle emission fi lter ........179, 180
Passenger compartment fi lter ....180
Personalisation .............................50
Player, CD MP3 ..................285, 286
Port, USB ........................... 112, 287
Priming the fuel system ..............175
Protecting
children ..... 121, 124, 126-128, 138
Puncture .....................................182
R Radio ..........................257, 258, 281
Radio pre-equipment ..................208
Rear screen (demisting) ...............70
Recharging the battery ...............201
Reduction of electrical load ........203
Reinitialising
the electric windows ...................90R Reinitialising the remote control ...82
Remote control .................79, 80, 83
Removable screen
(snow shield) ............................204
Removing a wheel ......................189
Removing the mat ...................... 116
Repair kit, puncture ....................182
Replacing bulbs ..................191, 195
Replacing fuses ..........................197
Replacing the air fi lter ................180
Replacing the oil fi lter .................180
Replacing the particle
emission fi lter ...........................180
Replacing the passenger
compartment fi lter ....................180
Replacing wiper blades ......107, 203
Resetting the service indicator .....46
Resetting the trip recorder ............48
Rev counter .............................28-32
Reversing lamps ........................195
Risk areas (update) ....................236
Roof bars ....................................204
Roof blind .....................................92
Routine checks ...................180, 181
Running out of fuel (Diesel) ........175
S Safety for children ................90, 129
Satellite navigation system ...........56
Screen, colour
and mapping ........56, 57, 229, 268
Screen,
monochrome ........51, 53, 280, 304
Screen, multifunction (with audio
equipment) .............51, 53, 56, 280
Screen menu map ...... 268, 304-306
Screenwash, front ......................106
Seat, rear bench ...........................75
