brake Citroen C5 2000 (DC/DE) / 1.G Owner's Manual
[x] Cancel search | Manufacturer: CITROEN, Model Year: 2000, Model line: C5, Model: Citroen C5 2000 (DC/DE) / 1.GPages: 259, PDF Size: 2.29 MB
Page 2 of 259
Downloaded from www.Manualslib.com manuals search engine PRESENTATION
THIS HANDBOOK summarises the specifications, adjustments, checks and special features of theCITROEN C5.
The handbook is divided into the following sections representing the main functions :
GENERAL - ENGINE - INJECTION - IGNITION - CLUTCH - GEARBOX - DRIVESHAFTS - AXLES - SUSPENSION - STEERING - BRAKES - HYDRAULICS -
ELECTRICAL - AIR CONDITIONING.
Page 3 of 259
Downloaded from www.Manualslib.com manuals search engine INJECTION
Idling - antipollution 111
Petrol injection 112
Emission standards 113 - 119
Prohibited operations : HDi 120 - 121
Safety requirements : HDi 122 - 123
Checking the fuel supply circuit 124 - 125
Checking the air supply circuit 126 - 130
Exhaust gas recycling 131 - 134
Checking turbo pressure 135 - 138
Features of injection systems 139 - 168
IGNITION
Sparking plugs 169
CLUTCH-GEARBOX
Speedometers 170
Clutch specifications 171 - 172
Gearbox and tyre specifications 173 - 174
BE4/5 gearbox controls 175 - 183
ML/5 gearbox controls 184 - 192
AL4-4HP20 gearbox controls 193 - 203
Driveshafts 204
AXLES-SUSPENSION
Wheels and tyres 205 - 211
Axle geometry 212 - 214
Front and rear axle 215 - 216Suspension 217 - 220
Steering specifications 221 - 222
BRAKES
Brake specifications 223 - 228
Handbrake adjustment 229
Bleeding and filling braking system 230 - 233
HYDRAULICS
Specifications 234 - 237
Suspension spheres 238 - 240
ELECTRICAL
Starter motors 241
Alternators 242
Charging circuit 243
AIR CONDITIONING
Quantities in R 134a aircon system 244
Special features 245
Pollen filter 246
Dryer cartridge 247 - 249
Checking oil level 250 - 251
Checking pressures 252
Air conditioning : 6FN-RFN-RLZ 253
Air conditioning circuit : XFX 254
Air conditioning circuit : RHY-RHZ 255
Air conditioning circuit : 4HX 256
INDEX
GENERAL
Identification of vehicles 1 - 4
General : Dimensions 5 - 6
Weight specifications 7 - 8
Towing specifications 9 - 10
Lifting / supporting the vehicle 11 - 14
Capacities 15 - 18
Lubricants 19 - 32
ENGINES
Engine specifications 34 - 58
Cylinder head marking / tightening
6FZ-RFN-RLZ 38
XFX 51 - 52
RHY-RLZ 55 - 56
4HX 57 - 58
Auxiliaries drive belt 59 - 68
Checking and setting valve timing 69 - 90
Power unit suspension 91 - 95
Exhaust system 96 - 100
Cooling system 101 - 107
Checking oil pressures 108
Oil filter 109
Filling and bleeding engine coolant 110
Page 10 of 259
Downloaded from www.Manualslib.com manuals search engine GENERAL
Versions 1.8i16V 2.0i16V 2.0 HPi 3.0i V6 1.8i16V 2.0i16V 3.0i V6
6FZ RFN RLZ XFX 6FZ RFN XFX
Gearbox typeBE4/5 ML/5 AL4 4 HP 20
Payload520 527 520 530 520 520 500
Unladen weight in running order1290 1318 1325 1480 1315 1325 1520
Gross vehicle weight1810 1845 1845 2010 1835 1845 2020
Gross train weight3310 3345 3345 3610 3335 3345 3420
Maximum trailer weight without brakes660 695 700 750 695 700 750
Maximum trailer weight with brakes
Incline 12%1500 1500 1500 1600 1500 1500 1400
Incline 10%1550 1600 1600 1700 1550 1600 1700
Incline 8%1800 1900 1900 2000 1800 1900 2000
Maximum nose weight75
Maximum roof rack load75
7
GENERAL SPECIFICATION : WEIGHTS
Exterior dimensions (mm)
Manual gearbox Automatic gearbox
Page 11 of 259
Downloaded from www.Manualslib.com manuals search engine GENERAL
8
Versions 2.0 HDi 2 .0 HDi 2.2 HDi 2.0 HDi 2.2 HDi
RHY RHZ 4HX RHZ 4HX
Gearbox typeBE4/5 ML/5 AL4 4 HP 20
Payload520 520 500 500 500
Unladen weight in running order1360 1385 1485 1410 1520
Gross vehicle weight1880 1905 1985 1910 2020
Gross train weight3380 3405 3485 3410 3120
Maximum trailer weight without brakes715 730 750 740 750
Maximum trailer weight with brakes
Incline 12%1500 1500 1500 1500 1500
Incline 10%1600 1600 1700 1600 1700
Incline 8%2000 2000 2000 2000 1800
Maximum nose weight75
Maximum roof rack load75
GENERAL SPECIFICATION : WEIGHTS
Exterior dimensions (mm)
Manual gearbox Automatic gearbox
Page 34 of 259
Downloaded from www.Manualslib.com manuals search engine GENERAL
31
Liquide de refroidissement moteur
LUBRICANTS – TOTAL recommended oils
PacksCITROEN reference
GLYSANTIN G 33 REVCOGEL 2000
CITROEN Fluid 2 litres9979 70 9979 72
All countries
Protection : - 35°C 5 litres9979 71 9979 73
20 litres9979 76 9979 74
210 litres9979 77 9979 75
Synthetic brake fluid
Packs CITROEN reference
All countriesCITROEN Fluid0.5 litre9979 05
1 litre9979 06
5 litres9979 07
CITROEN hydraulic circuit fluid
Orange-coloured synthetic fluid, for HYDRACTIVE 3 suspension and for steering
TOTAL LDS FLUIDPacks CITROEN reference
All countries 1 litre9979.69
Hydraulic circuit rinsing fluid – green colour
TOTAL HYDRAURINCAGE
Page 143 of 259
Downloaded from www.Manualslib.com manuals search engine 140
INJECTION
FEATURES OF MULTIPOINT INJECTION SYSTEM
Fuel circuit
Air inlet circuit
(diagr.) Component Supplier Reference Observations
30
4
19
21
20
7
31
6
5
9Recommended fuel
Petrol injector
Canister purge electrovalve
Fuel tank
Canister reservoir
Fuel pump and gauge assembly
with integral fuel filter
Air temperature sensor
Air inlet pressure sensor
Idle regulation stepper motor
Butterfly housing
PotentiometerSAGEM
BOSCH
SAGEM (1)
SOLVAY
MGI
MARWAL
MAGNETI
MARELLI
BOSCH
MGI
MAGNETI
MARELLI (1)
MGI
MAGNETI
MARELLI280520274
IAT S04
0261230034
B13 (1)Unleaded 95 RON or 98 RON
2 way black connector. Resistance : 12,2 ohms
2 way brown connector. Installation : between the engine
fusebox and the brake amplifier
Capacity = 66 Litres
Installation : in the rear LH wheelarch
6 way black connector. Pressure : 3,5 Bars.
2 way grey connector, fixed on the butterfly housing
3 way grey connector integral with the inlet manifold.
4 way black connector, fixed on the butterfly housing
The butterfly housing comprises the inlet air temperature
sensor, the butterfly potentiometer, the electric motor.
3 way black connector, installed on the butterfly housing.
(1) = RFNengine
Page 146 of 259
Downloaded from www.Manualslib.com manuals search engine FEATURES OF MULTIPOINT INJECTION SYSTEM
Summary
1)Accelerator pedal position sensor
(2)Denox catalyser downstream oxygen sensor
(3)Denox catalyser
(4)Downstream exhaust gas temperature sensor
(5)3-function precatalyser
(6)Precatalyser upstream oxygen sensor
(7) Upstream exhaust gas temperature sensor
(8)Petrol pressure regulator
(9)Petrol high pressure pump
(10)Knock sensor
(11) EGR electrovalve
(12)Canister purge electrovalve
(13)Motorised butterfly housing
(14)Canister reservoir
(15)Fuel pump and tank assembly
(16) Fuel tank
(17)Inlet air temperature sensor
(18) Inlet air pressure sensor(19)Engine coolant temperature sensor
(20) Sparking plug
(21) Ignition coil block
(22) High pressure injector
(23) Engine oil temperature sensor
(24)Engine speed sensor
(25)Inlet camshaft dephaser electrovalve
(26) Camshaft position sensor
(27)Petrol high pressure sensor
(28) Power steering pressure sensor
(29) Aircon fluid pressure sensor
(30)Cooling fan unit
(31)ABS block
(32)Clutch pedal sensor
(33)Brake pedal sensor
(34)Air conditioning ECU
(35) Engine management ECU
(36)Built-in systems interface BSI
(37)Rev counter
(38) Coded immobiliser
(39)Vehicle cruise control
(40) Diagnostic connector
B1HP1C6P
143
INJECTION
Page 156 of 259
Downloaded from www.Manualslib.com manuals search engine 153
INJECTION
Component (diagr.) Supplier Reference Observations
88 way connector. Flash eprom type sequential
Diesel injection ECU1BOSCHEDC 15C2 injection (reprogrammable eprom). Installed in the
ECU compartment.
Engine speed sensor2ELECTRIFIL
Camshaft position sensor3ELECTRIFIL Air gap value : 1,2 mm.
Coolant temperature sensor7ELECTRIFIL 962859028A Fixed on the coolant housing.
Accelerator pedal sensor8PHILIPS
Vehicle speed sensor9EATON On the gearbox.
Brake pedal switch10aOpen at rest.
10bClosed at rest.
Clutch pedal switch11
Atmospheric pressure sensor12BOSCHIntegrated in the injection ECU.
Battery
13FULMEN058426 – 12 Volt
400 ampsUnder the bonnet.
Injection double relay14BITRON 240 10915 way black connector. Installed in the ECU
compartment.
FIRST3 way black connector. Installed in the front RH
Inertia switch30INERTIA Type 505wheelarch, fixed on the suspension mounting.
SWITCHManual rearming in the event of the cut-out system
being activated.
FEATURES OF BOSCH HDi DIRECT INJECTION SYSTEM
Electrical circuit
Page 162 of 259
Downloaded from www.Manualslib.com manuals search engine Electrical circuit (continued)
INJECTION
FEATURES OF BOSCH HDi DIRECT INJECTION SYSTEM
159
Component (diagr.) Supplier Reference Observations
Preheater unit41NAGARES 960411P
CARTIER 735068
Preheater plugs42CHAMPION CH170
BOSCH0250202032
Coolant temperature sensor8ELECTRIFIL Fixed on the coolant outlet housing
Electronic immobiliser37
Accelerator pedal sensor9PHILIPS
Brake pedal switch 11 aOpen at rest
11 bClosed at rest
Clutch pedal switch12
Additional heating control relay
47
Additional heating46 a
Boiler heater elements46 b
Air conditioning compressor45
Automatic gearbox ECU44
Cruise control switch43
Page 167 of 259
Downloaded from www.Manualslib.com manuals search engine 164
INJECTION
FEATURES OF BOSCH HDi DIRECT INJECTION SYSTEM
Electrical circuit (continued)
Component (diagr.) Supplier Reference Observations
Coolant temperature sensor46ELECTRIFIL 962859028A Fixed on the coolant outlet housing
Accelerator pedal sensor54
Brake pedal switch36PHILIPS
56
Clutch pedal switch55
Additional heating control
relay1
Additional heating2 aOpen at rest
Boiler elements2 bClosed at rest
Air conditioning compressor 30
Automatic gearbox ECU22
Cruise control switch34
Heated rear screen20
ESP ECU21
«Service» warning lamp25
Cooling fan29
Fuel cap warning lamp28
Coolant temperature alert warning lamp31
Coolant temperature indicator32
