40M O N I T O R I N G

Total distance recorder
System which measures the total
distance travelled by the vehicle
during its life.
The total and trip distances are dis-
played for thirty seconds when the
ignition is switched off, when the
driver's door is opened and when
the vehicle is locked or unlocked.
Trip distance recorder
System which measures a distance
travelled during a day or other pe-
riod since it was reset to zero by the
driver.

 With the ignition on, press the
button until zeros appear. Lighting rheostat
System for manual adjustment of
the brightness of the instruments
and controls in relation to the exte-
rior brightness.
Operation

 Press button A to decrease the
brightness of the instruments
and controls.

 Press button B to increase the
brightness of the instruments
and controls. Deactivation
When the lighting is off, or in day
mode on vehicles fi tted with daytime
running lamps, pressing the buttons
does not have any effect.

II
41
M U L T I F U N C T I O N S C R E E N S
MONOCHROME SCREEN C Main Menu
Press on the button A to view the
Main Menu of the multifunction
screen. This menu gives you access
to the following functions:
Presentation
Radio-CD
(see "Audio and Telematics"
chapter)
Bluetooth ®
system
(see "Audio and Telematics"
chapter)
Controls

1. Time

2. Ambient temperature

3. Date and display zone
When the outside temperature is
between +3 °C and -3 °C, the tem-
perature display fl ashes (ice risk).
The ambient temperature displayed
may be greater than the actual tem-
perature, if the vehicle is parked in
bright sunlight.
It is recommended that the driver
should not operate the controls
while the vehicle is in motion. Personalisation-
Configuration
This permits activation/deactivation of the:
- brightness and contrast of the multifunction screen,
- date and time,
- units of the outside temperature displayed.

A. Access to the "Main Menu"

B. Cancellation of the operation or
return to the previous display

C. Scrolling in the screen menus
Confi rmation at the steering wheel

D. Confi rmation on the audio equip-
ment control panel

II
42
M U L T I F U N C T I O N S C R E E N S
Adjusting the brightness and
contrast

 Press on A .

 Use C to select the "Brightness -
video adjustment" menu. Confi rm
with a press on C on the steering
wheel or D on the audio equip-
ment.

 Select the confi guration of the
screen using C . Confi rm with a
press on C on the steering wheel
or D on the audio equipment.

 Select the brightness setting.
Confi rm with a press on C on the
steering wheel or D on the audio
equipment.

 Select the inverse or normal dis-
play mode using C then validate
with a press on C on the steering
wheel or D on the audio equip-
ment. To adjust the brightness
select "+" or "-" and save your
setting with a press on C .

 Confi rm with "OK" on the
screen. Adjusting the date and the
time

 Press on A .

 Use C to select the "Date and
time adjustment" menu, then
confi rm your choice with a press
on C on the steering wheel or D
on the audio equipment.

 Select the screen confi guration
using C . Confi rm with a press
on C on the steering wheel or D
on the audio equipment.

 Select the date and the time set-
tings, using B . Confi rm with a
press on C on the steering wheel
or D on the audio equipment.

 Press C to select the values you
wish to modify. Confi rm your
choice with a press on C on the
steering wheel or D on the audio
equipment.

 Confi rm with "OK" on the
screen. Choosing the units

 Press on A .

 Use C to select the "Choice of
units" menu, then confi rm your
choice with a press on C on the
steering wheel or D on the audio
equipment.

 Using C , select the unit then val-
idate with a press on C on the
steering wheel or D on the audio
equipment.

 Confi rm with "OK" on the
screen.
Selection of the type of
information displayed (Mode)
Successive presses on the end of
the wiper stalk or on the MODE but-
ton on the audio equipment permit
selection of the type of informa-
tion presented on the multifunction
screen (date or radio, CD, MP3 CD,
CD changer).

II
43
M U L T I F U N C T I O N S C R E E N S
16/9 COLOUR SCREEN(WITH MY WAY)
Displays on the screen
It displays the following information
automatically and directly:
- time,
- date,
- altitude,
- ambient temperature (the value displayed fl ashes if there is a risk
of ice),
- audio functions,
- satellite navigation system infor- mation. Controls
From the MyWay control panel, to
select one of the applications:

 press the dedicated "RADIO" ,

"MUSIC" , "NAV" , "TRAFFIC" ,

"SETUP" or "PHONE" button
for access to the corresponding
menu,

 turn the dial to move the selection,

 press the dial to confi rm the se-
lection,
or

 press the "ESC" button to aban-
don the current operation and
return to the previous display.
* According to country. For more information on these
applications, refer to the "Audio
Equipment" section or to the spe-
cifi c user guide given to you with
the other owner's documents. "SETUP" menu

 Press the "SETUP" button to
gain access to the "SETUP"
menu. This allows you to select
from the following functions:
- "System language",
- "Date & time",
- "Display",
- "Units",
- "System".
System language
This menu allows you to select
the language used by the dis-
play: Deutsch, English, Espanol,
Français, Italiano, Nederlands,
Polski, Portugues, Türkçe * .

II
44
M U L T I F U N C T I O N S C R E E N S
Display
This menu allows you to set the
brightness of the screen, the screen
colour scheme and the colour of the
map (day/night or auto mode). Units
This menu allows you to select the
units for temperature (°C or °F) and
distance (miles or kilometres).
System
This menu allows you to restore the
factory confi guration, display the soft-
ware version and activate scrolling
text.
For safety reasons, confi guration
of the multifunction screen by the
driver must be only done when
stationary.
Date & time
This menu allows you to set the date
and time, the format of the date and
the format of the time.
To set the date and time:

 Press the "SETUP" control.

 Turn the dial to select "DATE &
TIME" .

 Press the dial to confi rm.

 Turn the dial to select "SET
DATE & TIME" .

 Press the dial to confi rm.

 Turn the dial to select a fi eld:
- C for the day,
- D for the month,
- E for the year,
- F for the time.
 Press the dial to confi rm.

 Turn the dial or use the alphanu-
meric keypad to select the digits
which form the date and time.

 Press the dial to confi rm each
fi eld.

 Turn the dial to select "DATE
FORMAT" .

 Choose the format required and
press the dial to confi rm.

 Turn the dial to select "TIME
FORMAT" .

 Choose the format required and
press the dial to confi rm.

II
45
M U L T I F U N C T I O N S C R E E N S
16/9 HIGH DEFINITION COLOUR SCREEN (WITH NAVIDRIVE 3D)
Displays on the screen
It displays the following information
automatically and directly:
- time,
- date,
- altitude,
- ambient temperature (the value displayed fl ashes if there is a risk
of ice),
- audio functions,
- telephone and address book in- formation,
- satellite navigation system infor- mation. Controls
From the NaviDrive 3D control pan-
el, to select one of the applications:

 press the dedicated "RADIO" ,

"MEDIA" , "NAV" , "TRAFFIC" ,

"ADDR BOOK" or "SETUP"
button for access to the corre-
sponding menu,

 turn the dial to move the selection,

 press the dial to confi rm the
selection,
or

 press the "ESC" button to aban-
don the current operation and
return to the previous display. For more information on these
applications, refer to the "Audio
Equipment" section or to the spe-
cifi c user guide given to you with
the other owner's documents.

II
46
M U L T I F U N C T I O N S C R E E N S * According to country.
"SETUP" menu

 Press the "SETUP" button to gain
access to the "SETUP" menu.
This allows you to select from
the following functions:
- "Languages and Speech",
- "Date & Time",
- "Display",
- "Units",
- "System".
Language & Speech
This menu allows you to:
- select the language used by the display (Deutsch, English,
Espanol, Français, Italiano,
Nederlands, Polski, Portugues,
Türkçe * ),
-
select the voice recognition pa-
rameters (activation/deactivation,
advice on use, personal voice
programming, etc.),
- set the volume of the voice syn- thesiser. Date & Time
This menu allows you to set the date
and time, the format of the date and
the format of the time (refer to the
"Audio Equipment" section or to the
specifi c user guide given to you with
the other owner's documents).
Display
This menu allows you to set the
brightness of the screen, the screen
colour scheme and the colour of the
map (day/night or auto mode).
Units
This menu allows you to select the
units: temperature (°C or °F) and
distance (km or miles).
System
This menu allows you to restore the
factory confi guration, display the soft-
ware version and activate scrolling
text.
For safety reasons, confi guration
of the multifunction screen by the
driver must only be done when
stationary.

III
47
C O M F O R T
VENTILATION

A. Sunshine sensor.

B. Soft air diffusion grille.
The soft air diffusion grille located in the centre of the dashboard
provides optimum distribution of
the air for the front seats.
This system eliminates unpleas- ant air currents while maintaining
an optimum temperature in the
passenger compartment.
To open the soft air diffusion grille, turn the wheel upwards.
To close the soft air diffusion grille, turn the wheel fully down-
wards.
In very hot weather, to obtain more satisfactory central and
side ventilation, it is advisable to
close the diffused air grille.

C. Cooled glove box.

D. Rear passenger vents.

III
48
C O M F O R T
Air conditioning
We recommend use of the automatic
regulation of the air conditioning.
It permits automatic and optimised
control of all of the following functions:
air fl ow, temperature in the passenger
compartment and air distribution, by
means of various sensors (ambient
temperature, sunshine). This elimi-
nates any need for you to change your
settings other than the temperature
value displayed.

 Take care not to cover the sun-
shine sensor A .
If you select the automatic mode (by
pressing the "AUTO" control) and leave
all of the vents open, optimum comfort
will be maintained and humidity and
condensation will be removed regard-
less of the exterior climatic conditions.
The temperature in the passenger
compartment can only be lower than
the ambient temperature if the air
conditioning is on.
HEATING, VENTILATION AND AIR CONDITIONING RECOMMENDATIONS
In order to be effective, the air condi-
tioning must be used with the windows
closed. If the vehicle has been parked
in the sun for a long period and the
interior temperature is very high, fi rst
ventilate the passenger compartment
with the windows open for a few min-
utes, then close the windows.
To keep the air conditioning system
in good working order it is essential
that it is operated at least once a
month.
The air conditioning uses engine power
during its operation. As a result, the fuel
consumption of the vehicle increases.
In certain cases of particularly ardu-
ous use (e.g. towing the maximum
load on a steep gradient in high
temperatures), switching off the air
conditioning saves engine power
and improves the towing capacity.
Air inlet
Check that the exterior grille for the
air inlet, at the bottom of the wind-
screen, is clean and free of dead
leaves, snow, etc.
When washing the vehicle using a
high pressure nozzle, avoid spraying
at the air inlet. Air circulation
Maximum comfort is obtained by
means of a good distribution of air in
the passenger compartment, both in
the front and in the rear.
To obtain a uniform distribution of
air, take care not to block the ex-
terior air intake grille located at the
base of the windscreen, the vents,
the air outlets under the front seats
and the air extractor located behind
the fl aps in the boot.
The front and rear vents are fi tted
with thumbwheels to adjust the air
fl ow and direction. We recommend
that you leave all of the vents open.
Dust filter/Odour filter
(active carbon)
There is a fi lter for excluding odours
and dust.
This fi lter must be changed in line
with the vehicle's servicing schedule
(see: "Maintenance and Warranty
Guide").

III
49
C O M F O R T
DIGITAL AIR CONDITIONING (MONO-ZONE)
This is the normal sys-
tem operating mode.
In accordance with the
level of comfort cho-
sen, pressing this con-
trol, confi rmed by the
switching on of indicator lamp A , per-
mits automatic and simultaneous con-
trol of all of the following functions:
- Air fl ow.
- Temperature in the passenger compartment.
- Air distribution.
- Air intake.
- Air conditioning.
1. Automatic operation
It is advisable to leave all of the
vents open.
Simply pressing one of the controls,
with the exception of control
2 , switches
the system to manual mode.
Indicator lamp A goes off. 2. Temperature adjustment
Turn control
2 to change
the temperature:
- Clockwise to in- crease the tempera-
ture.
- Anticlockwise to reduce the tem- perature.
The setting required is displayed.
The value indicated on the display
corresponds to a level of comfort
and not to a temperature in degrees
Celsius or Fahrenheit, depending on
the screen confi guration.
A setting around the value 21 usually
provides optimum comfort. However,
depending on your requirements, a
setting between 18 and 24 is normal.
On entering the vehicle, the interior
temperature may be much colder (or
warmer) than is comfortable. There
is no need to change the tempera-
ture displayed to obtain rapidly the
level of comfort required.
The automatic regulation of the air
conditioning will use its maximum
performance settings to correct the
temperature difference as quickly as
possible.
The air conditioning system ope-
rates with the engine running.

Mono-zone: this is the overall regu-
lation of the temperature, distribution
and fl ow of air in the passenger com-
partment.
The symbols and messages associ-
ated with the digital air conditioning
controls appear on the multifunction
screen.

1. Automatic operation

2. Temperature adjustment

3. Air distribution adjustment

4. Activation/deactivation of the air
conditioning

5. Air fl ow adjustment

6. Front demisting - defrosting

7. Rear demisting - defrosting

8. Air recirculation - intake of exterior
air

9. Screen
