Page 73 of 306
86
V I S I B I L I T Y
5
Linked with the automatic
"Guide-me-home" lighting
Link with the automatic lighting pro-
vides the "guide-me-home" lighting
with the following additional options:
- selection of the duration of light-ing for 15, 30 or 60 seconds in
the vehicle parameters on the
m u l t i f u n c t i o n s c r e e n c o n fi g u r a -
tion menu,
- automatic activation of "guide- me-home" lighting when auto-
matic lighting is in operation.
Operating fault
In the event of a malfunction of the
brightness sensor, the lamps come
on and a message appears on the
multifunction screen, accompanied
by an audible signal.
Consult a CITROËN dealer. In fog or snow, the brightness
s e n s o r m a y d e t e c t s u f fi c i e n t l i g h t .
Therefore, the lamps will not come
on automatically.
Do not cover the brightness sen-
sor, linked with the rain sensor and
located in the centre of the wind-
screen behind the interior mirror;
the associated functions would no
longer operate. MANUAL ADJUSTMENT OF THE HEADLAMPS
To avoid dazzling other road users,
the height of the halogen bulb head-
lamps must be adjusted according
to the load in the vehicle.
0.
1 or 2 people in the front seats.
-.
3 people.
1.
5 people.
-.
Intermediate setting.
2.
5 p e o p l e + m a x i m u m a u t h o r i s e d
loads.
-.
Intermediate setting.
3. D r i v e r + m a x i m u m a u t h o r i s e d
loads.
Initial setting is position "0".
AUTOMATIC ADJUSTMENT OF THE DIRECTIONAL HEADLAMPS
D o n o t t o u c h t h e x e n o n b u l b s .
Consult a CITROËN dealer. If a malfunction oc-
curs, this warning
lamp is displayed on
the instrument panel,
accompanied by an
audible signal and a
message on the multi-
function screen.
The system then places your head-
lamps in the lowest position.
In order to avoid causing a nuisance
to other road users, this system cor-
r e c t s t h e h e i g h t o f t h e x e n o n h e a d -
lamps beam automatically and when
stationary, in relation to the load in
the vehicle.
Page 169 of 306
168
P R A C T I C A L I N F O R M A T I O N
CHANGING A BULB
Procedure for replacing a faulty bulb
with a new bulb without the use of
any tools.
Headlamps
Model with Xenon headlamps
(D1S)
1. Sidelamps: W 5 W
2. Dual-function Xenon
headlamps (dipped/main): D1S
3. Angular lighting: HP19
4. Daytime-running lamps: HP24 Sidelamps
Lift up the pegs A to remove the
cover on the headlamp.
Remove the protective cap B .
Pull the bulb holder to remove it.
R e p l a c e t h e b u l b a n d r e fi t t h e
bulb holder.
For the maintenance of the front
headlamp unit and the changing of
HP19, D1S and HP24 bulbs, contact
a CITROËN dealer.
Risk of electrocution
Xenon bulbs must be re-
placed by a CITROËN
dealer.
You are advised to change both
D1S bulbs at the same time, if one
of them has failed.
R e fi t t h e p r o t e c t i v e c a p B .
R e fi t t h e c o v e r a n d fi x i t i n p l a c e
using the pegs A .
