lights Citroen C5 2008.5 (RD/TD) / 2.G Owner's Manual

28
I N S T R U M E N T S a n d C O N T R O L S
Indicator and warning lamps
When the ignition is switched on
The warning lamps come on for a
few seconds when the vehicle's igni-
tion is switched on.
When the engine is started, these
warning lamps should switch off. Operation indicator lights
Visual indicators informing the driver
that a system is in operation (opera-
tion or deactivation indicator lamps)
or of the occurrence of a fault (warn-
ing lamp).
1. Front fog lamps.

2. Left-hand direction
indicator.

3. Sidelamps.

4. Main beam headlamps.

5. Dipped headlamps.

6. Right-hand direction
indicator.

7. Rear fog lamp.

31
1
I N S T R U M E N T S a n d C O N T R O L S
Engine autodiagnostics system If this comes on, it indicates
the occurrence of a fault in
the engine management
system.
If it fl ashes, it indicates the occurrence of
a fault in the emission control system.
Maximum coolant temperature If this comes on, it indicates
that the temperature in the
cooling system is too high.
Stop the vehicle immediately
and as safely as possible.
Check the coolant level.
If the level is low, contact a CITROËN
dealer.
Fuel low
If this comes on, it indicates
that the range remaining
is approximately 30 miles
(50 km).
It may be less than this in certain
driving conditions and depending on
the engine.
The capacity of the tank is approxi-
mately 71 litres. Battery charge
If this comes on, it indi-
cates the occurrence of a
fault in the battery charging
circuit (dirty or loose termi-
nals, slack or cut alternator
belt...).
Seat belt not fastened/
unfastened *
* According to country.
This warning lamp lights
up on the instrument panel
to remind the driver and all
passengers that they must
fasten their seat belt.
It is linked to the seat belt informa-
tion given by the roof console. Seat belt non-fastening/
unfastening
This warning lamp
informs you of the
non-fastening and
unfastening of the
driver and passenger seat belts.
The illuminated positions represent
the passengers whose seat belts
are not fastened/unfastened.
Driver’s seat belt not fastened:
- The warning lamp lights up be- tween 0 and 12 mph (20 km/h).
Above 12 mph, it fl ashes ac-
companied by a sound signal for
around 120 seconds.
Front and rear passenger seat belts
not fastened:
- When the ignition is switched on, the points corresponding to
the seat positions with seat belts
not fastened remain lit up for
30 seconds.
Seat belts unfastened during the
journey:
- The point corresponding to the seat position with seat belt un-
fastened lights up between 0 and
12 mph (20 km/h). Above
12 mph, it fl ashes accompanied
by an audible signal for around
120 seconds. The audible signal
stops when the seat belt is re-
fastened or if a door is opened.

34
1
I N S T R U M E N T S a n d C O N T R O L S
Engine oil temperature gauge
Under normal operating conditions,
the bars should be within section 1 .
In severe operating conditions, the
bars may extend into section 2 .
In this event, slow down, and if neces-
sary, stop the engine and check the
levels (see corresponding chapter). Coolant temperature
indicator
Under normal operating conditions,
the bars should be within section
1 .
In severe operating conditions, the
bars may extend into section 2 , the
engine coolant temperature warning
lamp A and the STOP warning lamp
will light up, stop immediately . Switch
off the ignition. The cooling fan may
continue to operate for a certain
time .
Consult a CITROËN dealer.
If the SERVICE warning lamp lights
up, check the levels (see correspon-
ding chapter). On horizontal ground, the lighting of
the fuel low warning lamp warns you
that you are at the reserve level.
A message alert is displayed on the
instrument panel.
Fuel gauge indicator

35
1
I N S T R U M E N T S a n d C O N T R O L S
Total distance recorder
System which measures the total
distance travelled by the vehicle
during its life.
The total and trip distances are dis-
played for thirty seconds when the
ignition is switched off, when the
driver's door is opened and when
the vehicle is locked or unlocked.
Trip distance recorder
System which measures a distance
travelled during a day or other period
until it is reset to zero by the driver.

 With the ignition on, press the
button until zeros appear. Lighting rheostat
System for manual adjustment of
the brightness of the instruments
and controls in relation to the exte-
rior brightness.
Operation

 Press button A to decrease the
brightness of the instruments
and controls.

 Press button B to increase the
brightness of the instruments
and controls. Deactivation
When the lights are off, or in day
mode on vehicles fi tted with daytime
running lights, pressing the buttons
does not have any effect.

53
3
C O M F O R T
Adjusting the operating
duration

 Press button 3 and hold it down,
press button 2 or 7 at the same
time. Release button 3 . The time
and symbol 6 fl ash.

 Press again on button 3 and hold
it down, press button 2 or 7 at the
same time. Release button 3 .

 The programmed operating du-
ration is displayed and symbol 8
fl ashes.

 Adjust the operating duration
with button 2 or 7 .

 To memorise the setting, press
button 3 or wait until the display
goes off. Immediate start-up

 Press button 5 .
The screen displays the symbol 8
and the remaining operating dura-
tion. This can be adjusted. The maxi-
mum duration is 30 minutes.
The warning lamp 8 lights up and
remains lit for the whole duration of
the system’s operation. The dura-
tion of the system’s operation disap-
pears after 10 seconds.
Start-up of the heating system can
be programmed between 1 minute
and 24 hours in advance.
Adjusting the remaining
operating duration
When the heating mode is active,
the remaining operation duration
can be modifi ed by between 10 and
30 minutes using buttons
2 or 7 . Programming the start-up
time You can store up to three different
start-up times, but programme only
one delayed start-up time.
Factory settings
A :

54
3
C O M F O R T


Press button 3 several times until the
programme number corresponding
to the required programme time is
displayed. The chosen pre-selected
time is activated automatically after
10 seconds if no other buttons have
been pressed.
To confi rm that the mode is activated,
symbols 4 and 8 fl ash until the heat-
ing starts up.
When the heating starts up, the warn-
ing lamp 9 lights up on the dashboard
and the programmer screen.
 Press button 3 briefl y: the display
of the start-up time goes off.
In the event of a battery failure, the
factory settings are restored.
Stopping the heating system
while operating

 Press button 5 .
The warning lamp 8 and the screen
go out. When a programme is operating,
pressing button
2 or 7 displays the
heating start-up time. A second
press on these buttons displays the
time.
When a programme is not operat-
ing, pressing button 2 or 7 displays
the time.
When the heating is operating, the
remaining operating duration is dis-
played instead of the time.

83
V I S I B I L I T Y
5
LIGHTING CONTROLS
System for selection and control of
the various front and rear lamps pro-
viding the vehicle’s lighting.
Main lighting
The various front and rear lamps of
the vehicle are designed to adapt
the driver’s visibility progressively in
relation to the climatic conditions:
- sidelamps, to be seen,
- dipped headlamps to see with-out dazzling other drivers,
- main beam headlamps to see clearly when the road is clear,
- directional headlamps for im- proved visibility when cornering.
Additional lighting
Other lamps are fi tted to fulfi l the re-
quirements of particular driving con-
ditions:
- a rear fog lamp to be seen from a distance,
- front fog lamps for even better forward vision,
- daytime running lights to be seen during the day. Programming
Various automatic lighting control
modes are also available depending
on options:
- guide-me-home lighting,
- automatic lighting,
- directional lighting.
Manual controls
lamps off,
automatic switching on of
the lamps,
sidelamps only,
dipped headlamps or
main beam headlamps.

B. stalk for switching headlamps by
pulling: dipped headlamps/main
beam headlamps.
In the lamps off and sidelamps
modes, the driver can switch on the
main beam headlamps temporarily
("headlamp fl ash") by maintaining a
pull on the stalk.
Displays
Lighting of the corresponding indi-
cator lamp on the instrument panel
confi rms the selective switching on
of the lighting selected.
The lighting commands are issued
directly by the driver by means of
the ring
A and the stalk B .
A. main lighting mode selection
ring, with:

85
V I S I B I L I T Y
5
* According to country.
Daytime-running lamps
System which switches on special
lamps at the front, to make the vehi-
cle more visible by day.
They light up automatically and per-
manently, when the engine is running,
if:
- The function is activated * in the
"Main Menu" of the instrument
panel screen.
- The lighting control is at posi- tion 0 or AUTO .
- All the headlamps are off.
You can deactivate * this function
using the "Main Menu" of the instru-
ment panel screen. Manual guide-me-home
lighting
The temporary maintaining of the
dipped headlamps lighting after the
vehicle's ignition has been switched
off makes the driver's exit easier
when the light is poor.
Switching on

 With the ignition off, "fl ash" the
headlamps using the lever B .

 A second "headlamp fl ash"
switches the function off again.
Switching off
The manual guide-me-home lighting
switches off automatically after a set
time. Automatic lighting
The sidelamps and dipped head-
lamps are switched on automatically,
without any action on the part of the
driver, when a low level of external
light is detected or in certain cases of
activation of the windscreen wipers.
As soon as the brightness returns
to a suffi cient level or after the wind-
screen wipers are switched off, the
lights are switched off automatically.
Activation

 Turn ring A to the "AUTO" posi-
tion. The automatic lighting is ac-
companied by a message on the
multifunction screen.
Deactivation

 Turn ring A to a position other
than "AUTO" . Deactivation is
accompanied by a message on
the multifunction screen.

85
V I S I B I L I T Y
5
* According to country.
Daytime-running lamps
System which switches on special
lamps at the front, to make the vehi-
cle more visible by day.
They light up automatically and per-
manently, when the engine is running,
if:
- The function is activated * in the
"Main Menu" of the instrument
panel screen.
- The lighting control is at posi- tion 0 or AUTO .
- All the headlamps are off.
You can deactivate * this function
using the "Main Menu" of the instru-
ment panel screen. Manual guide-me-home
lighting
The temporary maintaining of the
dipped headlamps lighting after the
vehicle's ignition has been switched
off makes the driver's exit easier
when the light is poor.
Switching on

 With the ignition off, "fl ash" the
headlamps using the lever B .

 A second "headlamp fl ash"
switches the function off again.
Switching off
The manual guide-me-home lighting
switches off automatically after a set
time. Automatic lighting
The sidelamps and dipped head-
lamps are switched on automatically,
without any action on the part of the
driver, when a low level of external
light is detected or in certain cases of
activation of the windscreen wipers.
As soon as the brightness returns
to a suffi cient level or after the wind-
screen wipers are switched off, the
lights are switched off automatically.
Activation

 Turn ring A to the "AUTO" posi-
tion. The automatic lighting is ac-
companied by a message on the
multifunction screen.
Deactivation

 Turn ring A to a position other
than "AUTO" . Deactivation is
accompanied by a message on
the multifunction screen.

94
V I S I B I L I T Y
5
Front door storage pockets
automatic lighting
A white light is emitted to light up the
door storage pockets.
Operation
The lighting comes on automatically
when you place your hand inside
the storage pocket. It goes out a
few seconds after you remove your
hand. WELCOME LIGHTING
With the door open, this lights up the
ground next to the vehicle.
Floor lighting
In the front and the rear of the ve-
hicle, when a door is opened, this
lights up the interior of the vehicle.
The welcome lighting is made up of:
- The interior (roof) lamps.
- The fl oor lighting.
- The pavement lighting when a
door is open.
Pavement lighting
