IV
78
O P E N I N G S
Electric opening
BOOT (TOURER)
Manual opening

 Press upwards on lever A and lift
up the tailgate.

 Press upwards on lever A , or
press button B of the remote
control. Do not attempt to help the opening of
the tailgate manually after pressing
the control
A .
Manual closing

 Lower the tailgate using the inte-
rior handle C .
Electric closing

 Press the push-button D to close
the tailgate.
Do not interrupt the closing of the
tailgate; if any obstacle prevents it
closing, the operation will stop and
the tailgate will automatically rise
by a few centimetres.
Locking/unlocking
With the vehicle stationary, this is
carried out using:
- The remote control.
- The key in a door lock.
- The interior central locking/un- locking control. Interrupting the opening/
closing of the tailgate
When the tailgate is being opened or
closed electrically, you can interrupt
its movement at any point by press-
ing push-button
D , the control A or
button B .
You can then open or close the tail-
gate electrically or manually, if nec-
essary moving it in the opposite
direction to release it.
The boot automatically locks when
the vehicle is moving at a speed of
over 6 mph (10 km/h), even if auto-
matic central locking is deactivated.
It is unlocked when a door is opened
or when the central locking button
is pressed (at a speed of less than
6 mph (10 km/h)).
Memorisation of an
intermediate position
You can store an opening angle for
the tailgate:

 Manually or automatically move
the tailgate to the required posi-
tion.

 Make a long press on push-but-
ton D . The system emits a short
audible beep.

 Release the push-button D .

IV
79
O P E N I N G S
Cancelling the memorisation
With the tailgate in the intermediate
position, you can cancel the stored
position:

 Make a long press on push-
button D . The system emits a
long audible beep.

 Release the push-button D . The
tailgate will return to the fully
open position at the next use.
Electrical protection of the
motor
If the tailgate is repeatedly opened
and closed in quick succession, the
motor can start to overheat and then
cut out, preventing opening and
closing of the tailgate.
Allow the motor to cool down for ten
minutes without opening or closing
the tailgate.
Closing in manual back-up mode
remains possible. To avoid risk of injury, make sure
that no one is in the vicinity of the
boot while opening and closing.
If the tailgate is carrying extra
weight (snow, bicycle carrier, etc.)
there is a risk of it closing under
this load. Support the tailgate or
fi rst unload the bicycle carrier or
clear the snow.
When using an automatic car wash, don’t forget to lock the vehicle so
as to avoid any risk of motorised
opening of the tailgate.

IV
80
O P E N I N G S
PANORAMIC SUNROOF (SALOON)
Sunroof closed
- Press B to fi rst notch: tilting.
- Press B to second notch: auto-
matic complete tilting.
- Press A to fi rst notch: sliding to-
wards rear.
- Press A to second notch: auto-
matic total sliding towards rear. Sunroof open
- Press
B to fi rst notch: closure.
- Press B to second notch: auto-
matic total closure.
Always remove the ignition key
when leaving the vehicle, even if
for a short time.
In the event of anything being
caught by the sunroof closing, you
must reverse the roof movement.
Do this by reversing the position of
the control switch.
When the driver is operating the
sunroof, they must always make
sure that the passengers are not
preventing it from closing properly.
The driver must ensure that pas-
sengers use the sunroof control
correctly.
Pay special attention to where
children are when operating the
sunroof.
The fi tting of a sunroof as an
accessory is prohibited.
Operation
Tilted sunroof
- Press A to fi rst notch: closure.
- Press A to second notch: auto-
matic total closure.
Your sun roof is fi tted with a manually-
operated blind.
Anti-pinch
An anti-pinch device stops the sun roof
from closing, whether sliding or tilting. If
it meets an obstacle, it re-opens. Reinitialisation
After a battery disconnection or if
there has been a malfunction, you
have to re-initialise the anti-pinch
function.

 move control B until the roof is in
the complete tilting position,

 keep control B pressed down for
a minimum of 1 second.

During these operations, the anti-
pinch function does not operate
.

IV
81
O P E N I N G S
PANORAMIC SUNROOF (TOURER)
This comprises a tinted glass pan-
oramic area 1 to improve brightness
and vision in the passenger com-
partment.
It is fi tted with an electric blind 2 to
help maintain a comfortable temper-
ature and reduce noise. Opening

 Press control A .
Pressing to the 1st notch allows you
to open the blind step by step.
Pressing to the 2nd notch allows
you to fully open the blind.
The blind stops in the closest pre-
defi ned position (11 positions) as
soon as you release the control.
Closing

 Press control B .
Press to the fi rst notch to close the
blind step by step.
Press to the second notch to close
the blind completely.
The blind stops at the nearest pre-
set position (11 positions) as soon
as you release the control. After a battery disconnection, or if
there has been a malfunction, you
have to re-initialise the anti-pinch
function:

 press control B to the 2nd notch
(fully closed),

 wait until the blind is fully
closed,


press control B for at least 3 sec-
onds.
If the blind opens randomly during a
closing operation, and straight after
the blind stops:

 Press control B until the blind
closes fully.

During these operations, the anti-
pinch function does not operate.
In the event of anything being
caught when the blind is moving,
you must reverse the movement of
the blind. To do so, reverse the po-
sition of the control.
When the driver is operating the
blind, he or she must always make
sure that the passengers are not
preventing it from closing properly.
The driver must ensure that pas-
sengers use the blind correctly.
Pay particular attention to children
when operating the blind.
Anti-pinch
If the blind meets an obstacle whilst
closing, it stops and opens partially
again.
You must re-initialise the anti-pinch
function within 5 seconds of the
blind stopping:

 press control B until the blind is
fully closed (closing in steps of a
few centimetres).
SEQUENTIAL ELECTRIC BLIND

IV
82
O P E N I N G S
FUEL TANK

Capacity of the tank: approximately
71 litres.
Low fuel level
When the minimum level
in the tank is reached, this
warning lamp comes on
in the instrument panel,
accompanied by an audible warning
and a message on the multifunction
screen. When it fi rst comes on, there
remains around 5 litres of fuel in the
tank.
You must refuel to avoid running out
of fuel.

 Press at the top left corner, then
pull open from the left.
 turn the key a quarter turn to lock
and unlock the fi ller cap,

 when refuelling, place the cap on
hook A ,

 fi ll the tank, but do not persist
after the third cut-off ; this could
cause your vehicle to malfunc-
tion.

While you are refuelling, the engine
must be stopped and the ignition
switched off.

For a petrol engine with a catalytic
converter, unleaded fuel is compul-
sory.
Opening the fuel flap Additions of fuel must be of at least
5 litres to be taken into account by
the fuel gauge.
The fi ller neck is narrower to en-
sure that only unleaded petrol
nozzles can be put in.
Opening the fi ller cap may create
a noise of an inrush of air. This
vacuum, which is entirely normal,
is caused by the sealing of the fuel
system.
Refuelling

IV
83
O P E N I N G S
Quality of the fuel used for
petrol engines
The petrol engines are perfectly
compatible with E10 type petrol
biofuels (containing 10 % ethanol),
conforming to European standards
EN 228 and EN 15376.
E85 type fuels (containing up to 85 % ethanol) are reserved exclusively for
vehicles marketed for the use of this
type of fuel (BioFlex vehicles). The
quality of the ethanol must comply
with European standard EN 15293.
For Brazil only, special vehicles are
marketed to run on fuels containing
up to 100 % ethanol (E100 type). Quality of the fuel used for
Diesel engines
The Diesel engines are perfectly
compatible with biofuels which con-
form to current and future European
standards (Diesel fuel which com-
plies with standard EN 590 mixed
with a biofuel which complies with
standard EN 14214) available at the
pumps (containing up to 7 % Fatty
Acid Methyl Ester).
The B30 biofuel can be used in cer-
tain Diesel engines; however, this
use is subject to strict application
of the special servicing conditions.
Consult a CITROËN dealer.
The use of any other type of (bio)fuel
(vegetable or animal oils, pure or di-
luted, domestic fuel...) is strictly pro-
hibited (risk of damage to the engine
and fuel system).

V
84
V I S I B I L I T Y
EXTERIOR LIGHTING CONTROLS
Control stalk for the selection and con-
trol of the various front and rear lamps
providing the vehicle's lighting.
Main lighting
The various front and rear lamps of
the vehicle are designed to adapt
the driver's visibility progressively in
relation to the climatic conditions:
- sidelamps, to be seen,
- dipped beam headlamps to see without dazzling other drivers,
- main beam headlamps to see clearly when the road is clear.
Additional lighting
Other lamps are fi tted to fulfi l the re-
quirements of particular driving con-
ditions:
- a rear foglamp to be seen from a distance,
- front foglamps for even better forward vision,
- directional headlamps for im- proved visibility when cornering,
- daytime running lamps to be seen during the day. Programming
Various automatic lighting control
modes are also available depending
on options:
- guide-me-home lighting,
- automatic lighting,
- directional lighting.
Manual controls
lamps off,
automatic illumination of
headlamps,
sidelamps only,
dipped headlamps or
main beam headlamps.

B. Stalk for switching headlamps by
pulling: dipped headlamps/main
beam headlamps.
In the lamps off and sidelamps
modes, the driver can switch on the
main beam headlamps temporarily
("headlamp fl ash") by maintaining a
pull on the stalk.
Displays
Lighting of the corresponding indi-
cator lamp on the instrument panel
confi rms the selective switching on
of the lighting selected.
The lighting commands are issued
directly by the driver by means of
the ring A and the stalk B .
A. Main lighting mode selection ring,
with:
In some climatic conditions (e.g.
low temperature or humidity), the
presence of misting on the inter-
nal surface of the glass of the
headlamps and rear lamps is nor-
mal; it disappears after the lamps
have been on for a few minutes.

V
85
V I S I B I L I T Y

C. Foglamps selection ring.
The foglamps operate with the side-
lamps and the dipped and main
beam headlamps.
-
1 st turn forwards: rear foglamps on.
- 1 st turn rearwards: rear foglamps off.
- 1 st turn forwards: front foglamps on.
- 2 nd turn forwards: rear foglamps on.
- 1 st turn rearwards: rear foglamps off.
- 2 nd turn rearwards: front foglamps off.
Model with rear foglamps
only
Model with front and rear
foglamps In good or rainy weather, both day
and night, the front foglamps and
the rear foglamps are prohibited. In
these situations, the power of their
beams may dazzle other drivers.
They should only be used in fog or
snow.
In these weather conditions, it is
your responsibility to switch on the
foglamps and dipped headlamps
manually as the brightness sensor
may detect suffi cient light.
Do not forget to switch off the front
foglamps and the rear foglamps
when they are no longer necessary.
Lamps on buzzer
The triggering of an audible signal
when a front door is opened warns
the driver that he has forgotten to
switch off his vehicle's lamps, with
the ignition off and in manual lamps
mode.
In this case, switching off the lamps
stops the audible signal.
With the ignition off, if the dipped
headlamps remain on, they will
switch off automatically after thirty
minutes to prevent discharging of
the battery.

V
86
V I S I B I L I T Y
* According to country.
Daytime-running lamps
System which switches on special
lamps at the front, to make the ve-
hicle more visible by day.
They light up automatically and perma-
nently, when the engine is running, if:
- The function is activated * in the
"Main Menu" of the instrument
panel screen.
- The lighting control is at position 0
or AUTO .
- All the headlamps are off.
You can deactivate * this function
using the "Main Menu" of the instru-
ment panel screen. Manual guide-me-home
lighting
Temporarily keeping the dipped
beam headlamps on after the vehi-
cle's ignition has been switched off
makes the driver's exit easier when
the light is poor.
Switching on

 With the ignition off, "fl ash" the
headlamps using the lighting
stalk.


A further "headlamp fl ash" switches
the function off.
Switching off
The manual guide-me-home lighting
switches off automatically after a set
time. Automatic illumination of
headlamps
The sidelamps and dipped beam
headlamps are switched on automati-
cally, without any action on the part of
the driver, when a low level of external
light is detected or in certain cases of
activation of the windscreen wipers.
As soon as the brightness returns to a
suffi cient level or after the windscreen
wipers are switched off, the lamps are
switched off automatically.
Activation


Turn ring A to the "AUTO" position.
The automatic illumination of head-
lamps is accompanied by a message on the instrument panel screen.
Deactivation

 Turn ring A to a position other
than "AUTO" . Deactivation is
accompanied by a message on
the instrument panel screen.

V
87
V I S I B I L I T Y
Linked with the automatic
"Guide-me-home" lighting
Link with the automatic illumination
of headlamps provides the "guide-
me-home" lighting with the following
additional options:
- selection of the duration of light- ing for 15, 30 or 60 seconds in
the vehicle parameters on the in-
strument panel screen confi gu-
ration menu,
- automatic activation of "guide- me-home" lighting when auto-
matic illumination of headlamps
is in operation.
Operating fault
In the event of a malfunction of the
brightness sensor, the lamps come
on and a message appears on the
instrument panel screen, accompa-
nied by an audible signal.
Consult a CITROËN dealer.
In fog or snow, the brightness
sensor may detect suffi cient light.
Therefore, the lamps will not come
on automatically.
Do not cover the brightness sen-
sor, linked with the rain sensor and
located in the centre of the wind-
screen behind the rear view mirror;
the associated functions would no
longer operate.
MANUAL HEADLAMP ADJUSTMENT
To avoid dazzling other road users,
the height of the halogen bulb head-
lamps must be adjusted according
to the load in the vehicle.

0. 1 or 2 people in the front seats.

-. 3 people.

1. 5 people.

-. Intermediate setting.

2. 5 people + maximum authorised
loads.

-. Intermediate setting.

3. Driver + maximum authorised
loads.
Initial setting is position "0".
AUTOMATIC ADJUSTMENT OF DIRECTIONAL HEADLAMPS
Do not touch the xenon bulbs.
Consult a CITROËN dealer.
If a malfunction occurs,
this warning lamp is dis-
played on the instrument
panel, accompanied by
an audible signal and a
message on the instru-
ment panel screen.
The system then places your head-
lamps in the lowest position.
To avoid causing a nuisance to oth-
er road users, this system corrects
the height of the xenon headlamp
beams automatically and when sta-
tionary, depending on the load in the
vehicle.
