sensor Citroen C5 2015 (RD/TD) / 2.G Owner's Guide

136
C5_en_Chap04_conduite_ed01-2014
Operation
You have identified a parking space:
F P ress button A to select the function.
F

A
ctivate the direction indicator on the side
where the space is to be measured.
F

D
uring measurement, go for ward the
length of the space, at a speed less than
12 mph (approx. 20 km/h), to prepare for
your manoeuvre.
The system then measures the size of the space.
F

T
he system informs you of the level
of difficulty of the manoeuvre via a
message in the instrument panel screen
accompanied by an audible signal.
F

D
epending on the message issued by the
system, you may or may not be able to
per form the manoeuvre.The function displays the following types of message:
Parking YES
Parking DIFFICULT
Parking NO The function deselects itself automatically:
-

w
hen you engage reverse gear,
-
w
hen you switch off the ignition,
-
i
f measurement is not requested,
-
w
ithin five minutes of selection of the
function,
-
i
f the vehicle speed exceeds the threshold
of 45 mph (approx. 70 km/h) for one
minute.
If the lateral distance between your vehicle and
the parking space is too large, the system may
not be able to measure the space.
The function remains available after each
measurement and thus can measure more than
one space during your search.
In bad weather conditions or in winter, make
sure that the sensors are not covered by dirt, or
by ice or snow.
The parking space sensor function deactivates
the front parking sensors during space
measurement when you are in for ward gear.
If there is a fault, have the system
checked by a CITROËN dealer or a
qualified workshop.
Driving

137
C5_en_Chap04_conduite_ed01-2014
Visual and audible front and/or rear parking sensors
The parking sensors are switched on:
- b y engaging reverse gear,
-

a
t a speed below 6 mph (10 km/h) in
forward gear.
This is accompanied by an audible signal and/
or displaying of the vehicle in the multifunction
screen.
The proximity information is indicated by:
-

a
n audible signal which becomes more
rapid as the vehicle approaches the
obstacle,
-

a d
iagram in the multifunction screen, with
blocks which move closer to the vehicle.
The obstacle is located in relation to the
emission of the audible signal by the speakers;
front or rear and right or left.
When the distance between the vehicle and
the obstacle is less than approximately thirty
centimetres, the audible signal becomes
continuous and/or the "Danger" symbol
appears, depending on the multifunction
screen version. The parking sensors are switched off
:
- w hen you exit reverse gear,
-

w
hen the speed is higher than 6 mph
(10 km/h) in for ward gear,
-

w
hen the vehicle has been stationary for
more than three seconds in for ward gear.
The parking sensors system cannot, in
any circumstances, replace the need for
vigilance on the part of the driver.
System consisting of proximity sensors, installed
in the front and/or rear bumper.
It detects any obstacle (person, vehicle, tree,
barrier...) located in front of or behind the
vehicle, however, it will not be able to detect
obstacles located immediately below the
b u m p e r.
An object, such as a stake, a roadworks cone
or any other similar object may be detected at
the start of the manoeuvre but may no longer be
detected when the vehicle moves nearer to it.
4
Driving

138
C5_en_Chap04_conduite_ed01-2014
In bad weather or in winter, ensure that the
sensors are not covered with mud, ice or snow.
When reverse gear is engaged, an audible
signal (long beep) indicates that the sensors
may be dirty.
When the speed of the vehicle is below about
6 mph (10 km/h), some sources of noise
(motorcycle, lorry, pneumatic drill, ...) may
trigger the audible parking sensor signals.
Reactivation
Deactivation
F Press button A , the warning lamp comes
on, the system is fully deactivated.
The system will be deactivated automatically
when a trailer is being towed or when a bicycle
carrier is fitted (vehicle fitted with a towbar or
bicycle carrier recommended by CITROËN).
F

P
ress button A again, the warning lamp
switches off, the system is reactivated.
Driving

186
C5_en_Chap08_information_ed01-2014
Bleeding the Diesel fuel filter
Protective cover
Removing the cover
Bleeding water from the
fuel filter
Bleed regularly (at each oil change).
To bleed the water, slacken the bleed screw or
the water in diesel fuel sensor, located at the
base of the filter.
Continue until all the water has flowed out.
Then tighten the bleed screw or the water
detection sensor.
HDi 115 and HDi 160 engines
F

P

ull the protective cover upwards to
remove it.
HDi 140 engine
F

R

emove the protective cover by first
unclipping at 3 , then 1 and 4.
F

U

nclip at 2 by pulling towards you,
then lift up.Refitting
F Firstly clip in at 2 .
F L ower and centre the cover.
F

C
lip in at 3 and 4 , pushing vertically and
gently from the rear.
F

C
lip in at 1 pushing vertically.
Practical information

197
C5_en_Chap08_information_ed01-2014
If your vehicle is fitted with a spare
wheel of a different size to those on the
vehicle, you must not exceed 50 mph
(80 km/h) whilst using the spare wheel.
The wheel bolts are specific to the type
of wheel.
If the type of wheel is changed,
check with your CITROËN dealer or a
qualified workshop that the wheel bolts
are compatible with the new wheels.
Take care to note down the code
number engraved on the head of the
security bolt socket. This will enable
you to obtain a replacement security
bolt socket from your dealer.
F

T

ighten the security bolt using
wheelbrace


1 and security bolt socket
(depending on equipment).
F

T

ighten the other bolts using just the
wheelbrace 1 .
F

R

efit the protectors on the bolts.
F

S

tow the tools in the carrier box.
F

R

eturn the suspension to the normal
position.
F

E

nsure the tyre pressure is correct and
have the balancing checked.Tyre under-inflation detection
The space-saver type or steel spare
wheel does not have a sensor.
The punctured wheel must be repaired
by a CITROËN dealer or a qualified
workshop.
8
Practical information

212
C5_en_Chap08_information_ed01-2014
Fusebox A
Fusebox B
Fuse N°Rating Function
G29 -Not used
G30 5 AHeated door mirrors
G31 5 ARain and sunshine sensor
G32 5 ASeat belt not fastened warning lamps
G33 5 AElectrochrome mirrors
G34 20 ASunroof (saloon)
G35 5 APassenger door lighting - Passenger door mirror adjustment
G36 30 AElectric tailgate (Tourer)
G37 20 AHeated front seats
G38 30 ADriver’s electric seat
G39 30 APassenger’s electric seat - Hi-Fi amplifier
G40 3 ATrailer relay unit supply
Fuse N° Rating Function
G36 15 A
6 -speed automatic gearbox
5 A 4-speed automatic gearbox
G37 10 ADaytime running lamps - Diagnostic socket
G38 3 ADSC/ASR
G39 10 AHydraulic suspension
G40 3 AST
o
P
switch
Practical information

213
C5_en_Chap08_information_ed01-2014
Fusebox C
Fuse N°Rating Function
F1 15 ARear screen wipe (Tourer)
F2 30 ALocking and deadlocking relay
F3 5 AAirbags
F4 10 AAutomatic gearbox - Additional heater unit (Diesel) - Electrochrome rear view mirrors
F5 30 AFront window - Sun roof - Passenger door lighting - Passenger door mirror adjustment
F6 30 ARear window
F7 5 AVanity mirror lighting - Glove box lighting - Interior lamps - Torch (Tourer)
F8 20 ARadio - CD changer - Steering mounted controls - Screen - Under-inflation detection - Electric boot ECU
F9 30 ACigarette lighter - Front 12 V socket
F10 15 AAlarm - Steering mounted controls, lighting, signalling and wiper stalks
F11 15 ALow current anti-theft switch
F12 15 ADriver’s electric seat - Instrument panel - Seat belt not fastened warning lamps - Air conditioning controls
F13 5 AEngine relay unit - Hydraulic suspension pump cut-off relay - Airbag ECU supply
F14 15 ARain and sunshine sensor - Parking sensors - Passenger’s electric seat - Trailer relay unit - HI-FI amplifier ECU -
Bluetooth system - Lane Departure Warning System
F15 30 ALocking and deadlocking relay
F17 40 AHeated rear screen - Heated door mirrors
FSH SHUNTPARK SHUNT
8
Practical information

223
C5_en_Chap08_information_ed01-2014
Blanking cover
When towing, you must remove the blanking
cover in the front bumper as well as the bonnet
seal if fitted.
Contact a CITROËN dealer or a qualified
workshop for this.
Ty r e s
F Check the tyre pressures of the towing vehicle and of the trailer, observing the
recommended pressures.
Lighting
F Check the electrical lighting and signalling on the trailer.
The rear parking sensors will be
deactivated automatically if a genuine
CITROËN towbar is used.
Braking
Towing a trailer increases the braking distance.
To avoid overheating of the brakes on a long
mountain type of descent, the use of engine
braking is recommended.
8
Practical information

228
C5_en_Chap08_information_ed01-2014
* To avoid any risk of jamming of the pedals:- e nsure that the mat is positioned and
secured correctly,
-

n
ever fit one mat on top of another.
accessories
"Comfort":
front and rear parking sensors, isotherm
module, reading lamp, sun blinds, headrest-
mounted coat hanger...
"Transport solutions":
boot liner, boot carpet, towbars, towbar wiring
harness, transverse roof bars, bicycle carrier,
ski carrier, roof boxes, boot dividers, boot net,
boot organiser, sliding boot tray, platform on
towbar, ...
"Style":
alloy wheels, rear spoiler, chromed mirror
shells, door sill protectors, gear lever knobs...
"Security and safety":
anti-intrusion alarm, warning triangle and
high visibility vest, breathalyzer, first aid kit,
snow chains, non-skid covers, security wheel
bolts, vehicle tracking system, child seats, fire
extinguisher, caravan mirror, pet cage and seat
belt, dog guard...
"Protection":
mats*, seat covers, mud flaps, bumper
protectors, vehicle covers, door and boot sill
protectors...
A wide range of accessories and genuine parts is available from the CITROËN dealer network.
These accessories and parts are all suitable for your vehicle and benefit from CITROËN's recommendation and warranty.
Practical information

335
C5_en_Chap12_index-alpha_ed01-2014
P
Paint colour code ........................................25 6
Paintwork, matt ........................................... 2
27
Panoramic glass sunroof

..............................56
P

arking brake
.............................. 1
00, 101, 241
Parking brake, electric

.......................... 2
7, 101
Parking sensors, rear.................................. 137
Parking space sensor

................................13

5
Particle filter
........................................2

38, 240
Passenger compartment filter
.................... 23

9
Player, CD MP3

...............................
.... 295, 319
Port, USB

..................... 8
8, 298, 299, 320, 322
Priming the fuel system

..............................18

7
Programmable heating
(Webasto)
................................................... 77
P

rotecting children
.......................16

2, 168 -182
Puncture
................

...................................... 188
ROS
Radio ................................................... 291, 317
Reading lamps, rear ...................................... 83
R
ear demisting
........................................ 6
9, 73
Recharging the battery

........................21

7, 218
Regeneration of the particle filter

...............24

0
Reinitialising the electric windows

................48
R

einitialising the remote control
...................42
R

einitialising the sunroof
..............................55
R

emote control
........................................ 3

9-43
Removable screen (snow shield)
...............................

..............226
Removing a wheel

..............................
........19 4
Removing the mat

...............................
.......... 87
Repair kit, puncture

..................................... 18

8
Replacing bulbs
..............................

....19 9 -209
Replacing fuses
..............................

.....210 -215
Replacing the air filter

.................................23

9
Replacing the oil filter

.................................23

9
Replacing the passenger
compartment filter

.................................... 23

9
Replacing wiper blades............................... 153
Resetting the service indicator

.....................2

2
Resetting the trip recorder

............................25
R

ev counter
................................................... 15
R

eversing camera
...............................
........13 9
Reversing lamp
...................................2

03, 205
Risk areas (update)

..................................... 2

70
Roof bars
..................................................... 2

24
Routine checks

.................................... 2

3 9 - 2 41
Running out of fuel (
die

sel)
..................................................... 18

7Safety for children
........................16
2, 168 -182
Screen, colour and mapping...............263, 302
Screen menu map

...............................3
02, 326
Screen, monochrome C

........3
4, 316, 326, 327
Screen, colour
............................................... 37
S

creenwash fluid level
................................23

8
Screenwash, front
....................................... 1

51
Screen-wash reservoir
............................... 23

8
Seat adjustment

...............................
.......58, 59
Seat belts
..................................... 16

0 -162, 174
Seats, rear
..................................................... 65
S

ecurity bolts
......................................19

4, 197
Serial number, vehicle

................................25

6
Service indicator
..................................... 2

1, 22
Servicing
...............................

.................. 13, 22
Setting the clock

.....................................3
6, 38
Short-cut menus

..............................
...........264
Sidelamps
...........................1

42, 199, 203, 205
Side repeater
..............................

................19 9
Ski flap

..............................
............................90
Snow chains
................................................ 19

8
S
no
W
M
oT
I
o
n
..........................................15

7
Spare wheel
...............................

.........192, 197
Speed limiter
...............................

................128
Speedometer
..............................

..................15
Starting the engine

.......................................97
S

teering mounted controls.................. 262, 315
Steering wheel, fixed centred controls

.......12

6
Stopping the vehicle

.....................................97
St

op & Start
.............................. 1
9, 72, 76, 121,
183, 216, 231, 239
Storage compartments
................................. 88
S

toring driving positions
...............................61
S

towing rings
..............................
..................91
Oil change
...............................
.................... 235
Oil consumption
.......................................... 23
5
oil

filter
...............

......................................... 239
oi

l level ..................................................23, 235
Oil temperature indicator

.............................. 24
O

pening the bonnet

.................................... 2

31
Opening the boot

..............................

............ 40
Opening the doors

...............................

... 39, 49
Opening the fuel filler flap

........................... 18

3
Opening the panoramic sunroof blind

....5

5, 56
Opening the sunroof

..................................... 55
O

peration indicator lamps

...................... 26

-33
.
alphabetical index
