Removing the seat cushionReturning the seat backrest to
its original position
F Put the seat backrest 3 into the fully upright
position and secure it.
F Return the seat cushion 1 to its original position.F Refit the head restraints or put them back in place.
When returning the rear seat to its
original position, take care not to trap
the seat belts and ensure that their
buckles are positioned correctly. F

M
ove the corresponding front seat for ward
if necessary.
F
R
aise the front of the seat cushion 1
.
F
T
ilt the seat cushion 1 fully against the front
seat.
Refitting the seat cushion
F Position the seat cushion 1 vertically.
F I nsert one of the fixing brackets 2 into one
of the seat cushion supports. Carry out the
same operation for the other side keeping it
firmly towards the middle.
F

F
ully fold down the seat cushion 1 .
F

P
ress on the seat cushion to secure it.
The red indicator on the control 2 should
no longer be visible; if it is, push the seat
backrest
3

fully back. F
Extract the fixing brackets 2
from the seat
cushion support by keeping it firmly towards the
middle. Carry out the same operation for the
other side.
F Remove the seat cushion 1 by pulling upwards.
3
Ease of use and comfort

70
C5_en_Chap03_ergonomie-et-confort_ed01-2016
Ventilation
A. Sunshine sensor.
B. Soft air diffusion grille.
T

he soft air diffusion grille located in the
centre of the dashboard provides optimum
distribution of the air for the front seats.
T

his system eliminates unpleasant air
currents while maintaining an optimum
temperature in the passenger compartment.
T

o open the soft air diffusion grille, turn the
wheel upwards.
T

o close the soft air diffusion grille, turn the
wheel fully downwards.
I

n very hot weather, to obtain more
satisfactory central and side ventilation, it
is advisable to close the diffused air grille.
C.
C

ooled glove box.
D.
R

ear passenger vents.
Ease of use and comfort

71
C5_en_Chap03_ergonomie-et-confort_ed01-2016
In order for these systems to be fully effective, follow the operation and maintenance
guidelines below:
F
T
o obtain an even air distribution, take care not to obstruct the exterior air intake grilles
located at the base of the windscreen, the nozzles, the vents and the air outlets, as well
as the air extractor located in the boot.
F

D
o not cover the sunshine sensor, located on the dashboard; this is used for regulation
of the air conditioning system.
F

O
perate the air conditioning system for at least 5 to 10 minutes, once or twice a month
to keep it in per fect working order.
F

E
nsure that the passenger compartment filter is in good condition and have the filter
elements replaced regularly.
W

e recommend the use of a combined passenger compartment filter. Thanks to its
special active additive, it contributes to the purification of the air breathed by the
occupants and the cleanliness of the passenger compartment (reduction of allergic
symptoms, bad odours and greasy deposits).
F

T
o ensure correct operation of the air conditioning system, you are also advised to
have it checked regularly as recommended in the maintenance and warranty guide.
F

I
f the system does not produce cold air, switch it off and contact a CITROËN dealer or
a qualified workshop.
When towing the maximum load on a steep gradient in high temperatures, switching off the
air conditioning increases the available engine power and so improves the towing ability.
Recommendations for ventilation and air conditioning
Stop & Start
The heating and air conditioning
systems only work when the engine is
running.
To maintain a comfortable temperature
in the passenger compartment, you can
temporarily deactivate the Stop & Start
system.
For more information on Stop & Star t ,
refer to the corresponding section. The condensation created by the air
conditioning results in a discharge
of water under the vehicle which is
per fectly normal.
If after an extended stop in sunshine,
the interior temperature is very
high, first ventilate the passenger
compartment for a few moments.
Put the air flow control at a setting high
enough to quickly change the air in the
passenger compartment.
Contains fluorinated greenhouse gas R134A.
From 1st October 2016, depending on version and country of sale, contains fluorinated
greenhouse gas R134A (gas capacity 0.525 kg +/- 0.025 kg, GWP index 1 430, 0.751 t
equivalent CO
2). The air conditioning system does not
contain chlorine and does not present
any danger to the ozone layer.
3
Ease of use and comfort

72
C5_en_Chap03_ergonomie-et-confort_ed01-2016
Digital air conditioning (dual-zone)
The air conditioning system operates with the engine running.
Dual-zone: this is the independent regulation of the temperature and air distribution on the driver's
side and the front passenger's side.
The driver and front passenger can each adjust the temperature and the air distribution to suit their
requirements.
The symbols and messages associated with the digital air conditioning controls appear in the
display screen. This is the normal system
operating mode. In accordance
with the level of comfort chosen,
pressing this control, confirmed
by illumination of indicator
lamp
A, permits automatic and
simultaneous control of all of the
following functions:1a-1b. Automatic operation
1a. Automatic operation on the driver's side
1b. A utomatic operation on the passenger's
side
2a.
T

emperature adjustment on the driver's
side
2b.
T

emperature adjustment on the
passenger's side
3a.
A

ir distribution adjustment on the driver's
side
3b.
A

ir distribution adjustment on the
passenger's side 4a. D
river's zone screen
4b. P assenger's zone screen
5.
A

ir flow adjustment
6.
A

ir conditioning On / Off
7.
R

ecirculation of interior air
8.
R

ear demisting / defrosting
9.
F

ront demisting / defrosting-

A
ir flow.
-
T
emperature in the passenger
compartment.
- A ir distribution.
-

A
ir conditioning.
-

A
utomatic air recirculation.
It is advisable to leave all of the vents open.
Simply pressing one of the controls, with the
exception of temperature regulation 2a and 2b,
switches the system to manual mode. Indicator
lamp A goes off.
Ease of use and comfort

73
C5_en_Chap03_ergonomie-et-confort_ed01-2016
2a-2b. Temperature adjustmentControl via the manual controls3a-3b.
A ir distribution
adjustment
F Press control 3b to change the distribution
of the air flow on the passenger's side.
The indicator lamps corresponding to the
distribution chosen come on:
-

W
indscreen and front side windows.
-

F
ront ventilation (central and side vents
and air diffusion grille if open) and rear
ventilation.
-

F
ront and rear footwells.
F

T

urn control 2a
to change the temperature
on the driver's side and control 2b
to change the temperature on the
passenger's side: to the right to increase or
to the left to reduce it.
The setting required is displayed.
The value indicated on the display corresponds
to a level of comfort and not to a temperature in
degrees Celsius or Fahrenheit, depending on
the screen configuration.
A setting around the value 21 usually provides
optimum comfort. However, depending on your
requirements, a setting between 18 and 24 is
normal. F

P
ress control 3a

to change the
distribution of the
air flow on the
driver's side.
F

P

ress one of the controls, with the
exception of temperature regulation 2a and
2b . The indicator lamps A in the "AUTO"
controls go off.
It is possible to adjust one or more functions
manually while leaving the other functions in
automatic mode.
Switching to manual mode may result in
discomfort (temperature, humidity, odour,
condensation) and may not provide optimum
comfort.
To return to "AUTO" mode, press controls 1a
and 1b . The indicator lamps A come on.
On entering the vehicle, the interior
temperature may be much colder
(or

warmer) than is comfortable. There
is no need to change the temperature
displayed in order to quickly obtain the
level of comfort required.
The automatic regulation of the air
conditioning will use its maximum
per formance settings to correct the
temperature difference as quickly as
possible.
Simultaneous display of the
distribution of air to the windscreen
and side windows and of front and rear
ventilation is not possible.
3
Ease of use and comfort

74
C5_en_Chap03_ergonomie-et-confort_ed01-2016
5. Air flow adjustment
Reducing the air flow to minimum switches
the air conditioning system OFF.
To prevent condensation and deterioration
of the quality of the air in the passenger
compartment, ensure that an adequate flow of
air is maintained.
6. Air conditioning
The air conditioning will only
operate when the engine is running.
The air blower control (air flow
adjustment) must be active in order
to obtain air conditioning.
7. Recirculation of interior air
F Press control 7 once to activate recycling of the
interior air.
This function permits recirculation
of the air and isolation of the
passenger compartment from
exterior fumes and odours.
F

P

ress button 7 again
to activate automatic
recirculation with pollution
detection. F

P
ress control 7 a third time
to return to the standard
automatic mode (without
pollution detection).
Using a pollution sensor, the system
automatically activates recirculation of the
interior air once it detects a certain level of
pollutants in the interior air.
When the air quality returns to a satisfactory
level, the recirculation of interior air is
automatically deactivated.
F
P
ress the control:
-
t
o increase the air flow,
-

t

o reduce the air flow.
The air flow level is indicated by the
progressive illumination of the fan
blade indicator lamps.
Avoid prolonged use of air
recirculation
- Risk of misting and
deterioration of air quality!
You can store the settings of the air
conditioning system.
For more information on the Front
seats (and in particular storing driving
positions), refer to the corresponding
section.
F

P

ress control 6 . The indicator lamp comes
on.
In order to be effective, the air conditioning
must be used with the windows closed. Recirculation of the interior air is automatically
activated when engaging reverse or if the
screenwash is used.
The system is inactive when the ambient
temperature is below +5 °C to avoid the risk of
formation of mist on the windscreen and side
windows. This system is not designed to detect
unpleasant odours.
The system is inactive when the exterior
temperature is below +5 °C to avoid the risk of
formation of mist on the windscreen and side
windows.
Ease of use and comfort

75
C5_en_Chap03_ergonomie-et-confort_ed01-2016
9. Front demisting / defrosting
In certain cases, the "AUTO"
mode may not be sufficient to
demist or defrost the windows
(humidity, several passengers,
i c e).
8. Rear demisting / defrosting
The heated rear screen operates
independently of the air
conditioning system.
F

P

ress control 8 , with the engine running, to
demist the rear screen and the mirrors. The
indicator lamp comes on.
Demisting is switched off automatically to
avoid excessive consumption of current and
depending on the exterior temperature.
It may be stopped by pressing control 8 again
or when the engine is switched off.
In this latter case, the demisting resumes if the
engine is switched on again within one minute. F

P
ress control 9 to clear the windows
quickly. The indicator lamp comes on.
This system controls the temperature, air flow
and intake and distributes the ventilation to the
windscreen and front side windows.
Resuming manual control exits from the
"Demisting" mode. It must be cancelled as
soon as possible to permit renewal of the air in
the passenger compartment and demisting.
Pressing one of the controls 1a or 1b returns
the system to the "AUTO" mode.
With Stop & Start, when demisting has
been activated, the STOP mode is not
available. When starting with the engine cold,
air flow will reach its optimum level
gradually to prevent an excessive
distribution of cold air.
When entering the vehicle after it has
been parked for a fairly long period, if
the interior temperature is very different
from your comfort setting there is
no need to change the temperature
displayed in order to quickly reach the
level of comfort required. The system
automatically uses its maximum
per formance to correct the difference in
temperature as quickly as possible.
The water resulting from the air
conditioning condensation is
discharged via an opening provided
for this purpose; therefore, a puddle of
water may form underneath the vehicle
when stationary.
In all seasons, if the weather is cool,
the air conditioning is useful as it
removes the humidity from the air
and the condensation. Avoid driving
for prolonged periods with the air
conditioning switched off.
Switch off the rear screen and
exterior mirrors demisting when you
consider this necessary, as low current
consumption reduces fuel consumption.
3
Ease of use and comfort

76
C5_en_Chap03_ergonomie-et-confort_ed01-2016
Map reading lamps
F With the ignition on, press the corresponding switch.
Panoramic sunroof rear
reading lamps (Tourer)
With the key in position or with the ignition on:
F P ress the corresponding switch 1 .
The reading lamp concerned comes on for
ten
m

inutes.
The rear reading lamps come on:
-

w
hen the key is removed from the ignition,
-

w
hen the vehicle is unlocked.
They switch off gradually:
-

w
hen the vehicle is locked,
-

w
hen the ignition is switched on.
Courtesy lamps
1. Front courtesy lamp
2. M ap reading lamp s
Front courtesy lamp
Rear courtesy lamp
1. Rear courtesy lamp
2. M
ap reading lamps In this position, the courtesy lamp
comes on gradually:
Lighting off.
Lighting on.
-
w
hen the vehicle is unlocked,
-
w
hen a door is opened,
-
w
hen the key is removed from the ignition,
-
w
hen the remote control locking button is
activated, in order to locate your vehicle.
It switches off gradually:
-
w
hen the vehicle is locked,
-
w
hen the ignition is switched on,
-
3
0 seconds after the last door is closed.
In lighting on mode, different lighting
times are available:
-
w
ith the ignition off, approximately
ten minutes,
- i n energy economy mode,
approximately thirty seconds,
-

w
ith the engine running, unlimited.
Ease of use and comfort

77
C5_en_Chap03_ergonomie-et-confort_ed01-2016
Interior mood lightingYour vehicle is equipped with interior mood lighting for the centre console and the door handles.
Central consoleLighting for door opening
controls
Operation
These lamps are activated with the automatic
illumination of headlamps, when the ambient
light is poor. They are deactivated when the
instrument panel is off.
The intensity of the lighting varies along with
that of the instrument panel.
F

P
ress buttons A to increase or reduce the
intensity of the lighting. This is located on the front and rear interior
door opening controls.
The rear door opening controls lighting is
deactivated if the child lock is on.
The lamps are located on the roof console,
near the front interior lamp. They illuminate the
central console.
3
Ease of use and comfort

78
C5_en_Chap03_ergonomie-et-confort_ed01-2016
Pavement lighting
With the door open, this illuminates the ground
next to the vehicle.
Floor lighting
In the front of the vehicle, when a door
is opened, this illuminates the interior of
the vehicle.
The welcome lighting is made up of:
-

T
he interior (roof) lamps.
-
T
he floor lighting.
-
T
he pavement lighting when a door is open.
Welcome lighting
Ease of use and comfort
