C5_EN_CHAP00C_ECO-CONDUITE_ED01-2016.
Optimise the use of your gearbox
With a manual gearbox, move off gently and change up without waiting.
During acceleration change up early.
With an automatic or electronic gearbox, give preference to automatic
mode and avoid pressing the accelerator pedal heavily or suddenly.
Control the use of your electrical
equipment
Before moving off, if the passenger compartment is too warm, ventilate it
by opening the windows and air vents before using the air conditioning.
Above 30 mph (50 km/h), close the windows and leave the air vents
open.
Remember to make use of equipment that can help keep the
temperature in the passenger compartment down (sunroof and window
blinds...).
Switch off the air conditioning, unless it has automatic regulation, as
soon as the desired temperature is attained.
Switch off the demisting and defrosting controls, if not automatic.
Switch off the heated seat as soon as possible.
Switch off the headlamps and front foglamps when the level of light
does not require their use.
Avoid running the engine before moving off, particularly in winter; your
vehicle will warm up much faster while driving.
As a passenger, if you avoid connecting your multimedia devices
(film, music, video game...), you will contribute towards limiting the
consumption of electrical energy, and so of fuel.
Disconnect your portable devices before leaving the vehicle.
Eco-driving
Eco-driving is a range of everyday practices that allow the motorist to optimise their fuel consumption and CO2 emissions.
The gear efficiency indicator invites you to engage the most suitable
gear: as soon as the indication is displayed in the instrument panel,
follow it straight away.
For vehicles fitted with an electronic or automatic gearbox, this
indicator appears only in manual mode.
Drive smoothly
Maintain a safe distance between vehicles, use engine braking rather
than the brake pedal, and press the accelerator progressively. These
practices contribute towards a reduction in fuel consumption and
CO
2 emissions and also help to reduce the background traffic noise.
I
f your vehicle has cruise control, make use of the system at speeds
above 25 mph (40 km/h) when the traffic is flowing well.
Eco-driving

15
C5 _en_Chap01_instruments-bord_ed01-2016
* Only with the Audio system .
The instrument screen A is located in the
centre of the instrument panel.
-

W

ith the vehicle stationary, you can access
the main menu of the screen by quickly
pressing on the left-hand thumb wheel B
on the steering wheel.
-

W

hilst driving, the message "Action
impossible while driving" is displayed in
the instrument panel if you try to open the
main menu.
"Vehicle parameters" menu*
This allows you to access the settings for
certain functions, grouped by category:
-

A
ccess to the vehicle.
-
L

ighting.
-

D
riving assistance.
"Choice of language" menu
This allows you to choose the display and voice
recognition language.
Main menu
The main menu allows you to programme
certain vehicle functions* and the instrument
panel screen:
"Choice of units" menu
This allows you to choose metric or imperial
units.
1
Instruments

17
C5 _en_Chap01_instruments-bord_ed01-2016
System that gives you information on the current journey (range, fuel consumption…).
In the instrument panel screen
Information displays
F Turn the left-hand thumb wheel A on the steering wheel to display the various trip
computer tabs in succession:
Trip computer
- The current information tab is displayed in zone B of the instrument panel screen, with:
●

t
he range,
●

t
he current fuel consumption,
●

t
he digital speed reading or the Stop &
Start time counter.
-

T
he trip "1" tab is displayed in zone C of
the instrument panel screen, with:
●

t
he distance travelled,
●

t
he average fuel consumption,
●

t
he average speed,
f

or the first trip.
-

T
he trip "2" tab is displayed in zone C of
the instrument panel screen, with:
●

t
he distance travelled,
●

t
he average fuel consumption,
●

t
he average speed,
f

or the second trip.
Trip reset
F When the trip required is displayed, press the left-hand thumb wheel on the steering
wheel for more than two seconds.
Tr i p s "1" and "2" are independent but their use
is identical.
For example, trip "1" can be used for daily
figures and trip "2" for monthly figures.
1
Instruments

18
C5 _en_Chap01_instruments-bord_ed01-2016
In the touch screen tablet
Information display
F Press the MENU button. -
T
he current information tab with:
●
t
he range,
●
t
he current fuel consumption,
●
t
he Stop & Start time counter.
-
T
he trip "1"
tab with:
●
t
he average fuel consumption,
●
t
he distance travelled,
●
t
he average speed,
f

or the first trip.
- T he trip "2"
tab with:
● t he average fuel consumption,
●

t
he distance travelled,
●

t
he average speed,
f

or the second trip.
Trip reset
F When the desired trip is displayed, press the reset button.
F

Sel

ect " Driving " to display the
various tabs.
F

S

elect the desired tab using your finger. For example, trip "1"
can be used for daily
figures, and trip "2" for monthly figures.
Tr i p s "1"
and "2" are independent but their use
is identical.
Instruments

19
C5 _en_Chap01_instruments-bord_ed01-2016
A few definitions…
Range
(miles or km)
The distance which can still be
travelled with the fuel remaining
in the tank (at the average fuel
consumption seen over the last
few miles (kilometres) travelled).
Current fuel
consumption
(mpg or l/100 km or km/l)
Calculated over the last few seconds.
Average fuel consumption
(mpg or l/100 km or km/l)
Calculated since the last trip
computer reset.
Distance travelled
(miles or km)
Calculated since the last trip
computer reset.
When the range falls below 20 miles (30 km),
dashes are displayed.
After filling with at least 5 litres of fuel, the
range is recalculated and is displayed if it
exceeds 60 miles (100 km).
Stop & Start time
counter
(minutes / seconds or hours /
m inutes)
If your vehicle is fitted with
Stop & Start, a time counter
calculates the time spent in
STOP mode during a journey.
It resets to zero every time the
ignition is switched on with
the
key.
This function is only displayed from
20

mph (30 km/h).
This value may vary following a change
in the style of driving or the relief,
resulting in a significant change in the
current fuel consumption.
If dashes are displayed continuously
while driving in place of the digits,
contact a CITROËN dealer or a
qualified workshop.
Average speed
(mph or km/h)
Calculated since the last trip
computer reset.
1
Instruments

20
C5 _en_Chap01_instruments-bord_ed01-2016
Return to the main
instrument panel screen
display
Successive rotations of the left-hand thumb
wheel on the steering wheel allow you to return
to the main instrument panel screen display
(vehicle speed), via the navigation information
screen, then the screen displaying only the
total mileage and the trip mileage (bottom of
screen).You can display navigation information in
the
instrument panel screen by rotating the
left-hand thumb wheel on the steering wheel. This function allows you to check certain
indicators and display the log of alerts.
F

P
ress on button A.
The following information appears in turn in the
instrument panel screen:
-

R
epeat of the service indicator.
-

R
epeat of the range indicator for the
AdBlue
® and the SCR system for BlueHDi
Diesel versions.
-

R

epeat of the engine oil level indicator.
-

A

ny alert messages.
Check function
Display of navigation
information in the
instrument panel screen
Instruments

21
C5 _en_Chap01_instruments-bord_ed01-2016
Engine oil temperature
gauge
Under normal operating conditions, the bars
should be within section 1.
In severe operating conditions, the bars may
extend into section 2 .
In this event, slow down, and if necessary,
stop the engine and check the levels (see the
corresponding section).
Coolant temperature
gauge
Under normal operating conditions, the bars
should be within section 1 .
In severe operating conditions, the bars may
extend into section 2 , the engine coolant
temperature warning lamp A and the STOP
warning lamp come on in the instrument panel.
Stop as soon as it is safe to do so . Switch off
the ignition. The cooling fan may continue to
operate for a cer tain time .
Contact a CITROËN dealer or a qualified
workshop.
If the SERVICE warning lamp comes on, check
the levels (see the corresponding section). On horizontal ground, illumination of the fuel
low warning lamp indicates that you are at the
reser ve level.
An alert message is displayed in the instrument
panel.
Fuel gauge
Indicators
1
Instruments

22
C5 _en_Chap01_instruments-bord_ed01-2016
More than 1 700 miles (3 000 km)
remain before the next service
is due
When the ignition is switched on, no service
information appears in the instrument panel
screen.
Between 600 miles (1 000 km) and 1 800 miles
(3 000 km) remain before the next service is due
For a few seconds after the ignition is switched
on, the spanner symbolising the service
operations comes on and a message is
displayed in the instrument panel indicating
the distance or time remaining before the next
service is due.
Example: 1 900 miles (2 800 km) remain
before the next service is due.
When the ignition is switched on, the
instrument panel screen temporarily indicates:
Less than 600 miles (1 000 km)
remain before the next service is due
For a few seconds after the ignition is switched
on, the spanner symbolising the service
operations flashes and a message is displayed
in the instrument panel indicating the distance or
time remaining before the next service is due.
Example: 500 miles (900 km) remain before the
next service is due.
When the ignition is switched on, the instrument
panel screen indicates for a few seconds:
After the message disappears, the spanner
remains on alongside the mileage recorder as
a reminder that a service must be carried out
soon.
Service indicator
System which informs the driver when the
next service is due, in accordance with the
manufacturer's service schedule.
The point at which the service is due is
calculated from the last service indicator reset
to zero, according to the mileage covered and
the time elapsed since the last service.
A few seconds after the ignition is switched on,
the spanner goes off.
For BlueHDi Diesel versions, depending
on the country of sale, the degree of
deterioration of the engine oil may also
be taken into account.
Instruments

23
C5 _en_Chap01_instruments-bord_ed01-2016
Service indicator
zero resetService overdue
For a few seconds after the ignition is switched
on, the spanner flashes to indicate that
the service must be carried out as soon as
possible.
Example: the service is overdue by 300 miles.
When the ignition is switched on, the
instrument panel screen indicates:
The spanner remains on alongside the
mileage recorder to indicate that a service is
overdue. For BlueHDi Diesel versions, the
spanner may also come on early,
according to the level of deterioration
of the engine oil, which depends on the
driving conditions in which the vehicle
is used.
After each service, the service indicator must
be reset to zero.
If you have carried out the service yourself:
F

s
witch off the ignition,
F

p
ress and hold the trip distance recorder
zero reset button,
F

s
witch on the ignition; the distance recorder
display begins a countdown,
F

w
hen the display indicates "=0", release
the button; the spanner disappears.
Following this operation, if you wish to
disconnect the battery, lock the vehicle and
wait at least five minutes for the zero reset to
be taken into account.
For BlueHDi Diesel versions, the
Service
warning lamp also comes on
when the ignition is switched on. The spanner may come on if you have
exceeded the period since the last service,
as indicated in the manufacturer's service
schedule.
1
Instruments
