oil filter Citroen C5 RHD 2015 (RD/TD) / 2.G Owner's Manual

11
Technical data - Maintenance
Petrol engines 242
Petrol weights 243
Diesel engines 244
Diesel weights 245
Dimensions (Saloon) 246-247
Dimensions (Tourer) 248 -249
Identification markings 250
Opening the bonnet 224
Petrol under-bonnet layout 225
Diesel under-bonnet layout 226
Running out of fuel - Diesel
180
Checking the levels 227-230
- oil
- brake fluid
- power steering fluid
- coolant
- screenwash / headlamp wash fluid
AdBlue additive 234-241
Very cold climate protection
219
Changing bulbs 193-203
- front
- rear
- interior Checking components
231-233
- battery
- air / passenger compartment filter
- oil filter
- particle filter (Diesel)
- brake pads / discs
Batter y 210 -212
Energy economy mode 213
Engine compartment

fuses 204, 208 -209
.
over view

13
Limit the causes of excess consumption
Spread loads throughout the vehicle; place the heaviest items in the
bottom of the boot, as close as possible to the rear seats.
Limit the loads carried in the vehicle and reduce wind resistance
(roof bars, roof rack, bicycle carrier, trailer...). Use a roof box in
preference.
Remove roof bars and roof racks after use.
At the end of winter, remove snow tyres and refit your summer tyres.
Observe the recommendations on
maintenance
Check the tyre pressures regularly, when cold, referring to the label in
the door aperture, driver’s side.
Carry out this check in particular:
- before a long journey,
- at each change of season,
- after a long period out of use.
Don’t forget the spare wheel and the tyres on any trailer or caravan.
Have your vehicle serviced regularly (engine oil, oil filter, air filter,
passenger compartment filter...) and observe the schedule of
operations recommended in the manufacturer’s service schedule.
With a BlueHDi Diesel engine, if the SCR system is faulty your vehicle
becomes polluting; go to a CITROËN dealer or a qualified workshop
without delay to have the emissions of nitrous oxides brought back to
the legal level.
When refuelling, do not continue after the third cut-off of the nozzle to
avoid any over flow.
At the wheel of your new vehicle, it is only after the first 1 800 miles
(3 000 kilometres) that you will see the fuel consumption settle down to
a consistent average.
.
Eco-driving

225
The various caps and covers allow access for
checking fluid levels and for replacing certain
components.THP
Petrol engines
1. Screenwash and headlamp wash fluid
reservoir.
2. Power steering fluid reservoir
or
or power steering and Hydractive III +
suspension fluid reservoir.
3. Engine coolant header tank.
4. Engine oil dipstick.
5. Engine oil filler cap.
6. Brake fluid reservoir.
7. Battery.
8. Air filter.
9
Checks

226
Diesel engines
HDi 160
BlueHDi 150 / BlueHDi 180
The various caps and covers allow access
for checking fluid levels, for replacing certain
components and for priming the fuel system.
1.
Screenwash and headlamp wash fluid
reservoir.
2. Power steering fluid reservoir
or
power steering and Hydractive III +
suspension fluid reservoir.
3. Engine coolant header tank.
4. Engine oil dipstick.
5. Engine oil filler cap.
6. Air filter.
7. Brake fluid reservoir.
8. Battery.
The Diesel fuel system operates under
high pressure:
- Never carry out any work on this
system yourself.
- HDi engines make use of advanced
technology.
All maintenance and repairs require
specially trained staff, which only a
CITROËN dealer can provide.
Checks

230
Diesel additive level
(Diesel engine with
particle filter)
To p p i n g u p
This additive must be topped up by a CITROËN
dealer or a qualified workshop without delay.
Used products
A low additive level is indicated by
illumination of this warning lamp,
accompanied by an audible warning
and a message in the instrument
panel screen.
Screenwash and headlamp
wash fluid
In the case of vehicles fitted with
headlamp washers, the low fluid level
is indicated by an audible signal and
a message in the screen.
Fluid specification
For optimum cleaning and to avoid freezing,
this fluid must not be topped up with or
replaced with plain water.
Reservoir capacity (depending on version).
- screenwash fluid: approximately 3.5 litres,
- screenwash and headlamp wash fluid:
approximately 6.15 litres.
Top up the reservoir when you next stop
the vehicle.
Avoid prolonged contact of used oil or
fluids with the skin.
Most of these fluids are harmful to
health or indeed very corrosive.
Do not discard used oil or fluids into
sewers or onto the ground.
Take used oil to a CITROËN dealer or
a qualified workshop (France) or to an
authorised waste disposal site.
Checks

231
Checks
12 V battery
The battery does not require any maintenance.
However, check that the terminals are clean
and correctly tightened, particularly in summer
and winter.
The presence of this label, in particular with
the Stop & Start system, indicates the use of
a specific 12 V lead-acid battery with special
technology and specification. The involvement
of a CITROËN dealer or a qualified workshop
is essential when replacing or disconnecting
the battery. Unless other wise indicated, check these components in accordance with the manufacturer's service schedule and according to your engine.
Other wise, have them checked by a CITROËN dealer or a qualified workshop.
Air filter and passenger compartment filter
Depending on the environment (e.g. dusty
atmosphere) and the use of the vehicle (e.g.
city driving), replace them twice as often if
necessary.
A clogged passenger compartment filter may
have an adverse effect on the per formance
of the air conditioning system and generate
undesirable odours. Replace the oil filter each time the
engine oil is changed.
Oil filter
Refer to the manufacturer's service schedule
for details of the replacement interval for this
component.
Refer to the manufacturer's
service schedule for details of the
replacement intervals for these
components.
When carrying out work on the battery,
refer to the "12 V battery" section for
details of the precautions to be taken
before disconnecting the battery and
following its reconnection.
9
Checks

232
Manual gearbox
The gearbox does not require any
maintenance (no oil change).
Automatic gearbox
The gearbox does not require any
maintenance (no oil change).
Refer to the manufacturer's service schedule
for the checking interval for this component.
Refer to the manufacturer's service schedule
for details of the level checking interval for this
component.
Particle filter system
(Diesel)
Complementary to the catalytic converter,
this filter makes an active contribution to the
preservation of air quality by trapping unburnt
pollutant particles. Black exhaust fumes are
thus no longer emitted.
After prolonged idling or driving at very low
speeds, you may occasionally notice water
vapour being emitted from the exhaust when
accelerating. This is of no consequence to the
running of the vehicle or to the environment. If there is risk of blockage, a message
appears in the instrument panel screen,
accompanied by an audible signal and
illumination of the service warning lamp.
This alert tells you that the particle filter
is approaching saturation (in conditions
of urban driving of exceptionally long
duration: low speeds, traffic jams etc.)
To regenerate the filter, it is advised to
drive as soon as possible, when traffic
conditions permit, at a speed of 40 mph
(around 60 km/h) or more for at least
five minutes (until the alert message
disappears).
If this alert persists, contact a CITR
oËn
dealer or a qualified workshop.
Checks

242
Engines and gearboxes
Petrol engineTHP 155THP 160
THP 15 0
Gearbox Automatic (6-speed)Automatic (6-speed)
Model code:
RD... RW... 5F V- A

5 FN - A* * 5FM-A

5FE-A /D**
Cubic capacity (cc) 1 5981 598
Bore x stroke (mm) 77 x 85.877 x 85.8
EU standard maximum power (kW)* / hp DIN 115 / 110**120 / 110**
Maximum power engine speed (rpm) 6 0006 000
EU standard maximum torque (Nm) 240240
Maximum torque engine speed (rpm) 1 4001 400
Fuel UnleadedUnleaded
Catalytic converter Ye sYe s
Engine oil capacity (with filter replacement) 4.254.25
* The maximum power corresponds to the type approved value on a test bed, under conditions defined by European legislation
(directive 1999/99/EC).
** In Russia, the maximum power is 110 kW and in Brazil, the maximum power is 120 kW. RD...: Saloon.
RW...: Tourer.
Technical data

244
RD...: Saloon.
RW...: Tourer.
* The maximum power corresponds to the type approved value on a test bed, under conditions defined by European legislation
(directive 1999/99/EC).
Engines and gearboxes
Diesel engine BlueHDi 150 S&SHDi 160BlueHDi 180 S&S
Gearbox Manual (6-speed)Automatic (6-speed)EAT6 automatic (6-speed)
Model code:
RD... RW... AHR- M/S
RHH-AAHW-T/S
Cubic capacity (cc) 1 9971 9971 997
Bore x stroke (mm) 85 x 8885 x 8885 x 88
EU standard maximum power (kW)* 11 0120 13 3
Maximum power engine speed (rpm) 4 0003 7503 750
EU standard maximum torque (Nm) 370340 400
Maximum torque engine speed (rpm) 2 0002 0002 000
Fuel diesel diesel diesel
Catalytic converter Ye sYe sYe s
Particle filter (FAP) Ye sYe sYe s
Engine oil capacity (with filter replacement) 5 .15.5 5 .1
.../S: model fitted with Stop & Star t.
Technical data

334
Emergency warning
lamps .......................................................... 148
Emissions control system, SCR ...................................................... 33, 234
Energy economy
mode ........................................................... 213
Engine compartment ............................ 225, 226
Engine, Diesel .......................179, 226, 244, 245
Engine, petrol ........................ 179, 225, 242, 243
Environment .............................................. 12, 49
Deactivating the passenger

airbag .......................................................... 15 8
Deadlocking .................................................... 47
Demisting/defrosting,
front ......................................................... 77, 82
Demisting/defrosting, rear ........................ 78, 82
d iesel ............................................................ 179
Dimensions ................................................... 246
Dipstick .................................................... 24, 227
Direction indicators ....................... 148, 195, 199
d isplay screen,
instrument panel .............................. 14, 17, 114
d isplay screen,
multifunction ................................................. 37
d oors ............................................................... 55
Driving economically ....................................... 12
Driving positions (storing) ...............................67
Dynamic stability control (DSC) ..............29, 151
CITR
oËn Localised
Emergency Call .................................. 149, 251
Closing the boot .............................................. 46
Closing the doors ...................................... 46, 55
Configuration,
vehicle ............................... 15, 37, 42, 286, 328
Connection, b luetooth ......... 296, 304, 305, 324
Connection, MirrorLink ................................. 299
Connection, Wi-Fi network ...........................296
Control, electric windows ................................53
Control, emergency
boot release .................................................. 58
Control, emergency door ................................ 57
Control, heated seats ...................................... 66
Control, panoramic sunroof blind ................................................. 62
Control stalk, lighting .............................13 6 -14 0
Control stalk, wipers ..............................14 4 -146
Courtesy lamps ............................................... 83
Cover, load space ........................................... 93
Cruise control ................................................ 125
Cup holder ................................................. 88, 89
DAB (Digital Audio Broadcasting) - Digital radio ......................................... 280, 281
Date (setting) ............................................. 39, 44
Daytime running lamps .........................139, 193
Deactivating ESP .......................................... 152
D
Eco-driving ..................................................... 12
Economy
mode ........................................................... 213
Electronic brake force distribution (EBFD) ........................................................ 150
Emergency braking assistance (EBA) .......................................................... 150
Emergency call ..................................... 149, 251
E
Filling the fuel tank ................................. 17 7-179
Filter, air ........................................................ 231
Filter, oil ......................................................... 231
Filter, particle ........................................ 230, 232
Filter, passenger
compartment .............................................. 231
Fitting a wheel ............................................... 19 0
Fitting roof bars ............................................. 218
Fittings, boot ............................................. 91, 92
Fittings, interior ............................................... 86
Fittings, rear .................................................... 89
Flap, fuel filler ......................................... 17 7, 178
Flashing indicators ........................................ 148
Foglamps, front ..................................... 137, 196
Foglamps, rear ............................... 137, 197, 199
Folding the rear seats ..................................... 71
Frequency (radio) ..........................278, 279, 318
F
alphabetical index
