Citroen C6 2007 1.G Owner's Manual

113
IIIA
S U N R O O F
Glass sun roof
The sun roof is operated by the electrical control A.
An action to the fi rst notch of the control starts a movement which stops as soon as you release the control.
An action to the second notch of the control opens or closes the sun roof fully. A further action stops the movement.
ANTI-PINCH
An anti-pinch device is present to stop the sun roof from sliding shut. If it meets an obstacle it slides in the opposite direction.
After a battery disconnection or if there has been a malfunction, you have to re-initialise the anti-pinch function.
To do that, action the control A to the second notch to make the sun roof open fully, then keep the control A pressed for at least 1 seconds.
Warning: During this manœuvre, the anti-pinch does not operate.
Your vehicle's sun roof has a manually-operated blind.
Always remove the ignition key when leaving the vehicle, even if for a short time.
In the event of anything being caught by the sun roof clos ing, you must reverse the roof movement.
To do that, reverse the position of the control concerned.
When the driver is operating the sun roof, he or she must always make sure that the passengers are not preventing it from closing properly.
The driver must ensure that passengers use the sun roof control correctly.
PAY ESPECIAL ATTENTION TO WHERE CHILDREN ARE WHEN OPERATING THE SUN ROOF.

114
IV
1
4
6
2
3
5
S7
ADHECJIK
UQOFNMLRPVW
BG
R D S A U D I O C O M P A C T D I S C S Y S T E M

115
IV
AOn / Off.Volume adjust.
BCD eject.
CCD aperture.
DSOURCESelection of sound source (Radio, CD, CD changer).
ETELOne press: Display of information concerning the Bluetooth®system if your vehicle is so equipped.
FCall-up of audio adjustments.
GLIST
Radio source:Short press: Display of the list of radio stations available (30 maximum). Display
Long press: Update of list of stations.CD source: Display of list of tracks of the CD.

116
IV
1
Radio source:Scrolling of pre-set stations.
CD changer source:Selection of CD.CD changer source:
Other sources:Within a menu, selection of a choice.

117
IV
ON / OFF
With the key in Drive position M, press on control A to switch the radio on or off.Note:If the radio was on the last time Ifyou switched off the ignition, it will resume automatically when you switch on the ignition again. You will not have to press on control A.
After switching off the ignition, Afteryou can still operate the audio system even without the igni-tion key being present. Simply press on button A. The system will turn itself off after approx.30minutes.
ANTI-THEFT SYSTEM
This radio is coded in such a way as to function only on your particu-lar vehicle. It would be unusable if installed on any other vehicle.Note: The anti-theft system is automatic and requires no action on your part.

118
IV
NOTES ON RADIO RECEP-TION
Your radio will be subject to certain phenomena that are not encoun-tered by domestic systems.
The reception of AM and FM sig-nals may suffer from interference, which is caused by the nature and propagation of the signals and does not refl ect on the quality of your radio installation.
In AM, the reception may be affected when passing under power lines or bridges, or when travelling through tunnels.
In FM mode, the reception may be affected by the distance from the station transmitter, the refl ect-ing of signals off obstacles (moun-tains, hills, tower blocks) and radio blackspots (no coverage from the station transmitter).
SELECTION OF RADIO SOURCE
Press button D to select the source.
You can also do this by means of control 5 at the steering wheel.
R A D I O S O U R C E
SELECTION OF FREQUEN-CIES AND MEMORY BANKS
Press button R successively to go through the memory banks FM1, FM2 and FM3, for the FM waveband, and the mem-ory banks MW/LW, for the AM waveband.
MANUAL SEARCH
Manual search is via buttons Jor M.
By keeping button J or M pressed, you will be able to scroll through the waveband. Scrolling will stop as soon as you release the button. The radio will remain tuned to the frequency that is displayed.
TUNING SENSITIVITY
Automatic searches can be carried out according to two levels of sen-sitivity:To capture the most powerful transmitters, choose the local search mode “LO” (default option).
To capture the weakest or most distant transmitters, choose the sensitive search mode “DX”.

119
IV
DISPLAY AND SELECTION OF A STATION AVAILABLE IN THE AREA IN WHICH YOU ARE TRAVELLING
Briefl y press on button G to bring up a list of stations, this is updated every 10 minutes.
You can also update this list at any time by giving a long press on but-ton G.
To listen to one of these stations, select by pressing buttons J or Mand validate using button L.
MANUAL PRE-SETTING
Select the waveband and memory bank required using button R.
Select a station using either auto-matic or manual search.
Keep pressing for more than two seconds on one of the pre-selection buttons 1 to 6 on the keypad P.
The sound momentarily cuts off, then returns to its previous level to confi rm that it has memorised the station.
R A D I O S O U R C E
AUTOMATIC MEMORISA-TION OF TRANSMITTERS (AUTOSTORE FUNCTION)
In FM, if you hold down button Rfor more than two seconds, your radio will automatically memorise the 6 strongest stations on the FM3 memory bank.
The display shows “FM AST”.
The radio memorises the 6 strong-est transmitters, deleting the 6 pre-viously memorised.
After the memorisation, the radio goes directly to memory 1 of mem-ory bank FM3.Note:If the traffi c information func-Iftion has been activated (see RDS SYSTEM), the stations offering this facility will be mem-orised as priority.
If it is unable to memorise any Ifnew stations, the system will retain the previously memo-rised stations.If the system is unable to fi nd If6 stations, the unfi lled memory slots will remain free.

120
IV
USING THE RDS (RADIO DATA SYSTEM) FUNCTION ON FM
The majority of FM radio stations use the RDS system. The radio in your vehicle has this system,.
The RDS system enables these stations to transmit non-audible data in addition to the broadcasting of their programmes. The data pro-vides access to various functions described in this chapter, such as: display of the station name, inter-mittent traffi c information fl ashes or automatic scanning of stations. This enables you to continue lis-tening to your chosen radio station, regardless of the different frequen-cies it uses in the regions through which you are travelling.
SCANNING OF RDS STA-TIONS
Your radio keeps the best possible reception by continuously looks for any other frequencies on which the selected radio station is broadcast, automatically choosing the fre-quency offering the best reception (if the station broadcasts on more than one transmitter or frequency.
R D S S Y S T E M
ACTIVATION/DEACTIVATION OF THE RDS FUNCTIONS
The RDS functions can be accessed via the following two menus:Main menu (press button O).
AUDIO menu (press button L).
To activate/deactivate the functions RDS1. Press button O.2. Select the AUDIO icon using buttons J or M.3. Confi rm your choice with a press on button L.4. Select the sub-menu for the FM waveband, via but-tons J or M. Confi rm your choice with a press on button L.5. Select scanning for RDS sta-tions, via buttons J or M.6. Validate your choice with a press on button L.7. Using control L, select/deselect to activate/deactivate the func-tion.8. Validate your choice by select-ing “OK” on the display.

121
IV
REGIONAL SEARCH MODE
Some stations, when they are organised in networks, broadcast regional programmes at certain times of day, and national pro-grammes at other times.
It is possible to search.Either for a regional station Eitheronly.
Or across the whole network Orin order to fi nd a different pro-gramme.
To activate/deactivate this function, proceed as for Scanning of RDS stations.Note: When this mode is activated, the system will remain tuned to one specifi c regional station.
TA TRAFFIC INFORMATION (TRAFFIC ANNOUNCE-MENTS)
Some stations allow broadcast-ing, only in FM, of these messages thanks to the “TA” function.
You can activate the “TA” func-tion by pressing on button I. This allows you, even though you are listening to another audio source or to a radio programme not itself providing traffi c messages, to receive traffi c information fl ashes from an FM station which broad-casts them.

122
IV
SELECTING CD SOURCE
After inserting a CD, with the printed side facing upwards, the player will start playing the CD automatically.
To change manually to CD source (CD already inserted), press but-ton D until you obtain the source you require.
You can also do this by means of control 5 at the steering wheel.
EJECTING A CD
Press button B to eject the CD, the audio system will automatically switch to radio source.
If the CD is not removed within 10 to 15 seconds of being ejected, it will automatically be taken back into the CD player, although it will not be played.
SELECTING A TRACK
Press button K once to play the next track.
Press button N once to return to the beginning of the track currently being played, press a second time to go back to the start of the previ-ous track.
Press the buttons successively to skip several tracks at a time.
This can also be done via the con-trol G. As the list of tracks is dis-played on the screen, select the desired track using buttons J or M, then validate using button L.
C D S O U R C E
You can also do this via the con-trols 2 and 3 at the steering wheel.
FAST FORWARD AND RAPID REVERSE WITH ACCELER-ATED SOUND
To move swiftly through the CD, press and keep pressed button Kor N, respectively for fast forward or rapid reverse with accelerated sound.
Play resumes as normal when the button is released.
MENU
This menu allows activation/deac-tivation of two options:Playback of the fi rst 7 seconds (approx.) of each track of the CD.
Random playback of the CD tracks.
This can be accessed in two ways:Either by pressing button EitherOand proceeding as for Scan-ning of RDS stations – the sub-menu for Audio Preferences.
Or, provided you are in CD source, by pressing onbutton L. You can then access the Audio menu.Note: If one of these options is active, it remains active for CD changer source.
