Page 42 of 189
58
II
21
M
M E M O R I S A T I O N
DRIVING POSITIONSMEMORISED VIABUTTONS 1 AND 2
T o m e m o r i s e a d r i v i n g p o s i t i o n :a. P l a c e t h e i g n t i o n k e y i n "Drive" p o s i t i o n ( s e c o n d p o s i t i o n ) .b. M a k e y o u r a d j u s t m e n t s o f t h e seat , t h e steering wheel , t h e rear view mirrors a n d t h e Head-up Display.c. P r e s s s u c c e s s i v e l y o n button M then on button 1 ( fi r s t d r i v i n g p o s i t i o n ) o r 2 ( s e c o n d d r i v i n g p o s i t i o n ) .
T h e m e m o r i s a t i o n i s c o n fi r m e d b y a s o u n d s i g n a l .Note: The memorisation of a new driving position cancels and replaces the previous one.
T h e m e m o r i s a t i o n f u n c t i o n a l l o w s t o m a k e t h e f o l l o w i n g d a s h b o a r d a d j u s t m e n t s : D r i v e r ' s s e a t
S t e e r i n g w h e e l
E x t e r i o r r e a r v i e w m i r r o r s H e a d - u p d i s p l a y .
S e e " S t e e r i n g c o l u m n a d j u s t m e n t " , " R e a r v i e w m i r r o r s " a n d " H e a d - u p Display".
Y o u h a v e t h e p o s s i b i l i t y t o m e m o -rise two driving positions u s i n g buttons 1 a n d 2.
Page 44 of 189
60
II12
R E A R V I E W M I R R O R S
Operation of the interior rear-view mirror
S w i t c h o n t h e i g n i t i o n a n d p r e s s button 1. W a r n i n g l a m p 2 o n ( s w i t c h o n ) : a u t o m a t i c m o d e .
W a r n i n g l a m p 2 o f f : a u t o m a t i c m o d e o f f . T h e m i r r o r s t a y s a t i t s l i g h t e s t s e t t i n g .Note: For optimal vision, the inte-rior rear-view mirror lightens when reverse gear is engaged.
Page 45 of 189
61
II
21
R E A R V I E W M I R R O R S
ELECTRIC EXTERIOR REAR VIEW MIRRORS
Features
T h e e n d o f t h e g l a s s i n t h e e x t e - r i o r r e a r v i e w m i r r o r s i s a s p h e r i c a l , s o a s t o e n l a r g e t h e l a t e r a l fi e l d o f vision.
Objects observed in the aspheri-cal part of the rear view mirrors are in reality closer than they appear.
Y o u m u s t t a k e t h i s i n t o a c c o u n t i n o r d e r t o b e p r o p e r l y a w a r e o f t h e d i s t a n c e s i n v o l v e d .
Adjustment of the rear view mirrors
T h i s c a n o p e r a t e w h e n t h e i g n i t i o n i s s w i t c h e d o n .
T h e d r i v e r s e l e c t s t h e r e a r v i e w m i r r o r b y m o v i n g c o n t r o l 1 , t o t h e l e f t o r t o t h e r i g h t , t h e n a d j u s t s t h e m i r r o r i n t h e f o u r d i r e c t i o n s b y m o v i n g c o n t r o l 2.
D e m i s t i n g - d e i c i n g o f t h e r e a r v i e w m i r r o r s i s l i n k e d w i t h t h a t f o r t h e r e a r screen.
T h e a d j u s t m e n t s y o u h a v e m a d e t o t h e r e a r v i e w m i r r o r s a r e i n c l u d e d i n t h e m e m o r i s a t i o n o f d r i v i n g p o s i t i o n s . S e e " M e m o r i s a t i o n " .
Fold-back of door mirrors
W h e n t h e v e h i c l e i s p a r k e d , t h e d o o r m i r r o r s c a n b e f o l d e d b a c k e i t h e r m a n u a l l y or electrically.
Electric fold-back
F r o m t h e c e n t r a l p o s i t i o n , o n e p r e s s t o w a r d s t h e r e a r o n c o n t r o l 1 f o l d s t h e r e a r v i e w m i r r o r s b a c k .
T o r e t u r n t h e m t o t h e i n i t i a l p o s i t i o n , p r e s s a g a i n o n c o n t r o l 1 t o w a r d s t h e rear.
Automatic fold-back
A u t o m a t i c f o l d - b a c k o p e r a t e s w h e n y o u l o c k t h e d o o r s .
Page 46 of 189
62
II
1
R E A R V I E W M I R R O R S
ELECTRIC EXTERIOR REAR VIEW MIRRORS (CONTINUED)
In reverse gear: adjustment of the indexed positions for the passenger’s and driver’s rear view mirrors
W i t h t h e e n g i n e r u n n i n g :1. S e l e c t t h e ( d r i v e r ' s o r p a s s e n g e r ' s ) r e a r v i e w m i r r o r u s i n g c o n t r o l 1.2. E n g a g e r e v e r s e g e a r , t h e m i r r o r g l a s s a u t o m a t i c a l l y p o s i t i o n s i t s e l f t o i m p r o v e y o u r v i s i o n o f t h e p a v e m e n t .3. I f n e c e s s a r y , a d j u s t t h e m i r r o r t o y o u r p r e f e r e n c e u s i n g t h e e l e c t r i ccontrol.
Deactivation of the rear view mirror indexing function
T o d e a c t i v a t e t h e f u n c t i o n , m o v e c o n t r o l 1 to the central position.
Page 72 of 189
88
III
5
6
7
A U T O M A T I C A I R C O N D I T I O N I N G
5. FRONT DEMISTING - DEICING
Press button 5 for rapid clear windows. The warning lamp comes on. This system controls the air condi- t i o n i n g , t h e a i r fl o w a n d t h e e n t r y o f a i r f r o m o u t s i d e . I t sends the ventilation towards the windscreen and side windows.
A press on the 1 button returns you to "AUTO" mode.
6. REAR DEMISTING - DEICING
Press button 6, with the engine running, to start a rapid deicing or demisting of the rear screen and rear view mirrors. The warning lamp comes on.
This mode stops automatically depending on the out-side temperature. It can be paused by pressing again on button 6 or by stopping the engine.
In the latter case, demisting will resume when the engine is switched on again.Note: The heated rear screen operates independently of the automatic air conditioning.
7. AIR RECIRCULATION – ENTRY OF AIR FROM OUTSIDE
Press repeatedly on button 7 to select the air entry mode. The corresponding warning lamp lights up:Air intake in automatic pollution control mode (on by default, with automatic comfort regulation).
The automatic mode makes use of an air quality sen-sor. It analyses the air and isolates the cabin from the exterior if the presence of pollutants is detected. In this case it automatically activates recirculation of the cabin air.
Please note: this function does not detect and there-fore protect the cabin from unpleasant odours. It is not active when the ambient temperature is below +5 °C so as to avoid the risk of misting the vehicle’s windows.
Closing the exterior air intake
Press button 7 to close the intake of air from the exte-rior.
While maintaining the other settings, this position allows the driver to avoid unpleasant odours and smoke out-side the vehicle at any time.
It should be cancelled as soon as possible to allow exchange of the cabin air and to avoid misting of the vehicle’s windows.
Exterior air intake
Press button 7 once to open the exterior air intake.
Page 97 of 189
113
III
To prevent dazzle from ahead, fold the visor downwards.
They can be disengaged from their c e n t r a l fi x i n g a n d p i v o t e d o v e r t o the side windows if required.
SUN VISOR WITH ILLUMINATED MIRROR
Illuminates automatically on opening t h e m i r r o r c o v e r fl a p ( i g n i t i o n o n ) .
CARD-HOLDER
This is situated above the sun visor.
REAR BLIND
Take the blind by its grip and unroll it.
E n g a g e t h e b l i n d o n t h e fi x i n g s o n each side of the third stoplamp.
BADGE READER
The athermic windscreen has a darkened area above the level of the interior rear view mirror, to per-mit the optical registering of access permits (e.g. motorway toll cards).
GRAB HANDLES - COAT HOOKS
I N T E R I O R C O M F O R T
Page 128 of 189
145
VI
H
E
F
A
D
BC
G
I
D I M E N S I O N S
( I N M E T R E S )
A2.900
B1.124
C0.884
D4.908
E1.586
F2.0802.115**
G1.558
H1.860
I*1.464
* Without roof bars.
** With new rear-view mirrors during the year.
Page 189 of 189
60
II
AUTOMATIC INTERIOR REAR-VIEW MIRROR
By means of a sensor, which mea-
sures the light from the rear of
the vehicle, this system automati-
cally and progressively changes
between the day and night uses.
It has an anti-dazzle system
which darkens the mirror glass:
this reduces any driver discomfort
caused by the light beam of follow-
ing vehicles, the sun... In order to guarantee optimum vis-
ibility during your manoeuvres, the
mirror lightens automatically when
reverse gear is engaged.
