torque Citroen DS3 2009.5 1.G Owner's Manual

MODELS: ENGINES AND GEARBOXES
Model codes: SA... 8FR0 5FS0 5FS9 5FXH
PETROL ENGINES VTi 95 VTi 120 THP 150
Cubic capacity (cc) 1 397 1 598 1 598
Bore x stroke (mm) 77 x 75 77 x 85.8 77 x 85.8
Max power: EU standard (kW) 70 88 115 110 *
Max power engine speed (rpm) 6 000 6 000 6 000
Max torque: EU standard (Nm) 136 160 240
Max torque engine speed (rpm) 4 000 4 250 1 400
Fuel Unleaded Unleaded Unleaded
Catalytic conver ter yes yes yes
GEARBOX Manual (5 -speed) Manual (5 -speed) Auto (4-speed) Manual (6 -speed)
OIL CAPACITIES (in litres)
Engine (with filter replacement) 4.2 4.2 4.2 4.2
Gearbox - Final drive 2.0 2.0 - 2.0
* Belgium only.

MODELS: ENGINES AND GEARBOXES
Model codes: SA... 8HZC 9HP0 9HR8
DIESEL ENGINES HDi 70 PEF HDi 90 PEF HDi 110 PEF
Cubic capacity (cc) 1 398 1 560 1 560
Bore x stroke (mm) - x - 75 x 88.3 75 x 88.3
Max power: EU standard (kW) - 68 82
Max power engine speed (rpm) - 4 000 3 600
Max torque: EU standard (Nm) - 230 270
Max torque engine speed (rpm) - 1 750 1 750
Fuel Diesel Diesel Diesel
Catalytic conver ter yes yes yes
Par ticle emissions filter (PEF) yes yes yes
GEARBOX Manual (5 -speed) Manual (5 -speed) Manual (6 -speed)
OIL CAPACITIES (in litres)
Engine (with filter replacement) 3.75 3.75 3.75
Gearbox - Final drive 2.0 1.9 2.2
