TRIP COMPUTER/VEHICLE PARAMETERS


TRIP COMPUTER

Press the MODE button several
times in succession until the trip
computer is displayed.
Range:
displays the distance which can travelled with the
remaining fuel detected in the tank, based on the average fuel
consumption over the last few miles (kilometres).
This displayed value may vary signifi cantly following a change in
the vehicle speed or the relief of the route.
When the range falls below 20 miles (30 km), dashes are
displayed. After fi lling with at least 5 litres of fuel, the range is
recalculated and is displayed when it exceeds 60 miles (100 km).
If, whilst driving, dashes are displayed continuously in place of the
digits, contact a CITROËN dealer.

Each press of the button at the end of the wiper stalk displays
the different trip computer information in succession, according to
the screen.



A FEW DEFINITIONS



- The "vehicle" tab:
The range, the current fuel
consumption and the distance
remaining or the Stop & Start
time counter.

- The "1" (trip 1) tab with :
The average speed, the average
fuel consumption and the
distance travelled calculated
over trip "1".

- The "2" (trip 2) tab with the same
functions for a second trip.
Current fuel consumption:
only calculated and displayed above
20 mph (30 km/h).

Average fuel consumption:
this is the average fuel consumption
since the last trip computer zero reset.

Distance travelled:
calculated since the last trip computer zero
reset.

Distance remaining to the destination:
calculated with reference
to the fi nal destination, entered by the user. If guidance is activated,
the navigation system calculates it as a current value.

Average speed:
this is the average speed calculated since the last
trip computer zero reset (ignition on).







Stop & Start time counter
(minutes/seconds or hours/minutes)
If your vehicle is fi tted with Stop & Start, a time counter calculates
the time spent in STOP mode during a journey.
It resets to zero every time the ignition is switched on with the key.

QUESTION



ANSWER



SOLUTION


TA is selected. However,
certain traffi c jams
along the route are not
indicated in real time. On starting, it is several minutes before the system begins to receive the
traffi c information. Wait until the traffi c information is being received
correctly (displaying of the traffi c information
symbols on the map).
In certain countries, only major routes (motorways...) are listed for the
traffi c information. This phenomenon is normal. The system is
dependent on the traffi c information available.
I receive a speed camera
alert for a camera which
is not on my route. The system announces all speed cameras located in a conical zone
forward of the vehicle. It may detect speed cameras on nearby or parallel
roads. Zoom the map to view the exact position of the
speed camera.
The audible speed
camera alert is not
working. Audible alerts are not active. Activate audible alerts in Navigation Menu,
Settings, Set parameters for risk areas.
The alert volume level is set to minimum. Increase the speed camera alert volume.
The altitude is not
displayed. On starting, the initialisation of the GPS may take up to 3 minutes to
receive more than 3 satellites correctly. Wait until the system has started up completely.
Check that there is a GPS coverage of at least
3 satellites (long press on the SETUP button, then
select GPS coverage).
Depending on the geographical environment (tunnel...) or the weather,
the conditions of reception of the GPS signal may vary. This phenomenon is normal. The system is
dependent on the conditions of reception of the
GPS signal.
The route is not
calculated successfully. The exclusion criteria may confl ict with the current location (exclusion of
toll roads on a motorway with tolls). Check the exclusion criteria.

05
1
1
2
3
USB BOX


The system puts together playlists (temporary memory) created
over a period which depends on the capacity of the USB device.
The other sources are available during this time.
The playlists are updated each time the ignition is switched off or
each time a USB memory stick is connected.
When connecting for the fi rst time, the classifi cation suggested
is by folder. When you reconnect, the classifi cation selected
previously is retained.
Connect the memory stick to the port, directly or
using a lead. If the audio equipment is switched
on, the USB source is detected as soon as it
is connected. Play begins automatically after a
delay which depends on the capacity of the USB
memory stick.
The fi le formats recognised are .mp3 (mpeg1
layer 3 only), .wma (standard 9 only, 128 kbits/sec
compression), .wav and .ogg.
The playlists types accepted are m3u, .pls, .wpl.
This unit consists of a USB port and an auxiliary
Jack socket * . The audio fi les are transmitted
from portable equipment such as a digital player
or a USB memory stick to your Audio system to
be listened to via the vehicle's speakers.

USB memory stick (1.1, 1.2 and 2.0) or iPod
®
of
generation 5 or later:


- USB memory sticks should be formatted
FAT or FAT 32 (NTFS not supported),

- the iPod
®
lead is essential,

- navigation through the fi le database is by
means of the steering mounted controls,

- the iPod
®
software should be regularly
updated for the best connection.

The list of compatible equipment and the compression rates supported
are available from CITROËN dealers.













USING THE USB BOX


CONNECTING A USB MEMORY STICK

Other iPod
®
players of earlier generations and
players using the MTP protocol * :


- play via Jack-Jack lead only (not supplied),

- navigation through the fi le database is from
the portable device.


*
According to vehicle.

11
08
295

Each press of the button, located at the end of
the wiper stalk, displays the different trip computer
information in succession, depending on the screen.


- the "vehicle " tab with:


●
the range, the current fuel consumption and the distance remaining
to the destination or the Stop & Start time counter,

- the "1" tab (trip 1) with:


●
the average speed, the average consumption and the distance
travelled calculated over trip " 1
",

- the "2" tab (trip 2) with the same information for a second trip.


A FEW DEFINITIONS


Zero reset
When the required trip is displayed, press the control for more than
two seconds.


TRIP COMPUTER


Range:
displays the distance which can travelled with the remaining fuel
detected in the tank, based on the average fuel consumption over the last
few miles (kilometres).
This displayed value may vary signifi cantly following a change in the
vehicle speed or the relief of the route.
When the range falls below 20 miles (30 km), dashes are displayed.
After fi lling with at least 5 litres of fuel, the range is recalculated and is
displayed when it exceeds 60 miles (100 km).
If, whilst driving, dashes are displayed continuously in place of the digits,
contact a CITROËN dealer.

Current fuel consumption:
only calculated and displayed above 20 mph (30 km/h).


Average fuel consumption:
this is the average fuel consumption since
the last trip computer zero reset.

Average speed:
this is the average speed calculated since the last trip
computer zero reset (ignition on).
Distance travelled:
calculated since the last trip computer zero reset.

Distance remaining to the destination:
calculated with reference to
the fi nal destination, entered by the user. If guidance is activated, the
navigation system calculates it as a current value.







Stop & Start time counter
(minutes/seconds or hours/minutes)
If your vehicle is fi tted with Stop & Start, a time counter calculates the
time spent in STOP mode during a journey.
It resets to zero every time the ignition is switched on with the key.

Map reading lamps ............................. 116, 209
Markings, identification ............................... 240
Mat .............................................................. 123
Menu, main .................................................284
Mini fuel level .............................................. 100
Misfuel prevention ....................................... 102
Monochrome screen .................. 284, 296, 298
Motorway function (direction indicators) ..... 140
Mountings for ISOFIX seats ............... 134, 136
MP3 CD ...............................................265, 287
Multifunction screen
(with audio equipment) ...................52, 55, 59
Music media players ...................................264
MyWay ..........................................59, 250, 272
R
Navigation ................................................... 253
Number plate lamps .................................... 207
NP
Paint colour code ........................................ 240
Parking brake ...................................... 156, 187
Par ticle emission filter ........................ 185, 186
Passenger compar tment filter .................... 186
Petrol engine ............................... 101, 181, 230
Player, CD MP3 ...................................265, 287
Priming the fuel system .............................. 180
Protecting children .......128, 132, 134-136, 149
Puncture ...................................................... 190
Radio ...................................................263, 285
Rear foglamp ............................................... 207
Rear foglamps ............................................. 108
Rear head restraints ..................................... 82
Rear parcel shelf ......................................... 125
Rear parking sensors .................................. 173
Rear screen (demisting) ................................ 74
Rear seats ..................................................... 82
Rear view mirror ............................................ 85
Rear wash-wipe .......................................... 113
Rear wiper ................................................... 113
Recharging the battery ............................... 217
Reduction of electrical load ........................ 220
Refitting a wheel ......................................... 199
Reinitialising the electric windows ................ 94
Reinitialising the remote control ................... 92
Remote control ..................................88, 89, 93
Removing a wheel ...................................... 199
Removing the mat ....................................... 123
Repair kit, puncture ..................................... 190 Keeping children safe ................. 128, 134, 149
Key in ignition warning .................................. 90
Key with remote control .................... 88 -90, 93
LLabels, identification ................................... 240
Lamps, warning and indicator ...........30, 34, 35
Lateral airbags .................................... 151, 153
LED lamps ........................................... 111, 206
Level, brake fluid ......................................... 183
Levels and checks........................ 181-183, 185
Lighting, guide-me home .................... 109, 110
Lighting, interior ...........................116, 117, 209
Lighting bulbs (replacement) ...... 203, 207, 208
Lighting rheostat ........................................... 44
Lighting stalk ............................................... 106
Loading.......................................................... 22
Load reduction mode .................................. 220
Localised assistance call ............................ 246
Localised emergency call ........................... 246
Locating your vehicle .................................... 90
Locking from the inside ................................. 97
LPG .............................................................234
Luggage retaining strap .............................. 124
K
Main beam ..........................................106, 205
Manual gearbox .................. 157, 158, 166, 187M
Oil filter ........................................................ 186
Oil level .................................................. 43, 183
Opening the bonnet .................................... 179
Opening the boot ....................................88, 99
Opening the doors ........................... 88, 96, 98
Opening the fuel
filler flap .................................................... 100
Operation indicator lamps .......................30, 34
O

313Alphabetical index
Replacing bulbs .......................... 203, 207, 208
Replacing fuses .......................................... 210
Replacing the air filter ................................. 186
Replacing the oil filter ................................. 186
Replacing the particle emission filter ......... 186
Replacing the passenger
compar tment filter .................................... 186
Replacing wiper blades ....................... 115, 220
Resetting the ser vice indicator ..................... 42
Resetting the trip recorder ............................ 44
Rev counter ............................................. 26, 28
Reversing lamp ........................................... 207
Routine checks ................................... 186, 187
Routine maintenance .................................... 22
Running out of fuel (Diesel) ........................ 180
Safety for children ............................... 132, 136
Satellite navigation
system ....................................................... 253
Scented air freshener ................................... 75
Screen, colour 16/9 .......................59, 250, 272
Screen, multifunction
(with audio equipment) ...................52, 55, 59
Screen-wash reser voir................................ 183
Screen menu map ...................... 272, 296, 298
Screenwash ................................................ 113
Screenwash fluid
level ........................................................... 183
Seat adjustment ...................................... 77, 80
Seat belts ............................................ 145, 147
S
Selector lever,
"SensoDrive" .................................... 159, 187
Serial number,
vehicle ....................................................... 240
Ser vice indicator ........................................... 41
Ser vicing ....................................................... 22
Setting the clock ......................................... 270
Shor t-cut menus ................................. 251, 252
Sidelamps ...................................106, 205, 207
Side repeater............................................... 205
Spare wheel ................................................ 196
Speed limiter ............................................... 169
Speedometer .......................................... 26, 28
Stability control
(ESP)......................................................... 143
Star ting the vehicle ....................... 90, 159, 162
Steering mounted
controls ..................................................... 283
Stopping the vehicle ..................... 90, 159, 162
Stop Star t ....................... 48, 71, 100, 166, 179,
18 6, 217, 271, 295
Storage ................................................ 120, 121
Storage box ................................................. 125
Stowing rings .............................................. 124
Sun visor ..................................................... 121
Synchronising the remote control ................. 92
Systems, ASR and ESP .............................. 143
Table of weights ......................... 230, 234, 236
Tables of engines ....................... 230, 234, 236Tables of fuses ............................................ 210
Tank, fuel ............................................. 100, 102
Technical data ............................ 230, 234, 236
Telephone ........................................... 267, 268
Te m p e r a t u r e
adjustment .................................................. 71
Temperature control
for heated seats ......................................... 79
Te m p o r a r y
tyre repair kit ............................................. 190
Third brake lamp ......................................... 208
Time ................................................... 293, 294
TMC (Traffic info) ........................................ 261
Tools ............................................................ 196
Total distance recorder ................................. 44
To w b a r ......................................................... 223
Towed loads ............................... 230, 234, 236
Towing another
vehicle ....................................................... 221
Traction control (ASR) ................................ 143
Traffic information (TA) .............. 262, 263, 286
Traffic information (TMC) .................... 261, 262
Trip computer .................................... 46 - 48, 55
Trip distance recorder ................................... 44
Tyre pressures ............................................ 240
Ty r e s .............................................................. 22
TUnlocking ...................................................... 88
Unlocking from
the inside .................................................... 97
U
