219Practical information
Energy economy mode
System which manages the period of use of cer tain functions to conser ve a sufficient level of charge in the battery.
After the engine has stopped, you can still use functions such as the audio equipment, windscreen wipers, dipped beam headlamps, cour tesy
lamps, etc. for a maximum combined period of thirty minutes.
This period may be greatly reduced if
the battery is not fully charged.
A flat battery prevents the engine from
starting (refer to the corresponding
paragraph). If the telephone is being used at
the same time on the MyWay audio
navigation system, it will be interrupted
after 10 minutes.
Switching to economy mode
Once this period has elapsed, a message
appears on the multifunction screen indicating
that the vehicle has switched to economy mode
and the active functions are put on standby.
Exiting economy mode
These functions are reactivated automatically
the next time the vehicle is driven.
)
In order to resume the use of these
functions immediately, star t the engine and
let it run for a few minutes.
The time available to you will then be double
the period for which the engine is left running.
However, this period will always be between
five and thir ty minutes.
Page 222 of 324
Changing a front or rear wiper blade
Procedure for replacing a worn wiper blade with a new one without the use of tools.
Before removing a front
wiper blade
)
Within one minute after switching off the
ignition, operate the wiper stalk to position
the wiper blades in the ver tical position.
This position must be used in order to avoid
damaging the wiper blade and the bonnet.
Removal
)
Raise the corresponding wiper arm.
)
Unclip the wiper blade and remove it.
Fitting
)
At the front, check the size of the wiper
blade as the shor ter blade is fitted to the
passenger side of the vehicle.
)
Put the corresponding new wiper blade in
place and clip it.
)
Fold down the wiper arm carefully.
After fitting a front wiper
blade
)
Switch on the ignition.
)
Operate the wiper stalk again to park
the wiper blades.
Load reduction mode
System which manages the use of cer tain
functions according to the level of charge
remaining in the battery.
When the vehicle is being driven, the load
reduction function temporarily deactivates
cer tain functions, such as the air conditioning,
the heated rear screen...
The deactivated functions are reactivated
automatically as soon as conditions permit.
Page 223 of 324
221Practical information
Towing the vehicle
Procedure for having your vehicle towed or for towing another vehicle using a removable towing eye.
The towing eye is installed in the boot under
the floor.
To gain access to it:
)
open the boot,
)
raise the floor,
)
remove the polystyrene storage box,
)
remove the towing eye from the holder.
Access to the tools
General recommendations
Obser ve the legislation in force in your country.
Ensure that the weight of the towing vehicle is higher than that of the towed vehicle.
The driver must stay at the wheel of the towed vehicle.
Driving on motor ways and fast roads is prohibited when towing.
When towing a vehicle with all four wheels on the ground, always use an approved towing
bar; rope and straps are prohibited.
When towing a vehicle with the engine off, there is no longer any power assistance for
braking or steering.
In the following cases, you must always call on a professional recovery ser vice:
- vehicle broken down on a motor way or fast road,
- when it is not possible to put the gearbox into neutral, unlock the steering, or release
the parking brake,
- towing with only two wheels on the ground,
- where there is no approved towing bar available...
Page 224 of 324
)
On the front bumper, unclip the cover by
pressing at the bottom.
)
Screw the towing eye in fully.
)
Install the towing bar.
)
Place the gear lever in neutral (position N
for an SensoDrive or automatic gearbox).
)
On the rear bumper, unclip the cover by
pressing at the bottom.
)
Screw the towing eye in fully.
)
Install the towing bar.
)
Switch on the hazard warning lamps on
both vehicles.
)
Move off gently and drive for a short
distance only.
Towing your vehicle
Towing another vehicle
Failure to obser ve this special condition
could result in damage to cer tain
components (braking, transmission...)
and the absence of braking assistance
the next time the engine is started.
)
Unlock the steering by turning the key one
notch in the ignition switch and release the
parking brake.
)
Switch on the hazard warning lamps on
both vehicles.
)
Move off gently and drive for a short
distance only.
Page 225 of 324
223Practical information
Towing a trailer, a caravan, etc.
Towbar suitable for the attachment of a
trailer or caravan with additional lighting and
signalling.
Your vehicle is primarily designed for
transpor ting people and luggage, but it may
also be used for towing a trailer. We recommend the use of genuine
CITROËN towbars and their harnesses
that have been tested and approved
from the design stage of your vehicle,
and that the fitting of the towbar is
entrusted to a CITROËN dealer or a
qualified workshop.
If the towbar is not fitted by a CITROËN
dealer, it is imperative that it is
fitted in accordance with the vehicle
manufacturer's instructions.
Driving with a trailer places greater demands
on the towing vehicle and the driver must take
particular care.
Driving advice
Distribution of loads
)
Distribute the load in the trailer so that the
heaviest items are as close as possible to
the axle and the nose weight approaches
the maximum permitted without
exceeding it.
Air density decreases with altitude, thus
reducing engine per formance. Above
1 000 metres, the maximum towed load must
be reduced by 10 % for every 1 000 metres of
altitude.
Refer to the "Technical Data" section for details
of the weights and towed loads which apply to
your vehicle.
Side wind
)
Take into account the increased sensitivity
to side wind.
Page 226 of 324
The rear parking sensors will be
deactivated automatically if a genuine
CITROËN towbar is used.
Cooling
Towing a trailer on a slope increases the
temperature of the coolant.
As the fan is electrically controlled, its cooling
capacity is not dependent on the engine speed.
)
To lower the engine speed, reduce your
speed.
The maximum towed load on a long incline
depends on the gradient and the ambient
temperature.
In all cases, keep a check on the coolant
temperature.
Braking
Towing a trailer increases the braking distance.
Ty r e s
)
Check the tyre pressures of the towing
vehicle and of the trailer, obser ving the
recommended pressures.
Lighting
)
Check the electrical lighting and signalling
on the trailer.
)
If the warning lamp and the
STOP
warning lamp come on,
stop the vehicle and switch off
the engine as soon as possible.
RACING towbar
Your vehicle cannot be fitted with a
towbar. The space occupied by the
spor t diffuser prevents this.
Page 227 of 324
225Practical information
A wide range of accessories and genuine par ts is available from the CITROËN dealer network.
These accessories and par ts have been tested and approved for reliability and safety.
They are all adapted to your vehicle and benefit from CITROËN's recommendation and warranty.
Accessories
"Comfort":
sun blinds, air deflectors, isotherm module,
ashtray, fragrance cartridges, coat hanger fixed
to head restraint, front centre armrest, movable
mirror, reading lamp, front and rear parking
sensors...
"Transport solutions":
boot liner, boot spacers, boot carpet, boot net,
transverse roof bars, bicycle carrier, ski carrier,
roof boxes, towbars, towbar wiring harnesses...
"Styling":
full grain leather steering wheel, coloured and
carbotech dashboards, coloured and leather
gear lever knobs, aluminium footrest, spoiler,
alloy wheels, coloured wheel trims, coloured
wheel caps, exterior expressive stickers,
exterior chrome kit...
*
To avoid any risk of jamming of the pedals:
- ensure that the mat is positioned and
secured correctly,
- never fit one mat on top of another.
"Security and safety":
anti-intrusion alarm, wheel security devices,
vehicle tracking system, breathalyser, first aid
kit, warning triangle, high visibility safety jacket,
child seats, snow chains, non-skid covers, fire
extinguisher...
"Protection":
mats * , mudflaps, seat covers, vehicle covers,
bumper protectors...
When fitting a towbar outside the
CITROËN dealer network, the
installation must be done using the
vehicle's electrical pre-equipment and
following the vehicle manufacturer's
recommendations.
Page 228 of 324
"Multimedia":
hands-free system, audio systems, semi-
integral satellite navigation system, por table
navigation systems, mapping update CD,
speed camera warning, DVD player, reversing
camera, USB Box, speakers, Hi-Fi module,
230V socket, WiFi on Board...
By visiting a CITROËN dealer, you can also
obtain cleaning and maintenance products
(interior and exterior) - including ecological
products from the "TECHNATURE" range,
products for topping up (screenwash fluid...),
touch-up pens and paint aerosols for the exact
colour of your vehicle, refills (cartridge for the
temporar y puncture repair kit...), ...
Installation of radio
communication transmitters
Before installing any after-market radio
communication transmitter, you can
contact a CITROËN dealer for the
specification of transmitters which can
be fitted (frequency, maximum power,
aerial position, specific installation
requirements), in line with the Vehicle
Electromagnetic Compatibility Directive
(2004/104/EC).
The fitting of electrical equipment
or accessories which are not
recommended by CITROËN may result
in a failure of your vehicle's electronic
system and excessive electrical
consumption.
Please note this precaution. You
are advised to contact a CITROËN
representative to be shown the range
of recommended equipment and
accessories.
Depending on the legislation in force
in the country, it may be compulsory
to have a high visibility safety vest,
warning triangle and spare bulbs and
fuses available in the vehicle.
Page 229 of 324
227Practical information
Page 230 of 324
012
Technical data
This section contains the specifications of your vehicle depending on its
engine and gearbox, such as the maximum power and torque, unladen
and maximum weights, trailer weights, exterior dimensions and all of its
identification markings.
