Citroen DS3 2011 1.G Owner's Manual

MODELS:



ENGINES AND GEARBOXES



Model codes:


SA...


8FR0



8FR0/P



5FS0



5FS9



5FR8

5FX8 *



PETROL ENGINES


VTi 95



VTi 120



THP 150


Cubic capacity (cc)
1 397
1 598
1 598
Bore x stroke (mm)
77 x 75
77 x 85.8
77 x 85.8
Max power: EU standard (kW)
70
88
115
11 0 *

Max power engine speed (rpm)
6 000
6 000
6 000
Max torque: EU standard (Nm)
13 6
160
240
Max torque engine speed (rpm)
4 000
4 250
1 400
Fuel
Unleaded
Unleaded
Unleaded
Catalytic conver ter
yes

yes
yes

GEARBOX

Manual
(5 -speed)
Electronic
(5 -speed)
Manual
(5 -speed)
Auto
(4 - speed)
Manual
(6 -speed)

OIL CAPACITIES (in litres)




Engine (with filter replacement)
4.25
4.25
4.25
4.25

*
Belgium and Russia only.

231Technical data


ENGINE AND GEARBOX
- R ACING



MODELS:
Model codes: SA...


5FF8



5FD8



PETROL ENGINE








Cubic capacity (cm 3
)

1 598
Bore x stroke (mm)

77 x 85.8
Max power: EU standard (kW)
149
152
Max power engine speed (rpm)
6 000
Max torque: EU standard (Nm)
275
Max torque engine speed (rpm)
2 000
Fuel

Unleaded **

Catalytic conver ter

Ye s

GEARBOX

Manual
(6 -speed)

OIL CAPACITY (in litres)






Engine (with filter replacement)
4.25

**
CITROËN recommends the use of 98 RON unleaded petrol to ensure optimum engine per formance.

WEIGHTS AND TOWED LOADS (in kg)



Petrol engines


VTi 95



VTi 120



THP 150



Gearboxes


Manual



Electronic



Manual



Auto



matic

Manual



Model codes:
SA...


8FR0



8FR0/P



5FS0



5FS9



5FR8

5FX8




- Unladen weight
1 075
1 079
1 075
1 089
1 165


- Kerb weight
1 150
1 154
1 150
1 164
1 240


- Gross vehicle weight (GV W)
1 552
1 558
1 554
1 587
1 597


- Gross train weight (GTW)
on a 12 % gradient
2 452
2 458
2 454
2 487
2 497


- Braked trailer (within the GTW limit)
on a 12 % gradient
900
900
900
900
900


- Braked trailer * (with load transfer within the
GTW limit)
1 150
1 150
1 150
1 150
1 150


- Unbraked trailer
570
570
570
570
570


- Recommended nose weight
46
46
46
46
46
*

The weight of the braked trailer can be increased, within the GTW limit, if the GV W of the towing vehicle is reduced by an equal amount.
Warning: towing using a lightly loaded towing vehicle may have an adverse effect on its road holding.
The GTW and towed load values indicated are valid up to a maximum altitude of 1 000 metres; the towed load mentioned must be reduced by 10 % for
each additional 1 000 metres of altitude.
The speed of a towing vehicle must not exceed 60 mph (100 km/h) (comply with the legislation in force in your country).
High ambient temperatures may result in a reduction in the per formance of the vehicle to protect the engine; if the ambient temperature is above 37 °C,
limit the towed load.

233Technical data


WEIGHTS (in kg)
- R ACING



Petrol engine









Gearbox


Manual



Manual



Model codes: SA...


5FF8



5FD8




- Unladen weight

1 165


- Kerb weight

1 240


- Gross vehicle weight (GV W)
1 597


- Gross train weight (GTW)
on a 12 % gradient
1 597


- Braked trailer (within the GTW limit)
on a 12 % slop
0


- Braked trailer (with transfer of load within
the GTW limit)
0


- Unbraked trailer

0


- Recommended nose weight **

0

** See "Practical information - § Towing a trailer".

MODELS:



ENGINE AND GEARBOX



Model codes:
SA...


8FR0/GPL



LPG ENGINE



VTi 95


Cubic capacity (cc)

1 397
Bore x stroke (mm)

77 x 75
Max. power: EU standard (kW)
70
Max. power speed (rpm)

6 000
Max torque: EU standard (Nm)
13 6
Max. torque speed (rpm)

4 000
Fuel

LPG/Unleaded
Catalytic conver ter

Ye s

GEARBOX

Manual
(5 -speed)

OIL CAPACITY (in litres)




Engine (with filter replacement)
4.25
For more information on the operation and use of your LPG vehicle, refer to the specific inser t attached to the other vehicle documents.

235Technical data

*

The weight of the braked trailer can be increased, within the GTW limit, if the GV W of the towing vehicle is reduced by an equal amount; warning,
towing using a lightly loaded towing vehicle may have an adverse effect on its road holding.



WEIGHTS AND TOWED LOADS (in kg)



LPG engines



VTi 95



Gearbox



Manual



Model codes:
SA...


8FR0/GPL




- Unladen weight

1 152


- Kerb weight

1 227


- Gross vehicle weight (GV W)
1 552


- Gross train weight (GTW)
on a 12 % slope
2 452


- Braked trailer (within GTW limit)
on a 12 % slope
900


- Braked trailer * (with load transfer within the
GTW limit)
1 150


- Unbraked trailer

570


- Recommended nose weight
46
The GTW and towed load values indicated are valid up to a maximum altitude of 1 000 metres; the towed load mentioned must be reduced by 10 % for
each additional 1 000 metres of altitude.
The speed of a towing vehicle must not exceed 60 mph (100 km/h) (comply with the legislation in force in your country).
High ambient temperatures may result in a reduction in the per formance of the vehicle to protect the engine; if the ambient temperature is above 37 °C,
limit the towed load.

MODELS:



ENGINES AND GEARBOXES



Model codes:
SA...


8HR0



9HP4



9HP0
9HP0/S



9HR8



DIESEL ENGINES


HDi 70
PEF



HDi 90 PEF
99g



HDi 90 PEF



HDi 110 PEF


Cubic capacity (cc)
1 398
1 560
1 560
Bore x stroke (mm)
73.7 x 82
75 x 88.3
75 x 88.3
Max power: EU standard (kW)
50
68
82
Max power engine speed (rpm)
4 000
4 000
3 600
Max torque: EU standard (Nm)
160
230
270
Max torque engine speed (rpm)
2 000
1 750
1 750
Fuel
Diesel
Diesel
Diesel
Catalytic conver ter
yes
yes
yes
Particle emissions filter (PEF)
yes
yes
yes

GEARBOX

Manual
(5 -speed)
Manual
(5 -speed)
Manual
(6 -speed)

OIL CAPACITIES (in litres)








Engine (with filter replacement)
3.75
3.75
3.75

.../S:
e-HDi model fitted with Stop & Star t.

237Technical data


WEIGHTS AND TOWED LOADS (in kg)



Diesel engines


HDi 70
PEF



HDi 90 PEF 99g



HDi 90 PEF



e-HDi 90 PEF



HDi 110 PEF



Gearbox


Manual



Manual



Manual



Manual



Manual



Model codes:
SA...


8HR0



9HP4



9HP0



9HP0/S



9HR8




- Unladen weight
1 070
1 080
1 080
1 085
1 090


- Kerb weight
1 145
1 155
1 155
1 160
1 165


- Gross vehicle weight (GV W)
1 553
1 565
1 584
1 602
1 612


- Gross train weight (GTW)
on a 12 % gradient
2 253
2 065
2 484
2 502
2 512


- Braked trailer (within GTW limit)
on 12 % gradient
700
500
900
900
900


- Braked trailer * (with load transfer with
the GTW limit)
950
500
1 150
1 150
1 150


- Unbraked trailer
570
500
570
570
570


- Recommended nose weight
46
46
46
46
46
The GTW and towed load values indicated are valid up to a maximum altitude of 1 000 metres; the towed load mentioned must be reduced by 10 % for
each additional 1 000 metres of altitude.
The speed of a towing vehicle must not exceed 60 mph (100 km/h) (comply with the legislation in force in your country).
High ambient temperatures may result in a reduction in the per formance of the vehicle to protect the engine; if the ambient temperature is above 37 °C,
limit the towed load.
*

The weight of the braked trailer can be increased, within the GTW limit, if the GV W of the towing vehicle is reduced by an equal amount. Warning:
towing using a lightly loaded towing vehicle may have an adverse effect on its road holding.

Dimensions (in mm)
