Page 45 of 324
43Monitoring
System which informs the driver whether the
engine oil level is correct or not.
This information is indicated for a few seconds
when the ignition is switched on, after the
service information.
Engine oil level indicator
The level shown will only be correct
if the vehicle is on level ground and
the engine has been off for more than
30 minutes.
Oil level correct
Oil level low
This is indicated by the flashing of "OIL"
, linked
with the ser vice warning lamp, accompanied
by an audible signal and a message in the
multifunction screen.
If the low oil level is confirmed by a check using
the dipstick, the level must be topped up to
prevent damage to the engine.
Oil level indicator fault
This is indicated by the flashing of "OIL --"
.
Contact a CITROËN dealer or a qualified
workshop.
There are 2 marks on the
dipstick:
- A
= max; never exceed this
level (risk of damage to the
engine),
- B
= min; top up the level via
the oil filler cap, using the
grade of oil suited to your
engine.
Dipstick
Refer to the "Checks" section to locate the
dipstick and the oil filler cap on your engine.
Page 67 of 324
65Comfort
Recommendations for ventilation and air conditioning
If after an extended stop in sunshine,
the interior temperature is very
high, first ventilate the passenger
compartment for a few moments.
Put the air flow control at a setting high
enough to quickly change the air in the
passenger compartment.
The air conditioning system does not
contain chlorine and does not present
any danger to the ozone layer. In order for these systems to be fully effective, follow the operation and maintenance
guidelines below:
)
To obtain an even air distribution, take care not to obstruct the exterior air intake grilles
located at the base of the windscreen, the nozzles, the vents and the air outlets, as well
as the air extractor located in the boot.
)
Do not cover the sunshine sensor, located on the dashboard; this is used for regulation
of the digital air conditioning system.
)
Operate the air conditioning system for at least 5 to 10 minutes, once or twice a month
to keep it in per fect working order.
)
Ensure that the passenger compartment filter is in good condition and have the filter
elements replaced regularly (refer to the "Checks" section).
We recommend the use of a combined passenger compartment filter. Thanks to its
special active additive, it contributes to the purification of the air breathed by the
occupants and the cleanliness of the passenger compartment (reduction of allergic
symptoms, bad odours and greasy deposits).
)
To ensure correct operation of the air conditioning system, you are also advised to have
it checked regularly as recommended in the Maintenance and Warranty Guide.
)
If the system does not produce cold air, switch it off and contact a CITROËN dealer or a
qualified workshop.
When towing the maximum load on a steep gradient in high temperatures, switching off the
air conditioning increases the available engine power and so improves the towing ability.
The condensation created by the air
conditioning results in a discharge
of water under the vehicle which is
per fectly normal.
Page 70 of 324
The heating/ventilation or air conditioning systems operates with the engine running, as well as in STOP mode with Stop & Start.
1. Temperature adjustment
)
Turn the dial from blue
(cold) to red (hot) to adjust
the temperature to your
requirements.
2. Air fl ow adjustment
)
Turn the dial from position 1
to position 5
to obtain a
comfortable air flow.
)
If you place the air flow control
in position 0
(deactivation of the
system), the temperature is no
longer maintained at a comfor table
level. However, a slight flow of air,
due to the movement of the vehicle,
can still be felt.
3. Air distribution adjustment
Windscreen and side windows.
Windscreen, side windows and
footwells.
Footwells.
Central and side vents.
The air distribution can be
adapted by placing the dial
in an intermediate position.
4. Air intake/Air recirculation
The intake of exterior air avoids the formation of
mist on the windscreen and side windows.
The recirculation of interior air insulates the
passenger compar tment from exterior odours
and smoke.
Return to exterior air intake as soon as possible
to prevent deterioration of the air quality and
the formation of mist.
Manual control panel
)
Move the manual control to
the left to be in the "recycling
interior air" position.
)
Move the manual control to the
right to return to the "fresh air
intake" position.
Page 73 of 324
71Comfort
Digital air conditioning
The air conditioning operates when the engine is running, as well as in STOP mode with Stop & Start.
Automatic operation
1. Automatic "comfort"
programme
Press the "AU TO "
button. The
"AU TO "
symbol is displayed.
We recommend that you use
this mode. It provides optimised
automatic control of all of the following
functions: passenger compar tment
temperature, air flow, air distribution and air
intake, in accordance with the comfort value
that you have chosen.
This system is designed to operate effectively
in all seasons, with the windows closed. For your comfor t, when the engine is
switched off, the settings are retained
until the engine is switched on again.
To prevent too great a distribution of
cold air when the engine is cold, the air
flow will only reach its optimum level
gradually.
2. Temperature adjustment
The value indicated on the display corresponds
to a level of comfor t and not to a temperature in
degrees Celsius or Fahrenheit. On entering the vehicle, if the interior
is very cold or hot, there is no need to
change the value displayed in order
to reach the required level of comfor t.
The system corrects the temperature
difference automatically and as quickly
as possible.
Press the "
"
and "
"
buttons to
change this value. A setting around
the value 21
enables optimum
comfor t to be obtained. However,
depending on your requirements, a
setting between 18 and 24 is usual.
3. Automatic "visibility"
programme
The automatic comfor t programme
may not be sufficient for rapid
demisting or defrosting of the
windscreen and side windows
(humidity, several passengers, ice, etc.).
In this case, select the automatic visibility
programme. The button 3
indicator lamp
comes on.
The system automatically controls the air
conditioning and the flow of air and provides
optimum air distribution to the windscreen and
side windows. It deactivates air recirculation 5
.
To exit this programme, press button 3
again or
"AU TO "
, the indicator lamp on the button goes
off and "AU TO "
is displayed.
With Stop & Star t, when demisting has
been activated, the STOP mode is not
available.
Page 76 of 324
Rear screen demist - defrost
The control button is located on the heating or air conditioning system control panel.
Switching on
The rear screen demisting/defrosting can only
operate when the engine is running.
)
Press this button to demist /defrost the rear
screen and (depending on version) the door
mirrors. The indicator lamp associated with
the button comes on.
Switching off
The demisting/defrosting switches off
automatically to prevent an excessive
consumption of current.
)
It is possible to stop the demisting/
defrosting operation before it is switched
off automatically by pressing the button
again. The indicator lamp associated with
the button switches off.
)
Switch off the demisting/defrosting
of the rear screen and door mirrors
as soon as appropriate as lower
current consumption results in
reduced fuel consumption.
If the engine is switched off before the
demisting/defrosting is switched off
automatically, demisting/defrosting
will resume next time the engine is
switched on.
Page 81 of 324
79Comfort
Access to the rear seats
)
Pull the control upwards to fold the seat
back and move the seat for ward.
When put back in place, the seat returns to
its initial position.
No person or object should prevent the
seat slide from returning to its initial
position; the return to this position is
necessary for longitudinal locking.
Check that the seat belt has reeled in
correctly so as to not impede access to
the rear seats for passengers.
Heated seats control
With the engine running, the front seats can be
heated separately.
)
Use the adjustment dial, placed on the side
of each front seat, to switch on and select
the level of heating required:
0: Off.
1
: Low.
2
: Medium.
3
: High.
Grab handle
This easy to use handle, located at the top of
the side trim:
- provides a means of suppor t for the outer
rear passengers when moving,
- provides a hand hold to ease access to the
rear seats,
- facilitates exit from the rear seats.
Page 86 of 324
Mirrors
Each fitted with an adjustable mirror glass
permitting the lateral rear ward vision necessary
for over taking or parking. They can also be
folded for parking in confined spaces.
Demisting - Defrosting
If your vehicle is fitted with heated
mirrors, the demisting-defrosting
operates with the engine running, by
switching on the heated rear screen
(refer to the "Rear screen demist-defrost"
page).
Adjustment
)
Move control A
to the right or to the left to
select the corresponding mirror.
)
Move control B
in all four directions to
adjust.
)
Return control A
to the central position.
Door mirrors
The objects obser ved are, in reality,
closer than they appear.
Take this into account in order to
correctly judge the distance of vehicles
approaching from behind.
Folding
)
From outside: lock the vehicle using the
remote control or the key.
)
From inside: with the ignition on, pull the
control A
in the central position rear wards.
Unfolding
)
From outside: unlock the vehicle using the
remote control or the key.
)
From inside: with the ignition on, pull the
control A
in the central position rear wards. If the mirrors are folded using control A
,
they will not unfold when the vehicle is
unlocked. Pull again on control A
.
The folding and unfolding of the door
mirrors using the remote control can be
deactivated by a CITROËN dealer or a
qualified workshop.
Never fold or unfold the electric folding
mirrors manually.
Page 92 of 324
This is indicated by lighting of the cour tesy
lamps and flashing of the direction indicators
for a few seconds.
Locating your vehicle
)
Press the closed padlock to
locate your locked vehicle in a
car park.
Anti-theft protection
Electronic engine immobiliser
The key contains an electronic chip which has
a special code. When the ignition is switched
on, this code must be recognised in order for
star ting to be possible.
This electronic engine immobiliser locks the
engine management system a few minutes
after the ignition is switched off and prevents
star ting of the engine by anyone who does not
have the key.
In the event of a malfunction, you
are informed by lighting of this
warning lamp, an audible signal and a message
on the multifunction screen.
In this case, your vehicle does not start; contact
a CITROËN dealer as soon as possible.
- Position 1: Stop
- Position 2: Ignition
- Position 3: Starting
Ignition switch
Page 93 of 324
91Access
Starting the vehicle
)
Inser t the key in the ignition switch.
The system recognises the star ting code.
)
Turn the key fully towards the dashboard to
position 3 (Star ting)
.
)
When the engine star ts, release the key.
)
Immobilise the vehicle.
)
Turn the key fully towards you to position 1
(Stop)
.
)
Remove the key from the ignition switch.
Switching the vehicle off
Do not attach any heavy objects to
the key as this could weigh down on it
when in the ignition switch and cause
a fault.
Key reminder
If the key is left in the ignition switch, an
audible signal sounds when the driver's
door is opened.
Page 95 of 324
93Access
Do not throw the remote control
batteries away, they contain metals
which are harmful to the environment.
Take them to an approved collection
point.
Lost keys
Visit a CITROËN dealer with the vehicle's V5 registration document and your personal
identification documents.
The CITROËN dealer will be able to retrieve the key code and the transponder code
required to order a replacement key.
Remote control
The high frequency remote control is a sensitive system; do not operate it while it is in your
pocket as there is a possibility that it may unlock the vehicle, without you being aware of it.
Do not repeatedly press the buttons of your remote control out of range and out of sight of
your vehicle. You run the risk of stopping it from working and the remote control would have
to be reinitialised.
The remote control does not operate when the key is in the ignition, even when the ignition
is switched off, except for reinitialisation.
Locking the vehicle
Driving with the doors locked may make access to the passenger compar tment by the
emergency services more difficult in an emergency.
As a safety precaution (with children on board), remove the key from the ignition when you
leave the vehicle, even for a shor t time.
Anti-theft protection
Do not make any modifications to the electronic engine immobiliser system; this could
cause malfunctions.
When purchasing a second-hand vehicle
Have the key codes memorised by a CITROËN dealer, to ensure that the keys in your
possession are the only ones which can star t the vehicle.
