fuel filter Citroen DS3 RHD 2013 1.G Owner's Manual

25

Limit the causes of excess consumption

Spread loads throughout the vehicle; place the heaviest items in the bottom of the boot, as close as possible to the rear seats.
Limit the loads carried in the vehicle and reduce wind resistance (roof bars, roof rack, bicycle carrier, trailer...). Use a roof box in preference.
Remove roof bars and roof racks after use.


At the end of winter, remove snow tyres and refit your summer tyres.


Observe the recommendations on
maintenance

Check the tyre pressures regularly, when cold, referring to the label inthe door aperture, driver's side.
Carry out this check in par ticular:


- before a long journey,

- at each change of season,

- after a long period out of use.
Don't forget the spare wheel and the tyres on any trailer or caravan.


Have your vehicle ser viced regularly (engine oil, oil filter, air filter...) andobser ve the schedule of operations recommended by the manufacturer.


When refuelling, do not continue after the third cut-off of the nozzle toavoid any over flow.


At the wheel of your new vehicle, it is only after the first 1 800 miles (3 000 kilometres) that you will see the fuel consumption settle down toa consistent average.

Diesel engines
1.
Screenwash fluid reservoir.2.
Coolant header tank.3.
Air filter.
4.
Brake fluid reservoir.5.
Battery.
6.Fusebox.
7. Engine oil dipstick. 8.Engine oil filler cap.9.
Priming pump (on fuel filter).

229Practical information

Fuse table
Fuse N°RatingFunctions
F120 A
Engine control unit supply, cooling fan unit control relay, multifunction engine control main relay, injection pump(Diesel).
F
215 A Horn.
F
310 A Front / rear wash-wipe.
F420 A LED lamps.
F5
15 A Diesel heater (Diesel), particle filter additive pump (Diesel), air flow sensor (Diesel), EGR electrovalve (Diesel),
blow-by heater and electrovalves (VTi).
F
610 A ABS/ESP control unit, secondary stop switch.
F
710 A Electric power steering, automatic gearbox.
F8
25 A Starter control.
F
910 A Switching and protection unit (Diesel).
F10 30 A
Fuel heater
(Diesel), blow-by heater (Diesel), fuel pump (VTi), injectors and ignition coils (petrol).
F1140 A Heater blower.

MODELS:ENGINES AND GEARBOXES
Model codes:
SA...HMZ0HMZ0/PS8FR0
8FP05FS05FS95FV85FN8 *
5FM8**

PETROL ENGINESVTi 82e-VTi 82VTi 95VTi 120THP 155THP 150*THP 160**

Cubic capacity (cc) 1 19 9
1 397 1 598
1 598

Bore x stroke
(mm)

75 x 90.5
77 x 75
77 x 85.8 77 x 85.8
Max power: EU standard
(kW) ***
6070
88

115
110 *120 **
Max power engine speed (rpm) 5 750
6 000
6 000
6 000

Max torque: EU standard
(Nm) 11 8
13 6
160
240

Max torque engine speed
(rpm) 2 750
4 000 4 250
1 400

Fuel Unleaded Unleaded
Unleaded
Unleaded


Catalytic conver ter yes
yes
yes
yes
GEARBOX
Manual(5-speed)
Electronic(5-speed)
Electronic(5-speed)
Manual(5-speed)
Automatic
(4-speed)
Manual(6-speed)

OIL CAPACITIES
(in litres)
Engine (with filter replacement) 3.25

4.25
4.25

4.25

4.25

*
For Belgium and Russia. **
For Brazil.
***
The maximum power corresponds to the value type-approved on a test bed, under conditions defined in European legislation (Directive 1999/99/EC).

247Technical data
ENGINE AND GEARBOX- RACING
MODELS:Model codes: SA...5FF85FD8
PETROL ENGINE
Cubic capacit
y (cc) 1 598

Bore x stroke
(mm) 77 x 85.8

Max power: EU standard (kW) *

149 152
Max power en
gine speed (rpm) 6 000

Max torque: EU standard
(Nm)

275

Max torque en
gine speed (rpm)
2 000

F
uel
Unleaded **

Catalytic converter Yes

GEARBO
XManual (6-speed)

OIL CAPACITY (in litres)
En
gine (with filter replacement) 4.25


**

CITROËN strongly recommends the use of 98 RON unleaded petrol to ensure optimum operation of the engine (refer to the label inside the fuel filler flap).
*

The maximum power corresponds to the value type-approved on a test bed, under conditions defined in European legislation (Directive 1999/99/EC).

MODELS:ENGINES AND GEARBOXES
Model codes: SA...8HR48HP4/PS9HPK/S9HP8/PS9HD8/S9HR8/S
DIESEL ENGINESHDi 70PEFe- HDi 70 PEFe-HDi 90 PEFe-HDi 115 PEF

Cubic capacity (cc) 1 398
1 560 1 560
Bore x stroke
(mm)

73.7 x 8275 x 88.3

75 x 88.3

Max power: EU standard (kW) * 50
68
84
Max power en
gine speed (rpm)
4 000
4 0003 600

Max torque: EU standard
(Nm) 160
230 270
Max torque en
gine speed (rpm)
2 000
1 7501 750

Fuel Diesel
Diesel
Diesel
Catal
ytic conver ter yes
yes
yes

Particle emissions filter (PEF) yes
yes
yes
GEARBOX
Manual(5-speed)
Manual
(5-speed)
Manual
(5-speed)
Electronic gearbox system (6-speed)
Manual(6-speed)
OIL CAPACITIES (in litres)

Engine (with filter replacement) 3.75 3.75 3.75
.../S
:e-HDi model fitted with Stop & Start
*
The maximum power corresponds to the value type-approved on a test bed, under conditions defined in European legislation (Directive 1999/99/EC).

Identifi cation markings
A. Vehicle identification number (VIN) under
the bonnet.This number is engraved on the bodywork near
the passenger compar tment filter.
B. Vehicle identification number on the dashboard.This number is indicated on a self-adhesive label which is visible through the windscreen.
D. Tyre/paint label.
This label is affixed to the left hand centrepillar.

Wheels which are fitted with 205/45 R17 tyres cannot be fitted withsnow chains. For more information, contact a CITROËN dealer or a qualifiedworkshop.

Low tyre pressures increase fuelconsumption.

The tyre pressures must be checked when the tyres are cold, at least oncea month.
C. Manufacturer's label.
The VIN is indicated on a self-destroying label
affixed to the left hand centre pillar. It bears the
following information:


- the tyre pressures, for unladen and laden conditions,

- the wheel rim and tyre sizes,

- the brands of tyre recommended by the manufacturer,

- the spare tyre inflation pressure,

- the paint colour code.

A
3D rear lamps................................................222
Battery...................................................198,232Battery, charging...........................................232Battery, remote control.............................94, 95Black panel......................................................47Bluetooth (hands-free)..........................286,327Bluetooth (telephone)....................................286Bonnet...........................................................191Boot...............................................................105Boot lamp..............................................123,224Brake discs ....................................................199Brake lamps..........................................221,222Brake pads ....................................................199Brakes ...........................................................199Braking assistance system ...........................152
Capacity, fuel tank........................................106CD MP3.........................................................323Central locking........................................90, 103Changing a bulb.............................217, 221-223Changing a fuse............................................225Changing a wheel.........................................209Changing a wiper blade........................ 121, 236Changing the date...............................54,57, 61Changing the remote control battery..............94Changing the time...............................54,57, 61Checking levels......................................195-197Checking the engine oil level..........................45Checking tyre pressures (using the kit)........202Checks ..................................193, 194,198, 199Children.................................141,143,145, 146Child seats ............................ 134-136, 140, 141Child seats, conventional..............................140Citroën Localised Assistance Call................262Citroën Localised Emergency Call...............262Cleaning (advice)..........................................241Closing the boot ......................................90, 105Closing the doors ....................................90, 102Connectors, audio .........................128, 324,326Coolant level...........................................42, 196Coolant temperature indicator........................r42Courtesy lamps.............................................224Courtesy mirror.............................................r127Cruise control................................................184Cup holder.....................................................r126
BC
Assistance call..............................151,261,262Audible warning............................................151Audio streaming (Bluetooth) ................302, 329Audio system .................................317, 330, 332Automatic illumination of headlamps ....113,116Automatic operation of hazard warning
lamps ..........................................................151Automatic rain sensitive windscreen
wipers.................................................118,120Auxiliary socket....................................303,326Auxiliary sockets...........................................324
ABS and EBFD systems...............................152Accessories..................................................242Accessory socket, 12V.................................128Access to rear seats.................................81,82Adjusting headlamps....................................117Adjusting head restraints ................................80Adjusting the steering wheel...........................85Advice on care and maintenance.................241Airbags .......................................................... 137Airbags, curtain.....................................162,163Airbags, front.........................................159,163Airbags, lateral......................................161,163Air conditioning...............................................24Air conditioning, automatic.......................67, 73Air conditioning, manual ...........................67,70Air filter..........................................................r198Air flow............................................................24Air intake .........................................................73Air recirculation...............................................73Air vents..........................................................66Alarm...............................................................96Alloy wheels..................................................241Anti-lock braking system (ABS)....................152Anti-pinch ......................................................100Anti-theft..........................................................92Armrest, front................................................127

Main beam ............................................112,219Maintenance....................................................24Maintenance (advice)....................................241Map reading lamps...............................122,224Markings, identification.................................256Mat ................................................................129Menu, main ...................................................320Mini fuel level ................................................106Mirror, rear view ..............................................87
M
Navigation.............................................269, 270Number plate lamps..............................221, 222
N L
Labels, identification.....................................256Lamps, front..................................................217Lamps, rear...................................................r221Lamps, warning and indicator.............r32,36, 37Leather (care)................................................241LED daytime running lamps..................117, 220Level, brake fluid...........................................195Levels and checks..................................193-197Lighting, guide-me home......................115,116Lighting, interior............................r122,123,224Lighting bulbs (replacement).........217,221-223Lighting control stalk .....................................112Lighting dimmer..............................................r46Loading............................................................24Load reduction mode ....................................236Locating your vehicle......................................92Locking from the inside.................................103Luggage retaining strap................................130
Jack...............................................................209JACK socket.................................303, 324, 326
J
Indicators, direction......................................150Inflating accessories (using the kit)..............202Inflating tyres ..................................................24
Inputs for audio system ................303, 324, 326Instrument panel lighting................................ 46Instrument panels .....................................28,30Instrument panel screen ...................28, 30,177Interior fittings.......................................126,127Interior lamp..................................................122Interior mood lighting....................................123ISOFIX...........................................................145ISOFIX child seats........................143, 145,146ISOFIX mountings.................................143,146
IMirrors, door....................................................r86Misfuel prevention.........................................108Motorway function (direction indicators).......150Mountings for ISOFIX seats .................143, 146MP3 CD .........................................................323Music media players .....................................298
K
Keeping children safe.....134-136, 143,145, 159Key in ignition warning ....................................92Key with remote control .....................90,92,95
O
Oil filter..........................................................r198Oil level ....................................................45, 195Opening the bonnet......................................191Opening the boot ....................................90, 105Opening the doors..........................90,102,104Opening the fuel filler flap.............................106Operation indicator lamps.........................32,36

347
Alphabetical index
R P
Paint colour code..........................................256Paintwork, matt.............................................241Parcel shelf, rear...........................................r131Parking brake........................................166, 199Parking sensors, rear....................................r186Particle emission filter..........................r196-198Passenger compartment filter......................r198Player, CD MP3.............................................323Port, USB.............................128, 303, 324,326Priming the fuel system................................192Protecting children........................134-136, 141,143,145, 146, 159Puncture........................................................202
Radio............................................295,296,321Rear foglamp.........................................221, 222Rear screen (demisting)..................................76Recharging the battery.................................232Reduction of electrical load..........................236Regeneration of the particle emissions filter.....r198Reinitialising the electric windows ................ 100Reinitialising the remote control .....................94Remote control..........................................90,95Removing a wheel........................................212Removing the mat.........................................129Repair kit, puncture.......................................202Replacing bulbs .............................217, 221-223
Safety for children.................................141,146Scented air freshener.....................................r77Screen, colour 16/9.........................................61Screen, colour and mapping.................267,306Screen, monochrome ..................320, 330, 332Screen, multifunction (with audio equipment).....................54,57,61Screen-wash reservoir.................................. 196Screen menu map........................306, 330, 332Screenwash..................................................119Screenwash fluid level..................................196Seat, rear bench.............................................84Seat adjustment........................................79, 82Seat belts ......................................140,155,157
S
Replacing fuses............................................225Replacing the air filter...................................r198Replacing the oil filter...................................r198Replacing the passengercompartment filter......................................r198Replacing wiper blades .........................121, 236Resetting the service indicator.......................r44Resetting the trip recorder..............................r46Rev counter...............................................r28, 30Reversing lamp.....................................221,222Risk areas (update).......................................274Routine checks.....................................198,199Running out of fuel (Diesel) ..........................192
Seats, rear.......................................................r84Serial number, vehicle..................................256Ser vice indicator.............................................r43Servicing.........................................................24Setting the clock.................................54, 57, 61Shor t-cut menus ...........................................268Sidelamps ............................. 112, 219, 221, 222Side repeater.................................................219Snow chains..................................................216Spare wheel..................................................209Speed limiter.................................................r182Speedometer............................................r28,30Stability control (ESP) ...................................153Starting the vehicle .........................92,168, 173Steering mounted controls, audio.................319Stopping the vehicle .......................92,168, 173Stop & Start.......50, 73,106,178,191, 198, 232Storage..................................................126,127Storage box...................................................131Stowing rings................................................130Sun visor.......................................................r127Synchronising the remote control...................94Synthesiser, voice .........................................280System, navigation ........................................270Systems, ASR and ESP ................................153
