steering Citroen DS4 2010.5 1.G Owner's Guide

Stop & Start The Stop & Star t system puts the engine temporarily on standby - STOP mode - during stops in the traffic (red lights, traffic jams, or other...). The engine restar ts automatically - START mode - as soon as y ou want to move off. The restar t takes place instantly, quickly and silently. Per fect for urban use, the Stop & Star t system reduce s fuel consumption and exhaust emissions as well as the noise level when stationary.
Operation
Going into engine STOP mode
With the automatic gearbox system, for your comfor t during parking maoeuvres, STOP mode is not available for a few seconds after coming out of reverse gear. STOP mode does not affect the functionality of the vehicle, such as braking, power steering, for example.
Never refuel with the engine in STOP mode; you must switch off the ignition with the key.
The "ECO" warning lamp comes on in the instrument panel and the engine goes into standby:
- with a manual gearbox , at speeds below 12 mph (20 km/h), when you put the gear lever into neutral and release the clutch pedal, - with the 6-speed electronic gearbox system , at a speed below 5 mph (8 km/h),
when you press the brake pedal or put the gear lever into position N .
If your vehicle is fitted with the system, a time counter calculates the sum of the periods in STOP mode during a journey. It resets itself to zero every time the ignition is switched on with the key.
STOP mode is not invoked when: - the driver's door is open, - the driver's seat belt is not fastened, - the vehicle has not exceeded 6 mph (10 km/h) since the last engine start using the key, - the electric parking brake is applied or being applied, - the engine is needed to maintain a comfor table temperature in the passenger compar tment, - demisting is active, - some special conditions (battery charge, engine temperature, braking assistance, ambient temperature...) where the engine is needed to assure control of a system.
Special cases:STOP mode unavailable
In this case, the "ECO" warning lamp flashes for a few seconds, then goes off. This operation is per fectly normal.

Memorising speeds This memorisation of speeds applies to both the speed limiter and the cruise control.
Operation
You can memorise up to 5 speeds in the system. By default, some speeds are already memorised.  Go to the main menu: - on the monochrome screen C; press the "MENU" button, then select the "Personalisation-configuration" menu and confirm. - on the central colour screen associated
with the satellite navigation system; press the thumb wheel on the left of the steering column.
 Select "Vehicle parameters" menu and confirm.  Select the "Driving assistance" line and
conform.  Select "Speeds memorised" line and confirm.  Modify the speed.  Select " OK " and confirm to save the modifications.
Access
Press the MEM button to display the list of memorised speeds.
Selection
To select a memorised speed:  press and hold the " + " or " - " button; the system stops at the nearest memorised speed,  press and hold again the " + " or " - " button to select another memorised speed. A reminder of the speed and the state of the system (on/off) is displayed in the instrument panel.
For safety reasons, when using the monochrome screen C the driver must only carry out these operations when stationary. These operations are only possible
when stationary, when using the central colour screen associated with the satellite navigation system.

213Driving
System which prevents the vehicle from exceeding the speed programmed by the driver. When the programmed speed limit is reached, pressing the accelerator pedal no longer has any effect.
Speed limiter
The speed limiter cannot, in any circumstances, replace the need to respect speed limits, nor can it replace the need for vigilance and responsibility on the par t of the driver.
The functions of this system are grouped together on the steering mounted controls. 1. Speed limiter mode selection dial. 2. Programmed value decrease button. 3. Programmed value increase button. 4. Speed limiter on/off button. 5. List of memorised speeds display button. (see "Memorising speeds")
Steering mounted controls
The programmed information is grouped together in the instrument panel screen. 6. Speed limiter on/off indication. 7. Speed limiter mode selection indication. 8. Programmed speed value. 9. Selection of a memorised speed. (see "Memorising speeds")
Displays in the instrument panel
Operation
The speed limiter is switched on manually: it requires a programmed speed of at least20 mph (30 km/h). The speed limiter is switched off by manual d offoperation of the control. The programmed speed can be exceeded temporarily by pressing the accelerator firmly beyond the point of resistance. To return to the programmed speed, simply release the accelerator pedal. The programmed speed remains in the memory when the ignition is switched off.

215Driving
Cruise control
System which automatically maintains the speed of the vehicle at the value programmed by the driver, without any action on the accelerator pedal.
The functions of this system are grouped together on the steering mounted controls. 1. Cruise control mode selection dial. 2. Speed programming/value decrease button. 3. Speed programming/value increase button. 4. Cruise control off/resume button. 5. Stored speeds display button. (see "Storing speeds")
Steering mounted controls
The cruise control system cannot, in any circumstances, replace the need to respect speed limits, nor can it replace the need for vigilance and responsibility on the par t of the driver. You are advised to keep your feet near the pedals at all times.
The programmed information is grouped together in the instrument panel screen. 6. Cruise control off/resume indication. 7. Cruise control mode selection indication. 8. Programmed speed value. 9. Selecting a stored speed. (see "Storing speeds")
Displays in the instrument panel
Operation
The cruise control is switched on manually: it requires a minimum vehicle speed of 25 mph (40 km/h) and engagement of: - four th gear on the manual gearbox, - second gear on the electronic gearbox system, in sequential driving mode, - position A on the electronic gearbox system. The cruise control is switched off manually d offor by pressing the brake or clutch pedal or on triggering of the ESP system for safety reasons. It is possible to exceed the programmed speed temporarily by pressing the accelerator pedal. To return to the programmed speed, simply
release the accelerator pedal. Switching off the ignition cancels any programmed speed value.

227Checks
Petrol engines
The various caps and covers allow access for checking the levels of the various fluids and for replacing cer tain components.
1. Power steering reser voir. 2. Screenwash and headlamp wash reser voir. 3. Coolant reser voir. 4. Brake fluid reser voir. 5. Battery/Fuses. 6. Fusebox. 7. Air filter. 8. Engine oil dipstick. 9. Engine oil filler cap.

Diesel engines
The various caps and covers allow access for checking the levels of the various fluids, for replacing cer tain components and for priming the fuel system.
1. Power steering reser voir. 2. Screenwash and headlamp wash reser voir. 3. Coolant reser voir. 4. Brake fluid reser voir. 5. Battery/Fuses. 6. Fusebox. 7. Air filter. 8. Engine oil dipstick. 9. Engine oil filler cap. 10. Priming pump * . 11. Bleed screw * .
* According to engine.

Changing the coolant
The coolant does not have to be changed.
Coolant specifi cation
The coolant must conform to the manufacturer's recommendations.
Coolant level
The coolant level should be close to the "MA X" mark but should never exceed it. When the engine is warm, the temperature of the coolant is regulated by the fan. This can operate with the ignition off. On vehicles which are fitted with a par ticle
emission filter, the fan may operate after the vehicle has been switched off, even if the engine is cold.
In addition, as the cooling system is pressurised, wait at least one hour after switching off the engine before carrying out any work. To avoid any risk of scalding, unscrew the cap by two turns to allow the pressure to drop. When the pressure has dropped, remove the cap and top up the level.
Power steering fluid level
The power steering fluid level should be close to the "MA X" mark. Unscrew the cap, with the engine cold, to check the level.
To check the level or top up the fluid, immobilise the vehicle and switch of the engine.
Screenwash/headlamp
wash level

Temporary puncture repair kit
and a sealant car tridge which permits temporar y repair of a tyre so that you can pairdrive to the nearest garage. It is designed to repair most punctures which
could affect the tyre, located on the tyre tread or shoulder.
Access to the kit
The speed limit sticker I must be affixed to the vehicle's steering wheel to remind you that a wheel is in temporary use. Do not exceed a speed of 50 mph (80 km/h) when driving with a tyre repaired using this type of kit.
Description of the kit
A. "Sealant" or "Air" position selector. B. On "I" /off "O" switch. C. Deflation button. D. Pressure gauge (in bar or p.s.i.). E. Compar tment housing: - a cable with adaptor for 12 V socket, - various inflation adaptors for accessories, such as balls, bicycle tyres...
F. Sealant car tridge. G. White pipe with cap for repair. H. Black pipe for inflation. I. Speed limit sticker.
This kit is installed in the storage box, under the boot floor.

Towing the vehicle Procedure for having your vehicle towed or for towing another vehicle using a removable towing eye.
The towing eye is installed in the boot under the floor. To gain access to it:  open the boot,  raise the floor,
 secure it by hooking its cord on the hook on the rear parcel shelf suppor t,  remove the towing eye from the holder.
Access to the tools
General recommendations
Obser ve the legislation in force in your country. Ensure that the weight of the towing vehicle is higher than that of the towed vehicle. The driver must stay at the wheel of the towed vehicle. Driving on motor ways and fast roads is prohibited when towing. When towing a vehicle with all four wheels on the ground, always use an approved towing bar; rope and straps are prohibited. When towing a vehicle with the engine off, there is no longer any power
assistance for braking or steering.
In the following cases, you must always call on a professional recovery ser vice: - vehicle broken down on a motor way or fast road, - when it is not possible to put the gearbox into neutral, unlock the steering, or release the parking brake, - towing with only two wheels on the ground, - where there is no approved towing bar available...

269Practical information
 On the front bumper, unclip the cover by pressing at the bottom.  Screw the towing eye in fully.  Install the towing bar.
 On the rear bumper, unclip the cover by pressing at the bottom.  Screw the towing eye in fully.  Install the towing bar.  Switch on the hazard warning lamps on both vehicles.  Move off gently, drive slowly and for a shor t distance.
Towing your vehicle Towing another vehicle
 Place the gear lever in neutral (position N on the electronic gearbox system). Failure to obser ve this special condition could result in damage to cer tain components (braking, transmission...) and the absence of braking assistance the next time the engine is star ted.
 Unlock the steering by turning the key in the ignition one notch and release the
parking brake.  Switch on the hazard warning lamps on both vehicles.
 Move off gently, drive slowly and for a shor t distance.
