 To connect a 12 V accessory (max power: 120 W), remove the cap and connect an appropriate adaptor.  Turn the key to the ignition on position.
12 V accessory socket
This is a removable lamp, fitted in the boot wall, which can be used to light the boot or as a torch.
For the boot lamp function, refer to the "Visibility - § Boot lamp" section.
Torch
Operation
This torch operates with NiMH type rechargeable bateries.
It has an battery life of approximately 45 minutes and charges while you are driving.
Obser ve the polarities when fitting the rechargeable batteries. Never replace the rechargeable batteries with normal batteries.

 To connect a 12 V accessory (max power: 120 W), remove the cap and connect an appropriate adaptor.  Turn the key to the ignition on position.
12 V accessory socket
This is a removable lamp, fitted in the boot wall, which can be used to light the boot or as a torch.
For the boot lamp function, refer to the "Visibility - § Boot lamp" section.
Torch
Operation
This torch operates with NiMH type rechargeable bateries.
It has an battery life of approximately 45 minutes and charges while you are driving.
Obser ve the polarities when fitting the rechargeable batteries. Never replace the rechargeable batteries with normal batteries.

Electric child lock Remote control system to prevent opening of the rear doors using their interior controls and use of the rear electric windows . The control is located on the dashboard, driver’s side.
Switching on
 Press this button. The indicator lamp in the button comes on, accompanied by a message in the screen. This indicator lamp remains on until the child lock is switched off.
Switching off
 Press this button again. The indicator lamp on button A goes off, accompanied by a message in the screen. This indicator lamp remains on while child lock is switched on.
This system is independent and in no circumstances does it take the place of
the central locking control. Check the status of the child lock each time you switch on the ignition. Always remove the key from the ignition when leaving the vehicle, even for a shor t time. In the event of a serious impact, the electric child lock is switched off automatically to permit the exit of the rear passengers.
Any other status of the indicator lamp indicates a fault with the electric child lock. Have it checked by a CITROËN dealer or a qualified workshop.

Direction indicators
 Left: lower the lighting stalk passing the point of resistance.  Right: raise the lighting stalk passing the point of resistance.
"Motorway" function
 Press briefly upwards or downwards, without going beyond the point of resistance; the direction indicators will flash 3 times.
Hazard warning lamps
A visual warning by means of the direction indicators to aler t other road users to a vehicle breakdown, towing or accident.  Press this button, the direction indicators
flash. They can operate with the ignition off.
If you forget to cancel the direction indicators for more than twenty seconds, the volume of the audible signal will increase if the speed is above 40 mph (60 km/h).

Direction indicators
 Left: lower the lighting stalk passing the point of resistance.  Right: raise the lighting stalk passing the point of resistance.
"Motorway" function
 Press briefly upwards or downwards, without going beyond the point of resistance; the direction indicators will flash 3 times.
Hazard warning lamps
A visual warning by means of the direction indicators to aler t other road users to a vehicle breakdown, towing or accident.  Press this button, the direction indicators
flash. They can operate with the ignition off.
If you forget to cancel the direction indicators for more than twenty seconds, the volume of the audible signal will increase if the speed is above 40 mph (60 km/h).

Deactivation
In exceptional conditions (star ting a vehicle which is bogged down, stuck in snow, on soft ground...), it may be advisable to deactivate the ASR and ESP systems, so that the wheels can
move freely and regain grip.  Press the "ESP OFF" button, located on the left below the steering wheel.
If this warning lamp comes on in the instrument panel and the indicator lamp in the button comes on, this indicates that the ASR and ESP systems are deactivated.
Reactivation
These systems are reactivated automatically each time the ignition is switched back on or from 30 mph (50 km/h).  Press the "ESP OFF" button again to
reactivate them manually.
Operating fault
The ESP/ASR systems offer exceptional safety in normal driving, but this should not encourage the driver to take extra risks or drive at high speed. The correct functioning of these systems is assured provided that manufacturer's recommendations are obser ved on: - wheels (tyres and rims), - braking components, - electronic components, - assembly and repair procedures. After an impact, have these systems checked by a CITROËN dealer or a qualified workshop.
If this warning lamp comes on, accompanied by an audible signal and a message in the screen, this
indicates a fault with these systems. Have it checked by a CITROËN dealer or a qualified workshop.

Safety
Seat belts
Front seat belts
The front seat belts are fitted with a pretensioning and force limiting system. This system improves safety in the front seats in the event of a front or side impact.
Depending on the severity of the impact, the pretensioning system instantly tightens the seat belts against the body of the occupants. The pretensioning seat belts are active when the ignition is on. The force limiter reduces the pressure of the seat belt on the chest of the occupant, so improving their protection.
Fastening
 Pull the strap, then inser t the tongue in the buckle.  Check that the seat belt is fastened
correctly by pulling the strap.
Unfastening
 Press the red button on the buckle.  Guide the seat belt as it reels in.
Seat belt not fastened/unfastened warning lamp
When the ignition is switched on, this warning lamp comes on in the instrument panel if the driver and/or the front passenger has not fastened their seat belt. From approximately 12 mph (20 km/h) this warning lamp flashes for two minutes accompanied by an audible signal of increasing volume. Once these two minutes have elapsed,
this warning lamp remains on until the driver and/or the front passenger fastens their seat belt.
Height adjustment
 To lower the attachment point, squeeze the control A and slide it downwards.  To raise the attachment point, slide the control A upwards.

Safety
Seat belt unfastened warning lamp
This warning lamp comes on in the instrument panel when one or more rear passengers unfasten their seat belt. From approximately 12 mph (20 km/h), this warning lamp flashes for two minutes accompanied by an audible signal of increasing volume. Once these two minutes have elapsed, this warning lamp remains on until the one or
more rear passengers fasten their seat belt.
Seat belt unfastened warning lamps display
3. Rear right seat belt warning lamp. 4. Rear centre seat belt warning lamp. 5. Rear left seat belt warning lamp. When the ignition is switched on, with the engine running or when the vehicle is moving at less than 12 mph (20 km/h), the corresponding warning
lamps 3 , 4 and 45 come on in red for approximately 30 seconds, if the seat belt is not fastened. When the vehicle is moving at more than 12 mph
(20 km/h), the corresponding warning lamps 3 , 4 and 5 come on in red, accompanied by an audible signal and a message in the screen, if a rear passenger has unfastened their seat belt.

181Safety
Airbags
System designed to maximise the safety of the occupants (with the exception of the rear centre passenger) in the event of violent collisions. It supplements the action of the force-limiting seat belts (with the exception of the rear centre passenger). If a collision occurs, the electronic detectors record and analyse the front and side impacts sustained in the impact detection zones: - in the case of a serious impact, the airbags are deployed instantly and protect the occupants of the vehicle (with the exception of the rear centre passenger); immediately after the impact, the airbags deflate rapidly so that they do not hinder visibility or the exit of the occupants, - in the case of a minor or rear impact or in cer tain roll-over conditions, the airbags will not be deployed; the seat belt alone is sufficient to provide optimum protection in
these situations.
The airbags do not operate when the ignition is switched off. This equipment will only deploy once. If a second impact occurs (during the same or a subsequent accident), the airbag will not be deployed again.
Impact detection zones
A. Front impact zone. B. Side impact zone.
Deployment of the airbag(s) is
accompanied by a slight emission of harmless smoke and a noise, due to the activation of the pyrotechnic car tridge incorporated in the system. This smoke is not harmful, but sensitive individuals may experience slight irritation. The noise of the detonation may result in a slight loss of hearing for a shor t time.

183Safety
Deactivation
Only the passenger's front airbag can be deactivated:  with the ignition off , inser t the key in the n offpassenger airbag deactivation switch,  turn it to the "OFF" position,  then, remove the key keeping the switch in the new position.
According to version, this warning lamp comes on either in the instrument panel or in the seat belt and passenger's front airbag warning lamps display when the ignition is on and until the airbag is reactivated.
To assure the safety of your child, the passenger's front airbag must be deactivated when you install a "rear facing" child seat on the front
passenger seat. Other wise, the child would risk being seriously injured or killed if the airbag were deployed.
Reactivation
When you remove the child seat, turn the switch to the "ON" position to reactivate the airbag and so assure the safety of your front passenger in the event of an impact.
With the ignition on, this warning
lamp comes on in the seat belt and passenger's front airbag warning lamps display for approximately one minute, if the passenger's front airbag is activated.
Operating fault
If this warning lamp flashes, contact a CITROËN dealer or a qualified workshop. The passenger’s front airbag may no longer be deployed in the event of a serious impact.
If even one of the two airbag warning
lamps comes on continuously, do not install a child seat on the front passenger seat. Have the system checked by a CITROËN dealer or a qualified workshop.
If this warning lamp comes on in the instrument panel, accompanied by an audible warning and a message in the screen, contact a CITROËN dealer or a qualified workshop to have the system checked. The airbags may no longer be deployed in the event of a serious impact.
