11 3Access
System allowing the doors to be locked and
unlocked manually in the event of a malfunction
of the central locking system or battery failure.
Emergency control
Locking the driver's door
)
Inser t the key in the door lock, then turn it
to the rear.
You can also apply the procedure described
for the passenger doors.
Unlocking the driver's door
)
Inser t the key in the door lock, then turn it
to the front.
Locking the front and rear
passenger doors
)
Open the doors.
)
On the rear doors, check that the child lock
is not on (see Child Safety).
)
Remove the black cap, located on the edge
of the door, using the key.
)
Insert the key in the socket without forcing
it, then without turning it, move the latch
sideways towards the inside of the door.
)
Remove the key and refit the cap.
)
Close the doors and check that the vehicle
has locked correctly from the outside.
Unlocking the front and rear
passenger doors
)
Pull the interior door opening control.
Page 116 of 396
Boot
System allowing the mechanical unlocking of
the boot in the event of a battery or central
locking system malfunction.
Ta i l g a t e r e l e a s e
Unlocking
)
Fold back the rear seats to gain access to
the lock from inside the boot.
)
Inser t a small screwdriver into hole A
of the
lock to unlock the tailgate.
)
Move the latch to the left.
)
After unlocking the boot or the vehicle
using the remote control or the key, press
the opening control, then raise the tailgate.
Opening
Closing
)
Lower the boot lid using the interior grab
handle.
- when the engine is running
,
this warning lamp comes on,
accompanied by the display of an
aler t message for a few seconds,
- when the vehicle is moving
(speed above
6 mph (10 km/h)), this warning lamp comes
on, accompanied by an audible signal and
the display of an aler t message for a few
seconds.
Locking after closing
If the fault persists after closing again, the boot
will remain locked.
If the tailgate is not closed correctly:
Page 118 of 396
Safety anti-pinch
When the window rises and meets an obstacle,
it stops and partially lowers again.
Reinitialisation
If a window does not rise automatically,
its operation must be reinitialised:
)
pull the control until the window stops,
)
release the control and pull it again until
the window closes fully,
)
continue to hold the control for
approximately one second after the
window has closed,
)
press the control to lower the window
automatically to the low position,
)
when the window has reached the low
position, press the control again for
approximately one second.
The safety anti-pinch function is not
operational during these operations.
If the window cannot be closed
(for example, in the presence of ice),
once the window has lowered:
)
press and hold the control until the
window opens fully,
)
then pull the control immediately
and hold it until the window closes,
)
continue to hold the control for
approximately one second after the
window has closed.
The safety anti-pinch function is not
operational during these operations.
Always remove the key from the ignition
when leaving the vehicle, even for a
shor t time.
If an obstacle is encountered during
operation of the electric windows,
you must reverse the movement of the
window. To do this, press the control
concerned.
When the driver operates the
passenger's electric window control,
they must ensure that nothing is
preventing the windows closing
correctly.
The driver must ensure that the
passengers use the electric windows
correctly.
Be aware of children when operating
the windows.
Page 119 of 396
11 7Access
Fuel tank
Capacity of the tank: approximately 60 litres.
Low fuel level
Refuelling
Additions of fuel must be of at least 5 litres to
be registered by the fuel gauge.
Opening the filler cap may result in an inrush of
air. This vacuum is entirely normal and results
from the sealing of the fuel system.
)
Press control A
until the automatic opening
of the fuel flap is heard.
This control remains active for a few minutes
after switching off the ignition. If necessary,
switch the ignition on again to reactivate it.
)
Take care to select the pump that delivers
the correct fuel for your vehicle.
)
Introduce the nozzle so as to push in the
metal non-return flap B.
)
Make sure that the nozzle is pushed in as
far as possible before star ting to refuel (risk
of blowback).
)
Maintain this position while refuelling.
)
Push the fuel flap to close it.
If you are filling your tank to the top, do not
persist after the third cut- off; this could
cause your vehicle to malfunction.
When the low fuel level in the tank
is reached, this warning lamp on
the instrument panel comes on,
accompanied by an audible warning
and a message in the screen.
When it first comes on, around 6 litres of fuel
remain in the tank.
You must refuel as soon as possible to avoid
running out.
With Stop & Star t, never refuel with the
system in STOP mode; you must switch
off the ignition with the key.
Page 138 of 396
1.
Front cour tesy lamp
2.
Front map reading lamps
3.
Rear courtesy lamp
4.
Rear map reading lamps
Courtesy lamps
In this position, the courtesy
lamp comes on gradually:
Front and rear courtesy lamps
- when the vehicle is unlocked,
- when the key is removed from the ignition,
- on opening a door,
- when the remote control locking button is
used to locate your vehicle.
It switches off gradually:
- when the vehicle is locked,
- when the ignition is switched on,
- 30 seconds after the last door is closed.
Permanently off.
Permanent lighting. In permanent lighting mode, the
lighting time varies according to the
circumstances:
- with the ignition off, approximately
ten minutes,
- in energy economy mode,
approximately thirty seconds,
- with the engine running, unlimited.
When the cour tesy lamp is in the
"permanent lighting" position, the rear
courtesy lamp also comes on, except if
it is in the "permanently off " position.
To switch off the rear cour tesy lamp,
put it in the the "permanently off "
position.
Front and rear map reading
lamps
)
With the ignition on, press the
corresponding switch.
Take care not to put anything in contact
with the cour tesy lamps.
Page 157 of 396
155Fittings
)
To connect a 12 V accessory
(max power: 120 W), remove the cap and
connect an appropriate adaptor.
)
Turn the key to the ignition on position.
12 V accessory socket
This is a removable lamp, fitted in the boot
wall, which can be used to light the boot or as
a torch.
For the boot lamp function, refer to the
"Visibility - § Boot lamp" section.
To r c h
Operation
This torch operates with NiMH type
rechargeable batteries.
It has a battery life of approximately 45 minutes
and charges while you are driving.
Obser ve the polarities when fitting the
rechargeable batteries.
Never replace the rechargeable batteries
with normal disposable batteries.
Page 167 of 396
165Child safety
Advice on child seats
The incorrect installation of a child seat in a
vehicle compromises the child's protection
in the event of an accident.
Remember to fasten the seat belts or the
child seat harnesses keeping the slack
relative to the child's body to a minimum,
even for shor t journeys.
When installing a child seat using the seat
belt, ensure that the seat belt is tightened
correctly on the child seat and that it
secures the child seat firmly on the seat
of your vehicle. If your passenger seat is
adjustable, move it for wards if necessary.
For optimum installation of the "for wards-
facing" child seat, ensure that the back of
the child seat is in contact with the back
of the vehicle's seat and that the head
restraint does not cause any discomfor t.
If the head restraint has to be removed,
ensure that it is stored or attached securely
to prevent it from being thrown around the
vehicle in the event of sharp braking. Children under the age of 10 must not travel
in the "for wards-facing" position on the front
passenger seat, unless the rear seats are
already occupied by other children, cannot
be used or are absent.
Deactivate the passenger airbag when a
"rear wards-facing" child seat is installed on
the front seat.
Other wise, the child would risk being
seriously injured or killed if the airbag were
to inflate.
Installing a booster seat
The chest par t of the seat belt must be
positioned on the child's shoulder without
touching the neck.
Ensure that the lap part of the seat belt
passes correctly over the child's thighs.
CITROËN recommends the use of a
booster seat which has a back, fitted with a
seat belt guide at shoulder level.
As a safety precaution, do not leave:
- a child or children alone and
unsuper vised in a vehicle,
- a child or an animal in a vehicle which
is exposed to the sun, with the windows
closed,
- the keys within reach of children inside
the vehicle.
To prevent accidental opening of the doors
and rear windows, use the "Child lock".
Take care not to open the rear windows by
more than one third.
To protect young children from the rays of
the sun, fit side blinds on the rear windows.
Page 171 of 396
169Child safety
Manual child lock
Mechanical system to prevent opening of the rear door using its interior control.
The control is located on the edge of each rear door.
Locking
)
Using the ignition key, turn the red control
as far as it will go:
- to the left on the left-hand rear door,
- to the right on the right-hand rear door.
Unlocking
)
Using the ignition key, turn the red control
as far as it will go:
- to the right on the left-hand rear door,
- to the left on the right-hand rear door.
Page 187 of 396
185
Safety
Deactivation
Only the passenger's front airbag can be
deactivated:
)
with the ignition off
, inser t the key in the
passenger airbag deactivation switch,
)
turn it to the "OFF"
position,
)
then, remove the key keeping the switch in
the new position.
According to version, this warning
lamp comes on in the instrument
panel and/or in the seat belt and
passenger's front airbag warning lamps display
when the ignition is on and until the airbag is
reactivated. To assure the safety of your child,
the passenger's front airbag must
be deactivated when you install a
"rear facing" child seat on the front
passenger seat.
Other wise, the child would risk being
seriously injured or killed if the airbag
were deployed.
Reactivation
When you remove the child seat, turn the
switch to the "ON"
position to reactivate the
airbag and so assure the safety of your front
passenger in the event of an impact.
With the ignition on, this warning
lamp comes on in the seat belt and
passenger's front airbag warning
lamps display for approximately one
minute, if the passenger's front airbag
is activated.
Operating fault
If this warning lamp flashes in the
instrument panel and/or in the
seat belt and passenger's front
airbag warning lamps display, contact a
CITROËN dealer or a qualified workshop. The
passenger's front airbag may no longer be
deployed in the event of a serious impact.
If even one of the two airbag warning
lamps comes on continuously, do not
install a child seat on the front passenger
seat.
Have the system checked by a CITROËN
dealer or a qualified workshop.
If this warning lamp comes on in the
instrument panel, accompanied by
an audible warning and a message
in the screen, contact a CITROËN dealer or a
qualified workshop to have the system checked.
The airbags may no longer be deployed in the
event of a serious impact.
Page 214 of 396
Stop & Start
The Stop & Start system puts the engine temporarily into standby - STOP mode - during stops in the traffic (red lights, traffic jams, or other...). The
engine restarts automatically - START mode - as soon as you want to move off. The restart takes place instantly, quickly and silently.
Per fect for urban use, the Stop & Start system reduces fuel consumption and exhaust emissions as well as the noise level when stationary.
Operation
Going into engine STOP mode
With the electronic gearbox system,
for your comfort during parking
maoeuvres, STOP mode is not
available for a few seconds after
coming out of reverse gear.
STOP mode does not affect the
functionality of the vehicle, such as
braking, power steering, for example.
Never refuel with the engine in STOP
mode; you must switch off the ignition
with the key. The "ECO"
warning lamp comes
on in the instrument panel and the
engine goes into standby:
- with a manual gearbox
, at speeds below
12 mph (20 km/h), when you put the gear
lever into neutral and release the clutch
pedal,
- with the 6-speed electronic gearbox
system
, at a speed below 5 mph (8 km/h),
when you press the brake pedal or put the
gear lever into position N
.
If your vehicle is fitted with the
system, a time counter calculates
the sum of the periods in STOP
mode during a journey. It resets
itself to zero every time the ignition
is switched on with the key. STOP mode is not invoked when:
- the driver's door is open,
- the driver's seat belt is not fastened,
- the vehicle has not exceeded 6 mph
(10 km/h) since the last engine star t
using the key,
- the electric parking brake is applied or
being applied,
- the engine is needed to maintain a
comfor table temperature in the passenger
compartment,
- demisting is active,
- some special conditions (battery charge,
engine temperature, braking assistance,
ambient temperature...) where the engine is
needed to assure control of a system.
Special cases: STOP mode
unavailable
In this case, the "ECO"
warning lamp
flashes for a few seconds, then goes
off.
This operation is per fectly normal.
