Page 234 of 396
Running out of fuel
(Diesel)
On vehicle fitted with HDi engines, the fuel
system must be primed if you run out of fuel;
refer to the engine compar tment view on the
"Diesel engine" page.
1.6 litre HDi engine
)
Fill the fuel tank with at least five litres of
diesel.
)
Open the bonnet.
)
If necessary, unclip the styling cover for
access to the priming pump.
)
Squeeze and release the priming pump
repeatedly until resistance is felt (there may
be resistance at the first press).
)
Operate the star ter until the engine star ts
(if the engine does not star t at the first
attempt, wait around 15 seconds before
trying again).
)
If the engine does not star t after a few
attempts, operate the priming pump again
then star t the engine.
)
Clip the styling cover back in place.
)
Close the bonnet.
If the tank on your vehicle is fitted with
a misfuel prevention device, refer to the
section "Access - § Misfuel prevention
(Diesel)".
2 litre HDi engine
)
Fill the fuel tank with at least five litres of
Diesel.
)
Open the bonnet.
)
Unclip the style cover for access to
the priming pump.
)
Slacken the bleed screw.
)
Squeeze and release the priming pump
repeatedly until fuel appears in the
transparent pipe with the green connector.
)
Tighten the bleed screw.
)
Operate the star ter until the engine star ts.
)
Put the style cover back in position and
clip it in place, ensuring that it has clipped
correctly.
)
Close the bonnet.
If the engine does not star t first time,
don't keep trying. Star t the procedure
again from the beginning.
Page 235 of 396
233Checks
Petrol engines
The various caps and covers allow access for
checking the levels of the various fluids and for
replacing cer tain components.
1.
Power steering reservoir.
2.
Screenwash and headlamp wash reser voir.
3.
Coolant reser voir.
4.
Brake fluid reser voir.
5.
Battery/Fuses.
6.
Fusebox.
7.
Air filter.
8.
Engine oil dipstick.
9.
Engine oil filler cap.
Page 236 of 396
Diesel engines
The various caps and covers allow access for
checking the levels of the various fluids, for
replacing cer tain components and for priming
the fuel system.
1.
Power steering reservoir.
2.
Screenwash and headlamp wash reser voir.
3.
Coolant reser voir.
4.
Brake fluid reser voir.
5.
Battery/Fuses.
6.
Fusebox.
7.
Air filter.
8.
Engine oil dipstick.
9.
Engine oil filler cap.
10.
Priming pump * .
11.
Bleed screw * .
*
According to engine.
Page 237 of 396
235Checks
Checking levels
Check all of these levels regularly and top them up if necessary, unless other wise indicated.
If a level drops significantly, have the corresponding system checked by a CITROËN dealer or a qualified workshop.
Oil level
Engine oil change
Refer to the ser vicing booklet for the inter val for
this operation.
In order to maintain the reliability of the engine
and emission control system, the use of
additives in the engine oil is prohibited.
Oil specifi cation
The oil must correspond to your engine
and conform to the manufacturer's
recommendations.
Brake fluid level
Changing the fl uid
Refer to the Maintenance and Warranty Guide
for the inter val for this operation.
Fluid specifi cation
The brake fluid must conform to the
manufacturer's recommendations and meet
the DOT4 standard.
The brake fluid level should be close
to the "MA X" mark. If it is not, check
the brake pad wear.
The reading will only be correct if
the vehicle is on level ground and
the engine has been off for more than
30 minutes.
The check is carried out either when the ignition
is switched on using the oil level indicator in the
instrument panel, or using the dipstick.
When working under the bonnet, take
care, as cer tain areas of the engine
may be extremely hot (risk of burns).
It is normal to top up the oil level
between two ser vices. CITROËN
recommends that you check the oil
level, and top up if necessary, every
3 000 miles (5 000 kilometres).
Page 238 of 396
Changing the coolant
The coolant does not have to be changed.
Coolant specifi cation
The coolant must conform to the
manufacturer's recommendations.
Coolant level
The coolant level should be close
to the "MA X" mark but should never
exceed it.
When the engine is warm, the
temperature of the coolant is regulated by the
fan. This can operate with the ignition off.
On vehicles which are fitted with a par ticle
emission filter, the fan may operate after
the vehicle has been switched off, even if
the engine is cold.
In addition, as the cooling system is pressurised,
wait at least one hour after switching off the engine
before carrying out any work.
To avoid any risk of scalding, unscrew the cap
by two turns to allow the pressure to drop.
When the pressure has dropped, remove
the cap and top up the level.
Power steering fluid level
The power steering fluid level should
be close to the "MA X" mark. Unscrew
the cap, with the engine cold,
to check the level. To check the level or top up the
fluid on vehicle fitted with headlamp
washers, immobilise the vehicle and
switch of the engine.
Screenwash/headlamp wash
level
Page 240 of 396
Checks
Battery
Air filter and passenger compartment filter
Oil filter
Unless other wise indicated, check these components in accordance with the ser vicing booklet and according to your engine.
Other wise, have them checked by a CITROËN dealer or a qualified workshop.
The battery does not require any
maintenance.
However, check that the terminals
are clean and correctly tightened,
particularly in summer and winter.
When carrying out work on the battery, refer
to the "Practical information" section for
details of the precautions to be taken before
disconnecting the battery and following its
reconnection. Refer to the servicing booklet for
details of the replacement inter vals
for these components.
Depending on the environment
(e.g. dusty atmosphere) and the use of the vehicle
(e.g. city driving), replace them twice as often if
necessary
(refer to the "Engines" section).
A clogged passenger compar tment filter may
have an adverse effect on the per formance
of the air conditioning system and generate
undesirable odours.
Replace the oil filter each time
the engine oil is changed.
Refer to the servicing booklet for
details of the replacement inter val for
this component.
The presence of this label, in particular with
the Stop & Star t system, indicates the use of
a specific 12 V lead-acid battery with special
technology and specification, for which the
involvement of a CITROËN dealer or a qualified
workshop is required when replacing or
disconnecting the battery.
Failure to obser ve this recommendation may
shor ten the life of the battery.
Page 242 of 396
Electric parking brake
This system does not require any
routine servicing. However, in the
event of a problem, have the system
checked by a CITROËN dealer or a
qualified workshop.
For more information, see "Driving - Electric
parking brake - § Operating faults".
Only use products recommended by
CITROËN or products of equivalent
quality and specification.
In order to optimise the operation
of units as impor tant as the braking
system, CITROËN selects and offers
very specific products.
To avoid damaging the electrical units,
the use of a high pressure washer
in the engine compar tment is strictly
prohibited
.
Brake disc wear
For information on checking brake
disc wear, contact a CITROËN dealer
or a qualified workshop.
Manual parking brake
If a loss of effectiveness of this
system is noticed, the parking brake
must be checked, even between
two ser vices.
Checking this system must be done by a
CITROËN dealer or a qualified workshop.
Brake pads
Brake wear depends on the style
of driving, par ticularly in the case
of vehicles used in town, over shor t
distances. It may be necessary to
have the condition of the brakes checked,
even between vehicle ser vices.
Unless there is a leak in the system, a drop in
the brake fluid level indicates that the brake
pads are worn.
Page 247 of 396
245Practical information
1. Sealing
)
Uncoil the white pipe G
fully.
)
Unscrew the cap from the white pipe.
)
Connect the white pipe to the valve of the
tyre to be repaired.
Repair procedure
Avoid removing any foreign bodies
which have penetrated into the tyre.
)
Connect the compressor's electric plug to
the vehicle's 12 V socket.
)
Star t the vehicle and leave the engine
running.
)
Switch off the ignition.
)
Turn the selector A
to the
"sealant" position.
)
Check that the switch B
is in
position "O"
.
Take care, this product is harmful
(e.g. ethylene-glycol, colophony...) if
swallowed and causes irritation to the
eyes.
Keep it out of reach of children.
Page 249 of 396
247Practical information
2. Infl ation
)
Adjust the pressure using the compressor
(to inflate: switch B
in position "I"
; to deflate:
switch B
in position "O"
and press button C
),
in accordance with the vehicle's tyre pressure
label (located on the left hand door aperture).
A loss of pressure indicates that the
puncture has not been fully plugged;
contact a CITROËN dealer or qualified
workshop for assistance.
)
Remove and stow the kit.
)
Drive at reduced speed (50 mph [80 km/h]
max) limiting the distance travelled to
approximately 120 miles (200 km).
)
Turn the selector A
to the "air"
position.
)
Uncoil the black pipe H
fully.
)
Connect the black pipe to the
valve of the wheel.
)
Connect the compressor's electric plug to
the vehicle's 12 V socket.
)
Star t the vehicle again and leave the
engine running.
)
Visit a CITROËN dealer or a
qualified workshop as soon as
possible.
You must inform the technician
that you have used this kit. After
inspection, the technician will
inform you whether the tyre can be
repaired or must be replaced.
Page 250 of 396
Removing the cartridge
)
Stow the black pipe.
)
Detach the angled base from the white pipe.
)
Suppor t the compressor ver tically.
)
Unscrew the car tridge from the bottom.
Checking tyre pressures/
inflating accessories
Beware of discharges of fluid.
The expiry date of the fluid is indicated
on the car tridge.
The sealant car tridge is designed for
single use; even if only par tly used,
it must be replaced.
After use, do not discard the car tridge
into the environment, take it to an
authorised waste disposal site or a
CITROËN dealer.
Do not forget to obtain a new sealant
car tridge, available from CITROËN
dealers or from a qualified workshop.
You can also use the compressor, without
injecting any product, to:
- check or adjust the pressure of your tyres,
- inflate other accessories (balls, bicycle
tyres...).
)
Connect the compressor's electrical
connector to the vehicle's 12 V socket.
)
Star t the vehicle and let the engine run.
)
Adjust the pressure using the compressor
(to inflate: switch B
in position "I"
;
to deflate: switch B
in position "O"
and
press button C
), according to the vehicle's
tyre pressure label or the accessory's
pressure label.
)
Remove the kit then stow it.
)
Turn the selector A
to the "Air"
position.
)
Uncoil the black pipe H
fully.
)
Connect the black pipe to the
valve of the wheel or accessory.
If necessary, fit one of the adaptors
supplied with the kit first.
