boot Citroen DS4 2011 1.G Owner's Manual

MULTIFUNCTION
SCREENSCOMFORT ACCESS VISIBILITY
62 Monochrome screen C
66 Colour screen and map
70 Tr i p c o m p u t e r78 Ventilation
80 Manual air conditioning
82 Dual-zone digital air
conditioning
87 Rear screen demist - defrost
88 Front seats
93 Rear seats
94 Steering wheel adjustment
95 Mirrors100 Remote control key
109 Alarm
112 Doors
114 Boot
115 Electric windows
117 Fuel tank
119 Misfuel prevention (Diesel)122 Lighting controls
123 Daytime running lamps
126 Automatic illumination of
headlamps
127 Welcome lighting
128 Headlamp adjustment
129 Directional lighting
131 Wiper controls
132 Automatic rain sensitive
wipers
136 Courtesy lamps
137 Interior mood lighting
138 Boot lamp
004004005005002002003003

SAFETY DRIVING FITTINGS CHILD SAFETY
192 Electric parking brake
200 Manual parking brake
201 Manual gearbox
202 Gear shift indicator
203 6 -speed electronic gearbox
system
207 Automatic gearbox
211 Hill start assist
212 Stop & Start
215 Lane depar ture warning
system
216 Blind spot sensors
220 Speed limiter
222 Cruise control
224 Parking space sensors
226 Parking sensors 172 Direction indicators
172 Hazard warning lamps
173 Horn
173 Emergency or assistance call
174 Ty r e u n d e r- i nfl ation detection
176 Braking assistance systems
17 7 Trajectory control systems
(ESP)
179 Front seat belts
183 Airbags 160 Child seats
166 ISOFIX child seats
169 Child lock 142 Interior fi ttings
14 8 Front armrest
15 3 Boot fi ttings
008008009009006006007007

100



Opening



A.
Folding/unfolding the key
(first press this button).


3-button remote
control
When a sensor detects a low level of light,
the remote switching on of the dipped beam
headlamps, the sidelamps and the side spotlamps
makes your approach to the vehicle easier.

Welcome lighting

Complete or selective unlocking of
the vehicle
(rapid flashing of the direction
indicators).
Opening the windows
(hold until the desired position is reached).
Selective unlocking of the boot. Normal locking
(press once; fixed lighting of the
direction indicators).
Closing the windows
(hold until the desired position is reached).

127

In the same way, the passenger compar tment
lighting, such as the cour tesy lamps and the
footwell lamps, comes on.

11Familiarisation

117, 119



A.
Opening the fuel filler flap.
Capacity of the fuel tank: approximately 60 litres.


Fuel t ank

Opening


101, 114





1.
Selective unlocking of the boot.

2.
Opening the boot.


Boot

35

Limit the causes of excess
consumption

Spread loads throughout the vehicle; place the
heaviest items in the bottom of the boot, as
close as possible to the rear seats.
Limit the loads carried in the vehicle and
reduce wind resistance (roof bars, roof rack,
bicycle carrier, trailer...). Use a roof box in
preference.
Remove roof bars and roof racks after use.

At the end of winter, remove snow tyres and
refit your summer tyres.



Observe the recommendations
on maintenance

Check the tyre pressures regularly, when
cold, referring to the label in the door
aperture, driver's side.
Carry out this check in par ticular:


- before a long journey,

- at each change of season,

- after a long period out of use.
Don't forget the spare wheel and the tyres on
any trailer or caravan.

Have your vehicle ser viced regularly (engine
oil, oil filter, air filter...) and obser ve the
schedule of operations recommended by the
manufacturer.



When refuelling, do not continue after
the 3 rd cut-off of the nozzle to avoid any
over flow.

At the wheel of your new vehicle, it is only
after the first 1 800 miles (3 000 kilometres)
that you will see the fuel consumption settle
down to a consistent average.

Switch off the headlamps and front foglamps
when the level of light does not require their
use.

Avoid running the engine before moving off,
particularly in winter; your vehicle will warm
up much faster while driving.

As a passenger, if you avoid connecting
your multimedia devices (film, music, video
game...), you will contribute towards limiting
the consumption of electrical energy, and so
of fuel.
Disconnect your portable devices before
leaving the vehicle.

Familiarisation

Warning lamp



is on



Cause



Action/Observations






Electric parking
brake


flashing. The application or release of the
electric parking brake was interrupted. You must stop as soon as it is safe to do so.
Park on level ground, switch off the ignition and contact
a CITROËN dealer or a qualified workshop.

+

Electric
parking brake
malfunction


fixed. The electric parking brake has a fault. Automatic application/release is no longer possible.
Contact a CITROËN dealer or a qualified workshop
without delay.
The parking brake can be released manually using the
emergency release procedure.
For more information on the electric parking brake,
refer to the "Driving" section.





Door(s) open


fixed if the speed is
below 6 mph (10 km/h).
A door or the boot is still open. Close the door or boot.
fixed and accompanied
by an audible signal
if the speed is above
6 mph (10 km/h).

* According to country.

Seat belt not
fastened/
unfastened *


fixed, then flashing,
accompanied by an
increasing audible
signal. The driver or front passenger has not
buckled or has unbuckled their seat
belt. Pull on the belt in question and inser t the tongue in
the buckle.
This warning repeats the seat belt information given
by the roof console warning lamps. At least one rear passenger has
unbuckled their seat belt.

45Monitoring





Service


temporarily,
accompanied by a
message. A minor malfunction has occurred
for which there is no specific warning
lamp. Identify the malfunction by reading the message
displayed in the screen, such as, for example:


- the opening of the doors, boot or bonnet,

- the engine oil level,

- the remote control battery,

- the tyre pressures,

- saturation of the par ticle emission filter on
Diesel vehicles (see "Checks - § Checks/Particle
emissions filter").
For any other malfunctions, contact a CITROËN dealer
or a qualified workshop.

fixed, accompanied
by a message and an
audible signal. A major malfunction has occurred
for which there is no specific warning
lamp. Identify the malfunction by reading the message
displayed in the screen and contact a CITROËN dealer
or a qualified workshop.

Warning lamp



is on



Cause



Action/Observations



Particle
emissions filter
(Diesel)
fixed, accompanied
by an audible signal
message on the risk of
blockage of the particle
emissions filter. This indicates that the par ticle
emissions filter is star ting to become
saturated. As soon as driving conditions allow, regenerate the
filter by driving at a speed of at least 35 mph (60 km/h)
until the warning lamp goes off.
fixed, accompanied by
an audible signal and
and a message that the
particle emissions filter
additive level is too low.

This indicates the low level of the
additive reservoir. Have the reser voir topped up as soon as possible by a
CITROËN dealer or a qualified workshop.

Monochrome screen C

This displays the following information:


- time,

- date,

- ambient temperature (this flashes if there is
a risk of ice),

- openings check (if a doors or the boot is
open),

- parking sensor information,

- current audio source,

- telephone or Bluetooth system information,

- trip computer (refer to the end of the
section).
Warning messages (e.g.: "Emission control
system faulty") or information messages (e.g.:
"Automatic switching on of the headlamps
activated") may appear temporarily. These can
be cleared by pressing the "ESC"
button.


Displays in the screen

From the control panel of your audio system,
you can press:


)
button A
to chooses between the display
of audio information in full screen or the
shared display of audio and trip computer
information,

)
the "MENU"
button for access to the main
menu
,

)
the "
" or "
" buttons to scroll through the
items on the screen,

)
the "
" or "
" buttons to change a setting
value,

)
the "OK"
button to confirm,
or


)
the "ESC"
button to abandon the operation
in progress.



Controls



)
Press the "MENU"
button for access to the
main menu
:


- "Multimedia",

- "Telephone",

- "Trip computer",

- "Bluetooth connection",

- "Personalisation-configuration",

)
Press the "
" or "
" button to select the
menu required, then confirm by pressing
the "OK"
button.



Main menu

Defi ne the vehicle
parameters


- "Driving assistance":


●
"Parking brake automatic" (Automatic
electric parking brake; see the "Driving"
section),

●
"Rear wipe in reverse gear" (Rear
wiper coupled to reverse gear; see the
"Visibility" section),

●
"Speeds memorised" (Memorising
speeds; see the "Driving" section).



- "Vehicle lighting" (see the "Visibility"
section):


●
"Directional headlamps" (Main/additional
directional lighting),

●
"Daytime lights" (Daytime running
lamps).



- "Interior lighting" (see the "Visibility"
section:


●
"Follow-me-home headlamps"
(Automatic operation of headlamps after
switching off the ignition),

●
" Welcome lighting" (Exterior and interior
welcome lighting).
For example: setting of the duration of the
"follow-me-home" lighting


)
Press the "
" or "
" buttons, to select the
"Define the vehicle parameters" menu, then
the " OK
" button.

)
Press the "
" or "
" buttons to select
the "Interior lighting" line, then the
"OK"
button; then follow the same
procedure to select the "Follow-me-home
headlamps" line. This menu allows you to activate or deactivate
the following equipment, classified in different
categories:


- "Access to the vehicle" (see the "Access"
section):


●
"Plip action" (Selective unlocking of the
driver's door),

●
"Unlocking boot only" (Selective
unlocking of the boot).



"Personalisation-
configuration" menu
This menu gives access to the following
functions:


- "Define the vehicle parameters",

- "Choice of language",

- "Display configuration",

- "Choice of sounds".

69Multifunction screens

Vehicle parameters

This menu is used to activate or deactivate
cer tain driving and comfor t systems, classified
in different categories:


- "Access to the vehicle"
(see "Access" section):


●
"Plip action" (Selective unlocking of the
driver's door),

●
"Unlocking only boot"
(Selective unlocking of the boot).



- "Driving assistance":


●
"Parking brake automatic" (Automatic
electric parking brake; see "Driving"
section),

●
"Rear wipe in reverse gear" (Rear wiper
coupled to reverse gear; see "Visibility"
section),

●
"Speeds memorised" (Memorising
speeds; see "Driving" section).



- "Vehicle lighting" (see "Visibility" section):


●
"Directional headlamps" (Main/additional
directional lighting),

●
"Daytime lights" (Daytime running
lamps).



- "Interior lighting" (see "Visibility" section):


●
"Follow-me-home " (Automatic timed
operation of headlamps),

●
"Welcome lighting" (Interior/exterior
welcome lighting).




Display confi guration

This menu is used to configure:


- the display language of the central colour
screen, from a pre-defined list,

- the units: temperature (°Celsius ou
°Fahrenheit) and fuel consumption
(l/100 km, mpg or km/l),

- the colour schemes of the central screen.



Choice of sounds

This menu allows you to choose a family of
polyphonic sounds from the four available.
These sounds are grouped together in a family
and are adapted to suit the situation and
context (alert, confirmation, rejection, direction
indicators, lighting left on, key in ignition...).
