radio Citroen DS4 2012 1.G Owner's Guide

01 FIRST STEPS


Automatic search up/down for radiofrequencies.
Select previous/next CD, USB,streaming track.
Navi
gation in a list.
Displa
y the list of stationsreceived, CD/MP3 tracks or folders.
Lon
g press: managing the classifi cation of MP3/WMA fi les/update the list of stationsreceived.

Abandon the current
operation.
Up one level (menu or folder).
On/Off.

Selection of AM/FM wavebands.Select preset radio station.
Long press: store a station.
Select screen display between modes:
Full screen: Audio(or telephone if call in
progress)/
In a window: Audio (or telephone if call in
progress) - Time or Tripcomputer.
Long press: black screen (DARK).

Audio settings:
audio ambiences, treble,
bass, loudness, distribution,
le
ft/right balance, front/rear fader, automatic volume.
Access to main menu.

TA
(Traffi cAnnouncement) function On/Off.
Lon
g press:
access to type of
information.
Select source:
Radio, CD, AUX, USB,Streaming.
Accept an incomin
gcall.
Confi rmation or display of contextual menu.
Manual step b
y step search up/downfor radio frequencies.
Select previous/next MP3 folder.
Select previous/next folder/genre/artist/playlist in the USB device.
Navigation in a list.
Volume ad
justment.

02
351
STEERING MOUNTED CONTROLS


- Change the audio source.
Lon
g press: mute.


- In
crease volume.


- D
ecrease volume.


- Radio: displa
y the list of stations.
Media: displa
y the list of tracks.
Lon
g press: update the list of stations received.


- R
otation:
Radio: search for the
previous/nextstation.
Media: previous
/next track.
Pr
ess: confi rmation. -
Access to telephone menu:
Dial
/Directory/Calls list/Voice mail box.
- M
ove in the menus.
Pr
ess: confi rmation.
- Abandon the current operation.

03
"Multimedia": Media parameters, Radio parameters.
"Trip computer ": Warning log. r

For a detailed global view of the menusavailable, refer to "Screen menu map"in this section.

"Bluetooth connection
": Connections management, Search for a device.


" Telephone
": Call, Directorymanagement, Telephone management, Hang up.

MAIN MENU
"Personalisation-confi guration": Defi ne the vehicle parameters, Choice of language, Display confi guration, Choice of units, Date andtime adjustment. > SCREEN C

353
1
2
3
04AUDIO
Press SOURCEor SRCseveral times in succession and select radio.
Pr
ess BAND to select a waveband. Pr
ess LISTto display the list of stationsreceived in alphabetical order.

A press changes to the next or previous letter (e.g. A, B, D, F, G, J, K, ...).







RADIO

Select the desired radio station andconfi rm by pressing OK.

SELECTING A STATION

A lon
g press on LIST
builds or updates
the list of stations; audio reception is cut
momentarily.
The exterior environment
(hills, buildings, tunnel, car park, belowground...) may prevent reception, even in RDS station tracking mode. This phenomenon is normal in the propagation of radio
waves and is in no way indicative of a fault with the audio system.

1
2
04
1

RDS, if displayed, enables you to continue listening to the samestation by automatic retuning to alternative frequencies. However,
in certain conditions, coverage of an RDS station may not be
assured throughout the country as radio stations do not cover
100 % of the territory. This explains the loss of reception of the station during a journey.

AUDIO


RDS





RECEIVING TA MESSAGES


The TA (Traffi c Announcement) function gives priority to TA alert messages. To operate, this function needs good reception of a radio station transmitting this type of message. When a traffi c report is transmitted, the current audio source (Radio, CD,
USB, Ö) is interrupted automatically to play the TA message. Normal playback of the audio source resumes at the end of the
transmission of the message.

Pr
ess TA INFO
to activate or deactivatethe reception of traffi c messages.
When the radio is displayed on the screen, press OKto display thecontextual menu.
Select " RDS
" and confi rm to save.
"RDS " is displayed in the screen.

355
1
2
04
1
2

Radio text is information transmitted by the radio station related to
the current programme or song.

With the radio displa
yed on the screen,press OK
to display the contextualmenu.

Select "RadioText (TXT) display" andconfi rm OKto save.


DISPLAY RADIO TEXT


SCREEN C
Make a long press on TA INFO
to
display the list of categories.

LISTENING TO INFO MESSAGES
The INFO function gives priority to TA alert messages. To beactive, this function needs good reception of a radio station that
transmits this type of message. When a message is transmitted,
the current audio source (Radio, CD, USB, ...) is interrupted automatically to receive the INFO message. Normal play resumes at the end of the message transmission.
Select or deselect categories to activate
or deactivate the reception of thecorresponding messages.

371
1
2
06
3
Press ‘
to display the audio settingsmenu.

The settin
gs available are:


-
Ambience,


- Bass,

-
Treble,

- Loudness,

- Distribution: Personalised or Driver ,

- Left/ri
ght balance ,

- Fader
(front/rear balance),

-
Auto. volume.



SCREEN C


The distribution (or spatialisation using the Arkamys© system),©
is an audio process which allows the sound quality to be improved
according to the setting chosen, corresponding to the position of the
listeners in the vehicle.
AUDIO SETTINGS
Select and confi rm " Other settings…"
to display the next setting in the list. The Ambience, Treble and Bass audio settin
gs are different andindependent for each sound source.
Arkamys©: in a vehicle, the sound quality suffers from the physicalconstraints imposed by the safety standards and the requirement
to optimise the space available in the passenger compartment. Speakers are fi tted in the doors, which can result for the driver and passenger in the sound being too one-sided, either "all on the right"or "all on the left".
The Arkam
ys© software installed in your audio system processes©
the digital signal from the media players (radio, CD, MP3, ...) and recreates a natural musical scene, with harmonious placement
of instruments and voices in the space facing passengers, at the height of the windscreen.

373
08SCREEN MENU MAP
SCREEN C

Multimedia
Media parameters
Choice of playback mode
Choice of track listing


Telephone


Call
Dial
Directory
Calls list
Voice mail box


Directory management
Consult an entr
y
Delete an entry
Delete all entries
Normal
Random
R
andom all
Repeat
B
y folders
B
y artists








MAIN FUNCTION
Option A1
Option A2
OPTION A
OPTION B1
2
2
1
2
2
2
2
1
2
2
2
3
3
3
3
3
3
1
2
2
1
By genres
B
y playlists
Radio parameters
3
3
1


Telephone management
Telephone status

Hang up
1
2
1

375
FREQUENTLY ASKED QUESTIONS
QUESTIONANSWER SOLUTION
There is a difference in sound quality between
the different audiosources (radio, CD...).
For optimum sound quality, the audio settings
(Volume, Bass, Treble,
Ambience, Loudness) can be adapted to the different sound sources,
which may result in audible differences when changing source (radio,
CD...).
Check that the audio settings (Volume, Bass,
Treble, Ambience, Loudness) are adapted to
the sources listened to. It is advisable to set
the AUDIO functions (Bass, Treble, Front-Rear Fader, Left-Right Balance) to the middle position, select the musical ambience "None" and set theloudness correction to the "Active" position in CD mode or to the "Inactive" position in radio mode.
When chan
ging the settings for treble andbass, the ambience setting is deselected.

When changing the
ambience setting, treble
and bass are reset to zero.Choosin
g an ambience imposes settings for treble and bass. Modifyingone without the other is not possible. Modify the treble and bass settings or the
ambience setting to obtain the desired sound quality.

When changing the balance setting, distribution is deselected.
Choosing a distribution setting imposes a balance setting. Modifying one
without the other is not possible. Modify the balance setting or the distribution setting to obtain the desired sound quality. The
following tables contain answers to the most frequently asked questions.

FREQUENTLY ASKED QUESTIONS
QUESTIONANSWER SOLUTION
The quality of receptionof the radio station
listened to gradually
deteriorates or the stored stations do not function(no sound, 87.5 MHz is
displayed...). The vehicle is too
far from the transmitter used by the station listened
to or there is no transmitter in the geographical area through which the
vehicle is travelling. Activate the RDS function to enable the system
to check whether there is a more powerful
transmitter in the geographical area.
The environment
(hills, buildings, tunnels, basement car parks...) block reception, including in RDS mode. This phenomenon is normal and does not indicate
a failure of the audio equipment.
The aerial is absent or has been dama
ged (for example when goingthrough a car wash or into an underground car park). Have the aerial checked by a CITROËN dealer.

Sound cut-outs of 1 to2 seconds in radio mode.During this brief sound cut-out, the RDS searches for any frequency
permitting better reception of the station. Deactivate the RDS function if the phenomenon is
too frequent and always on the same route.
Th
e traffi c announcement(TA) is displayed. I donot receive any traffi c
information.Th
e radio station does not broadcast traffi c information. Tune to a radio station which broadcasts traffi c
information.

The stored stations arenot found (no sound, 87.5 MHz is displayed...).
An incorrect waveband is selected. Press the BAND AST button to return to the
waveband on which the stations are stored.
