cruise control Citroen DS4 2012 1.G Owner's Manual

SAFETY DRIVING FITTINGS CHILD SAFETY
194 Electric parking brake
202Manual parking brake
203 Manual gearbox
204Gear shift indicator
205 6-speed electronic gearboxsystem
209Automatic gearbox
213 Hill start assist
214Stop & Start
217 Lane departure warningsystem
218 Blind spot sensors
222Speed limiter
224Cruise control
226 Parking space sensors
228Parking sensors
174 Direction indicators
174 Hazard warning lamps
175Horn
175Emergency or assistance call
176Tyre under-infl ation detection
178 Braking assistance systems
179Tr ajectory control systems(ESP)
181 Front seat belts
185 Airbags
162Child seats
168 ISOFIX child seats
171Child lock
14 4 Interior fi ttings
15 0Front armrest
155Boot fi ttings
008008009009006006007007

Instruments and controls
1.
Cruise control/speed limiter controls. 2.
Controls for optional functions.3.
Steering wheel adjustment control.4.
Lighting and direction indicator control stalk.5.
Instrument panel.
6.Driver's airbag.
Horn. 7. Controls for audio and telematic system. 8.Controls for Bluetooth system or telephone. 9.
Bonnet release. 10.Door mirror controls.
Electric window controls.11. Fusebox.12.Manual headlamp height adjustment
Lower side switch panel.
13.Fuel filler flap opening switch.Upper side switch panel. 14 .Side adjustable air vent. 15. Front side window demisting vent.

25
Familiarisation

Cruise control/speed limiter controls


Steering wheel with
integrated controls
60
Optional functions controls
222, 224
59 2
. Dashboard lighting dimmer.
300, 351

Audio system controls
300, 351


Bluetooth system or telephonecontrols
1.Black panel (black screen).
40
or
Control of the type 2 central instrumentscreen.
138
3. Courtesy lamp on/off.
226
or
Parking space sensors.

Monitoring

33Familiarisation
Driving safely
1.
Limiter mode On/Off. 2.Decrease the programmed value.3.Increase the programmed value.4.
Speed limiter On/Off.
5. Display the list of memorised speeds.


Speed limiter "LIMIT"

221
1.Cruise control mode On/Off.
2. Programme a speed/Decrease the
programmed value.3. Programme a speed/Increase the
programmed value.4. Cruise control Off/Resume.
5. Display the list of memorised speeds.
Cruise control "CRUISE"
221

The cruise control or speed limiter mode
appears in the instrument panel when it is
selected.

Display in the instrument panel

The values must be set with the engine running.
222
224
In order to be programmed or activated, the
vehicle speed must be higher than 25 mph (40 km/h), with at least fourth gear engaged on a manual gearbox (second gear for the 6 -speed
electronic gearbox system or automatic gearbox).
Speed limiter

Cruise control

Eco-driving
Eco-driving is a range of everyday practices that allow the motorist to optimise their fuel consumption and CO2emissions.
Optimise the use of your
gearbox
With a manual gearbox, move off gently,change up without waiting and drive by changing up quite soon. If your vehicle has the system, the gear shift indicator invites youto change up; it is displayed in the instrumentpanel, follow its instructions.
With an automatic or electronic gearbox, stay in Drive "D"or Auto "A"
, according to the type of gearbox, without pressing theaccelerator pedal heavily or suddenly.


Drive smoothly


Maintain a safe distance between vehicles, use engine braking rather than the brake pedal, and press the accelerator progressively. These practices contribute towards a reduction in fuel consumption and CO2emissions and also helpsreduce the background traffic noise.


If your vehicle has cruise control, make use of the system at speeds above 25 mph (40 km/h) when the traffic is flowing well.



Control the use of your
electrical equipment


Before moving off, if the passenger compartment is too warm, ventilate it by opening the windows and air vents before using the air conditioning. Above 30 mph (50 km/h), close the windowsand leave the air vents open.
Remember to make use of equipment that can help keep the temperature in thepassenger compar tment down (sunroof and window blinds...). Switch off the air conditioning, unless it hasautomatic digital regulation, as soon as the desired temperature is attained.
Switch off the demisting and defrosting controls, if not automatic. Switch off the heated seat as soon as possible.

Customisable colour instrument panel - Type 1
1.
Rev counter (x 1 000 rpm or tr/min). 2.
Gear efficiency indicator with manualgearbox or gear lever position and gear for
the electronic gearbox system.3.Analogue speedometer (mph or km/h). 4. Cruise control or speed limiter setting. 5.
Digital speedometer (mph or km/h).
6
.Engine oil level indicator.
Dials and screens
Control buttons
7.Ser vice indicator
(miles or km) then,
total mileage recorder.
These two functions are displayed successively on switching on the ignition.
Lighting dimmer setting (when making an
adjustment).
8. Tr i p m i l e age recorder (miles or km).9.Fuel gauge and associated low fuel
warning lamp.
10. Range (miles or km).
A.Dial COLOUR: customisation of the
background colour of the dials. B.Screen COLOUR: customisation of thebackground colour of the screens.
C.Lighting dimmer (available in night mode).D. Reminder of the ser vicing information
Reset the service indicator or the trip
mileage recorder.

Type 2 instrument panel central screen and controls
1. Speed limiter or cruise control settings.2.
Engine oil level indicator.
Reminder of the ser vicing information.
These functions are displayed successively
on switching on the ignition, after the
welcome sequence and before display of
the active available functions.
Alert or information messages may be displayed temporarily.
This
group of controls allows:

-
when stationary
, configuration of theyvehicle, central screen and instrument
panel parameters (driving and comfor t
systems, language, units, sounds...),
-
when stationary and while driving,scrolling the active functions available(trip computer, navigation-guidance...).


Controls

There is a button and a thumb wheel to control
the central screen in the instrument panel:
A.button on the end of the wiper stalk: run through the various active functionsavailable. B.thumb wheel on the left of the steering column,
- rotation (other than menu): scroll through
the list of active functions available,
- press: main menu, confirm the selection,
- rotation
(in a menu): move up or down in
the menu.

System allowing cer tain screens to be switched
off for night driving. The instrument panel remains on with the
vehicle speed, electronic or automatic gearbox
gear selected, cruise control or speed limiter
in
formation, if in use, and the low fuel aler ts asappropriate.
If there is an aler t or a chan
ge in a function
or to a setting, the black panel mode is
interrupted.
Black panel (black screen)
Activation
)
With the vehicle lighting on, press this button again to activate the black panel. )
Press once more to illuminate on thevarious screens again.


In the instrument panel, you can change thecolour of its dials (button A) independently fromAthat of the screens (button B ).
There are five colour variants, from white to
blue.)press the appropriate button as many times as needed to obtain the desired colour.
Customising the instrument
panel colours

Mats Removable carpet protection.
When fittin
g the mat for the first time, on the
driver's side use only the fixings provided in
the wallet attached. The other mats are simply placed on the carpet.
Fitting
Removal
To remove the mat on the driver's side: )
move the seat as far back as possible,
)
unclip the fixings,)
remove the mat.



Refitting

To refit the mat on the driver's side:)
position the mat correctly, )
refit the fixings by pressing,)
check that the mat is secured correctly.


To a v o i d a ny risk of jamming of the pedals:


- only use mats which are suitedto the fixings already present in the vehicle; these fixings must beused,

- never fit one mat on top of another.
The use of mats not approved by CITROËN may inter fere with access tothe pedals and hinder the operation of the cruise control/speed limiter.

221Driving








Memorising speeds
This memorisation of speeds applies to both the speed limiter and the cruise control.
You can memorise up to 5 speeds in the system. By default, a few speeds are already memorised.


With your Audio system
)Go to the main menu by pressing the"MENU"
button.)Select the "Personalisation-configuration" menu and confirm. )Select "Vehicle parameters" menu andconfirm. )Select the "Driving assistance" line andconform. )Select "Speeds memorised" line and confirm. )Modify the speed.)Select "OK
" and confirm to save themodifications.
With the eMyWay satellite
navi
gation system
) Press the "MEM"button to display the list
of speeds memorised.



Access

For safety reasons, the driver must only carry out these operations whenstationary.
)
Go to the main menu by pressing the left
hand thumb wheel at the bottom of the steering wheel. ) Select the "Vehicle parameters" menu andconfirm.)Select the "Driving assistance" line and confirm.)
Select the "Speeds memorised" line andconfirm.)
Modify the speed. )
Select " OK" and confirm to save the
modifications.
These operations are only possiblewhen stationary with this system.
Selection
To select a memorised speed: )
press and hold the " +" or "- " button; the system stops at the nearest memorised speed, )
press and hold again the "+
" or " -
" button toselect another memorised speed.
A reminder of the speed and the state of thesystem (on/off) is displayed in the instrument
panel.
