key Citroen DS4 2012 1.G Owner's Manual

Contents

Contents
6 FA M I L I A R I SAT I O N
34ECO-DRIVING
3
82 VISUAL
SEARCH
38
6 ALPHABETICAL
INDEXMONITORING
38 Instrument panels
42 Rev counter
43Warning and indicator lamps
54Indicators
57 Manual test
60Customisation
Key
sa
fety warning
additional information
contributes to the protection of the environment
programming a function with the configuration menu
001001
refer to the page indicated

MULTIFUNCTION
SCREENSCOMFORT ACCESS VISIBILITY
64Monochrome screenC
68 Colour screen and map
70Trip computer
78 Ventilation
80Manual air conditioning
82Dual-zone digital air conditioning
87 Rear screen demist - defrost
88 Front seats
93 Rear seats
94 Steering wheel adjustment
95 Mirrors
100 Remote control key
109 Alarm
112Doors
114 Boot
115 Electric windows
117 Fuel tank
119 Misfuel prevention (Diesel)
124 Lighting controls
125 Daytime running lamps
128 Automatic illumination of headlamps
129Welcome lighting
130 Headlamp adjustment
131 Directional lighting
133 Wiper controls
13 4 Automatic rain sensitive
wipers
138Courtesy lamps
139Interior mood lighting
140 Boot lamp
004004005005002002003003

100
Opening
A.
Folding/unfolding the key
(first press this button).
3-button remote
control

When a sensor detects a low level of light,
the remote switching on of the dipped beam headlamps, the sidelamps and the side spotlamps makes your approach to the vehicle easier.

Welcome lighting
Complete or selective unlocking of
the vehicle(rapid flashing of the direction
indicators).
Opening the windows (hold until the desired position is reached).
Selective unlockin
g of the boot.Normal lockin
g
(press once; fixed lighting of
the direction indicators).
Closin
g the windows(hold until the desired position is reached).
12
9
In the same way, the passenger compartment
lighting, such as the cour tesy lamps and
the footwell lamps, comes on.

Passenger safety
1.
Open the glove box.2.
Inser t the key.3.Select the position: "OFF"(deactivation), with "rear facing"child seat,
"ON"
(activation), with front passenger or "forwards facing" child seat.4.
Remove the key keeping the switch in the new position.
Passenger's front airbag
186
A.
Front left seat belt not fastened/unfastened
warning lamp.
B. Front right seat belt not fastened/unfastened warning lamp.C.
Rear right seat belt unfastened warninglamp. D.Rear centre seat belt unfastened warning lamp. E.Rear left seat belt unfastened warning lamp.
F. Passenger's front airbag deactivated
warning lamp.
G.Passenger's front airbag activated warning lamp.


Seat belts and passenger's
front airba
g
181, 187

31Familiarisation

Stop & Start


Engine going into STOP mode
214Th
e "ECO"warning lamp comes on in
the instrument panel and the engine isput into standby automatically:


- with a manual
gearbox;
at speeds below
12 mph (20 km/h), when you put the gear
lever into neutral and release the clutchpedal, -with the 6-speed electronic gearbox
system;at speeds below 5 mph (8 km/h),
when you press the brake pedal or put the
gear lever in position N.
Engine going into START mode

Deactivation/Reactivation
You can deactivate the system at any time bypressing the "ECO OFF"
button; the button's
warning lamp comes on.
215
215
The system is reactivated automatically every time you start the engine withthe key.


Before refuelling or doing anything under the bonnet, you must switch off the ignition with the key. Th
e "ECO"
warning lamp goes off
and the engine restarts automatically:
-
with a manual gearbox;when you fullydepress the clutch pedal, -
with the 6-speed electronic gearboxsystem;


●
with the gear lever in position A
or M ,
when you release the brake pedal,

●
or gear lever in position N
and brake
pedal released, when you change to
position
Aor M ,

●
or when you engage reverse.

In certain circumstances the ST
OP mode may not be available; the "ECO"warning lamp
flashes for a few seconds then goes off.In certain condition, START mode may engageautomatically; the "ECO"
warning lamp flashes
then goes off.
Driving safely

Approaching the maximum engine speed,
the bars are displayed in red and flash,
to indicate to you the need to change up a gear.
Rev counter
Choice of sounds
This menu allows you to choose a family of polyphonic sounds from the four available.
These sounds are grouped together in a familyand are adapted to suit the situation andcontext (alert, confirmation, rejection, direction
indicators, lighting left on, key in ignition...).

Display confi guration
This menu is used to configure:
- the display language of the central screen,
from a pre-defined list,
- the units: temperature
(°Celsius or °Fahrenheit) and fuel consumption(l/100 km, mpg or km/l),
- the graphical presentation of the central
screen, from a pre-defined list.

61Monitoring
Customising the polyphonic
sounds
This menu allows you to choose a family of polyphonic sounds from the four available.
These sounds are grouped together in a familyand are adapted to suit the situation and context (alert, confirmation, rejection, direction
indicators, lighting left on, key in ignition...).

For the type 2 customisablecolour instrument
)
Press the thumb wheel for access to the main menu.)
Select the "Choice of sounds" line and confirm.
)
Select the desired family of sounds and confirm. )
Save the modifications by confirming "OK".

For safety reasons, the driver mustonly carry out these operation when stationary.

For safety reasons, these operations are only possible when stationary.
For the type 1 customisable colour instrument panel
)
Press the "MENU"button for access to the
main menu. ) Select the "Personalisation-configuration"
menu and confirm.
) Select the "Choice of sounds" line andconfirm.)
Select the desired family of sounds and confirm.)
Save the modifications by confirming "OK".

67
Multifunction screens
)Press the "
" or "
" buttons to set thevalue required (15, 30 or 60 seconds), then press the "OK"
button to confirm.
Choice of language
Once this menu has been selected, you canchoose the language used by the display from a pre-defined list.
Display confi guration
This menu gives access to the followingsettings:
- "Choice of units",
- "Date and time ad
justment",
- "Display parameters",
- "Brightness".



Choice of sounds

This menu allows you to choose a family of
polyphonic sounds from the four available.
These sounds are grouped together in a familyand are adapted to suit the situation and context (alert, confirmation, rejection, direction
indicators, lighting left on, key in ignition...).


For safety reasons, configuration of the multifunction screen by the driver mustonly be done when stationary.
)Press the "  " or "  " buttons, then the "OK"button to select the "OK"
box and confirm or press the "ESC"button to cancel.

A few definitions…
This value may vary following a changein the style of driving or the relief,resulting in a significant change in thecurrent fuel consumption.

If dashes are displayed continuously while driving in place of the digits, contact a CITROËN dealer or a qualified workshop.
This function is only displayed from 20 mph (30 km/h).
The fuel consumption of your vehicle will be higher than the official figures obtainedby CITROËN during the first 3 000 miles(5 000 km) of the vehicle's life.
Range
(miles or km)This indicates the distancewhich can still be travelled with the fuelremaining in the tank in relation to the average
fuel consumption over the last few miles(kilometres) travelled.
When the ran
ge falls below 20 miles (30 km),
dashes are displayed. After filling with at least 5 litres of fuel, the range is recalculated and is
displayed when it exceeds 60 miles (10 0 km).

Current fuelconsumption
(mpg or l/100 km or km/l)
This is the average fuel consumption during the last few seconds.


Average fuel consumption
(mpg or l/100 km or km/l)
This is the average fuel consumption since the last trip computer zero reset.
Average speed
(mph or km/h)This is the average speed calculatedsince the last trip computer zero reset (ignition on).
Distance travelled
(miles or km)This indicates the distancetravelled since the last trip computer zero reset.
Stop & Start time counter
(minutes/seconds or hours/minutes)
If your vehicle is fitted with Stop & Star t, a timecounter calculates the time spent in STOP mode during a journey.
It resets to zero every time the ignition isswitched on with the key.

95
Comfort





Mirrors

Each fitted with an adjustable mirror glass permitting the lateral rear ward vision necessary for overtaking or parking. They can also be
folded for parking in confined spaces.

Demisting - Defrosting
Adjustment
)
Move control A
to the right or to the left to select the corresponding mirror. )
Move control B
in all four directions to
adjust. ) Return control Ato the central position.


Door mirrors
The objects obser ved are, in reality, closer than they appear. Take this into account in order to correctly judge the distance of vehicles approaching from behind.




Folding
)
From outside: lock the vehicle usingthe remote control or the key.)
From inside: with the ignition on, pull the control A
in the central position rear wards.


Unfolding
)
From outside: unlock the vehicle usingthe remote control or the key.)
From inside: with the ignition on, pull the control A
in the central position rear wards.

If the mirrors are folded using control A , they will not unfold when the vehicle is unlocked. Pull again on control A.

The folding and unfolding of the door mirrors using the remote control can be deactivated by a CITROËN dealer or a qualified workshop.
Never fold or unfold the electric folding mirrors manually.
I
f your vehicle is fitted with heated
mirrors, the demisting-defrostingoperates by switching on the heatedrear screen (refer to the "Rear screen
demist-defrost" page).
The rear screen demist - defrost can onl
yoperate when the engine is running.
