Page 58 of 396
A few seconds after the ignition is switched
on, the distance recorder resumes its normal
operation.
The spanner remains on.
The distance remaining may be weighted by the time factor, depending on the type of driving.
Therefore, the spanner may also comeon if you have exceeded the two year service interval.
Service indicator zero reset
After each ser vice, the ser vice indicator mustbe reset to zero.
The procedure for resetting to zero is as
follows: ) switch off the ignition, )
press and hold the ".../000"
trip distance
recorder zero reset button, ) switch on the ignition; the distance recorder
display begins a countdown,
) when the screen indicates "=/0"and thespanner disappears, release the button.
This operation cannot be carried out while a reminder of the ser vicing information is being displayed.
Following this operation, if you wish todisconnect the battery, lock the vehicleand wait at least five minutes for thezero reset to be registered.
Recalling the service information
You can recall the ser vice information at anytime. )Briefly press the ".../000"
trip distance recorder zero reset button.
The ser vice information is displayed for afew seconds, in the total distance recorder
line or in the type 2 instrument panel central screen.
Service overdue
For a few seconds after the ignition is switched on,
the spanner flashes
to indicate that the servicemust be carried out as soon as possible. Example:
the ser vice is overdue by 180 miles(300 km).
For a few seconds after the ignition is switched on,
the screen indicates:
Page 243 of 396
241Checks
Par ticle emission filter (Diesel)
On a new vehicle, the first operations of regeneration of the par ticle emissions filter may be accompanied by the smell of "burning", w hic h is per fec t ly normal.Following prolonged operation of the vehicle at very low speed or at idle,you may, in exceptional circumstances,notice the emission of water vapour at the exhaust on acceleration. This doesnot affect the behaviour of the vehicleor the environment.
Manual gearbox
The gearbox does not require anymaintenance (no oil change).
Refer to the ser vicing booklet for the
details of the level checking interval for this component.
According to your version of instrument panel, the start of
saturation of the par ticle emissions filter is indicated by:
6-speed electronic gearbox
s
ystem
The gearbox does not require anymaintenance (no oil change).
Refer to the ser vicing booklet for
details of the checking inter val for
this component.
-
temporary illumination of theservice warning lamp, accompanied
b
y an audible signal and a message
that there is a risk of blockage of thepar ticle emissions filter.
-fixed illumination of the particle
emissions filter warning lamp,accompanied by an audible signaland a message that there is a risk of blockage of the particle emissions filter,
or
As soon as the traffic conditions permit,
regenerate the filter by driving at a speed of at
least 40 mph (60 km/h) until the warning lamp goes off.
If the warning lamp stays on, refer to the
"Additive level" section.
Automatic gearbox
The gearbox does not require anymaintenance (no oil change).
Refer to the ser vicing booklet for
details of the level checking intervalfor this component.
